Table of Contents

Advertisement

Quick Links

Disclaimer
The following online version of the Owner's Man-
ual describes all models as well as all the stand-
ard and optional equipment of your vehicle. Coun-
try-specific differences in the language variants
are possible. Note that your vehicle may not be
fitted with all features described. This is also the
case for safety-relevant systems and functions.
Please contact your authorised Mercedes-Benz
dealer if you would like to have a printed Owner's
Manual for other vehicle models and vehicle
model years. The online version is the current
valid Owner's Manual version. Possible variations
to your vehicle may not be taken into account as
Mercedes-Benz constantly updates their vehicles
and equipment to the state of the art and introdu-
ces changes in design and equipment.
Please also read the printed Owner's Manual, any
supplementary documents and the digital Own-
er's Manual in the vehicle.
Copyright
All Rights Reserved. All texts, images, graphics,
are subject to Copyright and other laws for the
protection of intellectual property. They may not
be copied for commercial purposes or for trans-
mission, nor changed and used on other websites.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLC 200 4MATIC and is the answer not in the manual?

Questions and answers

David newman
June 10, 2025

How to turn sound on radio

0
Михаил
May 7, 2025

Настройка часов

0

Related Manuals for Mercedes-Benz GLC 200 4MATIC

Summary of Contents for Mercedes-Benz GLC 200 4MATIC

  • Page 1 Note that your vehicle may not be fitted with all features described. This is also the case for safety-relevant systems and functions. Please contact your authorised Mercedes-Benz dealer if you would like to have a printed Owner’s Manual for other vehicle models and vehicle model years.
  • Page 2 Owner's manual Mercedes-Benz...
  • Page 3 Front passenger airbag warning & WARNING Risk of injury or death due to an enabled co-driver airbag If the co-driver airbag is enabled, a child on the co-driver seat may be struck by the co- driver airbag during an accident. NEVER use a rearward-facing child restraint system on a seat with an ENA- BLED FRONT AIRBAG.
  • Page 4 Mercedes-Benz is constantly developing its vehi- Thank you for buying Mercedes-Benz cles further. Before you first drive off, read this operator's Mercedes-Benz therefore reserves the right to manual carefully and familiarise yourself with your introduce changes in the following areas: vehicle.

  • Page 5: Table Of Contents

    Protection of the environment ....... 19 Seat belts ............. 45 Memory function ......... 119 Take-back of end-of-life vehicles ....19 Airbags ............49 Stowage areas ..........120 Mercedes-Benz GenuineParts ......20 ® PRE-SAFE system ........57 Cup holders ..........134 Owner's Manual ..........21 Automatic measures after an accident ...
  • Page 6 Automatic transmission ....... 202 Mercedes me app ........360 Notes on snow chains ......... 421 Function of 4MATIC ........206 Mercedes-Benz emergency call system ..370 Activating or deactivating snow chain Refuelling ............ 206 Radio & media ..........377 mode ............422 Charging the high-voltage battery (plug-in Sound settings ..........
  • Page 7 Contents Technical data ..........437 Notes on technical data ......437 On-board electronics ........437 Regulatory radio identification and notes ..439 Vehicle identification plate, VIN and engine number overview ......439 Operating fluids ........... 441 Vehicle data ..........450 Trailer hitch ..........

  • Page 8: Symbols

    Symbols In this Owner's Manual, you will find the following Observe notes on material damage. symbols: These symbols indicate useful instructions or & WARNING Danger due to not observing further information that could be helpful to the warning notices you. Warning notices draw your attention to haz- Instruction ards that may endanger your health or life, or...

  • Page 9: At A Glance

    At a glance – Cockpit Left-hand-drive vehicles...
  • Page 10 At a glance – Cockpit → → Steering wheel gearshift paddles Ü Switching the MBUX multimedia system on/off → Combination switch → a Switching sound on/off → Driver's display → ø Adjusting the volume → DIRECT SELECT lever → £ Hazard warning light system →...

  • Page 11: Cockpit (Plug-In Hybrid)

    At a glance – Cockpit (plug-in hybrid) Left-hand-drive vehicles...
  • Page 12 At a glance – Cockpit (plug-in hybrid) → ± Increases recuperation Central display: Plug-in hybrid settings Driver's display: → õ Operational readiness Energy flow display Sets charging times Power meter → ÷ DYNAMIC SELECT button Trip computer → → ° Haptic accelerator pedal ECO Assist →...

