Attach the pedestal kit side pieces

The pedestal kit right side piece attaches to the top of the server. The top cover of the server
might have ventilation holes in it to allow for proper air flow and cooling. The right side piece
of the pedestal kit also has ventilation holes in it to allow for the proper cooling and air flow.
Follow these steps to attach the pedestal kit right side piece.
WARNING!
the ventilation holes on the top cover of the HP Integrity rx2800 i2 server to allow for proper
cooling and air flow. Failure to heed this warning will cause the server to shut down with an
overtemp condition.
To attach the component:
1. Align the posts on the pedestal kit right side piece with the slots in the pedestal kit top and
bottom.
2. Hold the pedestal side flush against the server and slide it toward the front of the server.
Figure 2-5 Attaching the pedestal kit side piece
The ventilation holes in the pedestal kit right side piece must be matched up with
