Page 1: Qbix-Wp Waterproof Industrial Embedded System
QBiX-WP-APLA3940H-A1 (QW-3940A-SI) QBiX-WP Waterproof Industrial Embedded System Quick Start Guide www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
RJ45 Cable, waterproof (25CR0-1K8401-O0S) SIGNAL Cable, waterproof (25CR5-1K8500-O0R) HDMI Cable, waterproof (25CRC-180720-O0S) DC JACK Cable, waterproof (25CRD-1K8300-O0S) Wall mount (25HBA-826520-H5R) Exsiccator (10g) If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Skilled person have to pay special attention or take special protection. Only authorized by well trained professional person can access the restrict access location. (2) External metal parts are hot!! Before touching it, special attention or protection is necessary www.gigaipc.com... -
Page 9: Table Of Contents
COM 1 Connector for RS-232/422/485 & RI/5V/12V ... 19 COM 2/3 Connector for RS-232 ........19 DIO Connector .............. 19 DC-IN Connector ............20 LAN 1/2 Connectors ............ 20 USB 1/2 Connectors for USB 2.0 ........20 HDMI 1.4 Connector ............ 21 2.10 Support ................ 22 www.gigaipc.com... - Page 10 3.2.13 SATAPW (SATA power connector) ....... .41 3.2.14 SATAIII (SATA 6Gb/s Connector) ........42 3.2.15 FUSB20_1, FUSB2_2 (USB 2.0 header) ......43 3.2.16 GPIO_CNT (General Purpose input/output header) ... 44 3.2.17 SYS_PANEL (Front panel header) ........45 3.2.18 CLS_CMOS (Clean CMOS jumper) ......... 46 www.gigaipc.com...
-
Page 11: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 12 www.gigaipc.com...
-
Page 13: Specifications
1 x (M12) GPIO (8 bits) 1 x (M12) DC Jack — Power +9V~36VDC (Full Range) Operating temperature: -20°C to 80°C Operating humidity: 0-90% (non-condensing) Operation Non-operating temperature: -20°C to 70°C temperature Non-operating humidity: 0%-95% (non-condensing) Use wide temperature range memory and storage www.gigaipc.com... - Page 14 HDMI Cable, waterproof, x 1 (P/N: 25CRC-180720-O0S) DC JACK Cable, waterproof, x 1 (P/N: 25CRD-1K8300-O0S) Wall mount bracket (P/N: 25HBA-826520-H5R) System: 9BQW3940AMR-SI (Box packing) Order Information (Built in Components: Please contact with your sales representative for more information or e-mailed to : sales@gigaipc.com) www.gigaipc.com...
-
Page 15: Chapter 2 - Qbix-Wp-Apla3940H-A1 (Qw-3940A-Si)
Chapter 2 Chapter 2 – QBiX-WP-APLA3940H-A1 (QW-3940A-SI) Waterproof Industrial Embedded System Kit www.gigaipc.com... -
Page 16: Dimension
Dimension www.gigaipc.com... -
Page 17: Getting Familiar With Your Unit
2 x (IP67) USB 2.0 Connector 1 x (M8) HDD LED 1 x (M8) Power LED [Rear Side] 1 x (M12) COM1 (RS-232/422/485 & RI/5V/12V) 2 x (M12) COM2, COM3 (RS-232) 1 x (M12) DC IN 1 x (M12) GPIO (8 bits) www.gigaipc.com... - Page 18 [Left Side] [Right Side] [Bottom Side] www.gigaipc.com...
-
Page 19: Com 1 Connector For Rs-232/422/485 & Ri/5V/12V
Pin No. Pin Define Pin Asignments Shield — — Front View DIO Connector Pin No. Pin Define Pin No. Pin Define GPO1 GPO4 GPI1 GPI4 GPO2 SMB_CLK GPO2 SMB_DATA Pin Asignments GPO3 5V/ 1A Front View GPI3 — — www.gigaipc.com... -
Page 20: Dc-In Connector
LAN 1/2 Connectors Pin No. Pin Define Pin No. Pin Define TX + No Singal TX - No Singal No Singal No Singal Pin Asignments Front View USB 1/2 Connectors for USB 2.0 Conn.1 & Conn.2 Pin Asignments Front View www.gigaipc.com... -
Page 21: Hdmi 1.4 Connector
HDMI 1.4 Connector Pin No. Pin Define Pin No. Pin Define Clock+ D2 / Shield Clock / Shield Clock- D1 / Shield Utitity Pin Asignments Front View D0 / Shield 5V+ Power Hot Plug Datect — — www.gigaipc.com... -
Page 22: Support
Support ● For a list of tested memory, M.2, 2.5’’ SSD, wireless adapters and OS supported, go to: http://www.gigaipc.com ● To download the latest drivers and BIOS updates, go to: http://www. gigaipc.com ● For product support, go to: http://www.gigaipc.com www.gigaipc.com... -
Page 23: Safety And Regulatory Information
At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal. www.gigaipc.com... - Page 24 www.gigaipc.com...
