Icom IC-R9500 Service Manual Addendum page 257

NOTE: HOLD the adjustment condition (SG level and frequency etc.) until next ADJ item is displayed.
ADJUSTMENT ITEM
FIELD STREGTH METER
[HF dBu −20dB]
[HF dBu −10dB]
[HF dBu 0dB]
[HF dBu 10dB]
[HF dBu 20dB]
[HF dBu 40dB]
[HF dBu 60dB]
[HF dBu 80dB]
BPF LOSS
[HF BPF0 LOSS]
[HF BPF1 LOSS]
[HF BPF2 LOSS]
[HF BPF3 LOSS]
[HF BPF4 LOSS]
[HF BPF5 LOSS]
[HF BPF6 LOSS]
[HF BPF7 LOSS]
[HF BPF9 LOSS]
[HF BPF10 LOSS]
W-BPF LOSS
[HF W-BPF LOSS MIN]
[HF W-BPF LOSS CENTER]
[HF W-BPF LOSS MAX]
PRE1 GAIN FREQUENCY
CHARACTERISTIC
[HF PRE1 Gain f MIN]
[HF PRE1 Gain f CENTER]
[HF PRE1 Gain f MAX]
PRE1 GAIN FREQUENCY
CHARACTERISTIC
[HF PRE2 Gain f MIN]
[HF PRE2 Gain f CENTER]
[HF PRE2 Gain f MAX]
ADJUSTMENT CONDITION
• Set the SG as;
Frequency : 14.1515 MHz
Modulation : None
• Set the SG as;
Level : −20 dBu
• Set the SG as;
Level : −10 dBu
• Set the SG as;
Level : 0 dBu
• Set the SG as;
Level : +10 dBu
• Set the SG as;
Level : +20 dBu
• Set the SG as;
Level : +40 dBu
• Set the SG as;
Level : +60 dBu
• Set the SG as;
Level : 80 dBu
• Set the SG as;
Level : +40 dBu
• Set the SG as;
Frequency : 0.2515 MHz
• Set the SG as;
Frequency : 1.1015 MHz
• Set the SG as;
Frequency : 1.8215 MHz
• Set the SG as;
Frequency : 2.6015 MHz
• Set the SG as;
Frequency : 3.6015 MHz
• Set the SG as;
Frequency : 5.1015 MHz
• Set the SG as;
Frequency : 7.0815 MHz
• Set the SG as;
Frequency : 10.1015 MHz
• Set the SG as;
Frequency : 18.1515 MHz
• Set the SG as;
Frequency : 28.1015 MHz
• Set the SG as;
Frequency : 1.1015 MHz
• Set the SG as;
Frequency : 14.1515 MHz
• Set the SG as;
Frequency : 28.1015 MHz
• Set the SG as;
Frequency : 1.1015 MHz
• Set the SG as;
Frequency : 14.1515 MHz
• Set the SG as;
Frequency : 28.1015 MHz
• Set the SG as;
Frequency : 1.1015 MHz
• Set the SG as;
Frequency : 14.1015 MHz
• Set the SG as;
Frequency : 28.1015 MHz
OPERATION
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
4 - 9
VALUE
(Automatic
adjustment)
(Automatic
adjustment)