  • Page 13: Indicator And Warning Lamps

    At a glance – Indicator and warning lamps Driver's display...
  • Page 14 → ! ABS → L Low beam → h Tyre pressure monitoring system → T Standing lights → ; Engine diagnostics → R Rear fog light → ® å ESP → H Mercedes-Benz emergency call system → ® ÷ ESP...

  • Page 15: Overhead Control Panel

    At a glance – Overhead control panel...
  • Page 16 At a glance – Overhead control panel → Sun visors (folding, available in extendable Switches the right-hand reading lamp on/off design as an optional extra) → 3 Opens/closes the panorama sliding sun- → c Switches the front interior lighting on/off roof →...

  • Page 17: Door Operating Unit And Seat Adjustment

    At a glance – Door operating unit and seat adjustment...
  • Page 18 At a glance – Door operating unit and seat adjustment → → ß Ü Locks/unlocks the vehicle W Opens/closes the rear left side window → → W Opens/closes the left side window Opens the door → → Adjusts the seats electrically Adjusts the head restraints →...

  • Page 19: Emergencies And Breakdowns

    At a glance – Emergencies and breakdowns...
  • Page 20 At a glance – Emergencies and breakdowns → B-pillar with: Fire extinguisher → QR code for accessing the rescue card Fuel filler flap with: → → Safety vests information label on fuel type → → ; me button information label on tyre pressure →...

  • Page 21: Digital Owner's Manual

    Digital Owner's Manual You can search for keywords using the search Some sections in the Digital Owner's Manual, Calling up the Digital Owner's Manual field Search, in order to find quick answers to suchas warning notes, can be expanded and col- Multimedia system: lapsed.

  • Page 22: General Notes

    EU countries only: Change gear in good time and use each Operating conditions: Mercedes-Benz will take back your end-of-life gear only up to Ô of its maximum vehicle for environment-friendly disposal in Make sure that the tyre pressure is cor- engine speed.

  • Page 23: Mercedes-Benz Genuineparts

    (e.g. the brake system) may malfunction. Airbags and seat belt tensioners, as well as Only use Mercedes-Benz GenuineParts or parts of Mercedes-Benz GenuineParts control units and sensors for the restraint sys- equal quality. Only use tyres, wheels and acces-...

  • Page 24: Owner's Manual

    General notes This is the case in the following situations: The models and the standard and special Touch-sensitive controls equipment, which will only be available at a The vehicle type is different from that for In addition to conventional switches and buttons, later date.

  • Page 25: Mercedes Me App

    The on-demand feature has been activated. after purchasing your vehicle. For some features, a notification also appears & WARNING Risk of accident or injury due Information is available at any Mercedes-Benz in the vehicle's multimedia system. to improper modifications to electronic Service Centre.
  • Page 26 General notes You must not tamper with wiring, elec- If damage should occur, immediately If the underbody panelling is damaged, flam- tronic components, or their software. inform a qualified specialist workshop. mable materials such as leaves, grass or twigs can collect between the underbody and the Always have work on electrical and elec- underbody panelling.
  • Page 27 General notes & DANGER Risk of death and fire due to Never touch damaged components of the high-voltage on-board electrical sys- modified and/or damaged components of tem. the high-voltage on-board electrical sys- After an accident, do not touch any com- ponents of the high-voltage on-board The vehicle's high-voltage on-board electrical electrical system.

  • Page 28: Notes On Assembling The Number Plate On The Front Licence Plate Holder

    General notes Vehicles with hybrid systems generate signifi- Never perform modifications to compo- Notes on assembling the number plate on the cantly less noise when stationary and when being nent parts of high-voltage components. front licence plate holder driven than vehicles with combustion engines. Never touch damaged component parts When driving in electric mode, the vehicle may * NOTE Malfunctions and system failures...

