- Page 1 ASSEMBLY INSTRUCTION ITEM#: H21GK025VD-1-rev SKU#: 810589128 Y O R K T O W N S T A T I O N A R Y L O U N G E - B R O W N W I C K E R 1 (877) 800 –...
- Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY: To Ensure Alignment & Easy Assembly, Secure All Bolts & Washers In Place Before Fully Tightening Read all instructions before starting Clear a flat covered space to begin assembly Always best to do it with a friend Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product...
- Page 3 PARTS LIST PART MATERIAL CODE PART Q’TY LS-M6-50 BOLT M6*50 HKVS943M-BG DP-d6.5-D13 BACK ASSEMBLY WASHER d6.5*D13*1.0 HKVS943M-ZG LM-M6 SEAT ASSEMBLY JAM NUT M6*1.0 HKVS943M-SB HKVS943M-BM BACK CUSHION LS-M6-35 HKVS943M-ZM BOLT M6*35 SEAT CUSHION Tools Ⅳ STEP 1 PARTS REQUIRED: 2, 3, 4 & 6 Keep the bolts loose.
- Page 4 STEP 2 PARTS REQUIRED: 1, 3, 4, & 6 Keep the bolts loose. STEP 3 PARTS REQUIRED: 1, 2, 5, 6, & 7 Tighten all bolts by using the supplied Hex key. PAGE 3 OF 4...
- Page 5 STEP 4 PARTS REQUIRED: 8, & 9 Warranty • One–year limited warranty. • Proof of purchase (dated register receipt) is required for warranty claims. • It remains the customer’s responsibility for freight and packing charges to and from the service center. STOP! Missing A Part? No Need To Go Back To The Store The store where you made your purchase does not stock parts for this item.
