Omcan Aurora FR-CN-1219E-HC Instruction Manual page 15

Model RE-CN-0011E-HC
Item No. Description
AI387 Cabinet for 59056
AF744 Top Board for 59056
AI388 Right Door for 59056
AB197 Gasket for 59056
AA388 Axis Cover for 59056
AA955 Left/Right Spring Hinge for 59056
AA360 Bottom Left Hinge for 59056
AF070 Upper Right Hinge for 59056
AI389 Left Door for 59056
61468 Left Bottom Hinge for 59056
AB200 Upper Left Hinge for 59056
AF747 Castor Support B for 59056
AF734 Castor Support C for 59056
AF748 Castor Support A for 59056
26246 Caster with Brake for 59056
26247 Caster without Brake for 59056
59056
Position Item No. Description
1 AB320 Thermostat Installation Board for 59056
2 AI375 Thermostat for 59056
3 AF080 Stand Off Bracket for 59056
4, 10 AF085 Compressor Unit Track for 59056
5 AF749 Inner Drain Pan for 59056
6 AF738 Evaporator Cover Sticker for 59056
7 AF739 Evaporator Cover Sticker for 59056
Compressor Unit Installation Board for
8 AF106
59056
9 AA874 Outer Drain Pan for 59056
11 AB213 Condenser for 59056
12 AI390 Condenser Fan Motor for 59056
13 AA207 Condenser Fan Motor Cover for 59056
14 AI391 Blade of Condenser Fan Motor for 59056
15 AB595 Filter Fixer for 59056
16 AB594 Filter for 59056
17 AI386 Compressor for 59056
Parts Breakdown
Position Item No.
18 AI392
19 AI393
20 AI394
21 AF090
22 AF089
23 26884
24 AB220
25 AI371
26 AF752
27 AA128
28 AB169
29 AA133
30 AA135
31 AA379
32 AA596
33
15
Description Position
Compressor Starting Components for
34 - 37
59056
Back Grill for 59056 38
Evaporator Cover for 59056 39
K Strip-3 Holes for 59056 40
K Strip-2 Holes for 59056 41
K Clip for 59056 42
Shelf for 59056 43
Evaporator for 59056 44
Fan Motor Installation Board for 59056 45
Condenser Fan Motor for 59056 46
Foaming Hole Cover for 59056 47
Drain Hose for 59056 48
Power Cord for 59056 49
Temperature Probe for 59056 50
Thermometer for 59056 51