-
Page 25: Chapter 3 - Hardware Information
Chapter 3 Chapter 3 – Hardware Information www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 26: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. - Page 27 General Purpose input/output header 17 SYS_PANEL Front panel header 18 FUSB2_2 USB 2.0 header 19 MPCIE Mini-PCIe slot 20 M2M M.2 slot 21 SIM_CARD1 3G/4G Sim Slot www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
- Page 28 2 x USB3.0 Ports 25 FUSB30 26 HDMI 1 x HDMI Port 27 VGA 1 x VGA Port 28 CLS_CMOS 1 x Clear CMOS jumper www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
-
Page 29: Fan (Fan Connector)
3.2.1 FAN (FAN connector) Pin1 CPU/System FAN Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH 1 2 3 4 Pin No. Definition Detect Speed Control www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 30: Dc In (Dc In 1 X 4-Pin Power Connector)
3.2.2 DC IN (DC IN 1 x 4-pin power connector) Pin1 DC in Connector Connector PN Vendor 753-81-04TW00 PINREX Pin No. Definition DCIN DCIN www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 31: Com1, Com2, Com3, Com4 (Serial Port Header)
COM2, COM3, COM4 : Support RS-232 only TXD+ TXD- RXD- – RXD+ – – – – – – – – – No Connect – – RI/5V/12V – – www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 32: Spk_Out (Speaker Out Connector)
Speaker out connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out R+ Speaker Out R- Speaker Out L- Speaker Out L+ www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 33: Jcom11 (Ri# Pin Ri#/5V/12V Select Jumper For Com1 Port)
JCOM11 Jumper Select Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: PH06N53BAZ000 HORNGTONG 5V (Power COM) 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 34: Jrs11-Jrs14 (Rs11-14 Select Jumper For Serial Port)
1T/1R RS-422 Pure RS-232 3T/5R RS-232 (Default) RS-485 Half Duplex 1T/1R RS-485, TX ENABLE Low Active RS-485 Half Duplex 1T/1R RS-485, TX ENABLE High Active www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 35: At_Cn (At/Atx Power Mode Select Jumper)
1-2 Close : AT mode. 220-96-03GB01 PINREX 2-3 Close : ATX mode. PH03N2-7BAN000 HORNGTONG (Default setting) Pin No. Definition AT MODE Detect ATX MODE www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 36: Lsw (Lvds Resolution Jumper)
1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 37: Lvds (Lvds Connector)
Note: *The LVDS output connector of the unit is only intended to be connected to an UL/IEC/EN approval CLK2+ CLK1+ equipment with fire enclosure. CLK2- CLK1- www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 38: Bkl_Cn (Backlight Brightness Control Connector)
3.2.10 BKL_CN (Backlight brightness control connector) Pin1 Backlight brightness control connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition Back Light Enable www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 39: 3.2.11 Buzzer
3.2.11 BUZZER Pin1 Buzzer Connector PN Vendor 712-71-02TW01 PINREX A1250WV-02P JOINT-TECH Pin No. Definition -SPKR +VS5 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 40: 3.2.12 Battery
3.2.12 BATTERY Pin1 Battery Cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition 3.3V RTC www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 41: Satapw (Sata Power Connector)
3.2.13 SATAPW (SATA power connector) Pin1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition +12V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 42: Sataiii (Sata 6Gb/S Connector)
3.2.14 SATAIII (SATA 6Gb/s Connector) Pin1 SATA 6GB/S Connector SATAIII Connector PN Vendor WAT3M-07A1G3BU4W WINWIN ABA-SAT-054-S15 LOTES Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 43: Fusb20_1, Fusb2_2 (Usb 2.0 Header)
3.2.15 FUSB20_1, FUSB2_2 (USB 2.0 header) 15 18 Pin1 Pin1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 44: Gpio_Cnt (General Purpose Input/Output Header)
GPIO Connector Connector PN Vendor 725-81-12TW00 PINREX A2004WV-2X06P46 JOINT-TECH Pin No. Definition GPIO-output_1 GPIO-input_1 GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock SMBus DATA www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 45: Sys_Panel (Front Panel Header)
Vendor 210-92-05G111 PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 46: Cls_Cmos (Clean Cmos Jumper)
Pin No. Definition Open: Normal Operation (Default setting) Close: Clear COMS data. Connector PN Vendor 210-91-02GB01 PINREX Pin No. Definition PH02R23BAZ000 HORNGTONG Clear CMOS www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
