PAC CH1AJKIT Manual page 9

CH1AJKIT
Section 4: Radio Unit Installation
Step 4
Connect the 2-pin connector
coming from the CAN T-Harness
to the DATA CON connector
on the SRK-CH1A-HAR main
harness.
Step 7
The top support bracket on the
radio assembly needs to go over
the top of the factory radio support
bracket with the factory nut
centered in the bracket cut-out.
®
Pacific Accessory Corporation
Connect any additional
components (camera, amps,
SXM) and tuck excess cables,
wires and connectors to the
sides, not directly behind the
Once in position, install two
screws to hold the radio
assembly in place. We
recommend testing the radio
functions before completely
reassembling the vehicle.
© 2022 AAMP Global. All rights reserved. PAC is a Power Brand of AAMP Global.
AAMP Global is not affiliated with FCA US LLC. Jeep® is a registered trademark of FCA US LLC. The terms
OEM, Jeep®, Wrangler®, and Gladiator® all terms are used strictly for identification purposes only. It is not
implied that any part listed is a product of, or approved by, Fiat Chrysler Automobiles.
Step 5
radio.
Step 8
Vehicle Integration Upgrade Kit for
SR-JK11H / Stinger HEIGH10
2011-2018 Jeep Wrangler JK
®
Step 6
With the two display cables and the
CH1A-SRK harness and module
routed over the top of the radio
module, slide the assembly into
place. Take caution that no wiring
gets pinched between metal brackets.
Step 9
Connect the two display cables to
the back of the display.
Rev: V1
Date:102622
®
