Installation Guide
H/U952T Terminal Transmitter
3.2
Opening the Housing
Use a screwdriver or similar to release the cover by applying a light pressure to the two snap
catches (1) and remove the cover (2).
Figure 4. Releasing the cover.
NOTE: The internal metal shield should not be opened.
3.3
Installation Together with Other Units
1
Remove upper and lower covers. Fasten together the lower rectangular covers of
adjacent units (1).
2
Fasten each unit to the wall with three screws, see
3 July 2013 / Ver. G
1
1
1
1
figure 3
TD 92022EN
on page 6.
7
