Icom IC-R8600 Service Manual page 16

5-3 HF RECEIVE ADJUSTMENT (CONTINUED)
ADJUSTMENT ADJUSTMENT ITEM DISPLAY
16 HF BPF0 flat
HF-flat
17 HF BPF1 flat
18 HF BPF2 flat
19 HF BPF3 flat
20 HF BPF4 flat
21 HF BPF5 flat
22 HF BPF6 flat
23 HF BPF7 flat
24 HF BPF9 flat
25 HF BPF10 flat
26 HF BPF11 flat (L)
27 HF BPF11 flat ( M)
28 HF BPF11 flat (H)
29 HF PRE flat (L)
HF-flat
(Preamp ON)
30 HF PRE flat ( M)
31 HF PRE flat (H)
32 HF ATT 10dB flat
HF-flat
(ATT)
33 HF ATT 20dB flat
• After the adjustment, the receiver shows the HF receive adjustment menu.
• Push [EXIT] to return to the main menu screen.
: The output level of the standard signal generator (SSG) is indicated as the SSG's open circuit.
†
CONDITION
• Set the test equipment to:
Frequency: 0.2515 MHz
Modulation: None
Level: +40 dBμ (–67 dBm)
†
• Set the test equipment to:
Frequency: 1.1015 MHz
• Set the test equipment to:
Frequency: 1.8215 MHz
• Set the test equipment to:
Frequency: 2.6015 MHz
• Set the test equipment to:
Frequency: 3.6015 MHz
• Set the test equipment to:
Frequency: 5.1015 MHz
• Set the test equipment to:
Frequency: 7.0815 MHz
• Set the test equipment to:
Frequency: 10.1015 MHz
• Set the test equipment to:
Frequency: 18.1515 MHz
• Set the test equipment to:
Frequency: 28.1015 MHz
Set the test equipment to:
Frequency: 0.5015 MHz
• Set the test equipment to:
Frequency: 14.1515 MHz
• Set the test equipment to:
Frequency: 29.9015 MHz
• Set the test equipment to:
Frequency: 0.5015 MHz
• Set the test equipment to:
Frequency: 14.1515 MHz
• Set the test equipment to:
Frequency: 29.9015 MHz
• Set the test equipment to:
Frequency: 14.1515 MHz
Modulation: None
Level: +40 dBμ (–67 dBm)
†
5-4
OPERATION
Touch [SET].
(A beep sounds, and then
another beeps sound 1
second later.)
