Icom IC-R8600 Service Manual page 49

[ENCODER-1 UNIT]
REF PART
NO. NO.
J1* 6510031640 52793-0670
S1* 2250001020 RE1107CM1-V03-4672
[ENCODER-2 UNIT]
REF PART
NO. NO.
J1* 6510031640 52793-0670
S1* 2250001020 RE1107CM1-V03-4672
[ENCODER-3 UNIT]
REF PART
NO. NO.
J1* 6510031640 52793-0670
S1* 2250001030 RE1107CM1-V03-4673
[ENCODER-3 UNIT]
REF PART
NO. NO.
J1* 6510031640 52793-0670
S1* 2250001030 RE1107CM1-V03-4673
[SD UNIT]
REF PART
NO. NO.
J1* 6510028980 SCDABA0500
J31* 6510028200 UB-M5BR-S14-4S (LF) (SN)
J41* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
MP21* 8930093190 SPONGE (NT)
[CONV-BPF UNIT]
REF PART
NO. NO.
J2101* 6510032350 20279-001E-01
J2102* 6510031640 52793-0670
J2901* 6510032350 20279-001E-01
MP1* 8930097340 FERRITE SHEET (BG)
MP2 8930091060 RUBBER SHEET (CS)
MP2901* 8930071160 2427 F-EARTH SPRING
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[ACCESSORIES]
REF PART
QTY.
NO. NO.
P1 5610000430 AP331BK
1
P2 5610000660 P030050 FL
1
F1 5210000051 FGB 3A PBF (FGB0 125V)
F2 5210001390 0297003.WXNV OS>
W1 8920002220 CAB-1258
W2 8900015720 OPC-1605
QTY.
1
1
W1
QTY.
1
P1
1
F1
QTY.
1
1
QTY.
1
1
1
1
QTY.
1
1
1
1
1
1
7-4
DESCRIPTION QTY.
W2
P2
F2
3
2
2
1
1
1
