Lumineux Foremark Plus Series Installation Instructions

Foremark Plus
High Bay
Plug & Play (Zhaga)
1
READ THESE INSTRUCTIONS
THOROUGHLY BEFORE
INSTALLATION KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.
IMPORTANT:
This product must be installed
by a qualifi ed electrician or
competent person, and in
accordance with current building
and IET wiring regulations.
BOX CONTENTS
This lighting fi xture has been properly
packed to avoid damage during
transit. Before commencing with the
installation carefully inspect the
4
luminaire to confi rm there is no
damage. DO NOT INSTALL if any
damage has occurred to the fi xture
or any of its components:
• Light Fitting
• Instruction Manual
• Eye Bolt
TOOLS REQUIRED
• Screwdriver
• Cable
A
Manby Business Park, Manby, Lincolnshire, LN11 8UT
B B
Lumineux is a B&T Associates Ltd company.
G
INSTALLATION INSTRUCTIONS
2
on
off
5
80W, 120W and 150W
IP65
IK10
3
Electrical connection wiring
NEUTRAL = Blue
EARTH = Green/Yellow
LIVE (SW) = Brown
Technical Helpline: +44 (0)1507 328031
Foremark Plus
50,000 5 YR
≤185
Lm/W Warranty
Hours
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION.
WARNING: Risk of electric shock! Isolate
the mains power before proceeding.
• Turn off the mains power before performing
inspections, installation, or removal
• Verify that the supply voltage is correct by
comparing it with the luminaire label information
• It is the installers responsibility to ensure installation
is suitable for the total load of the luminaire(s). The
supply cable, fuses/circuit brakers must be correctly
rated for the electrical load and considering for any
transient inrush currents that may occur
• Do not perform insulation strength or resistance
6
tests on installed luminarie(s) connected
1. Isolate the circuit.
2. Attach the eye bolt to the top of the fi tting by
screwing the thread into the top hole.
3. Secure the eye bolt using a PH screwdriver.
4. Hang the light fi tting using a suitable
on
strengthened suspension cord or chain.
Recommend a suitable strength carabiner
clip for ease. (See Weights overleaf).
5. Connect the cable to the mains as per
off
image 5. Installation must be performed by
a qualifi ed electrician. (Terminal block not
included)
6. Power on.
For emergency information, see overleaf.
www.lumineux.co.uk
