Icom IC-R9500 Service Manual Addendum page 63

October 2016
[FRONT UNIT]
REF PART
NO. NO.
SP1 2510001390 2844 SP BOX
W1** 8900016130 OPC-1684 (P1N8L70)
W2** 8900016130 OPC-1684 (P1N8L70)
W3** 8900016140 OPC-1690 (P1N24L100)
W4** 8900016150 OPC-1679 (P0.5N30L80)
W5** 8900007682 OPC-741A-1 (P0.5N40L55)
W6** 8900015490 OPC-1450A (P1N10L53)
W7** 8900017130 OPC-926A (P1N24L70)
W8** 8900014750 OPC-519A (P0.5N30L55)
W9** 8900016130 OPC-1684 (P1N8L70)
W10** 8900016130 OPC-1684 (P1N8L70)
W11** 8900016130 OPC-1684 (P1N8L70)
W12** 8900016130 OPC-1684 (P1N8L70)
MP11 8210022000 2844 SP PANEL ASSEMBLY
MP14 8610012780 KNOB K261 ASSEMBLY
MP16 8610012750 KNOB K231 (A)-1 ASSEMBLY
MP17 8610012760 KNOB K232 (A)-1 ASSEMBLY
MP22 8930067320 2590 LENS HOLDER (A) ASSEMBLY
MP42 8610012720 KNOB N332 ASSEMBLY
MP44 8610012730 KNOB N333 ASSEMBLY
MP50 8610012770 KNOB N336 ASSEMBLY
MP67 8210031440 2590 10KEY PANEL (A)-1
MP72 8610012740 KNOB K230 (A)-2 ASSEMBLY
EP1 6910023970 UNIT BOARD
6910023970 UNIT BOARD
6910023970 UNIT BOARD
6910023970 UNIT BOARD
6910015291 LTA070B790F
6910023970 UNIT BOARD
6910023970 UNIT BOARD
6910023970 UNIT BOARD
EP2 6910017310 JSM5035-010100
MP1 8210021931 2844 FRONT PANEL-1
MP9 8010020080 2844 SUB CHASSIS
MP10 8930066190 2844 JACK PLATE
MP12 8610012510 KNOB K259
MP13 8610012520 KNOB K260
MP15 8610012540 KNOB K262
MP18 8610012600 KNOB K233 (A)-1
MP19 8610012650 KNOB K235 (A)-1
8610012650 KNOB K235 (A)-1
8610012650 KNOB K235 (A)-1
MP20 8610012590 KNOB K236 (A)-1
MP21 8310064660 2590 NAME PLATE (A) (SILVER)
MP27 8930062190 DOUBLE SIDE TAPE (AJ)
MP28 8930062180 DOUBLE SIDE TAPE (AK)
MP29 8930062170 DOUBLE SIDE TAPE (AL)
MP30 8930062910 DOUBLE SIDE TAPE (AO)
MP45 8610012490 KNOB N334
MP46 8610012500 KNOB N335
MP47 8610012690 KNOB N310 (B)
MP48 8610012680 KNOB N301 (A)
MP52 8610012710 KNOB N-309 COVER (A) (TOP)
MP53 8930061460 2590 BRAKE SPACER
MP54 8930061470 2590 BRAKE PLATE
MP55 8930061732 SPONGE (HI)-2
MP56 8850002010 PLAIN WASHER (AG)
MP57 8930066710 2844 BRAKE BUTTON
MP58 8830001410 1897 NUT
MP60 8930060592 2590 LCD HOLDER-2
MP61 8930085820 3009 LCD SPONGE
8930085820 3009 LCD SPONGE
8930085820 3009 LCD SPONGE
8930061620 2590 LCD SPONGE
8930085820 3009 LCD SPONGE
8930061620 2590 LCD SPONGE
8930061620 2590 LCD SPONGE
MP67 8210022130 2590 10-KEY PANEL (A)-1
8210022130 2590 10-KEY PANEL (A)-1
8210022130 2590 10-KEY PANEL (A)-1
MP68 8610012620 KNOB K234 (C)-1
8610012620 KNOB K234 (C)-1
8610012620 KNOB K234 (C)-1
MP70 8610012630 KNOB K234 (D)-1
8610012630 KNOB K234 (D)-1
8610012630 KNOB K234 (D)-1
MP71 8610012640 KNOB K234 (E)-1
8610012640 KNOB K234 (E)-1
8610012640 KNOB K234 (E)-1
MP76 8850001941 TOOTHED WASHER M9 ZC3
MP81 8810009181 BT M2×5 NI-ZC3
MP82 8810009181 BT M2×5 NI-ZC3
MP83 8810009181 BT M2×5 NI-ZC3
MP84 8810009181 BT M2×5 NI-ZC3
MP85 8810009181 BT M2×5 NI-ZC3
MP86 8810008971 BT M2×3.5 NI-ZC3
MP87 8810005701 PH M2×4 ZK3
MP88 8810008761 PHBT M2×8 NI-ZC3
MP89 8810008761 PHBT M2×8 NI-ZC3
MP90 8810008761 PHBT M2×8 NI-ZC3
MP91 8810008761 PHBT M2×8 NI-ZC3
MP92 8810008761 PHBT M2×8 NI-ZC3
MP93 8810008661 PHBT M3×8 NI-ZC3
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#09]
[#03]
[#08]
[#09]
[#02]
[#04]
[#05]
[#06]
[#07]
[#08]
[#09]
[#03]
[#08]
[#09]
[#03]
[#08]
[#09]
[#03]
[#08]
[#09]
[#03]
[#08]
[#09]
Only [#06]
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
(Amended page)
[FRONT UNIT]
REF PART
QTY.
