Installation and Cabling
Attaching the MultiConnect WF to a Fixed Location
1.
Typically, the MultiConnect WF is mounted against a flat
surface with two mounting screws. Drill the mounting holes at
the desired mounting location. The mounting holes must be
separated by 4-15/16 inches center-to-center.
2.
To attach the mounting bracket, slide it into the
corresponding slot on the back of the MultiConnect
chassis.
3.
Attach the MultiConnect to the surface with two screws.
MultiConnect Serial-to-Wi-Fi Device Server
5