  • Page 29: Declarations Of Conformity And Notes On Driving In Different Countries

    You can obtain further information from a vehicle is in compliance with the relevant statu- The manufacturers of the wireless components Mercedes-Benz service centre. tory requirements. The full texts of the declara- ensure that all wireless components installed in...
  • Page 30 For Nigeria only: The manufacturers of the wireless components installed in the vehicle hereby declare that all wireless components installed in the vehicle com- ply with the technical regulations for two-way radios. You can obtain further information from a Mercedes-Benz service centre.
  • Page 31 Besides the typical frequencies for mobile com- ply with the technical regulations for two-way munication cars by Mercedes-Benz make use of radios. You can obtain further information from a the following automotive radio applications.
  • Page 32 General notes Technology Frequency range Transmission output/magnetic field strength Block Heater Remote Control, Garage Door 868 MHz (868.0–868.6 MHz) ≤ 25 mW ERP Opener Block Heater Remote Control, Garage Door 869 MHz (868.7–869.2 MHz) ≤ 25 mW ERP Opener Bluetooth, Kleer, RLAN, wireless Headphones 2.4 GHz ISM band (2400–2483.5 MHz) ≤...
  • Page 33 General notes Technology Frequency range Transmission output/magnetic field strength Rear Seat Entertainment System ® ® Bluetooth Bluetooth 2400–2483.5 MHz -0.8 dBm WLAN 2.4 GHZ: WLAN 2.4 GHZ: 2400–2483.5 MHz 14.5 dBm WLAN 5 GHz: WLAN 5 GHz: 5150–5250 MHz 20.5 dBm 5725–5875 MHz 13.3 dBm Two-way radio (Tel7 telephone control unit)
  • Page 34 General notes Technology Frequency range Transmission output/magnetic field strength GSM (E-GSM 900, Class 4) < +33 dBm (±2 dB) GSM (E-GSM 1800, Class 1) < +30 dBm (±2 dB) GSM (E-GSM 900 8-PSK, Class E2) < +27 dBm (±3 dB) GSM (E-GSM 1800 8-PSK, Class E2) <...
  • Page 35 General notes Information about the specific absorption rate https://moba.i.daimler.com/baix/cars/SAR/ For France only: fr_FR/index.html The values have been determined and tested in accordance with the Décret n° 2019-1186 guide- line regarding the indication of the specific absorption rate (SAR) of wireless vehicle compo- nents.
  • Page 36 Milton Keynes, MK15 8BA PJSC “AUTOCAPITAL” mun. Chisinau, str. Hîncesti sos., 2/2 England Velyka Vasylkivska str. 15/2 For Turkey only: Importer of Mercedes-Benz spare parts 01004 Kyiv Importer Mercedes-Benz Parts Logistics Ukraine Mercedes Benz Otomotiv Ticaret ve Hizmetler Delaware Drive, Tongwell...
  • Page 37 General notes Milton Keynes, MK15 8BA Type, Number: Technical documentation of the product is stored at the premise of the manufacturer. The person England A) A 164 580 02 18, A 166 580 01 18 responsible for assembling the technical docu- B) A 240 580 00 18 mentation of the product: Head of the Technical Jack...

  • Page 38: Diagnostics Connection

    Manufacturer: Dunlop Tech GmbH you only use and connect products tion Address: Offenbacher Landstrasse 8, 63456 approved by a Mercedes-Benz service Hanau centre. Using devices at the diagnostics connection drains the battery. Authorised representative: IMS dept.

  • Page 39: Qualified Specialist Workshop

    Vehicle registration Qualified specialist workshop Mercedes-Benz may ask its service centres to A qualified specialist workshop has the necessary carry out technical inspections on certain vehi- special skills, tools and qualifications to correctly cles. The quality or safety of the vehicle is carry out any necessary work on your vehicle.

  • Page 40: Correct Use Of The Vehicle

    1907/2006, Article 33) stipulates a duty to sup- vehicle that, regardless of the operating status of can do this at a Mercedes-Benz service centre, ply information about substances of very high the vehicle, can generate magnetic fields on a par for example.

  • Page 41: Implied Warranty

    This damage is not covered either by the Electronic control units are fitted in your vehicle. vehicle components carrying live voltage Mercedes-Benz implied warranty or by the Control units process data which, forexample, New‑ or Used-Vehicle Warranty. This includes the charging cable and the they receive from vehicle sensors, generate them- charging control box, for example.
  • Page 42 General notes Personal data Governmental entities are themselves, in individ- state, component loads, maintenance require- Every vehicle is identified by a unique vehicle ual cases and within the applicable legal frame- ments and technical events or faults. identification number. Depending on the country, work, authorised to read out data from the vehi- Depending on the vehicle equipment, the follow- this vehicle identification number can be used by,...
  • Page 43 General notes and manufacturers or third parties, suchas break- Convenience and infotainment functions These data for convenience and infotainment down services. The same is true in the case of You can store convenience settings and individual functions may be saved locally in the vehicle or warranty claims and quality assurance measures.
  • Page 44 General notes This integration allows the use of selected smart- Manufacturer's services use. As a general rule, the manufacturer has no phone apps, suchas navigation or music player Regarding the manufacturer's online services, the influence on the content exchanged. apps. There is no further interaction between the individual functions are described by the manu- For this reason, when services are provided by smartphone and the vehicle;...

