Related Manuals for Thermo Scientific Sarasota ID900
Summary of Contents for Thermo Scientific Sarasota ID900
- Page 1 Sarasota ID900/FD900/PD900 Sarasota RTR900 Gas Density Meters & Instrument Retractor User Guide P/N HB-ID/FD900 Revision L Part of Thermo Fisher Scientific...
- Page 3 Sarasota ID900/FD900/PD900 Sarasota RTR900 Gas Density Meters & Instrument Retractor User Guide P/N HB-ID/FD900 Revision L...
- Page 5 © 2018 Thermo Fisher Scientific Inc. All rights reserved. “Ni-Span C” is a registered trademark of the Special Metals Corporation. “HART” is a registered trademark of the HART Communication Foundation. “Inconel” is a registered trademark of Special Metals Wiggin Ltd. “Microsoft”...
- Page 6 This page intentionally left blank.
- Page 7 Revised per ECO 7799. 04-2017 Change Temperature Range per ECO 9186 08-2017 Revised per ECO 9194 09-2017 Revised per ECO 9274 10-2021 Revised per ECO 10067 Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 8 This page intentionally left blank.
-
Page 9: Table Of Contents
Calibration ..................4-1 Air Checks................... 4-1 Chapter 4 Corrections ..................4-1 Liquid Checks ..................4-2 Vacuum Point Cleaning ..............4-2 Temperature Correction at Check Points ..........4-3 Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 10 Sarasota Gas Density Meters ...............B-1 Sarasota RTR900 ................B-4 Appendix C Drawings......................C-1 Appendix D Health & Safety Clearance Form..............D-1 Appendix E Toxic & Hazardous Substances Tables ............E-1 viii User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
-
Page 11: Important Safety Information
Electrocution can result if power is present. ▲ Warning Ensure the power supply is isolated. Take suitable precautions to prevent reinstatement of power while working on the system. ▲ Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 12 This page intentionally left blank.
-
Page 13: Product Overview
The Sarasota PD900 pocket density meter offers many of the same design features as the Sarasota ID900 but is mounted into a thermowell pocket that is installed directly into the pipeline. Since the pocket is in the... -
Page 14: Operation
This safety feature prevents removal of the top seal housing until seal housing pressure is released. The retractor allows the Sarasota ID900 to be removed from the system while leaving the seal housing still clamped to the system pipeline. It is designed to be used with pipeline pressures up to 170 bar (2500 psi). -
Page 15: Installation
Note Installation must be carried out in accordance with local site requirements and regulations. ▲ Sarasota ID900 The Sarasota ID900 should be mounted vertically in the pipeline with the outlet port downstream. There are three mountingmethods: Welded flange version ●... - Page 16 Installation Sarasota ID900 Figure 2–1. Sarasota ID900 dimensional drawing 2-2 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 17 Figure 2–3. Installation of Sarasota ID900 with Sarasota RTR900 Note If using the Sarasota RTR900 instrument retractor, be sure to review the following section for mounting instructions. ▲ Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 18: Sarasota Rtr900
Take care not to loose the Inconel C ring on top of the seal housing. 2-4 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 19 Fit the C ring and screw down the top of the seal housing and lead screw assembly. 10. Using the C wrench, tighten to clamp the ring to 330 Nm (250 lbf.ft). Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 20 Installation Sarasota RTR900 Figure 2–4. Sarasota RTR900 dimensional drawing 2-6 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 21 Installation Sarasota RTR900 Figure 2–5. Sarasota RTR900 installation Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 22: Sarasota Fd900
Caution Do not install the density meter too close to bends, pressure reducers, or pumps. ▲ Figure 2–6. Typical installation for Sarasota FD900 Figure 2–7. Sarasota FD900 with 1.5” BSP installation dimensions 2-8 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 23 Installation Sarasota FD900 Figure 2–8. Sarasota FD900 with flange installation dimensions Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 24 Installation Sarasota FD900 Figure 2–9. Sarasota FD900 dimensional drawing 2-10 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Thermo Fisher Scientific...
