GILBARCO VEEDER-ROOT FlexPay EPK ECIM RF Manual

Epp and scr kit for encore s e-cim
Hide thumbs

Advertisement

Quick Links

Download this manual

Introduction

Purpose
This manual provides instructions to install a FlexPay
Card Reader (SCR) Kit in Encore
Intended Users
This manual is intended for Gilbarco
(ASCs).

Table of Contents

Topic
Required Tools and Materials
Following tools and materials are required to install the FlexPay EPP and SCR Kit:
• 5/32-inch Nut Driver
• 5/16-inch and 1/4-inch Nut Driver or Ratchet/Socket Set
• Flat-blade Screwdriver
• Phillips
• Putty Knife
• Isopropyl Alcohol
MDE-4780D FlexPay™ EPP and SCR Kit (EPK ECIM RF) Installation Instructions for Encore® S E-CIM™ · December 2015
Page
1
5
7
7
28
Note: Use magnetic nut drivers for convenience.
Screwdriver
®
FlexPay
EPP and SCR Kit (EPK ECIM RF)
™
Installation Instructions for Encore
Encrypting PIN Pad (EPP) and Secure
™
S E-CIM
unit.
®
™
-trained and certified Authorized Service Contractors
®
MDE-4780D
S E-CIM
®
™
December 2015
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the FlexPay EPK ECIM RF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GILBARCO VEEDER-ROOT FlexPay EPK ECIM RF

Summary of Contents for GILBARCO VEEDER-ROOT FlexPay EPK ECIM RF

  • Page 1: Table Of Contents

    MDE-4780D FlexPay EPP and SCR Kit (EPK ECIM RF) ™ Installation Instructions for Encore S E-CIM ® ™ December 2015 Introduction Purpose This manual provides instructions to install a FlexPay Encrypting PIN Pad (EPP) and Secure ™ Card Reader (SCR) Kit in Encore S E-CIM unit.
  • Page 2 Introduction Parts List - EPK E-CIM RF Following table lists the parts included in the FlexPay EPP and SCR Kit: FlexPay EPP Kit Following table lists the parts included in the FlexPay EPP Kit: Quantity per Item Description Part Number Side Main Door, E-CIM Mono Display, EPP M08484AXXX...
  • Page 3 Introduction Quantity Item Description Part Number 1-sided Kit 2-sided Kit Card, Card Reader Cleaning Q11482 Decal, Patent and FCC M02962B009 Screw, Metric, Thread Forming Hexagonal Washer Head, Q11677-26 6-20X SCR Option - M07813K106 Following table lists the parts included in the M07813K106 Kit: Quantity Item Description...
  • Page 4 Introduction Term Description Point of Sale Price per Unit Secure Card Reader Secure Payment Technical Assistance Center TRIND Transmitter/Receiver in Dispenser ® Transistor-Transistor Logic Underwriters Laboratories Page 4 MDE-4780D FlexPay™ EPP and SCR Kit (EPK ECIM RF) Installation Instructions for Encore® S E-CIM™ · December 2015...

  • Page 5: Important Safety Information

    Important Safety Information Important Safety Information Notes: 1) Save this Important Safety Information section Read the Manual in a readily accessible location. Read, understand and follow this manual and any other labels 2) Although DEF is non-flammable, Diesel is or related materials supplied with this equipment. If you do not understand a procedure, call the Technical Assistance Center flammable.
  • Page 6 Important Safety Information No Open Fire In an Emergency Inform Emergency Personnel Compile the following information and inform emergency Open flames from matches, lighters, welding torches or personnel: other sources can ignite fuels and their vapors. • Location of accident (for example, address, front/back of No Sparks - No Smoking building, and so on) •...

