Optional – Direct DC Power Connection
•
Connect a fused DC power
cable into the power
connector on the
MultiConnect WF.
•
Then attach the two wires
at the other end of the
fused cable to a DC
fuse/terminal block on a
vehicle in which you are
mounting the MultiConnect
WF.
Connect the red wire to the
"+" positive and the black
wire to the "–" negative. Be
sure the GND connection is
correct.
Warning: Over-voltage
protection is provided on
the device. To ensure
complete protection, you
may want to add additional
filtering to the DC input.
Model Number for the Fused DC Power Cable:
FPC-532-DC
MultiConnect Serial-to-Wi-Fi Device Server
7