-
Page 25: Sarasota Pd900
1. Keep the valve between the meter and the density sample point very well insulated and fully open. If the valve is fully open, temperature changes at the vale are prevented. 2-11 Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... -
Page 26: Pressure Considerations
4. Fillet weld between 1 and 4. 5. Fillet weld between 3 and 2. 6. Fillet weld between 3 and 1. 7. Fillet weld between 2 and 4. 2-12 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... -
Page 27: Meter Installation
5. Secure the density meter to the pocket flange using 6 off M8 x 30 mm socket head bolts tightened to 27 Nm (20 lbf.ft). 2-13 Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... -
Page 28: Installing The Bypass System
The wiring is required to run to the instrument connection box when the retractor is fully installed. For Sarasota ID900 only: Provision must be made for the easy removal ● of the electrical wiring to allow the retractor to be rotated when it is used. -
Page 29: Hazardous Area Installation
In cases of location in Zone 0 (ATEX Category 1), where impact/abrasion or other mechanical forces may be expected, appropriate methods of protection must be used. 2-15 Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... -
Page 30: Marking
Ex ia IIC T4 Ga (-20°C ≤ Ta ≤ 60°C) IECEx BAS 16.0086X Installed in the hazardous area [BAS01ATEX1002X] is marked on the label as shown below: 2-16 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 31 Hazardous Area Installation Figure 2–14. Figure 2–15. List of IECEx and ATEX Standards are provided below: IEC 60079-0:2011 IEC 60079-11:2011 EN 60079-0:2012 + A11:2013 EN 60079-11:2012 2-17 Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 32: Electrical Data
2. When the equipment is installed, care must be taken to ensure the maximum ambient temperature of the electronics housing is not affected by the specified process temperature of the connected sensor assembly. 2-18 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 33 Installation Hazardous Area Installation This page intentionally left blank. 2-19 Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 34: Commissioning
2. Ensure the seal housing top clamp nut is fullytightened. 3. Carefully open bleed valve with a one-quarter turn, and slightly crack the main line valve. 3-2 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... -
Page 35: Insertion
8. Check that the flow arrow on the amplifier aligns with pipe flow direction for the density meterinstallation. 9. Check for leakage and make corrections asnecessary. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... -
Page 37: Retraction
▲ 6. If no leakage occurs at the bleed valve, the retractor seal housing top clamp nut may now be removed with the C Wrenchprovided. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 38 Cover the top of the housing to keep it clean. Alternatively, grease the C ring to protect it from dirt. Figure 3–1. Average insertion torque versus pressure 3-4 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 39 Commissioning Sarasota RTR900 Figure 3–2. Sarasota RTR900 commissioning sequence Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 40: Sarasota Pd900
If it is not possible provide a densitometer signal of at least 1.5 V p-p at the terminal box, consult the factory. 3-6 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... -
Page 41: Setting The Bypass Flow Rate
3. Re-open the valve very slowly and observe the density reading. It will change as flow through the bypass causes a change in pressure. A small change is acceptable, commensurate with the system accuracy required. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 42 This page intentionally left blank.
-
Page 43: Calibration
Tair temperature on the calibration sheet using the temperature coefficient of the spool. Refer to “Temperature Correction at Check Points” later in this chapter. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... -
Page 44: Liquid Checks
Ensure a vacuum <5 mm of mercury has been obtained (<0.01 kg/m ● Ensure no dirt or other contamination is affecting the chamber spool or ● body. Ensure there is no damage to the spool. ● 4-2 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... -
Page 45: Temperature Correction At Check Points
Tcof = temperature coefficient of transducer in µs from calibration certificate θ1 = temperature of Tvac or Tair on calibration certificate (°C) θ2 = temperature of instrument at time of vacuum point check (°C) Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 46 This page intentionally left blank.
