PC CONFIGURATOR
The following parameter items can be configured with the PC configurator software (model: R7CFG).
Refer to the users manual of the software for detailed operations.
■ INTERFACE SETTING
PARAMETER
Communication Timeout

DATA ALLOCATION

'Begin' address is determined by the R7F4HD's node address and the master setting.
■ Without Status
15 Output data
Begin + 0 R7F4HD-DAC32D (x0 to x15)
■ With Status
15 Output data
Begin + 0 R7F4HD-DAC32D (x0 to x15)
Status
+ 1

SETTING RANGE

0.0 – 32767 (0.1 sec.)
0
0
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
10 (0.1 sec.)
15 Input data
Begin + 0 R7F4HD-DAC32D (y0 to y15)
15 Input data
Begin + 0 R7F4HD-DAC32D (y0 to y15)
R7F4HD-DAC32D

DEFAULT SETTING

0
0
EM-8006-F P. 7 / 9
