I/O DATA DESCRIPTION
■ INPUT DATA / OUTPUT DATA
15
STATUS
Bit 8 - 10: Shows the power supply status.
15
0
Input 0 (Output 0)
Input 1 (Output 1)
Input 2 (Output 2)
Input 3 (Output 3)
Input 4 (Output 4)
Input 5 (Output 5)
Input 6 (Output 6)
Input 7 (Output 7)
Input 8 (Output 8)
Input 9 (Output 9)
Input 10 (Output 10)
Input 11 (Output 11)
Input 12 (Output 12)
Input 13 (Output 13)
Input 14 (Output 14)
Input 15 (Output 15)
0
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Communication/power supply
Excitation supply (input)
Excitation supply (output)
Unused
Unused
Unused
Unused
Unused
