INSTALLATION AND OPERATION MANUAL
3,500 / 5,000 POUND CAPACITY
QUICKJACK
MODELS:
BL-3500
VER B
BL-5000
VER B
BL-5000XL
VER B
RECEIVING
The shipment should be thoroughly inspected as soon as it
is received. The signed Bill of Lading is acknowledgement
by the shipping carrier as receipt of this product as listed
in your invoice as being in a good condition of shipment. If
any of these goods listed on this Bill of Lading are missing
or damaged, do not accept goods until the shipping carrier
makes a notation on the freight bill of the missing or dam-
aged goods. Do this for your own protection.
QUICKJACK
PATENTED. ALL RIGHTS RESERVED
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO
INSTALLATION
INSTALLATION AND OPERATION YOU AGREE THAT YOU FULLY
UNDERSTAND AND
MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO
OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.
By Ranger Products
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
AND
OPERATION.
COMPREHEND THE FULL CONTENTS OF THIS
BE SAFE
Your new jack was designed and built with safety in mind.
However, your overall safety can be increased with proper
training and thoughtful operation on the part of the operator.
DO NOT operate or repair this equipment without reading
this manual and the important safety instructions shown
inside. Keep this operation manual near the jack at all
times. Make sure that ALL USERS read and understand
this manual.
™
1
BY
PROCEEDING
MAN REV D 07-22-2015
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Toll Free 1-888-262-3880
Tel: 1-805-421-5114
www.quickjack.com
WITH
JACK
P/N 5900395