  • Page 7: Before You Begin

    Before You Begin Before You Begin  Read and understand all the safety information found in MDE-3804 Encore and Eclipse Start-up/Service Manual. CAUTION A properly grounded Electrostatic Discharge (ESD) wrist strap must be worn while servicing any electronic devices or components. Failure to use electrostatic precautions may damage electronic components and void warranty.
  • Page 8 Installing FlexPay EPP Kit Remove the grade select buttons by pushing down from the top of the soda button while pulling from the bottom of the soda buttons. The grade select bases will remain in position. Note: Be careful not to dislodge the magnets. Figure 1: Removing Grade Select Buttons Grade Select Buttons Removed Isolate the CRIND two-wire cable.
  • Page 9 Installing FlexPay EPP Kit Remove the five screws on the top row that hold the lower portion of the CIM assembly in place, using a Phillips screwdriver. Figure 3: Removing Lower Portion of E-CIM Door Disconnect the softkey cable from the softkey keypad. Remove the four screws that secure the door node.
  • Page 10 Installing FlexPay EPP Kit Remove the upper CIM insert screws (1/2 inch and 1/4 inch) and washers that hold the main display lens in place, to facilitate the removal of the existing CIM assembly. Figure 5: Removing Upper CIM Insert Screws and Washers Remove the four screws (1/4 inch) that secure the monochrome display, using a 1/4-inch nut driver.
  • Page 11 Installing FlexPay EPP Kit Remove the card reader and card reader bracket, using a 1/4-inch nut driver. Figure 7: Removing Card Reader and Card Reader Bracket Card Reader Remove any other peripherals that are installed on the CIM assembly. Remove the three screws that secure the Price per Unit (PPU) board assembly, using a 1/4-inch nut driver.
  • Page 12 Installing FlexPay EPP Kit Ensure that all wires that are connected to the CIM assembly have been removed. Remove the screws that secure the CIM assembly. Note: Retain the screws for reuse. Figure 9: Removing CIM Screws Removed Remove the existing CIM assembly. Verify if the gasket on the CIM assembly to be installed is in place.
  • Page 13 Installing FlexPay EPP Kit Reinstall the three screws removed in step page 11, which secure the PPU board bracket in place. Figure 11: Installing PPU Board Bracket Reinstall the two upper CIM insert screws and washers that were removed in step page 10, to secure the main display lens.
  • Page 14 Installing FlexPay EPP Kit Reinstall the door node, using the four screws removed in step page Figure 13: Installing Door Node Inspect the bosses on the door before installing the card reader and display. Use M14757B001 Screws if the door has metal bosses and use Q11677-24 Screws if the door has non-metal bosses, for installation of these components.
  • Page 15 Installing FlexPay EPP Kit Reinstall the monochrome display, using the four screws as determined in step page Figure 15: Installing Monochrome Display Monochrome Display Reconnect the softkey cable to the Softkey keypad. Connect the new call button cable that is installed on the door. Reinstall the card reader and card reader bracket, using the four screws as determined in ...
  • Page 16 Installing FlexPay EPP Kit Reconnect the cables that connect to the card reader. Figure 17: Connecting Cables to Card Reader Reinstall the five screws to secure the PPU board in place. Figure 18: Reinstalling PPU Board IMPORTANT INFORMATION Before proceeding, ensure that the five screws securing the PPU Board have been reinstalled.
  • Page 17 Installing FlexPay EPP Kit Reinstall the brand panel graphic. Figure 19: Installing Brand Panel Graphic Reinstall the grade select buttons. Ensure that these are in the appropriate locations. Figure 20: Installing Grade Select Buttons Grade Select Buttons Installed Repeat steps page 7 through for side B of the unit.
  • Page 18 Installing FlexPay EPP Kit SmartPad Connections for Monochrome Units ™ To connect the SmartPad to Monochrome units, proceed as follows: Connect the FlexPay EPP cable to the FlexPay EPP and the other end to P3101 SmartPad port on the CRIND Control Node (CCN). IMPORTANT INFORMATION Connect the FlexPay EPP cable to P3102 on the CCN for side A, and P3101 on the CCN for side B of the unit.
