RF Interface

Radio Characteristics
Frequency
Modulation
Channel Intervals
Number of Channels
Transmission Rate
RF Receive Sensitivity
RF Range

Default Power Up Settings

AT Command Response Form =
Bluetooth Service Profile =
Device Role = Slave
Baud Rate = 9600bps
Data Bits = 8 bits
Parity = None
Stop bits = 1 bit
Hardware Flow Control RTS/CTS =
Power Mode = Never go into deep sleep mode
Country Code = North America and Europe
Name of Device (local name) =
My Radio Status = 1,0 {slave, disconnected}
Service Name = COM0
Power up default ATSW24 settings =
connect, no minor}
Power up default ATSW25 settings =
Major & Minor Class Of Device (COD) =
Security PIN and Encryption =
Default PIN = "default" caps sensitive
Important Security PIN Note:
Do not forget your PIN. Write it down. If you forget it, there is no way it can be retrieved from
the device or the software. You will have to buy a new Bluetooth device and start over.
Page Scan Interval =
Page Scan Window =
Inquiry Scan Interval =
Inquiry Scan Window =
Timeout Connection Parameters
Inquiry = 60 seconds
Slave Connect =
Master Connect =
ATDM idle mode =
ATDM Master Mode =
Timeout for loss of Bluetooth connection =
Multi-Tech Systems, Inc. Serial-to-Bluetooth Adapter User Guide (S000370B)
2402 – 2480MHz
FHSS/GFSK
1MHz
79CH
721Kbps
-80dBm typical
Class 1 - 100 meters (330 feet)
Long Form
Serial Port Profile {SPP}
Enabled
Serial-to-Bluetooth Adapter
0,0,0,0 {long response, no authentication, no auto SCO
0,1,0,0 {slave, data, allow data to pass, SPP}
00000000 {undefined}
Disabled
0x400 {2560msec.}
0x200 {11msec.}
0x400 {2560msec.}
0x200 {11msec.}
60 seconds
60 seconds
60 seconds
indefinitely (need to perform ATUCL to cancel last command)
Chapter 1 – Description and Specifications
4 seconds
7
