Lumineux Darwell Installation Instructions

Installation Engineers Contact Details:
Name: Tel:
Luminaire Details: Full Recharge Duration 24Hours
ROUTINE TEST RECORD
Test Type Year 1
Signed Date Signed
Functional
Functional
Functional
Functional
Functional
Functional
Functional
Functional
Functional
Functional
Functional
3hr Duration
Dimensions:
Part No. Description L (mm)
430950 Darwell Emergency 350
Bulkhead
End Of Life Disposal:
Disassembly instructions for end of life disposal available on website.
Disposal of Electronic Equipment WEEE Directive 2002/96/EC This product falls within the scope of the
Waste Electrical & Electronic Equipment Directive (WEEE), which means the product should not be
disposed of as normal household waste. Please recycle where facilities exist or check with your Local
Authority. RoHS – All components and materials used in this product are RoHS 2002/95/EC compliant.
Specifications may change from time to time. The information contained in this leaflet is for guidance only
and should not be considered as always accurate and should be treated as not representative.
Manby Park, Manby, Louth, Lincolnshire, LN11 8UT
Lumineux Group is a trading name of B&T Associates Ltd.
Luminaire Ref / Location
Duration: 3 Hours Lamp Type: LED
Year 2 Year 3 Year 4
Date Signed Date Signed Date
W (mm) H (mm) Weight
110 64 0.35Kg
Installation Instructions
Darwell Emergency Bulkhead
Year 5
Signed Date
Input
Power
Operating Temp
Battery
Recharge Time
Function
Light Source Energy Rating N/A
Box Contents:
•
Emergency Bulkhead
• Fixing Kit
• Legend Kit
Tools Required For Installation:
•
Drill
•
Wire Cutter / Strippers
• Screwdriver
READ THESE INSTRUCTIONS THOROUGHLY BEFORE INSTALLATION
This product must be installed by a qualified electrician or competent person,
Warranty:
This luminaire is warranted for a period of 5 years from the date of purchase**. The backup battery pack in
the emergency version is warranted for a period of 5 Years. The warranty could be invalidated should the
light fitting not be installed according to these instructions, outside the scope of the specification or the
product has been altered or tampered with in any way. Please see website for terms and conditions.
Rev L1.0 241867
www.lumineux.co.uk
220-240V 50/60Hz
4W
0-30°C
3.2V LiFePO4 1500mAh
24Hrs
Self-Test / Manual Test
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IMPORTANT:
and in accordance with current building and IET wiring regulations.
Scan for more
Technical Helpline:
+44(0)1507 328031