  • Page 19 Installing FlexPay EPP Kit SmartPad Connections for Color Units Installing RS-232 to TTL and RS-232 to TTL Converter PCA (M07592A001) To install the RS-232 to TTL and RS-232 to TTL Converter PCA (M07592A001), proceed as follows: Make the following connections on the RS-232 to TTL and M07592A001 PCA Board: •...
  • Page 20 Installing FlexPay EPP Kit Connect J302X of the M07746A001 Cable to P302X on the color CRIND Interface Board (M06187A002). Figure 24: Connecting Power Supply Cables to Color CPU Assembly P302X on Color CPU Assembly (ii) Page 20 MDE-4780D FlexPay™ EPP and SCR Kit (EPK ECIM RF) Installation Instructions for Encore® S E-CIM™ · December 2015...
  • Page 21 Installing FlexPay EPP Kit Connect the M07749A001 Cable from the P227 COM2 port on M07592A001 PCA Board to CN27 on the 10.4-inch CPU Board (M03377A001). Figure 25: Connecting COM2 Port Cable to Color CPU Assembly CN27 Port (ii) MDE-4780D FlexPay™ EPP and SCR Kit (EPK ECIM RF) Installation Instructions for Encore® S E-CIM™ · December 2015 Page 21...
  • Page 22 Installing FlexPay EPP Kit Connect the M00719A004 Cable from the P202 COM1 port on M07592A001 PCA Board to CN2 on the 10.4-inch CPU board. Figure 26: Connecting COM1 Port Cable to Color CPU Assembly CN2 Port (ii) Page 22 MDE-4780D FlexPay™ EPP and SCR Kit (EPK ECIM RF) Installation Instructions for Encore® S E-CIM™ · December 2015...
  • Page 23 Installing FlexPay EPP Kit Connect the FlexPay EPP cables from the rear of the keypads to the appropriate SmartPad ports on the M07592A001 PCA Board: P3101 for side B and P3102 for side A. Figure 27: Connecting FlexPay EPP Cables to SmartPad Ports on Board (ii) P3102 SmartPad Port (side A) P3101 SmartPad Port (side B)
  • Page 24 Installing FlexPay EPP Kit Upgrading Flash Card on Color Screen CRIND CPU Assembly To upgrade the flash card on the color screen CRIND CPU assembly, proceed as follows: Release the color screen CRIND CPU assembly from the standoffs. Figure 28: CPU Board Lower the CPU board to gain access to the rear portion that contains the flash card.
  • Page 25 Installing FlexPay EPP Kit Remove the existing flash card and insert the CRIND Software Flash Card (M07743K001), which contains the upgraded software (see Figure 29). Note: Ensure that you do not bend the pins when you install the flash card. Figure 29: Replacing Flash Card (ii) Existing Flash Card...
  • Page 26 Installing FlexPay EPP Kit Check if any cables were disconnected from the color screen CRIND CPU assembly when installing the flash card. Secure/reconnect any loose/disconnected cables. Figure 30: Reconnecting Cables to Color Screen CRIND CPU Assembly (ii) After the flash upgrade has been performed, reload the personality screen(s). For more information on how to reload and configure the personality screens, refer to MDE-4769 Personality Screen Change for Color Screen Update and/or Upload Instructions.
  • Page 27 Installing FlexPay EPP Kit Check if debit transactions are accepted using the newly installed FlexPay EPP. Figure 31: Encore S E-CIM Unit with FlexPay EPP Installed Installing the FlexPay EPP Kit in Encore S E-CIM unit is now complete. MDE-4780D FlexPay™ EPP and SCR Kit (EPK ECIM RF) Installation Instructions for Encore® S E-CIM™ · December 2015 Page 27...

  • Page 28: Installing Scr Kit

    Installing SCR Kit Installing SCR Kit To install the SCR Kit, proceed as follows: Disconnect the ground cable and data cable from the existing (standard) card reader. Remove the four screws that secure the card reader assembly to the dispenser, using a 1/4-inch nut driver.
  • Page 29 Installing SCR Kit Install the new non-adhesive gasket over the front of the card reader and ensure that the gasket is seated on the flange and covers the dismount buttons as shown in Figure Note: The non-adhesive gasket is laid over the card reader snout first, then the card reader is inserted into the card reader opening on the door.
  • Page 30 Installing SCR Kit Install the card reader assembly on the door of the dispenser, using the four screws that were removed in step page Connect the ground cable to the jack on top of the card reader. Secure the ring terminal on the stud where the ground cable of the previous card reader was installed.