  • Page 45: Copyright

    General notes Copyright Information on licences for free and open-source software used in your vehicle can be found on the data carrier in your vehicle document wallet and with updates on the following website: https://www.mercedes-benz.com/opensource...

  • Page 46: Occupant Safety

    A seat belt can only provide the best level of pro- not possible to completely rule out the risk of tection if it is worn correctly. Depending on the Mercedes-Benz recommends that you use driving injury caused by the airbag deploying. detected accident situation, seat belt tensioners...
  • Page 47 Occupant safety Restraint system functionality Function of the restraint system in an accident Have the restraint system checked and repaired immediately at a qualified spe- When the vehicle is switched on, a self-test is per- How the restraint system works depends on the cialist workshop.

  • Page 48: Seat Belts

    & WARNING Risk of injury or death due to Mercedes-Benz recommends that you have the Knee airbag: frontal impact incorrectly fastened seat belt vehicle towed to a qualified specialist workshop Side airbag: side impact after an accident.
  • Page 49 Occupant safety Pregnant women must also take particular Limitations of the protection provided by the seat Always ensure that all vehicle occupants care with this. belt have their seat belts fastened correctly and are sitting properly. Never route the seat belt across sharp, poin- &...
  • Page 50 Persons under 1.50 m tall cannot wear the seat belt correctly without a suitable addi- Never modify the seat belt system, for Mercedes-Benz recommends that you have the tional restraint system. example the seat belt, seat belt buckle, vehicle towed to a qualified specialist workshop seat belt tensioner, seat belt anchorage Always secure persons under 1.50 m tall...
  • Page 51 Occupant safety A seat belt can only provide the best level of Seat belt adjustment function protection if it is worn correctly. Observe the ® Vehicles with PRE-SAFE : after a front seat belt notes on fastening the seat belt ( page 45).

  • Page 52: Airbags

    Occupant safety Seat belt warning function for the driver and front When the vehicle is switched on, the rear seat Airbags passenger belt status display informs you for a certain Overview of airbags amount of time which rear seat belt is not fas- The ü...
  • Page 53 Occupant safety Side airbag: ribcage, also pelvis for front seat Information on automatic front passenger airbag occupants shutoff Only when the PASSENGER AIR BAG OFF indica- Centre airbag: head and ribcage tor lamp is off can the front passenger airbag Window airbag: head deploy in the event of an accident.
  • Page 54 Occupant safety Only hold the steering wheel by the steering Only one person should use each seat Each vehicle occupant must make sure of the wheel rim. This allows the airbag to be fully belt at any one time. following: deployed.
  • Page 55 You should only use seat covers that have been approved for the correspond- The airbag may then deploy in an uncontrolled ing seats by Mercedes-Benz. manner and may even cause additional inju- ries to the vehicle occupants by deploying.
  • Page 56 Occupant safety Status of the front passenger front airbag restraint systems on the front passenger seat & WARNING Risk of injury due to malfunc- page 75). tioning sensors in the door ▌Function of the automatic front passenger air- A person on the front passenger seat must bag shutoff The function of the airbags can be impaired observe the following information:...
  • Page 57 Occupant safety Always observe the notes on the function of the the cockpit on the front passenger side A person in the front passenger seat could PASSENGER AIR BAG indicator lamps page 74). then, for example, come into contact with the page 54).
  • Page 58 Occupant safety bag. The PASSENGER AIR BAG OFF indicator lamp indicator lamp may be off. In this case, do not fit & WARNING Risk of injury or death when may be lit continuously or be off. the rearward-facing child restraint system to the using a rearward-facing child restraint sys- front passenger seat.
  • Page 59 Occupant safety A person on the front passenger seat must always smaller stature should not use the front Always move the front passenger seat as observe the following information: passenger seat. far back as possible and fully retract the seat cushion length adjustment. While If the front passenger seat is occupied by an &...

