- Page 1 Version 1.0 Brody Clothes Rack 4 Shelf fantasticfurniture.com.au...
- Page 2 Secure it! Reduce the risk of furniture tip-over accidents WARNING: ENSURE THE WALL STRAP IS ATTACHED TO AVOID SERIOUS INJURY OR DEATH. To avoid any serious or fatal injury, a wall strap has been provided with this product to prevent toppling. We strongly recommend that this product is permanently fixed to the wall or other suitable surface.
- Page 3 We’re thrilled you’ve chosen Fantastic Furniture to help create a home you’ll love! Love it? Share it! Fantastic buy! Share how it looks at home on Instagram for your chance to win a $250 Fantastic Furniture Gift Card! @fantasticfurniture fantasticfurniture.com.au Page 3...
-
Page 4: Assembly Checklist
Assembly Checklist Read through the instructions Make sure you have all the required tools. Never use power tools unless instructed. carefully before you begin. Unless instructed, do not fully tighten Identify and lay out all of the components before you begin assembly. screw s until the item is fully assembled. -
Page 5: What You Need
What You Need to assemble the product Hanging Rail (P14) Top Right Frame Top Middle Frame (P7) (P8) Box 1: Shelf Panel (P1) Shelf Panel (P1) Shelf Panel (P2) Shelf Panel (P3) (P12) (P12) Shelf Panel (P4) Top Left Frame Shelf Panel (P5) (P6) Top Left Frame (P6) - Page 6 Step 1 You will need Allen Key 4X Screws (H3) (H4) Attach Top Le t Frame (P6) to Lower Le t Frame (P9) with 2 x Screws (H3) by tightening with the Allen Key (H4); Repeat steps for the Top Right Frame (P8) and Lower Right Frame (P11). Step 2 You will need 2X Screws...
- Page 7 Step 3 You will need 12X Screws Allen Key Attach Small Bars (P12×2) to Shelf Panel (P1) with 4 x Screws (H2) by tightening with the Allen Key (H4). Repeats steps for Shelf Panels (P2) & (P3). Step 4 You will need 4X Screws Allen Key Attach Threaded Bars (P13×2) to Shelf Panel (P4) with 2 x Screws (H2) by tightening...
- Page 8 Step 5 Ensure the threaded rods are inserted through You will need the lower middle frame. 14X Screws Allen Key Attach Shelves (P1, P2, P3 & P4) to Top & Lower Le t Frames (P6&P9) and Top & Lower Middle Frames (P7&P10) as shown with 14 x Screws (H1) by tightening with the Allen Key(H4). Attach Large Bars (P15 ×2) to Lower Middle Frame (P10) by tightening to the ends of Threaded Bars (P13×2).
- Page 9 Step 7 You will need 4X Screws Allen Key Attach Hanging Rail (P14) to Top Middle & Top Right Frames (P7&P8) with 2 x Screws (H1) by tightening with Allen Key (H4). Secure Large Bars (P15×2) to Lower Right Frame (P11) with 2 x Screws (H1) by tightening with the Allen Key (H4).
-
Page 10: Job Complete
Step 9 You will need 1 x Washer (H7) Screws and wall plugs are not provided please use appropriate fixtures for your wall. Move the unit into it’s final position and then secure the Safety Strap to the wall. Ensure it is firmly attached. Screw and wall plug are not provided.
