[SW-A UNIT]
REF
ORDER
NO.
NO.
J1*
6510020091 52808-0871 (0890)
J2*
6510020091 52808-0871 (0890)
J3*
6510021722 30FLT-SM2-TB (LF) (SN) (M)
J4*
6510020091 52808-0871 (0890)
J5*
6510020091 52808-0871 (0890)
S1*
2260002740 LS8J2M-T
S2*
2260002740 LS8J2M-T
S3*
2260002740 LS8J2M-T
S4*
2260002740 LS8J2M-T
S5*
2260002740 LS8J2M-T
S6*
2260002740 LS8J2M-T
S7*
2260002740 LS8J2M-T
S8*
2260002740 LS8J2M-T
S11*
2260002740 LS8J2M-T
S12*
2260002740 LS8J2M-T
S13*
2260002740 LS8J2M-T
S14*
2260002740 LS8J2M-T
S15*
2260002740 LS8J2M-T
S16*
2260002740 LS8J2M-T
S17*
2260002740 LS8J2M-T
S18*
2260002740 LS8J2M-T
S19*
2260002740 LS8J2M-T
S20*
2260002740 LS8J2M-T
S21*
2260002740 LS8J2M-T
MP1*
8930063530 2590 B-EARTH SPRING
[SW-B UNIT]
REF
ORDER
NO.
NO.
J2*
6510021561 52808-2470 (2490)
S1*
2260002740 LS8J2M-T
S2*
2260002740 LS8J2M-T
S3*
2260002740 LS8J2M-T
S4*
2260002740 LS8J2M-T
S5*
2260002740 LS8J2M-T
S6*
2260002740 LS8J2M-T
S7*
2260002740 LS8J2M-T
S8*
2260002740 LS8J2M-T
S9*
2260002740 LS8J2M-T
S10*
2260002740 LS8J2M-T
S11*
2260002740 LS8J2M-T
S12*
2260002740 LS8J2M-T
S13*
2260002740 LS8J2M-T
S14*
2260002740 LS8J2M-T
S15*
2260002740 LS8J2M-T
S16*
2260002740 LS8J2M-T
S17*
2260002740 LS8J2M-T
S18*
2260002740 LS8J2M-T
S19*
2260002740 LS8J2M-T
S20*
2260002740 LS8J2M-T
S21*
2260002740 LS8J2M-T
S22*
2260002740 LS8J2M-T
[SW-C UNIT]
REF
ORDER
NO.
NO.
J3*
6510021561 52808-2470 (2490)
J5*
6510020091 52808-0871 (0890)
J6*
6510020091 52808-0871 (0890)
S23*
2260002740 LS8J2M-T
S24*
2260002740 LS8J2M-T
S25*
2260002740 LS8J2M-T
S26*
2260002740 LS8J2M-T
S27*
2260002740 LS8J2M-T
S28*
2260002740 LS8J2M-T
S29*
2260002740 LS8J2M-T
S30*
2260002740 LS8J2M-T
S31*
2260002740 LS8J2M-T
S32*
2260002740 LS8J2M-T
S33*
2260002740 LS8J2M-T
S34*
2260002740 LS8J2M-T
S35*
2260002740 LS8J2M-T
S36*
2260002740 LS8J2M-T
S37*
2260002740 LS8J2M-T
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[SENSOR UNIT]
REF
ORDER
QTY.
NO.
NO.
1
W1**
8900015710 OPC-1604
1
1
MP1
8930065891 2844 CLICK PLATE-1
1
MP2
8930071030 2844 S-COVER Y891
1
MP3
8930065880 2844 SENSOR PLATE Y780
MP4
8930065850 2844 SENSOR SPACER
1
MP5
8010020000 2844 SENSOR CHASSIS <SSC>
1
MP6
8930065860 2844 P125 PLATE
1
MP7
8930065870 2844 P50 PLATE
1
MP9
8850001930 2500 SPRING Y605
1
MP10
8930056351 2500 PLATE-1 Y597A
1
MP11
8950006460 STEEL BALL D=2.5
1
MP12
8810000101 PH M2 X 4 ZK3
1
MP13
8810010191 BIND M2 X4 BLACKSUS SSBC
1
MP14
8810009141 PH M2.6X 6 ZK3
1
MP15
8810003361 SET SCREWC M3 X 6 ZC3
1
MP16
8850001970 CRING M5 SUS (200)S5103-21
1
MP17
8850001900 INSULATION FLAT WASHER (AE)
1
MP18
8850000730 INSULATION FLAT WASHER (C)
1
MP19
8810003850 PHB03 M1.4X2.5 NI
1
MP20
8930071040 2844 CLICK SPRING Y892
1
MP21
8810000101 PH M2 X 4 ZK3
1
1
1
[VR-A BOARD]
1
REF
ORDER
NO.
NO.
J1*
6510020091 52808-0871 (0890)
S1*
2250000440 TP90N00E20-22.5F-2494
QTY.
1
[VR-B BOARD]
1
REF
ORDER
1
NO.
NO.
1
J1*
6510020091 52808-0871 (0890)
1
1
S1*
2250000440 TP90N00E20-22.5F-2494
1
1
1
1
[VR-C BOARD]
1
1
REF
ORDER
1
NO.
NO.
1
1
J2*
6510020091 52808-0871 (0890)
1
1
1
[VR-D BOARD]
1
1
REF
ORDER
1
NO.
NO.
1
1
J2*
6510020091 52808-0871 (0890)
[VR-E BOARD]
REF
ORDER
QTY.
NO.
NO.
1
J1*
6510020091 52808-0871 (0890)
1
1
S1*
2250000410 TP90D96E20-30F-2178-1
1
1
[VR-F BOARD]
1
1
REF
ORDER
1
NO.
NO.
1
1
J1*
6510020091 52808-0871 (0890)
1
1
1
1
[MAIN UNIT]
1
1
REF
ORDER
1
NO.
NO.
1
J1*
6510028210 SJ050010 (TMP-J01X-V6)
J21*
6510018961 B2B-PH-SM4-TB (LF) (SN)
J41*
6510019981 52808-1671 (1690)
J61*
6510021722 30FLT-SM2-TB (LF) (SN) (M)
J91*
6510018961 B2B-PH-SM4-TB (LF) (SN)
J1101*
6510019971 52808-1071
J2401*
6510019971 52808-1071
J3201*
6510028210 SJ050010 (TMP-J01X-V6)
J3251*
6510025960 AXN330C238P
J3252*
6510021722 30FLT-SM2-TB (LF) (SN) (M)
6 - 3
DESCRIPTION
QTY.
DESCRIPTION
QTY.
DESCRIPTION
QTY.
DESCRIPTION
QTY.
DESCRIPTION
QTY.
DESCRIPTION
QTY.
DESCRIPTION
QTY.
DESCRIPTION
QTY.
1
1
1
1
1
1
1
1
1
1
1
4
4
2
1
1
1
1
4
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
