Icom IC-R8600 Service Manual page 47

[MAIN UNIT]
REF PART
NO. NO.
J1* 6510011431 B3P-VH (LF) (SN)
J2* 6510031740 HEC3900-010110
J11* 6510022472 40FLT-SM2-TB (LF) (SN) (M)
J41* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J71* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J201* 6510018971 B4B-PH-SM4-TB (LF) (SN)
J241* 6510025940 PJ-3047S
J242* 6510014961 B2B-ZR-SM4-TF (LF) (SN)
J261* 6510023730 LGY6502-0600C
J290* 6510028210 SJ050010 (TMP-J01X-V6)
J321* 6510026540 UBB-4R-D14T-4D (LF) (SN)
J322* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
J371* 6510023730 LGY6502-0600C
J392* 6510023730 LGY6502-0600C
J531* 6510028210 SJ050010 (TMP-J01X-V6)
J541* 6510028210 SJ050010 (TMP-J01X-V6)
J601* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
6510025142 10FLT-SM2-TB (LF) (SN) (M)
J671* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
6510025142 10FLT-SM2-TB (LF) (SN) (M)
J961* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
6510025142 10FLT-SM2-TB (LF) (SN) (M)
J1001* 6510027111 08FLT-SM2-TB (LF) (SN) (M)
6510027111 08FLT-SM2-TB (LF) (SN) (M)
J1002* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
6510025142 10FLT-SM2-TB (LF) (SN) (M)
J1361* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
6510025142 10FLT-SM2-TB (LF) (SN) (M)
J1381* 6510027290 52808-0671
6510027290 52808-0671
J1401* 6510024040 TM11R-5M2-88-LP
J1451* 6510026540 UBB-4R-D14T-4D (LF) (SN)
J2022* 6510025142 10FLT-SM2-TB (LF) (SN) (M)
F1* 5220000400 FHA010-01F
F2* 5210001390 0297003.WXNV
S391* 2220000790 SSSS925800
S1301* 2230001480 LS37J2-T
T1401* 5920000990 H1102FNLT
BT1201* 3020000390 ML414HIV01E
MP41* 8930071160 2427 F-EARTH SPRING
8930071160 2427 F-EARTH SPRING
8930071160 2427 F-EARTH SPRING
MP101* 8510019340 3179 VCO CASE
MP102* 8510019350 3179 VCO COVER
MP121* 8510019340 3179 VCO CASE
MP122* 8510019350 3179 VCO COVER
MP131* 8930071160 2427 F-EARTH SPRING
8930071160 2427 F-EARTH SPRING
8930071160 2427 F-EARTH SPRING
MP141* 8510021680 3697 VCO CASE
MP142* 8510018160 2969 B-VCO COVER
MP143* 8930063971 SHIELD SPONGE (AM)-1
8930063971 SHIELD SPONGE (AM)-1
8930063971 SHIELD SPONGE (AM)-1
MP241* 8510022080 3818 AF CASE
MP271* 8510022090 3818 IF CASE
MP401* 8510022100 3818 REF CASE
MP441* 8510021150 3621 VCO CASE
MP442* 8510021160 3621 VCO COVER
MP481* 8930094090 3768 ANT SPRING
MP541* 8510022090 3818 IF CASE
MP571* 8510019800 3183 FILTER CASE
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
[#03]
[#06]
[#03]
[#06]
[#03]
[#06]
[#03]
[#06]
[#03]
[#06]
[#03]
[#06]
[#03]
[#06]
[#02]
[#04]
[#05]
[#02]
[#04]
[#05]
[#02]
[#04]
[#05]
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[RF UNIT]
REF PART
QTY.
NO. NO.
