1
INSTRUCTIONS FOR SAFETY AND USE ____________________________________32
2
3
INSTALLING THE APPLIANCE _____________________________________________ 35
4
ADAPTATION TO DIFFERENT TYPES OF GAS _______________________________ 39
5
FINAL OPERATIONS ____________________________________________________ 44
6
7
USING THE COOKING HOB _______________________________________________ 48
8
USING THE OVEN ______________________________________________________ 50
9
AVAILABLE ACCESSORIES _______________________________________________ 53
10
CLEANING AND MAINTENANCE ___________________________________________ 54
11
EXTRAORDINARY MAINTENANCE _________________________________________ 56
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified technician who must
carry out an adequate inspection of the gas system, install the appliance, set it functioning and carry
out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice, description of the commands and the
correct procedures for cleaning and maintenance of the appliance.
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
cerca il tuo prodotto tra le
migliori offerte di Cucine e Piani cottura
Contents
Smeg CB51GV1
o
31

Advertisement

Table of Contents
loading

Related Manuals for Smeg CB51GV1

Summary of Contents for Smeg CB51GV1

  • Page 1: Table Of Contents

    Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg CB51GV1 cerca il tuo prodotto tra le migliori offerte di Cucine e Piani cottura Contents INSTRUCTIONS FOR SAFETY AND USE ____________________________________32 RECYCLING INSTRUCTIONS - OUR ENVIRONMENT POLICY ___________________ 34...

  • Page 2: Instructions For Safety And Use

    Presentation 1 INSTRUCTIONS FOR SAFETY AND USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. THEREFORE IT MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKER. WE URGE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT CONTAINS CAREFULLY BEFORE USING THE COOKER.
  • Page 3 Presentation THE USE OF THIS APPLIANCE IS NOT PERMITTED TO PEOPLE (INCLUDING CHILDREN) OF REDUCED PHYSICAL AND MENTAL ABILITY, OR LACKING IN EXPERIENCE IN THE USE OF ELECTRICAL APPLIANCES, UNLESS THEY ARE SUPERVISED OR INSTRUCTED BY ADULTS OR PEOPLE RESPONSIBLE FOR THEIR SAFETY. IF THE APPLIANCE IS PLACED ON A PEDESTAL IT MUST BE INSTALLED SO THAT IT CANNOT SLIDE OFF.

  • Page 4: Recycling Instructions - Our Environment Policy

    The environment – Instructions for recycling 2 RECYCLING INSTRUCTIONS - OUR ENVIRONMENT POLICY Our household appliances are only packaged using non-pollutant, environment-friendly, recyclable materials. Please help by disposing of the packing correctly. You can obtain the addresses of collection, recycling and disposal centres from your retailer or from the competent local organisations.

  • Page 5: Installing The Appliance

    Instructions for the installer 3 INSTALLING THE APPLIANCE The appliance must be installed by a qualified technician and according to the regulations in force. Depending on the type of installation, it belongs to class 1 (Fig.A) or to class 2-subclass 1 (Fig.B-C). This appliance may be installed next to walls, one of which must be higher than the appliance, at a minimum distance of 50 mm from the side of the appliance, as shown in drawings A and B relative to the installation classes.
  • Page 6 Instructions for the installer 3.1 Electrical connection Make sure the voltage and the cross-section of the power supply line match the specifications indicated on the identification plate positioned in the storage compartment. Do not remove this plate for any reason. If the appliance is connected to the power supply network by means of a fixed connection, install a multipolar cut-out device on the power supply line, in compliance with installation regulations, located near the appliance and in an easily reachable position.
  • Page 7 Instructions for the installer 3.3 Extraction of the combustion products The combustion products must be extracted by means of hoods connected to a natural draught chimney whose efficiency is certain or via forced extraction. An efficient extraction system requires precision planning by a specialist qualified in this area and must comply with the positions and distances indicated by the regulations.
  • Page 8 Instructions for the installer 3.4.3 Connection to the gas cylinder in the internal compartment of the appliance (only on some models) Open the side compartment and insert a gas cylinder of max 15 kg. Push one end of the hose onto the hose connector and secure it with one of the two supplied clamps.

  • Page 9: Adaptation To Different Types Of Gas

    Instructions for the installer 4 ADAPTATION TO DIFFERENT TYPES OF GAS Before carrying out the following operations, disconnect the appliance from the power supply. The appliance is preset for natural gas G20 (2H) at a pressure of 20 mbar. In case of operation with other types of gas the burner nozzles must be changed and the minimum flame adjusted on the gas taps.
  • Page 10 Instructions for the installer 4.2 Burner and nozzle characteristics table (60 cm model) Rated heating Burner LIQUID GAS – G30/G31 30/37 mbar capacity (kW) Nozzle By-pass Reduced Capacity Capacity diameter capacity g/h G30 g/h G31 1/100 mm 1/100 Auxiliary Semi-rapid Reduced Rapid Triple crown 1500...
  • Page 11 Instructions for the installer Burner and nozzle characteristics table (80 cm model) Rated heating Burner LIQUID GAS – G30/G31 30/37 mbar capacity (kW) Nozzle By-pass Reduced Capacity Capacity diameter capacity g/h G30 g/h G31 1/100 mm 1/100 Auxiliary Semi-rapid Reduced Rapid Triple crown 1500 Oven...
  • Page 12 Instructions for the installer Rated Burner heating NATURAL GAS – G20 20 mbar capacity (kW) Nozzle diameter Reduced capacity 1/100 mm Auxiliary Semi-rapid Rapid (5) Triple crown 1500 Oven Maxi oven 1300 4.5 Arrangement of the burners on the hob (60 cm model) BURNERS 1.
  • Page 13 Instructions for the installer 4.8 Oven burner adjustment (only for models with a gas oven) To adjust the oven burner you need to open the oven door and carry out the following operations: • Remove the oven basin and its rack. •...

