Microphone
9
Adjustable stand
10

2.2 VCI Connector

The VCI connector works as a vehicle communication interface device, which is
used to connect to the vehicle's DLC (Data Link Connector) socket via the
diagnostic cable to read the vehicle data and then send it to the tablet. It only
applies to the 12V passenger cars.
*Note: Remember to remove the VCI connector from the vehicle's DLC after use.
1 Power indicator
Flip it out to any angle and work comfortable at
your desk, or hang it on steering wheel.
Illuminates red while the VCI is powered up.
5
