Icom IC-R9500 Service Manual Addendum page 67

October 2016
[REG UNIT]
REF PART
NO. NO.
F1 5210000131 FGB 4A PBF (FGB0 125V)
5210001030 0234002.MXP
5210001030 0234002.MXP
5210001030 0234002.MXP
5210000131 FGB 4A PBF (FGB0 125V)
5210001030 0234002.MXP
5210001030 0234002.MXP
5210001030 0234002.MXP
F2 5220000380 F-400-01A1
5220000390 F-400-01A2
5220000390 F-400-01A2
5220000390 F-400-01A2
5220000380 F-400-01A1
5220000390 F-400-01A2
5220000390 F-400-01A2
5220000390 F-400-01A2
MF1 2710000811 FD124010HB-1N7-1 (120)
W1 8900015620 OPC-1592
W2 8900015680 OPC-1598
8900015681 OPC-1598A
8900015681 OPC-1598A
8900015681 OPC-1598A
8900015680 OPC-1598
8900015680 OPC-1598
8900015681 OPC-1598A
8900015681 OPC-1598A
W3 8900015690 OPC-1600
W4 8900015700 OPC-1602
EP1 6910016800 PBA150F-15
EP2 6910023890 FN9222R-6-06
MP1 8510017020 2844 REG CASE
MP2 8510017090 2844 REG COVER
MP3 8930068520 2844 REG T-PLATE
MP4 8810008460 SET SCREW H M2.6×16 NI
MP5 8810007231 SET SCREW H M3×8 ZC3
MP6 8810009461 FLAT M3×8 ZK3
MP7 8810001990 PH M5×8 NI BS
MP8 8850000440 S-WASHER M5 NI
MP9 8830000360 WING NUT M5 NI
MP10 8830000211 NUT M5 BS-CD NI
MP11 8850000150 FLAT WASHER M5 NI BS
MP12 8810009880 BIND M4×8 NI FE
MP13 8310068790 2844 GROUNDING LABEL
MP14 8850001561 WASHER M4 ZC3
MP15 8930072550 2844 PW PLATE
MP16 8930088290 2844 PWR SHEET
MP17 8930049240 ALMINIUM SHEET (AC)
[CONNECT-B UNIT]
REF PART
NO. NO.
J1 6510023720 LGY6501-0600C
J101 6510024940 HEC2305-016250
J111 6510023671 TCS4480-0141577
J181 6510023720 LGY6501-0600C
J201 6510023751 01K1971-20
J202 6510028210 SJ050010 (TMP-J01X-V6)
J301 6450001130 JPJ2042-01-110
J401 6510023720 LGY6501-0600C
J501 6510023720 LGY6501-0600C
J601 6450001130 JPJ2042-01-110
J602* 6510018961 B2B-PH-SM4-TB (LF) (SN)
J603* 6510022191 B3B-PH-SM4-TB (LF) (SN)
J701 6450001800 JPJ1044-01-010
J702 6510028210 SJ050010 (TMP-J01X-V6)
J801 6510023751 01K1971-20
J802 6510028210 SJ050010 (TMP-J01X-V6)
J901* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J902* 6510022801 B10B-PH-SM4-TB (LF) (SN)
F101 5220000230 S-N5054 #01
F102 5220000230 S-N5054 #01
F103 5210000031 FGB 1A PBF (FGB0 125V)
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#09]
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#09]
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#09]
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
(Amended page)
[LOGIC UNIT] (Except for [#02])
REF PART
QTY.
NO. NO.
1 J1* 6510022491 AXK5S30047YG
1 J2* 6510019871 AXK5S40047YG
1 J52* 6510023261 B6B-PH-SM4-TB (LF) (SN)
1 J102* 6510019981 52808-1671
1 J604* 6510019971 52808-1071
1 J801 6510003441 B8B-EH-S (LF) (SN)
1
J802 6510003461 B10B-EH-S (LF) (SN)
1 J803* 6510020251 B9B-PH-SM4-TB (LF) (SN)
1 J805* 6510020081 52808-2071
1 J806* 6510022472 40FLT-SM2-TB (LF) (SN) (M)
1 J811* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1 J812* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1 J813* 6510024151 50FY-BMT-TB (LF) (SN)
1 J814* 6510019981 52808-1671
1 J815* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1 J816* 6510024522 12FLT-SM2-TB (LF) (SN) (M)
J817* 6510020081 52808-2071
J818* 6510019971 52808-1071
1 J819* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J820* 6510019981 52808-1671
J821* 6510019981 52808-1671
1 J822* 6510020521 52808-1271
1 J851* 6510018961 B2B-PH-SM4-TB (LF) (SN)
1 J852* 6510018961 B2B-PH-SM4-TB (LF) (SN)
1 J853* 6510019981 52808-1671
1 J900* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1
1
1
S51* 2260003630 TMG-325N-Q-T/R
1
1
1 T401* 5920000990 H1102FNLT
1 MP101 8510016490 2590 LOGIC B-PLATE
1 MP103 8930063300 AL SHEET (AK)
MP203 8510016500 2590 LOGIC A-PLATE
MP806 8930059122 THERMAL SHEET (AJ)-2 TC400TXS (7X7)
1
1
1
2
26
2
[MEMORY UNIT]
1
1
1
REF PART
1
NO. NO.
2
1 J1* 6510024211 AXK6S30437YG
1 J2* 6510024201 AXK6S40437YG
1
1
1 MP1 8930039870 SPONGE (EI)
1 MP2 8930039870 SPONGE (EI)
MP3 8930063720 AL SHEET (AN)
[VCO1 UNIT]
QTY.
REF PART
NO. NO.
1
MP1 8510017780 2844 VCO1 CASE
1
MP2 8510017790 2844 VCO1 U-COVER
1
MP3 8510017800 2844 VCO1 L-COVER
1
MP4 8810003961 SET SCREW A M2.6×5 ZC3
1
MP5 8930072390 2844 EARTH SPRING
1
MP6 8930072390 2844 EARTH SPRING
1
1
1
1
1
1
1
[VCO2 UNIT]
1
1
1
REF PART
1
NO. NO.
1
J4101 6910003841 IMSA-9230B-1-05Z003-PT1
J4102 6910003861 IMSA-9230B-1-07Z003-PT1
1
1
MP4101 8510017830 2844 VCO2 CASE
1
66
