Lumineux 421301 Installation Instructions

Fontburn Emergency
2in1 Exit Sign
Surface Mount & Hanging
1

READ THESE INSTRUCTIONS

THOROUGHLY BEFORE
INSTALLATION KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.

IMPORTANT:

This product must be installed
by a qualifi ed electrician or
competent person, and in
accordance with current building
and IET wiring regulations.

BOX CONTENTS

This lighting fi xture has been properly
packed to avoid damage during
transit. Before commencing with the
installation carefully inspect the
4
luminaire to confi rm there is no
damage. DO NOT INSTALL if any
damage has occurred to the fi xture
or any of its components.
• Light Fitting
• Instruction Manual

TOOLS REQUIRED

• Drill
• Screwdriver
• Cable
A
G G Manby Business Park, Manby, Lincolnshire, LN11 8UT
Lumineux is a B&T Associates Ltd company.
G
INSTALLATION INSTRUCTIONS
2
on
off
Tab locations
NON– EMERGENCY FITTINGS
CLASS I PRODUCT
EARTH CONNECTION
5

Product Specification:

Unit
4ft Single 220-240VAC, 50/60Hz
4ft Twin
5ft Single 220-240VAC, 50/60Hz
5ft Twin
6ft Single 220-240VAC, 50/60Hz
6ft Twin
Battery
IP20
6000K
Self-Test
3
L - LIVE (SW) = Brown
N - NEUTRAL = Blue
L1 - PERMANENT LIVE
LIVE = Brown
NEUTRAL = Blue
GND = Green/Yellow
REQUIRED.
6
Input Voltage Wattage Length Width Height LF(mm)
19W 1220 64 62
Rotate 90º
220-240VAC, 50/60Hz 38W 1220 64 62
27W 1524 64 62
220-240VAC, 50/60Hz 50W 1524 64 62
38W 1829 64 62
220-240VAC, 50/60Hz 60W 1829 64 62
Technical Helpline: +44 (0)1507 328031
3W
Fontburn
2 YR
5 YR
Battery
Warranty
Warranty
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION.
WARNING: Risk of electric shock! Isolate
the mains power before proceeding.
- EARTH = Green/Yellow
• Turn off the mains power before performing
inspections, installation, or removal
• Verify that the supply voltage is correct by
(PL) = Black
comparing it with the luminaire label information
• It is the installers responsibility to ensure installation
is suitable for the total load of the luminaire(s). The
supply cable, fuses/circuit brakers must be correctly
rated for the electrical load and considering for any
transient inrush currents that may occur
• Do not perform insulation strength or resistance
tests on installed luminarie(s) connected
1. Push in the two release tabs to separate the
mounting bracket with terminal block from the
gear-tray housing. (1)
1016
2. Unplug the cable from the gear-tray.
1016
1320
3. Secure the mounting bracket into position, passing
1320
the mains cable through the cable entry. (2)
1625
1625
Wall Mount
4. Connect the cables to the terminal block as shown
in the diagram. (3)
5. Connect the battery. (4)
6. Return the gear-tray back into position ensuring
no cables are trapped and the locking tabs
are engaged.
on
7. To fi t the emergency decal place in position and
use the 2 part plastic rivets to retain into position. (5)
off
8. When wall mounting rotate the gear-tray with decal
in one direction only. (6)
www.lumineux.co.uk
