Black 14" Mobile Projector and Laptop Cart
Instruction Manual
SKU: CART-V04C
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/cart-v04c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo CART-V04C
Summary of Contents for Vivo CART-V04C
- Page 1 Black 14” Mobile Projector and Laptop Cart Instruction Manual SKU: CART-V04C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/cart-v04c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 ASSEMBLY STEPS STEP 1 Place the base (B2) upside down and attach the feet (B1) using four M6x65 bolts (A1), four washers (A2), and four nuts (A3). Tighten using provided wrench (A9). A9x1 A3x4 A2x4 A1x4 STEP 2 Attach casters (G1,G2) to feet (B1) using wrench (A9) as shown in diagram. A9x1 G1x2 G2x2...
- Page 4 STEP 3 Turn assembly over and attach center pole (B3) using four M6x12 bolts (A4). Tighten using Allen key (A10). A4x4 A10x1 STEP 4 Secure center pole (B3) to base (B2) using one M6x65 bolt (A1), one washer (A2), and one nut (A3). Tighten with wrench (A9).
- Page 5 STEP 5 Attach lower shelf (B4) using two M6x30 bolts (A5), two washers (A2), and two nuts (A3). Tighten with wrench (A9) and Phillips screwdriver (not included). A5x2 A2x2 A3x2 A9x1 STEP 6 Adjust the height of center pole (B3) and secure in place using two M6x50 bolts (A6) and two adjustment knobs (G3).
- Page 6 STEP 7 Secure two plates (G4) to either side of center pole (B3). Place top shelf (B5) over assembly. G4x2...
- Page 7 STEP 8 Attach top shelf (B5) using one M6x50 bolt (A8), two washers (A2), and one nut (A3) in the top hole. Use one M6x50 bolt (A6), washer (A7), and knob (G3) in bottom hole. A8x1 A2x2 A10x1 A9x1 A3x1 A7x1 A6x1 G3x1...
