Icom IC-R9500 Service Manual Addendum page 64

October 2016
[SW-A UNIT]
REF PART
NO. NO.
J1* 6510020091 52808-0871
J2* 6510020091 52808-0871
J3* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J4* 6510020091 52808-0871
J5* 6510020091 52808-0871
S1* 2260002740 LS8J2M-T
S2* 2260002740 LS8J2M-T
S3* 2260002740 LS8J2M-T
S4* 2260002740 LS8J2M-T
S5* 2260002740 LS8J2M-T
S6* 2260002740 LS8J2M-T
S7* 2260002740 LS8J2M-T
S8* 2260002740 LS8J2M-T
S11* 2260002740 LS8J2M-T
S12* 2260002740 LS8J2M-T
S13* 2260002740 LS8J2M-T
S14* 2260002740 LS8J2M-T
S15* 2260002740 LS8J2M-T
S16* 2260002740 LS8J2M-T
S17* 2260002740 LS8J2M-T
S18* 2260002740 LS8J2M-T
S19* 2260002740 LS8J2M-T
S20* 2260002740 LS8J2M-T
S21* 2260002740 LS8J2M-T
MP1 8930063530 2590 B-EARTH SPRING
[SW-B UNIT]
REF PART
NO. NO.
J2* 6510021561 52808-2470
S1* 2260002740 LS8J2M-T
S2* 2260002740 LS8J2M-T
S3* 2260002740 LS8J2M-T
S4* 2260002740 LS8J2M-T
S5* 2260002740 LS8J2M-T
S6* 2260002740 LS8J2M-T
S7* 2260002740 LS8J2M-T
S8* 2260002740 LS8J2M-T
S9* 2260002740 LS8J2M-T
S10* 2260002740 LS8J2M-T
S11* 2260002740 LS8J2M-T
S12* 2260002740 LS8J2M-T
S13* 2260002740 LS8J2M-T
S14* 2260002740 LS8J2M-T
S15* 2260002740 LS8J2M-T
S16* 2260002740 LS8J2M-T
S17* 2260002740 LS8J2M-T
S18* 2260002740 LS8J2M-T
S19* 2260002740 LS8J2M-T
S20* 2260002740 LS8J2M-T
S21* 2260002740 LS8J2M-T
S22* 2260002740 LS8J2M-T
[SW-C UNIT]
REF PART
NO. NO.
J3* 6510021561 52808-2470
J5* 6510020091 52808-0871
J6* 6510020091 52808-0871
S23* 2260002740 LS8J2M-T
S24* 2260002740 LS8J2M-T
S25* 2260002740 LS8J2M-T
S26* 2260002740 LS8J2M-T
S27* 2260002740 LS8J2M-T
S28* 2260002740 LS8J2M-T
S29* 2260002740 LS8J2M-T
S30* 2260002740 LS8J2M-T
S31* 2260002740 LS8J2M-T
S32* 2260002740 LS8J2M-T
S33* 2260002740 LS8J2M-T
S34* 2260002740 LS8J2M-T
S35* 2260002740 LS8J2M-T
S36* 2260002740 LS8J2M-T
S37* 2260002740 LS8J2M-T
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
(Amended page)
[TENKEY UNIT]
REF PART
QTY.
NO. NO.
1 J1* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1 J3* 6510021561 52808-2470
1
1
1 S1* 2260002740 LS8J2M-T
S2* 2260002740 LS8J2M-T
S3* 2260002740 LS8J2M-T
1 S4* 2260002740 LS8J2M-T
1 S5* 2260002740 LS8J2M-T
1 S6* 2260002740 LS8J2M-T
1 S7* 2260002740 LS8J2M-T
1 S8* 2260002740 LS8J2M-T
1 S9* 2260002740 LS8J2M-T
1 S10* 2260002740 LS8J2M-T
1 S11* 2260002740 LS8J2M-T
1 S12* 2260002740 LS8J2M-T
1 S13* 2260002740 LS8J2M-T
1 S14* 2260002740 LS8J2M-T
1 S15* 2260002740 LS8J2M-T
1 S16* 2260002740 LS8J2M-T
1 S17* 2260002740 LS8J2M-T
1 S18* 2260002740 LS8J2M-T
1 S19* 2260002740 LS8J2M-T
1 S20* 2260002740 LS8J2M-T
1
1
1
[JACK UNIT]
REF PART
NO. NO.
J4 6510023590 HSJ2000-01-010
J5 6450001440 HSJ1403-01-010
J6 6450001440 HSJ1403-01-010
QTY.
J7* 6510023761 S10B-PH-SM4-TB (LF) (SN)
J8* 6510021601 S2B-PH-SM4-TB (LF) (SN)
1
1
1
1
1
[LED UNIT]
1
1
REF PART
1
NO. NO.
1
1
J1* 6510020711 52793-1070
1
1
1
1
1
1
1
[SENSOR UNIT]
1
1
REF PART
1
NO. NO.
1
1
W1 8900015710 OPC-1604
1
MP1 8930065891 2844 CLICK PLATE-1
MP2 8930071030 2844 S-COVER
MP3 8930065880 2844 SENSOR PLATE
MP4 8930065850 2844 SENSOR SPACER
MP5 8010020000 2844 SENSOR CHASSIS
MP6 8930065860 2844 P125 PLATE
MP7 8930065870 2844 P50 PLATE
MP9 8850001930 2500 SPRING
QTY.
MP10 8930056351 2500 PLATE-1
MP11 8950006460 STEEL BALL D=2.5
1
MP12 8810000101 PH M2×4 ZK3
1
MP13 8810010191 BIND M2×4 BLACK SUS SSBC
1
MP14 8810009141 PH M2.6×6 ZK3
MP15 8810003361 SET SCREW C M3×6 ZC3
MP16 8850001970 C-RING M5 SUS
1
MP17 8850001900 INSULATION FLAT WASHER (AE)
1
MP18 8850000730 INSULATION FLAT WASHER (C)
1
MP19 8810003850 PH B03 M1.4×2.5 NI
1
MP20 8930071040 2844 CLICK SPRING
1
MP21 8810000101 PH M2×4 ZK3
1
1
1
1
1
1
1
1
1
1
63
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
4
2
1
1
1
1
4
1
2
