Caddytek incontro sports Instructional Manual page 3

Assemble the Buggy
Fig. 1
Lift the upper bag holder
bracket.
Unfolding Motion
button
As shown in Fig 4, press the
button and rotate the front
wheel 180 degree clockwise
so the front wheel is at centre
of the buggy.
Handle
Adjusting Knob
Make sure the handle height
adjusting knob is fully tightened.
Pull the handle and upper bag
bracket as shown in Fig. 2 to
extend the buggy. (Shake the
buggy slightly to release the main
frame from the holding slot.)
Fig. 4
Release the wheel locking lever,
insert the wheel axel into the wheel
holder completely and then tighten
the locking lever.
Fig. 2
Height
Fig. 5
locking lever
2
Fig. 3
button
button
Press the button on both
sides of the golf bag holder
mechanism to unfold the bag
support wings automatically
as shown in Fig. 3.
Fig. 6
The buggy is fully
extended as shown in
Fig. 6.
