PAC CH1AJKIT Manual page 7

CH1AJKIT
Section 2: Radio Module and Harness Preparation (cont.)
Step 6
Connect the pink SPEED SEN lead
on the Main Harness to the pink
SPEED SEN lead on the 10-pin
Radio Harness.
Step 9
Apply supplied two-sided tape to
the back of the CH1A interface and
the PL1 as shown.
®
Pacific Accessory Corporation
On the SRK-CH1A-HAR Main
harness, plug the 16PIN Radio
harness and the 6PIN Steering
Wheel Control harness into the
Stick the PL1 to the top of the radio
module as shown. NOTE: The
CH1A module will be positioned
once the radio assembly is
© 2022 AAMP Global. All rights reserved. PAC is a Power Brand of AAMP Global.
AAMP Global is not affiliated with FCA US LLC. Jeep® is a registered trademark of FCA US LLC. The terms
OEM, Jeep®, Wrangler®, and Gladiator® all terms are used strictly for identification purposes only. It is not
implied that any part listed is a product of, or approved by, Fiat Chrysler Automobiles.
Step 7
HEIGH10 radio module.
Step 10
installed in the vehicle.
Vehicle Integration Upgrade Kit for
SR-JK11H / Stinger HEIGH10
2011-2018 Jeep Wrangler JK
®
Step 8
Plug in the 10-pin radio harness.
Plug in the gray LVDS and black
8-pin display cable connectors
into the radio module.
Rev: V1
Date:102622
®
Page 7
