Icom IC-R9500 Service Manual Addendum page 275

SECTION 5. .
[FRONT UNIT]
REF PARTS
NO. NO.
SP1 2510001390 SPE 2844 SP BOX <FG>
W1 8900016130 CAB OPC-1684 (P1N8L70) <TJM>
W2 8900016130 CAB OPC-1684 (P1N8L70) <TJM>
W3 8900016140 CAB OPC-1690 (P1N24L100) <TJM>
W4 8900016150 CAB OPC-1679 (P0.5N30L80) <TJM>
W5 8900007682 CAB OPC-741A-1(P0.5N40L55) <TJM>
W6 8900015490 CAB OPC-1450A (P1N10L53) <TJM>
W7 8900017130 CAB OPC-926A (P1N24L70) <TJM>
W8 8900014750 CAB OPC-519A (P0.5N30L55) <TJM>
W9 8900016130 CAB OPC-1684 (P1N8L70) <TJM>
W10 8900016130 CAB OPC-1684 (P1N8L70) <TJM>
W11 8900016130 CAB OPC-1684 (P1N8L70) <TJM>
W12 8900016130 CAB OPC-1684 (P1N8L70) <TJM>
EP1 6910015291 UNI LTA070B790F
EP2 6910017310 E.O JSM5035-010100
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
PARTS LIST
DESCRIPTION M.
LOCATION
[DISPLAY UNIT]
H/V REF PARTS
NO. NO.
IC1 1130011880 S.IC
IC2 1130011880 S.IC
IC3 1130011880 S.IC
IC6 1140015180 S.IC
IC201 1110006400 S.IC
IC210 1180000421 S.IC
IC601 1130011551 S.IC
IC651 1110005822 S.IC
Q200 1560001260 S.FET
Q201 1530003301 S.TRA
Q202 1530003301 S.TRA
Q203 1530002060 S.TRA
Q204 1520000651 S.TRA
Q205 1590003940 S.TRA
Q209 1520000651 S.TRA
Q210 1530002060 S.TRA
Q212 1590003940 S.TRA
Q350 1590003940 S.TRA
Q351 1590003940 S.TRA
Q352 1590003940 S.TRA
Q370 1590003940 S.TRA
Q371 1590003940 S.TRA
Q375 1590003940 S.TRA
Q420 1590003940 S.TRA
Q421 1590003940 S.TRA
Q601 1510000771 S.TRA
Q610 1550000090 S.FET
Q611 1550000090 S.FET
Q612 1590003940 S.TRA
Q613 1590003940 S.TRA
D9 1730002341 S.ZEN
D12 1730002511 S.ZEN
D601 1750002020 S.DIO
D602 1750002020 S.DIO
D603 1750002020 S.DIO
D610 1750001350 S.DIO
D611 1750001350 S.DIO
X1 6050009870 S.XTA
L201 6200001831 S.COI
L210 6190001191 S.COI
L211 6190001191 S.COI
L602 6200001831 S.COI
R2 7030003440 S.RES
R3 7030003440 S.RES
R4 7030003440 S.RES
R5 7030003440 S.RES
R6 7030003440 S.RES
R7 7030003440 S.RES
R8 7030003440 S.RES
R9 7030003440 S.RES
R10 7030003440 S.RES
R11 7030003440 S.RES
R12 7030003440 S.RES
R13 7030003440 S.RES
R14 7030003440 S.RES
R15 7030003440 S.RES
R16 7030003440 S.RES
R17 7030003440 S.RES
R18 7030003440 S.RES
R19 7030003440 S.RES
R20 7030003440 S.RES
R21 7030003440 S.RES
R22 7030003440 S.RES
R23 7030003560 S.RES
R24 7030003560 S.RES
R25 7030003560 S.RES
R26 7030003560 S.RES
R200 7030003440 S.RES
R201 7030003470 S.RES
R202 7030003470 S.RES
R203 7030003800 S.RES
R204 7030003560 S.RES
R205 7030003640 S.RES
R208 7030003360 S.RES
R209 7030003860 S.RES
R210 7030003860 S.RES
R212 7030003660 S.RES
R213 7030003580 S.RES
R235 7030003440 S.RES
R239 7030003440 S.RES
R240 7030003440 S.RES
R241 7030003680 S.RES
R242 7030003680 S.RES
R246 7030003440 S.RES
R247 7030003440 S.RES
R248 7030003440 S.RES
R249 7030003440 S.RES
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5 - 1
DESCRIPTION M.
