Icom IC-R9500 Service Manual Addendum page 265

NOTE: HOLD the adjustment condition (SG level and frequency etc.) until next ADJ item is displayed.
ADJUSTMENT ITEM
[V/U ATT20dB BPF7 (H) f]
[V/U ATT20dB BPF8 (L) f]
[V/U ATT20dB BPF8 (M1) f]
[V/U ATT20dB BPF8 (M2) f]
[V/U ATT20dB BPF8 (M3) f]
[V/U ATT20dB BPF8 (H) f]
[V/U ATT20dB BPF9 (L) f]
[V/U ATT20dB BPF9 (M1) f]
[V/U ATT20dB BPF9 (M2) f]
[V/U ATT20dB BPF9 (M3) f]
[V/U ATT20dB BPF9 (M4) f]
[V/U ATT20dB BPF9 (H) f]
ADJUSTMENT CONDITION
• Set the SG as;
Frequency : 499.9815 MHz
• Set the SG as;
Frequency : 500.0215 MHz
• Set the SG as;
Frequency : 562.5215 MHz
• Set the SG as;
Frequency : 625.0215 MHz
• Set the SG as;
Frequency : 687.5215 MHz
• Set the SG as;
Frequency : 749.9815 MHz
• Set the SG as;
Frequency : 750.0215 MHz
• Set the SG as;
Frequency : 820.0215 MHz
• Set the SG as;
Frequency : 910.0215 MHz
• Set the SG as;
Frequency : 990.0215 MHz
• Set the SG as;
Frequency : 1070.0215 MHz
• Set the SG as;
Frequency : 1149.9815 MHz
OPERATION
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
Push [F-7] key.
4 - 17
VALUE
(Automatic
adjustment)
