Attach the pedestal kit top and bottom

IMPORTANT:

In this document the server top, bottom, right and left always refer to the server as faced from

the front with the server in a horizontal orientation. The pedestal kit components are referred to

by their final position with the server in a vertical orientation. For example, the pedestal kit

bottom attaches to the server left side. See

orientations.

Figure 2-2 Front of server

Server top/pedestal right

Server left/pedestal top

The pedestal kit bottom attaches to the right side of the server when the server is in the horizontal

position. The pedestal kit top attaches to the left side of the server when in the server is in the

horizontal position. The pedestal bottom may be distinguished from the pedestal top by the

pedestal feet slots.

Installing the server into the pedestal kit

Figure 2-2 (page 10)

for the server and pedestal

Server bottom/pedestal left

Server right/pedestal bottom
