Wall plate fixing instructions
Hide thumbs Also See for Radius R225:

Advertisement

This instruction sheet explains in detail how to fix your Radius 225/
Radius 250 to the wall by using the wall fixing plate. This product
has been designed using the most up-to-date computer technology
to provide you with a secure fixing for your loudspeakers, whether
you want to position them horizontally or vertically. It has also
been designed to ensure that the exceptional sound quality is
maintained.
Please remember to always read the instructions first as they
are sequenced to provide a safe way of working.
WARNING: For safety reasons do not attempt to fix these
speakers to your wall if you are unsure of your ability to
provide a secure and safe fixing.
You will need to determine; the structure of the wall, where to fit the
bracket and if your loudspeaker cable is going to be run through the
wall and out through the cable hole in the fixing plate. If unsure,
please obtain the services of a competent qualified tradesperson.
WARNING: Ensure that there are no water pipes or electricity
cables running behind where the wall bracket is going to be
secured. Work from secure steps and avoid trailing wires.
ALWAYS CONNECT YOUR CABLES TO THE LOUDSPEAKERS
BEFORE CONNECTING THEM TO THE AMPLIFIER
©Monitor Audio 2005
Radius 225/ 250 Wall Plate Fixing Instructions