CD4051BPWR T
CD4051BPWR T
CD4051BPWR T
M30622M6P-535GP(SX-3009B-1) T
M62343GP D65J T
TA78L05F(TE12RF) T
RX-4581NB-F T
R3112N281A-TR-FE T
2SK3018 T106 T
2SC3647S-TD-E T
2SC3647S-TD-E T
2SC4081 T106 R T
2SB1201S-TL-E T
RN1105(TE85LF) T
2SB1201S-TL-E T
2SC4081 T106 R T
RN1105(TE85LF) T
RN1105(TE85LF) T
RN1105(TE85LF) T
RN1105(TE85LF) T
RN1105(TE85LF) T
RN1105(TE85LF) T
RN1105(TE85LF) T
RN1105(TE85LF) T
RN1105(TE85LF) T
2SA1586-GR(TE85LF) T
RSQ035P03TR T
RSQ035P03TR T
RN1105(TE85LF) T
RN1105(TE85LF) T
MAZ8047GML T
MAZ8027GHL T
DA2S10100L T
DA2S10100L T
DA2S10100L T
CLS02(TE16LQ) T
CLS02(TE16LQ) T
CR-567 SMD-49 9.8304 MHz
<KDS> T
NLV32T-100J T
D10F-#A814AY-101K T
D10F-#A814AY-101K T
NLV32T-100J T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 103 V (10K) T
ERJ3GEYJ 103 V (10K) T
ERJ3GEYJ 103 V (10K) T
ERJ3GEYJ 103 V (10K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 182 V (1.8K) T
ERJ3GEYJ 182 V (1.8K) T
ERJ3GEYJ 105 V (1M) T
ERJ3GEYJ 103 V (10K) T
ERJ3GEYJ 473 V (47K) T
ERJ3GEYJ 221 V (220) T
ERJ3GE JPW V T
ERJ3GE JPW V T
ERJ3GEYJ 683 V (68K) T
ERJ3GEYJ 153 V (15K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 104 V (100K) T
ERJ3GEYJ 104 V (100K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
ERJ3GEYJ 102 V (1K) T
S.=Surface mount
H/V
LOCATION
104.0/86.2
121.0/86.2
30.1/77.6
48.2/27.8
68.4/58.2
104.1/63.7
39.0/45.9
50.2/68.9
53.6/70.4
91.2/47.1
91.1/26.6
74.7/63.4
79.7/66.8
73.1/58.0
114.6/59.9
108.4/54.9
73.1/55.9
29.5/85.8
28.0/83.0
26.5/85.8
6.3/80.8
11.8/74.0
6.3/78.8
40.5/85.3
40.5/82.7
56.5/71.6
20.6/60.7
20.8/54.0
26.3/61.0
27.7/54.6
74.8/61.2
110.2/57.2
57.6/75.5
56.4/69.7
56.4/73.5
13.9/59.1
13.9/54.4
49.7/44.6
43.9/84.4
86.7/79.7
81.2/38.2
59.5/72.4
123.1/57.1
127.3/60.0
123.1/58.3
127.3/61.2
123.1/59.5
127.3/62.4
123.1/60.7
127.3/63.6
123.1/61.9
127.3/64.8
123.1/63.1
127.3/66.0
123.1/64.3
127.3/67.2
123.1/65.5
127.3/68.4
123.1/66.7
127.3/70.8
123.1/69.1
127.3/72.0
123.1/71.5
127.3/69.6
123.1/67.9
123.1/70.3
127.3/73.2
72.9/53.4
96.6/43.7
96.6/33.0
49.7/41.3
38.2/33.3
70.7/54.2
74.5/59.7
13.0/24.7
13.0/23.4
68.8/63.8
71.0/63.1
50.3/13.1
37.0/85.4
35.8/85.4
38.2/85.4
34.6/85.4
59.6/13.3
58.3/13.3
57.0/13.3
55.7/13.3