1 J4* 6450002520 RL-1515-2 (B.B)-L
1 J6* 6510023730 LGY6502-0600C
1 J501* 6510032350 20279-001E-01
1 J571* 6510028210 SJ050010 (TMP-J01X-V6)
1 J591* 6510032350 20279-001E-01
1 J751* 6510032350 20279-001E-01
1 J801* 6510028210 SJ050010 (TMP-J01X-V6)
1 J810* 6510032350 20279-001E-01
1 J812* 6510032350 20279-001E-01
1 J813* 6510032350 20279-001E-01
1 J901* 6510022472 40FLT-SM2-TB (LF) (SN) (M)
1 J1101* 6510032350 20279-001E-01
1 J1102* 6510027290 52808-0671
1 J1951* 6510032350 20279-001E-01
1
1
1 W501** 8920002370 CAB-1168A (8229JQ120000000101)
1 W812** 8920002370 CAB-1168A (8229JQ120000000101)
1 W813** 8920002310 CAB-1299 (822EKQ075000000101)
1 W1101** 8920002380 CAB-1306 (8229JQ045000000101)
1 W1102** 8900019300 OPC-2032 (P1N6L50)
1 W1951** 8920002310 CAB-1299 (822EKQ075000000101)
1
1
1
EP501* 6910000630 FSRH070140RN000B (FSOH070RN)
1 EP502* 6910000630 FSRH070140RN000B (FSOH070RN)
1
1
1 MP1* 8930094090 3768 ANT SPRING
1 MP2* 8510022220 3818 ANT COVER
1 MP3* 8510002280 VCOSHIELD PLATE (A) FX 15
1 MP4* 8930082601 SHIELD SPONGE (CT)-1
1 MP5* 8930071160 2427 F-EARTH SPRING
MP6 8930097540 SHIELD SPONGE (EI)
MP8 8930097450 FERRITE SHEET (BI)
1 8930097460 FERRITE SHEET (BJ)
1 8930097450 FERRITE SHEET (BI)
8930097450 FERRITE SHEET (BI)
8930097460 FERRITE SHEET (BJ)
1 MP9* 8930071160 2427 F-EARTH SPRING
1 MP51* 8930049131 SHIELD TAPE (D)-1
8930049131 SHIELD TAPE (D)-1
8930049131 SHIELD TAPE (D)-1
1 MP101* 8510022190 3818 BPF-A CASE
MP501* 8510018880 2355 P-VCO CASE
MP502* 8930071160 2427 F-EARTH SPRING
1 MP503* 8930071160 2427 F-EARTH SPRING
MP504* 8930071160 2427 F-EARTH SPRING
MP505* 8930097520 DOUBLE SIDE TAPE (CG)
1 MP506* 8930097520 DOUBLE SIDE TAPE (CG)
1
MP511* 8510018880 2355 P-VCO CASE
1 MP551* 8510014870 2577 RX-VCO CASE
1 MP601* 8510018880 2355 P-VCO CASE
1 MP701* 8510018940 2356 A-VCO CASE
1 MP702* 8930097540 SHIELD SPONGE (EI)
1 8930097540 SHIELD SPONGE (EI)
1 8930097540 SHIELD SPONGE (EI)
1 MP1001* 8510022230 3818 RELAY CASE
1 MP1002* 8930071160 2427 F-EARTH SPRING
1
MP1011* 8510022230 3818 RELAY CASE
1 MP1012* 8930071160 2427 F-EARTH SPRING
1 MP1013* 8930071160 2427 F-EARTH SPRING
1 MP1014* 8930071160 2427 F-EARTH SPRING
1 MP1015* 8930063971 SHIELD SPONGE (AM)-1
1 MP1016* 8930097310 FERRITE SHEET (BE)
1 MP1017* 8930069610 SPONGE (IV)
1 MP1021 8510012400 2177 D/A CASE Y454
1 MP1031* 8510018880 2355 P-VCO CASE
1
MP1101* 8510022200 3818 CONV-BPF CASE
1 MP1102* 8510022210 3818 CONV-BPF COVER
1 MP1103 8810007131 SET SCREWH M3 X 6 ZC3 2K
1 MP1104 8510022240 3818 RF PLATE Y1415
MP1105* 8930071160 2427 F-EARTH SPRING
MP1106* 8930071160 2427 F-EARTH SPRING
MP1107* 8930097300 FERRITE SHEET (BD)
MP1108* 8930097300 FERRITE SHEET (BD)
MP1109* 8930097320 FERRITE SHEET (BF)
MP1151 8930074741 SHIELD SPONGE (CE)-1
MP1152 8930074741 SHIELD SPONGE (CE)-1
MP1153 8930097170 FERRITE SHEET (BC)
MP1154 8930092020 SPONGE (NH)
MP1155 8930092020 SPONGE (NH)
MP1156 8930071551 SHIELD SPONGE (BM)-1
MP1201* 8510018930 2356 A-PLL CASE
MP1261* 8510018880 2355 P-VCO CASE
MP1281* 8510018880 2355 P-VCO CASE
MP1291* 8930097540 SHIELD SPONGE (EI)
MP1292* 8930097540 SHIELD SPONGE (EI)
MP1293* 8930097330 3818 FERRITE SHEET
MP1301* 8510022180 3818 BPF CASE Y1413
MP1302* 8930097340 FERRITE SHEET (BG)
MP1303* 8930097440 FERRITE SHEET (BH)
MP1511* 8510018880 2355 P-VCO CASE
MP1521* 8510018880 2355 P-VCO CASE
7-2
DESCRIPTION QTY.
[#02]
[#03]
[#04]
[#05]
[#06]
[#02]
[#04]
[#05]
[#02]
[#04]
[#05]
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
