O w n e r s M a n u a l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RADIUS 45HD and is the answer not in the manual?

Questions and answers

Related Manuals for Monitor Audio RADIUS 45HD

Summary of Contents for Monitor Audio RADIUS 45HD

  • Page 1 O w n e r s M a n u a l...

  • Page 3: Table Of Contents

    Contents Page Important Safety Instructions Safety Instructions For Fixing Your Radius Loudspeakers to a Wall Re-cycling RoHS Declaration of Conformity Background Introduction Setting up and Positioning Positioning - Front Speakers Positioning - Surround Speakers Optimum Speaker Placement Fixing to the Wall Specifications Guarantee and Service Claims under this Guarantee...

  • Page 4: Important Safety Instructions

    Only use attachments/ accessories specified by Monitor Audio. Use only with the cart , stand, tripod, bracket, or table specified by monitor Audio or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.

  • Page 5: Safety Instructions For Fixing Your Radius

    Safety Instructions For Fixing Your Radius Loudspeakers to a Wall WARNING: For safety reasons do not attempt to fix these speakers to your wall if you are unsure of your ability to provide a secure and safe fixing. You will need to determine where to fit the bracket and the structure of the wall.

  • Page 6: Introduction

    Introduction Congratulations and thank you for your purchase of the Radius loudspeakers. We are confident they will provide years of enjoyment and pleasure as only high quality components have been used throughout. Building on the overwhelming success of the original Radius Series, Radius brings redesigned cabinet profiles, enhanced cabinet structure, improved aesthetics and improved sonic balance and response.

  • Page 7: Setting Up And Positioning

    Setting up and Positioning Although position and suitability will have been considered prior to purchasing your Radius , this section will guide you through the optimum positioning and setting up of your loudspeakers. An illustration is provided on page 6 to assist you in ensuring your speakers are placed in the optimum positions.

  • Page 8: Optimum Speaker Placement

    Optimum Speaker Placement Left Right Centre 0° 22° 30° 90° Surround Surround 110° Left Right 135° 150° Rear Rear Surround Surround Right Left Figure 1. Radius...

  • Page 9: Fixing To The Wall

    Fixing to the Wall The R45 comes with a bracket to mount it on the wall. It is fixed using the 2 button head screws on the back of the cabinet either side of the terminals. WARNING: Ensure that there are no water pipes, or electricity cables running behind where the wall bracket is going to be secured.
  • Page 10 For fixing to a wooden wall/structure, use a 2mm drill bit to drill 2 pilot holes and use 25mm screws to secure the bracket. Fully unscrew the 2 wall bracket mounting screws in the back of the speaker cabinet using the ‘hex’ key provide (Fig.
  • Page 11 Using the 30mm cap head bolt (provided) secure the two parts together, but leave the bolt loose enough to allow some adjustment if necessary (Fig. 7). Figure 7. Adjust the speaker to the desired listening position and fully tighten the bolt. If you realise this is not the correct positioning, loosen the bolt slightly, re-adjust and then tighten the bolt.

  • Page 12: Specifications

    This guarantee covers both labour and parts. The liability of Monitor Audio is limited to the cost of repair or replacement of the defective parts (at the discretion of Monitor Audio) and under no circumstances extends to consequential losses or damage.

  • Page 13: Claims Under This Guarantee

    The equipment should be returned in its original packaging to the original supplier where possible, or to any other authorised Monitor Audio dealer. If it is not possible to return the equipment by hand, then it should be sent carriage prepaid via a reputable carrier.

  • Page 14: Ec Declaration Of Conformity

    EC Declaration of Conformity We, Monitor Audio Ltd. 24 Brook Road Rayleigh Essex SS6 7XL England Declare in own responsibility, that the Radius HD products described in this manual is in compliance with Technical Standards/Council Directives: (LVD) 2006/95/EC Low Voltage Directive EN60065: 2002+A1: 2006 Safety requirements for mains operated electronic and related apparatus for household and similar use.
  • Page 16 Monitor Audio Ltd. Unit 2, 24 Brook Road Rayleigh, Essex SS6 7XL England Tel: 01268 740580 Fax: 01268 740589 Email: info@monitoraudio.co.uk monitoraudio.co.uk Designed in the United Kingdom © 2008. Version 2...
