product sheet
product: hMt1000
segment: defense
division: security communication
the hybrid Mains and optical transmission
unit is an ancillary product to Ascom's palette of
military communication equipment. It is a
practical device that fulfils a special but common
requirement. the hMt1000 feeds isolated
stations with signal and power through a single
hybrid cable. It offers fast set-up, effectively
replaces power generators and can be deployed
by a single person.
reduced emission as well as distantly
placed transmitters give personnel an element
of added protected in the combat arena.
compliant with standards for military grade
electronics, the htM1000 is constructed of the
same quality standards as the family of Ascom
ruggedized openAccess Nodes. used primarily in
military environments, it is also suitable for
international peace keeping and crisis manage-
ment operations.
HMT1000 HYBRID MAINS AND OPTICAL
TRANSMISSION UNIT 1000 FOR REMOTE
OPERATION OF C4I INFRASTRUCTURE
the htM1000 delivers power and provides for remote operation of
semi-permanent transmitter stations or other c4I equipment. simplified
cabling allows a small signal core team to rapidly install - for example -
ad-hoc surveillance stations, command centres, transmitter stations and
check points even in difficult access sites such as snow and steep terrain.
the htM100 hybrid cable consists of a power transmission line and
four single-mode optical fibres bundled in a sturdy, yet compact and light
construction; complete with integrated terminal hybrid connectors that let
fast fail-safe mounting.
the unit boasts a high capacity data transmission rate for supporting
remote data networks and is provisioned with safety monitoring including
passive and active protection of the mains transmission line and provides
galvanically isolated operation.
the watertight ultra rugged enclosure is hermetically sealed to
withstand severe humidity, dust exposure and extreme temperatures. It is
corrosion resistant and shock/vibration protected.
Mobile command unit
230 VAC
HMT
1000
FO cable
FO connector
Hybrid connector
Typical HMT1000 configuration: Ad-hoc connection between a mobile command unit
('supply side') and a remote operation unit ('remote side').
Remote operation unit
230 VAC
Hybrid cable
HMT
1000
FO cable
PC
PC
PC