NO. NO.
1 MP94 8810008631 PHBT M3×6 NI-ZC3
MP95 8810008631 PHBT M3×6 NI-ZC3
MP96 8810008631 PHBT M3×6 NI-ZC3
1 MP97 8810008631 PHBT M3×6 NI-ZC3
1 MP98 8810008631 PHBT M3×6 NI-ZC3
1 MP100 8810003560 HEX M4×6 SUS
1
MP105 8930070770 2844 SP SPONGE
1 MP106 8310068420 2844 WINDOW PLATE
1 MP107 8930071770 2844 K-236 SHEET
1 MP108 8930071780 2844 K-260 SHEET
1 MP109 8930071790 2844 K-261 SHEET
1 MP110 8930063260 SPONGE (HV)
1 MP112 8930071840 HIMELON SHEET (CT)
1 MP113 8930062180 DOUBLE SIDE TAPE (AK)
1 MP114 8930062170 DOUBLE SIDE TAPE (AL)
MP115 8930072620 2844 K-231 SHEET
MP116 8930072870 SPONGE (JP)
1
MP117 8930072760 2844 SUB SHEET
1 MP118 8930063260 SPONGE (HV)
1 MP119 8930072990 2844 AL SHEET
2 MP120 8930082601 SHIELD SPONGE (CT)-1
1 MP121 8930063510 EMBOSS TAPE (L)
2 8930063510 EMBOSS TAPE (L)
2 8930063510 EMBOSS TAPE (L)
1 8930063510 EMBOSS TAPE (L)
1 8930063510 EMBOSS TAPE (L)
1 8930063510 EMBOSS TAPE (L)
8930063510 EMBOSS TAPE (L)
MP122 8930063500 EMBOSS TAPE (M)
1 8930063500 EMBOSS TAPE (M)
1 8930063500 EMBOSS TAPE (M)
1 8930063500 EMBOSS TAPE (M)
1 8930063500 EMBOSS TAPE (M)
1 8930063500 EMBOSS TAPE (M)
1 8930063500 EMBOSS TAPE (M)
1 MP123 8930063490 EMBOSS TAPE (N)
1 8930063490 EMBOSS TAPE (N)
1 8930063490 EMBOSS TAPE (N)
8930063490 EMBOSS TAPE (N)
8930063490 EMBOSS TAPE (N)
1 8930063490 EMBOSS TAPE (N)
1 8930063490 EMBOSS TAPE (N)
1 MP124 8930063540 2590 A-EARTH SPRING
1 MP125 8930063790 SHIELD SPONGE (AI)
1 MP126 8930063790 SHIELD SPONGE (AI)
1 MP127 8930072900 SHIELD SPONGE (CC)
1 MP128 8930062950 SHIELD SPONGE (AF)
1 MP129 8930062950 SHIELD SPONGE (AF)
1 MP130 6910020101 3009 SHIELD SHEET-1
1 MP131 8930077090 SHIELD TAPE (V)
1 MP132 8930077100 SHIELD TAPE (W)
1 MP133 8930077080 DOUBLE SIDE TAPE (BA)
2 MP134 8930077070 DOUBLE SIDE TAPE (AZ)
1
2
2
5
1
5
1
[DISPLAY UNIT]
1
1
REF PART
1
NO. NO.
2
1
J1* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1
J3* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1
J4* 6510021561 52808-2470
1
J5* 6510019971 52808-1071
1
J7* 6510019971 52808-1071
1
J201* 6510022472 40FLT-SM2-TB (LF) (SN) (M)
1
J202* 6510022472 40FLT-SM2-TB (LF) (SN) (M)
1
J203* 6510020081 52808-2071
1
J301* 6510018971 B4B-PH-SM4-TB (LF) (SN)
1
6510018971 B4B-PH-SM4-TB (LF) (SN)
1
6510018971 B4B-PH-SM4-TB (LF) (SN)
1
6510018971 B4B-PH-SM4-TB (LF) (SN)
1
6510021181 SM2 (8.0) B-BHS1TB (LF) (SN)
1
6510018971 B4B-PH-SM4-TB (LF) (SN)
1
6510018971 B4B-PH-SM4-TB (LF) (SN)
1
6510018971 B4B-PH-SM4-TB (LF) (SN)
1
J601 6510021861 BH-800.4GG
1
J610* 6510022191 B3B-PH-SM4-TB (LF) (SN)
1
J611* 6510022311 B5B-PH-SM4-TB (LF) (SN)
1
1
1
T201 5910001050 3319-T106-LF
1
1
3
BT601 3020000110 CR-2032L/BK
2
2
1
MP1 8930063860 2590 C-EARTH SPRING
4
MP2 8930063270 2590 EARTH SPRING
2
MP3 8930063270 2590 EARTH SPRING
4
MP301 8510015390 2591 REG PLATE
9
MP302 8510015390 2591 REG PLATE
6
8
6
2
4
62
DESCRIPTION QTY.
12
Only [#06]
[#02]
[#04]
[#05]
[#06]
[#07]
[#08]
[#09]
[#02]
[#04]
[#05]
[#06]
[#07]
[#08]
[#09]
[#02]
[#04]
[#05]
[#06]
[#07]
[#08]
[#09]
Only [#03]
Only [#03]
Only [#03]
Only [#03]
Only [#03]
DESCRIPTION QTY.
[#02]
[#03]
[#04]
[#05]
[#06]
[#07]
[#08]
[#09]
Only [#06]
Only [#06]
3
4
4
2
2
1
1
1
1
1
1
3
1
4
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
1
1
1
1
1
1
1
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