  • Page 14: Final Operations

    Instructions for the installer 5 FINAL OPERATIONS After replacing the nozzles, reposition the flame-spreader crowns, the burner caps and the pan stands. Following adjustment to a gas other than the preset one, replace the gas adjustment label fixed to the appliance with the one corresponding to the new gas. The label is inserted inside the pack together with the nozzles.
  • Page 15 Instructions for the installer 5.4 Assembling the skirt (on certain models only) • Loosen the nuts B. • Position the skirt above the top, taking care to align the pins C with the holes D. • Secure the skirt to the top by tightening screws A. 5.5 Positioning and levelling the appliance (depending on model) After making the electrical and gas connections, level the appliance on the floor by means of its four adjustable feet.

  • Page 16: Description Of The Controls On The Front Panel

    Instructions for the user 6 DESCRIPTION OF THE CONTROLS ON THE FRONT PANEL All the cooker controls are grouped together on the front panel. The symbols used are described in the table below. FRONT RIGHT-HAND BURNER CENTRAL BURNER REAR RIGHT-HAND BURNER ELECTRIC OVEN THERMOSTAT (OR PIZZA OVEN IF INCLUDED) REAR LEFT-HAND BURNER...
  • Page 17 Instructions for the user HOB BURNER CONTROL KNOB To light the flame, press the knob and turn it anticlockwise to the minimum flame symbol . To adjust the flame, turn the knob to the zone between the maximum ( ) and minimum ( ) settings. To turn off the burner, turn the knob to the position.

  • Page 18: Using The Cooking Hob

    Instructions for the user 7 USING THE COOKING HOB 7.1 Lighting the hob burners Before lighting the hob burners, check that the flame-spreader crowns are correctly in place with their respective burner caps, making sure that the holes A in the flame-spreaders are aligned with the plugs and thermocouples.
  • Page 19 Instructions for the user 7.3 Pan diameters (60 cm model) BURNERS min. and max. (60 X 60) Ø (in cm.) 12 – 14 1. Auxiliary 16 – 24 2. Semi-rapid 18 – 26 3. Triple crown 18 – 26 4. Reduced Rapid 7.4 Pan diameters (80 cm model) BURNERS...

  • Page 20: Using The Oven

    Instructions for the user 8 USING THE OVEN 8.1 Warnings and general advice When using the oven and the various heating elements for the first time, they should be heated to the maximum temperature (275°C) for long enough to burn off any oily residues left by the manufacturing process, which might contaminate foods with unpleasant smells.
  • Page 21 Instructions for the user 8.4 Using the electric grill To use this function you must first extinguish the oven burner by moving the relevant knob to the position and then turning the selector to the position. WARNING: IT IS NOT POSSIBLE TO OPERATE THE GAS OVEN AND THE GRILL AT THE SAME TIME.
  • Page 22 Instructions for the user 8.6 Gas cylinder compartment (on certain models only) The gas cylinder compartment, accessed by opening the side door, can also be used as a storage space. The 3 racks in the figure are not supplied with the appliance but can be purchased on request from Authorised Service Centres.

  • Page 23: Available Accessories

    Instructions for the user 9 AVAILABLE ACCESSORIES The main oven has 4 runners for positioning trays and racks at different heights and a roof lining. The auxiliary oven has 2 runners. Oven rack: for cooking food inside dishes, small cakes, roasts or foods that require slight grilling.

  • Page 24: Cleaning And Maintenance

    Instructions for the user 10 CLEANING AND MAINTENANCE 10.1 Cleaning of stainless steel and enamelled versions To keep stainless steel in good condition, it must be cleaned regularly when you are done using the cooker, after it has cooled. Do not use a steam jet for cleaning the appliance. 10.1.1 Ordinary daily cleaning To clean and preserve the stainless steel surfaces, always use only specific products that do not contain abrasives or chlorine-based acids.
  • Page 25 Instructions for the user 10.2.3 Burner caps and flame spreader crowns For easier cleaning, the flame spreader crowns can be removed; wash them with warm water and a non-abrasive detergent making sure to remove any encrustation and wait until they are perfectly dry. WARNING: never wash these parts in a dishwasher.

  • Page 26: Extraordinary Maintenance

    Instructions for the user 11 EXTRAORDINARY MAINTENANCE The oven may require extraordinary maintenance or replacement of parts subject to wear such as gaskets, bulbs, etc. The following instructions describe how to carry out these minor maintenance operations. Before any intervention that requires access to live parts, disconnect the appliance from the power supply.
  • Page 27 Instructions for the user 11.5 Removing the door (90 cm model) To remove the door proceed as follows: 1 Open the door completely and insert two pins into the holes on the hinges indicated in the figure. 2 Grasp the door on both sides with both hands, lift it forming an angle of around 30° and remove it. 3 To reassemble the door, put the hinges in the relevant slots in the oven, making sure that grooved sections A are resting completely in the slots.