-
Page 47: Chapter 5 Maintenance
Warning Refer to the local safety rules before commencing work. ▲ General The Sarasota ID900 should be checked and cleaned at every plant shutdown, unless these are very frequent. When the process fluid is dirty and more frequent cleaning is required, the instrument should be installed with the Sarasota RTR900 to enable removal without pipeline shutdown. - Page 48 The gland nut is identified with the stamp n where “n” is the number of that retractor within a batch. The gland body should be marked in the same way. 5-2 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 49 Ten years / 1. The unit should be inspected by an approved service agent or returned to 200 cycles the factory for full service. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 50: Gland Packing
3. The unit can now be cleaned with a solvent cleaner, preferably in an ultrasonic bath without removing the spool. 5-4 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... -
Page 51: The Spool
3. If deposit buildup is heavy or if there are magnetic solids stuck tothe inside of the body near the center, check the filters and increase the frequency of cleaning. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 52 Repeat the procedure 3 times until consecutive Tair readings are to within 0.002 to 0.003 µs. 10. Take a reading of Tair to within 0.001 µs and note the air temperature. 5-6 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 53 Maintenance Cleaning Figure 5–2. Types of spool damage Figure 5–3. Spool contamination Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 54 This page intentionally left blank.
-
Page 55: Chapter 6 Troubleshooting & Service
Voltage should be 25 V. 6. If readings are still unstable, remove the instrument. Clean it and check the filter. Determine the cause of any buildup. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 56 1. If readings are erratic, clean the densitymeter. 2. If readings are stable, check theinstallation. 3. Check for air bubbles. 4. Check for dirt in the fluid. 6-2 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
-
Page 57: Contact Information
A-101, 1CC Trade Tower Senapati Bapat Road Pune 411 016 Maharashtra, INDIA +91 (20) 6626 7000 +91 (20) 6626 7001 fax www.thermoscientific.com For returns, consult Thermo Fisher for specific instructions. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 58 This page intentionally left blank.
-
Page 59: Appendix A Ordering Information
ID900 fixed insertion, complete with integral flange: 3” ANSI B16.5 RF Class 600 ID900 fixed insertion, complete with integral flange: 3” ANSI B16.5 RF Class 900 Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 60 HME spare card set. Includes PC251 processor and PC252 safety and isolation PCBs Local display Local display kit for Sarasota HME900. Includes mounting components and display PCB LIQ FILTER KIT Liquid filter kit A-2 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 61 1x MTL5525 for density meter power; should be used when no earth ground is available or in some countries or locations when the device is used in Zone 0 hazardous area Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 62: Sarasota Fd900
Traceable Calibration Certificate: Provides a record of all the instruments used during calibration and their certificates A-4 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 63 1x MTL5525 for density meter power; should be used when no earth ground is available or in some countries or locations when the device is used in Zone 0 hazardous area Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 64: Sarasota Pd900
Traceable Calibration Certificate: Provides a record of all the instruments used during calibration and their certificates Non-destructive testing: NDT of pressure containing welds by Dye Penetrant; (50% all external welds; 100% all internal and external welds) A-6 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 65 1x KFD2-SD-Ex1.48 for density meter power; should be used when no earth ground is available or in some countries or locations when the device is used in Zone 0 hazardous area Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 66: Sarasota Rtr900
Code Options Wetted parts traceability to EN 10204. Type 3.1. NACE Conformance: All wetted parts suitable for sour gas service; NACE specification MR-01-75 A-8 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 67 Compression nut assembly 16/190 Grease, 14 oz 16/189 Machine oil, 500 ml ZV10-0020 Sampling valve with interlock ZW10-06-030/B Socket headed screws, packet of 10 RT80-3926P C wrench Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 68 This page intentionally left blank.