  • Page 60: Pre-Safe

    Occupant safety Be sure to also observe the following further rela- Vehicles with memory function: moving the If the seat belt pre-tensioning is not reduced, ted subjects: front passenger seat to a more favourable seat move the seat backrest back slightly. position.

  • Page 61: Automatic Measures After An Accident

    Occupant safety System limits impact is anticipated. This increases the distance vehicles with hybrid drive: switching off the between the door and the vehicle occupant. hybrid system and high-voltage on-board elec- The system will not initiate any action in the fol- trical system lowing situations: ®...

  • Page 62: Safely Transporting Children In The Vehicle

    For this reason, specific situation. In this way you can recog- cations and guidelines. Further information can Mercedes-Benz strongly advises that you fit a nise potential risks and avoid dangers if chil- be obtained at a qualified specialist workshop.
  • Page 63 Occupant safety Detecting risks, avoiding danger tem. In this case, the child sits in the opposite Never place objects (e.g. cushions) direction to the direction of travel and faces back- under or behind the child restraint sys- Securing systems for child restraint systems in wards.
  • Page 64 75). Observe the specific Have the securing systems for the child instructions for the rearward-facing and restraint systems checked at a qualified Mercedes‑Benz recommends Mercedes-Benz forward-facing child restraint systems specialist workshop before installing a care products for cleaning child restraint systems page 75).
  • Page 65 Mercedes-Benz rec- changing the transmission position. ommends that you use a Mercedes-Benz Never leave children unattended in the starting the vehicle. Service Centre for this purpose.
  • Page 66 Occupant safety Securing with ISOFIX Securing with the vehicle seat belt Weight category II/III (15 to 36 kg and from approximately 3 to 12 years) Weight category 0+ (up to 13 kg and up to Weight category 0 (up to 10 kg and approximately KIDFIX XP approx.
  • Page 67 Occupant safety ¯ Also secure Top Tether if present Approval categories for child restraint systems Approval categories in accordance with UN-R44 page 69). Only use approved child restraint systems Alternative securing system: Only child restraint systems that meet the follow- 7 Vehicle seat belt ( page 71) ing UNECE standards are permitted for use in the...
  • Page 68 Occupant safety The identification IUF refers to ISOFIX child Approval categories in accordance with UN-R129 The identification i‑U refers to i‑Size child restraint systems in the "Universal" category. restraint systems in the "Universal" category. These child restraint systems must also be These child restraint systems must also be secured using Top Tether or support points.
  • Page 69 Occupant safety Fitting an ISOFIX or i-Size child restraint system Weight group 0 (up to 10 kg and up to approx. 6 Size class – Left/right rear seat on the left and right rear seats months) Equipment Size class – Left/right rear seat ▌Overview of suitability of the seats for attaching C –...
  • Page 70 Occupant safety ▌Overview of suitability of the seats for attaching ▌Fitting the ISOFIX or i‑Size child restraint sys- Size class – Left/right rear seat i‑Size child restraint systems tem on the left and right rear seats Equipment i‑Size is a standardised securing system for spe- &...
  • Page 71 Occupant safety If the centre seat backrest is not engaged and on a label on the child restraint system, if ® When fitting an ISOFIX child restraint sys- locked in place, the red lock verification indicator present tem, also observe the following: will be visible.
  • Page 72 Occupant safety O The child restraint system must not be put * NOTE Damage to the seat belt for the under strain between the roof and the seat centre seat during installation of the child cushion and/or be fitted facing in the wrong restraint system direction.
  • Page 73 Occupant safety If necessary, slide head restraint upwards Observe the lock verification indicator. page 111). If the rear seat backrest is not engaged and Fit the ISOFIX or i‑Size child restraint system locked in place, the red lock verification indicator with Top Tether.
  • Page 74 Occupant safety Securing the child restraint system with the seat U, L 1 Child restraint systems with a supporting bracket are not suitable Centre rear seat belt for this seat. Weight category III: 22 to 36 kg ▌Notes on the suitability of seats for attaching U Suitable for child restraint systems of the "Universal"...
  • Page 75 Occupant safety ney, that the status of the front passenger air- Weight category III: 22 to 36 kg 1 Adjust the seat cushion inclination so that the front edge of the bag is correct for the current situation seat cushion is in the highest position and the rear edge of the seat page 54).
  • Page 76 Occupant safety ▌Securing the child restraint system with the When fitting a belt-secured child restraint system, O The backrest of the forward-facing child observe the following: restraint system must, as far as possible, be seat belt on the rear seat O Always comply with the manufacturer's resting on the seat backrest of the rear seat.
  • Page 77 Occupant safety Install the child restraint system. ▌Notes on vehicles without automatic front Make sure you observe the following information: The entire base of the child restraint system passenger airbag shutoff Never fit a rearward-facing child restraint sys- must always rest on the seat surface of the tem to the front passenger seat rear seat.
  • Page 78 Occupant safety ▌Notes on rearward-facing and forward-facing Observe the specific instructions for the rear- passenger airbag must always be disabled. ward-facing and forward-facing child restraint sys- This is only the case if the PASSENGER AIR child restraint systems on the front passenger tems ( page 75).
  • Page 79 Occupant safety Observe the notes under "Suitability of seats cushion and/or be fitted facing the wrong Set the front passenger seat as far back as for attaching belt-secured child restraint sys- direction. possible and move the seat into the highest tems"...
  • Page 80 Occupant safety Child safety locks When leaving the vehicle, always take the Always activate the installed child safety key with you and lock the vehicle. locks if children are travelling in the vehi- ▌Activating or deactivating the child safety lock cle.

