Mobile Projector Cart
Instruction Manual
SKU: CART-V04C
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/cart-v04c
help@vivo-us.com
www.vivo-us.com
1-800-371-5654

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CART-V04C and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo CART-V04C

  • Page 1 Mobile Projector Cart Instruction Manual SKU: CART-V04C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/cart-v04c help@vivo-us.com www.vivo-us.com 1-800-371-5654...
  • Page 2 WARNING! ASSEMBLY STEPS If you do not understand these directions, or if you have any doubts about the safety of the STEP 1 installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product Place the base (B2) upside down and attach the feet (B1) using four M6x65 bolts (A1), four washers for any purpose that is not explicitly specified in this manual.
  • Page 3 STEP 3 STEP 5 Turn assembly over and attach center pole (B3) using four M6x12 bolts (A4). Tighten using Allen key Attach lower shelf (B4) using two M6x30 bolts (A5), two washers (A2), and two nuts (A3). Tighten with (A10). wrench (A9) and Phillips screwdriver (not included).
  • Page 4 STEP 7 STEP 8 Secure two plates (G4) to either side of center pole (B3). Place top shelf (B5) over assembly. Attach top shelf (B5) using one M6x50 bolt (A8), two washers (A2), and one nut (A3) in the top hole. Use one M6x50 bolt (A6), washer (A7), and knob (G3) in bottom hole.
  • Page 5 Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
