5-4 VU RECEIVE ADJUSTMENT (CONTINUED)
ADJUSTMENT ADJUSTMENT ITEM DISPLAY
106 VU3 flat (1150 M)
VU3-flat
107 VU3 flat (1100 M)
108 VU3 flat (1220 M)
109 VU3 flat (1249 M)
110 VU3 flat (1375 M)
111 VU3 flat (1330 M)
112 VU3 flat (1420 M)
113 VU3 flat (1499 M)
114 VU3 flat (1575 M)
115 VU3 flat (1500 M)
116 VU3 flat (1650 M)
117 VU3 flat (1749 M)
118 VU3 flat (1875 M)
119 VU3 flat (1750 M)
120 VU3 flat (1830 M)
121 VU3 flat (1920 M)
122 VU3 flat (1999 M)
123 VU3 PRE flat (1150 M)
124 VU3 PRE flat (1375 M)
125 VU3 PRE flat (1575 M)
126 VU3 PRE flat (1875 M)
127 VU4 Total Gain PRE OFF ref
VU4 TOTAL GAIN
(Preamp OFF)
128 VU4 Total Gain PRE OFF set
129 VU4 Total Gain PRE ON ref
VU4 TOTAL GAIN
(Preamp ON)
130 VU4 Total Gain PRE ON set
: The output level of the standard signal generator (SSG) is indicated as the SSG's open circuit.
†
CONDITION
• Set the test equipment to set as
shown below:
Frequency: 1150.0215 MHz
Modulation: None
Level: +40 dBμ (–67 dBm)
†
• Set the test equipment to:
Frequency: 1100.0215 MHz
• Set the test equipment to:
Frequency: 1220.0215 MHz
• Set the test equipment to:
Frequency: 1249.9815 MHz
• Set the test equipment to:
Frequency: 1375.0215 MHz
• Set the test equipment to:
Frequency: 1330.0215 MHz
• Set the test equipment to:
Frequency: 1420.0215 MHz
• Set the test equipment to:
Frequency: 1499.9815 MHz
• Set the test equipment to:
Frequency: 1575.0215 MHz
• Set the test equipment to:
Frequency: 1500.0215 MHz
• Set the test equipment to:
Frequency: 1650.0215 MHz
• Set the test equipment to:
Frequency: 1749.9815 MHz
• Set the test equipment to:
Frequency: 1875.0215 MHz
• Set the test equipment to:
Frequency: 1750.0215 MHz
• Set the test equipment to:
Frequency: 1830.0215 MHz
• Set the test equipment to:
Frequency: 1920.0215 MHz
• Set the test equipment to:
Frequency: 1999.9815 MHz
• Set the test equipment to:
Frequency: 1150.0215 MHz
• Set the test equipment to:
Frequency: 1375.0215 MHz
• Set the test equipment to:
Frequency: 1575.0215 MHz
• Set the test equipment to:
Frequency: 1875.0215 MHz
• Set the test equipment to set as
shown below:
Frequency: 2424.0215 MHz
Modulation: None
Level: +60 dBμ (–47 dBm)
†
• Set the test equipment level to:
Level: OFF
• Set the test equipment level to:
Level: +60 dBμ (–47 dBm)
†
• Set the test equipment level to:
Level: OFF
5-9
OPERATION
Touch [SET].
(A beep sounds, and then
another beeps sound 1
seconds later.)
Touch [SET].
(A beep sounds, and then
another beeps sound
after the adjustment is
completed.)
Touch [SET].
(A beep sounds, and then
another beeps sound 10
seconds later.)
Touch [SET].
(A beep sounds, and then
another beeps sound
after the adjustment is
completed.)
Touch [SET].
(A beep sounds, and then
another beeps sound 10
seconds later.)
