MiLAN MIL-C2412 Installation Manual

R eg ul ato r y Ap p ro v a ls
• FCC Class A
• UL 1950
• CSA C22.2 No. 950
• EN60950
• CE
EN55022
– Class B
– EN50082-1
Can adi an EM I N o t ice
This Class A digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur
du Canada.
E uro pe an No t ic e
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage
Directive (73/23/EEC) issued by the commission of the European Community. Compliance with these
directives implies conformity to the following European Norms:
• EN55022 (CISPR 22) - Radio Frequency Interference
• EN50082-1 (IEC801-2, IEC801-3, IEC801-4) - Electromagnetic Immunity
• EN60950 (IEC950) - Product Safety
Five-Year Limited Warranty
Digi International warrants to the original consumer or purchaser that each of its products, and
all components thereof, will be free from defects in material and/or workmanship for a period of
five years from the original factory shipment date. Any warranty hereunder is extended to the
original consumer or purchaser and is not assignable.
Digi makes no express or implied warranties including, but not limited to, any implied warranty
of merchantability or fitness for a particular purpose, except as expressly set forth in this
warranty. In no event shall Digi be liable for incidental or consequential damages, costs, or
expenses arising out of or in connection with the performance of the product delivered
hereunder. Digi will in no case cover damages arising out of the product being used in a
negligent fashion or manner.
Tr ade m a r k s
Digi International™ and the Digi Logo are trademarks of Digi International. All other products and brands
are the trademarks of their respective holders. All rights reserved.
To C o nt a c t D ig i
For prompt response when calling for service information, have the following information ready:
• Product serial number and rev.
• Date of purchase
• Vendor or place of purchase
You can reach Digi LAN technical support at 408/744-2751
Or E-mail at: sun-tech@dgii.com
Address: 1299 Orleans Drive
Sunnyvale, CA 94089
Voice: 408/744-2775
Fax: 408/744-2793
E-mail: info@dgii.com
® Copyright 1998 Digi International Printed in the USA P/N: 90000205 Rev. A1
MIL-C2412
Fast Ethernet Media Converter for Digi's
Media Conversion System
Thumbscrews
TP
ACT
MDI-X MDI
TP
100BASE-TX LINK
MIL-
C2412

Installation Guide

This guide includes the following:
• "Introduction" on page 2
• "Installation" on page 3
• "MDI/MDI-X" on page 3
• "Link Sentry Feature" on page 5
• "Indicators" on page 6
Installation Guide: MIL-C2412
FX
100BASE-FX
ACT
FX
TX RX
LINK
