Lumineux Redbrook 421065 Quick Start Manual

Redbrook
Emergency
Exit Box
1
READ THESE INSTRUCTIONS
THOROUGHLY BEFORE
INSTALLATION KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.
IMPORTANT:
This product must be installed
by a qualified electrician or
competent person, and in
accordance with current building
and IET wiring regulations.
BOX CONTENTS
This lighting fixture has been properly
packed to avoid damage during
transit. Before commencing with the
installation carefully inspect the
4
luminaire to confirm there is no
damage. DO NOT INSTALL if any
damage has occurred to the fixture
or any of its components.
• Light Fitting
• Instruction Manual
• Fixing Kit
TOOLS REQUIRED
• Drill
• Screwdriver
• Cable
A
Manby Business Park, Manby, Lincolnshire, LN11 8UT
G G
Lumineux is a B&T Associates Ltd company.
G
INSTALLATION INSTRUCTIONS
2
on
off
Side screws
IP20
6000K
3
Mounting positions
5
L - LIVE (SW) = Brown
- EARTH = Green/Yellow
N - NEUTRAL = Blue
L1 - PERMANENT LIVE (PL) = Black
Technical Helpline: +44 (0)1507 328031
5W
Redbrook
2 YR
5 YR
Battery
Warranty
Warranty
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION.
WARNING: Risk of electric shock! Isolate
the mains power before proceeding.
• Turn off the mains power before performing
inspections, installation, or removal
• Verify that the supply voltage is correct by
comparing it with the luminaire label information
• It is the installers responsibility to ensure installation
is suitable for the total load of the luminaire(s). The
supply cable, fuses/circuit brakers must be correctly
rated for the electrical load and considering for any
transient inrush currents that may occur
• Do not perform insulation strength or resistance
tests on installed luminarie(s) connected
1. Isolate mains supply
2. Unscrew side panel and remove legend screen
3. Place housing to wall and mark mounting positions
and fix using adequate wall plugs and screws
as shown
on
4. Feed mains input cable through knockout you
desire as show
off
5. Power on mains supply when deemed safe
www.lumineux.co.uk