  • Page 81: Notes On Pets In The Vehicle

    Occupant safety ▌Activating and deactivating the child safety lock indicator lamp is off: via the switch on for the rear side windows the corresponding rear door or driver's door Notes on pets in the vehicle & WARNING Risk of accident and injury due to animals left unsecured or unattended in the vehicle If you leave animals in the vehicle unattended...
  • Page 82 Occupant safety Never leave animals unattended in the vehicle. Always correctly secure animals while driving, e.g. using a suitable animal car- rier.

  • Page 83: Opening And Closing

    Opening and closing Unlocks (with embossed surface) When leaving the vehicle, always take the key with you and lock the vehicle. Opens/closes the tailgate Overview of key functions Keep the vehicle key out of the reach of If indicator lamp does not light up after &...
  • Page 84 Opening and closing Activating/deactivating the acoustic locking verifi- Unlocking the driver's door and fuel filler flap er's door, only the driver's door and the fuel cation signal filler flap/socket flap are unlocked. Plug-in hybrid: unlocking the driver's door and fuel filler flap/socket flap Multimedia system: Deactivating the function of the key ©...
  • Page 85 Opening and closing When the vehicle is started with the key in the Inserting the emergency key enter the body, severe internal burns can stowage compartment of the centre console, occur within two hours. the function of the key is automatically activa- There is a risk of fatal injury.
  • Page 86 Mercedes-Benz recommends that you have the cover opens. When doing so, do not hold battery replaced at a qualified specialist work-...

  • Page 87: Doors

    Opening and closing Problems with the key, troubleshooting shielding due to metal objects or induction & WARNING Risk of injury to persons inside loops for electrical gate systems or automatic the vehicle when the additional door lock You can no longer lock or unlock the vehicle barriers is activated Possible causes:...
  • Page 88 Opening and closing You can prevent the additional door lock from Centrally locking and unlocking the vehicle from Plug-in hybrid: the socket flap is also locked and being activated by deactivating interior protection the inside unlocked. The socket flap can be opened even if a before locking the vehicle ( page 104).
  • Page 89 Opening and closing Problems with KEYLESS-GO, troubleshooting Deactivate the function of the key in these situations. You can no longer lock or unlock the vehicle using KEYLESS-GO Make sure that the key is at a minimum Possible causes: distance of 3 m away from the vehicle. The function of the key has been deactivated.
  • Page 90 Opening and closing mobile phones If the vehicle is being tested on a roller dyna- mometer. electronic devices (notebooks, tablets) shielding due to metal objects or induction Locking/unlocking the vehicle with the emer- loops for electrical gate systems or automatic gency key barriers Make sure that there is sufficient distance...

  • Page 91: Running Boards

    Opening and closing Locking the doors To lock the right-hand side of the vehicle: turn the emergency key clockwise as far as it will If the locked door is then closed, it can no longer be opened from the outside. Running boards Notes Your vehicle is equipped with running boards.

