- Page 1 INSTALLATION MANUAL Industrial Bar Faucet KPF-3127 www.kraususa.com Toll Free: 1.800.775.0703 © 2018 Kraus USA Inc. REV. June 16, 2021...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Prior to Installation: · Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. · Turn off the hot and cold water supply at the angle stops and turn on the old faucet to release any built up pressure. - Page 4 Diagram and Parts List Aerator Assembly Faucet Body 3A. Rubber Washer 3B. Metal Washer 3C. Mounting Nut 3D. Mounting Screws Waterlines...
-
Page 5: Faucet Dimensions
Faucet Dimensions 7 1/4" (185mm) 4 5/8" (118.7mm) 5 3/4" (147.1mm) Ø 2" Ø 1 3/8" (50mm) (34mm) Installer Tip: Shut off main water supply before installing new faucet. - Page 6 Step 1. Remove mounting hardware Remove the mounting screws (3D), mounting nut (3C), metal washer (3B) and rubber washer (3A) from the mounting pipe. Step 2. Install faucet and mounting hardware Insert faucet body (2) into hole in countertop or deck plate assembly.
- Page 7 Secure mounting hardware Step 3. Adjust direction of faucet body (2) so that handle is on right side of faucet. Tighten mounting nut (3C) until snug. Tighten mounting screws (3D) to nut with Phillips screwdriver until snug. Step 4. Connect waterlines Connect hot and cold copper lines (4) to angle stops.