-
Page 69: Appendix B Specifications
Sarasota ID900, fixed flange: 610 x 360 x 360 mm (24 x 14 x 14 in) dimensions Sarasota ID900, 1 meter stem: 1320 x 230 x 230 mm (52 x 9 x 9 in) Sarasota FD900: 610 x 360 x 360 mm (24 x 14 x 14 in) - Page 70 Standard pocket: Carbon steel ASTM A350 LF2 or stainless steel PD900 only) 316L/1.4404 Quick response pocket: Carbon steel ASTM A350 LF2 or stainless steel 316L/1.4404 B-2 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 71 IEC 60079-0 IECEx BAS 16.0086X Ex ia IIC T4 Ga (-20°C ≤ Ta ≤ 60°C) IEC 60079-11 with headmounted electronics option only EN 60079-0 EN 60079-11 Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 72: Sarasota Rtr900
Operating pressure range 177 bar (2567 psi) or flange rating Length of stroke 660 mm (26 in) Leadscrew pitch 4.23 mm (6 threads per inch) B-4 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 73 The instrument should be installed directly on a mating flange allowing minimum headroom of 1400 mm (55 in) for complete retraction. Environmental rating IP65 (NEMA 4X) Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 74 SEP (sound engineering practice) (97/23/EC) BS EN ISO 15156 / NACE Optional MR0175 Conformance Material traceability Wetted parts traceable to BS EN 10204.3.1.b. Certification available. B-6 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
-
Page 75: Appendix C Drawings
Contact the factory if you need a copy of the latest revision. ▲ Table C–1. Drawing # Rev. Description Page AD_6502 Wiring diagrams, barrier & non-hazardous/safe area C–2 options for Sarasota density meters (9 sheets) C-2 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 76 Drawings Figure C–1. AD_6502: Wiring diagrams, barrier & non-hazardous/safe area options for Sarasota density meters (sheet 1 of 9) Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 77 Drawings Figure C–2. AD_6502: Wiring diagrams, barrier & non-hazardous/safe area options for Sarasota density meters (sheet 2 of 9) C-4 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 78 Drawings Figure C–3. AD_6502: Wiring diagrams, barrier & non-hazardous/safe area options for Sarasota density meters (sheet 3 of 9) Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 79 Drawings Figure C–4. AD_6502: Wiring diagrams, barrier & non-hazardous/safe area options for Sarasota density meters (sheet 4 of 9) C-6 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 80 Drawings Figure C–5. AD_6502: Wiring diagrams, barrier & non-hazardous/safe area options for Sarasota density meters (sheet 5 of 9) Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 81 Drawings Figure C–6. AD_6502: Wiring diagrams, barrier & non-hazardous/safe area options for Sarasota density meters (sheet 6 of 9) C-8 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 82 Drawings Figure C–7. AD_6502: Wiring diagrams, barrier & non-hazardous/safe area options for Sarasota density meters (sheet 7 of 9) Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 83 Drawings Figure C–8. AD_6502: Wiring diagrams, barrier & non-hazardous/safe area options for Sarasota density meters (sheet 8 of 9) C-10 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 84 Drawings Figure C–9. AD_6502: Wiring diagrams, barrier & non-hazardous/safe area options for Sarasota density meters (sheet 9 of 9) Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
-
Page 85: Appendix D Health & Safety Clearance Form
The Health & Safety (COSHH) Clearance form can be found on the following page. Failure to return this form may result in the meter being returned. C-10 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific... - Page 86 This page intentionally left blank. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 87 27 Forge Parkway Franklin, MA 02038 USA Tel: 800.437.7979 Fax: 508.520.2800 HEALTH AND SAFETY (COSHH) CLEARANCE FORM Failure to comply with this procedure will result in equipment service delays. This form must be completed for all equipment returned to Thermo Fisher Scientific (Thermo Fisher) – Franklin Depot Repair.
- Page 88 This page intentionally left blank.
-
Page 90: Appendix E Toxic & Hazardous Substances Tables
Toxic & Hazardous Substances Tables The English and Chinese versions of the Toxic and Hazardous Substances tables for the Sarasota gas density meters are provided on the following pages. Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters... - Page 91 Toxic & Hazardous Substances Tables E-2 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 92 Toxic & Hazardous Substances Tables Thermo Fisher Scientific User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters...
- Page 93 Toxic & Hazardous Substances Tables E-4 User Guide for Sarasota ID900, FD900, & PD900 Gas Density Meters Thermo Fisher Scientific...
- Page 94 ThermoFisher Scientific 81 Wyman Street P.O. Box 9046 Waltham, Massachusetts 02454-9046 United States www.thermofisher.com...
