Purpose
Related Documents
Required Tools
Parts List
Read All Related Documentation
A0000265
MDE-3642A Mechanical Totalizer Kits K35489, K35490, K94580 for The Advantage
This document provides instructions for installing mechanical totalizers in The Advantage
Series units manufactured without mechanical totalizers. Order one kit per product intake
meter.
Kit Number
K35489
K35490
K94580
MDE-2531
Pump and Dispenser Start-Up and Service
PT-1728
The Advantage Series Illustrated Parts Manual
• drift pin
• hammer
• lithium grease
• pliers
• socket set, U.S.
Part Number
Description
T18464-G2
Assembly, cover plate and totalizer gears (U.S. gallon)
T18464-G3
Assembly, cover plate and totalizer gears (metric)
T18464-G4
Assembly, cover plate and totalizer gears (Imperial gallon)
N20965-12
Gear, counter
K77558-28
Cotter hair pin
Reviewing all related procedures before you begin work is important. Read and understand all
related manuals thoroughly. If you do not understand a procedure, call 1-800-743-7501 for
Gilbarco Tele-Support.
Read NFPA 30A and NFPA 70
Before servicing equipment, read and understand applicable information in the following
codes:
• The National Electric Code (NFPA 70)
• The Automotive and Marine Service Code (NFPA 30A)
• Any national, state and local codes that may apply.
Failure to service equipment in accordance with NFPA 30A and NFPA 70 may adversely
effect the safe use and operation of the system.
Mechanical Totalizer Kits
K35489, K35490, K94580 for
Unit of Measure
U.S. gallons
liters
Imperial gallons
Series • April 2003
®
MDE-3642A
The Advantage
Series
®
Qty
1 (K35489 kit only)
1 (K35490 kit only)
1 (K94580 kit only)
1
1
Page 1
Advertisement
Table of Contents
Related Manuals for GILBARCO VEEDER-ROOT K35489
Summary of Contents for GILBARCO VEEDER-ROOT K35489
- Page 1 A0000265 Failure to service equipment in accordance with NFPA 30A and NFPA 70 may adversely effect the safe use and operation of the system. MDE-3642A Mechanical Totalizer Kits K35489, K35490, K94580 for The Advantage Series • April 2003 Page 1...
- Page 2 Wear Eye Protection Spraying fuel from residual pressure in the lines can cause serious eye injuries. Always wear eye protection. Page 2 MDE-3642A Mechanical Totalizer Kits K35489, K35490, K94580 for The Advantage Series • April 2003 ®...
- Page 3 Lift pulser (1) until it clears drive shaft (3) and rotate out of the way. Remove screws (4) and cover plate (5) from air gap plate (6). Retain screws. Discard cover plate. MDE-3642A Mechanical Totalizer Kits K35489, K35490, K94580 for The Advantage Series • April 2003 Page 3 ®...
- Page 4 Installation Installing Mechanical Totalizer Install T18464-GX cover plate and totalizer gear assembly (8) onto pulser drive shaft (5). Note: Parts fit snugly. Lubricate inner surface of bushing with a small amount of lithium grease, if necessary. If bushing (6) comes out, use a drift pin to carefully replace bushing.