  • Page 92: Load Compartment

    Opening and closing If the tailgate is unlocked, pull the tailgate han- Press and hold the H button on the key. Load compartment dle and release it again immediately. If the tailgate has stopped in an intermediate Opening the tailgate position, pull it upwards.
  • Page 93 Opening and closing To close the tailgate: pull the tailgate down- Before the journey, secure objects, lug- wards slightly. Release it as soon as it begins gage or loads against slipping or tipping to close. over. & WARNING Risk of becoming trapped dur- Observe the notes on loading the vehicle.
  • Page 94 Opening and closing Vehicles with HANDS-FREE ACCESS Make sure that no body parts are in the Make a kicking movement with your foot closing area. below the bumper ( page 91). If someone is trapped, either: Press the H button on the key. Automatic reversing function for the tailgate The tailgate is equipped with automatic blockage Press or pull the remote operating switch...
  • Page 95 Opening and closing Two warning tones sound when the tailgate is or 6 m (automatic car wash) away from opening or closing. the vehicle. & WARNING Risk of burns caused by a hot When making the kicking movement, make sure exhaust system that you are standing firmly on the ground.
  • Page 96 Opening and closing The tailgate can open or close unintentionally in Limiting the opening angle of the tailgate the following situations: Activating the opening angle limiter A person's arms or legs are moving in the sen- You can limit the opening angle of the tailgate in sor detection range, e.g.

  • Page 97: Side Windows

    Opening and closing Unlocking the tailgate with the emergency key Insert emergency key into opening & WARNING Risk of becoming trapped when the trim and push it in the direction of the closing a side window Requirements: arrow. The rear seat backrest has been folded When closing a side window, body parts could The tailgate will be unlocked.
  • Page 98 Opening and closing Requirements: To start automatic operation: press the W & WARNING Risk of becoming trapped The power supply or the vehicle has been button beyond the point of resistance or pull despite there being reversing protection switched on. and release it.
  • Page 99 Opening and closing Rain is detected by a rain sensor on the wind- Convenience opening (ventilating the vehicle The seat ventilation of the driver's seat is screen. before starting a journey) switched on. in extreme temperatures If the roller sunblind of the panoramic sliding &...
  • Page 100 Opening and closing Resolving problems with the side windows If a side window is obstructed during closing and process and make sure that no body reopens again immediately: parts are in the closing area. & WARNING Risk of becoming trapped or Immediately after this, pull and hold the corre- fatally injured if reversing protection is not Requirements:...

  • Page 101: Sliding Sunroof

    Opening and closing Replace the key battery, if necessary Touch the control panel during automatic During the opening or closing process, page 82). operation. make sure that no body parts are in the The opening/closing process will be roller sunblind's range of movement. stopped.
  • Page 102 Opening and closing To raise or lower: press control panel Do not allow anything to protrude from briefly. the sliding sunroof. To start automatic operation: swipe forwards or backwards across control panel 1. * NOTE Damage to panorama sliding sun- roof caused by roof luggage rack To cancel automatic operation: press control panel...
  • Page 103 100 Opening and closing Rain is detected by a rain sensor on the wind- during resetting. & WARNING Risk of becoming trapped screen. despite reversing function During the closing process, make sure in extreme temperatures In particular, the reversing function does not that no body parts are in the closing after a certain time (depending on the on- react to soft, light and thin objects, e.g.
  • Page 104 Opening and closing 101 Repeat the previous step. & WARNING Risk of becoming trapped by Make sure that no parts of the body are The sliding sunroof will be closed again with in the closing area. automatic lowering of the sliding sunroof increased force.

  • Page 105: Roller Sunblinds

    102 Opening and closing The immobiliser is automatically activated when Roller sunblinds the vehicle is switched off, and deactivated when Extending the rear side window roller sunblinds the vehicle is switched on. * NOTE Damage to the inertia reel due to it ATA (Anti-Theft Alarm system) snapping back ▌Function of the ATA system...
  • Page 106 Opening and closing 103 after pressing the start/stop button with the Tow-away protection is only primed when the fol- key in the stowage compartment lowing components are closed: page 180) Doors ▌Deactivating the ATA Tailgate Press the Ü, s or H button on the Tow-away protection is automatically deactivated: key.
  • Page 107 104 Opening and closing Tow-away protection is primed again in the follow- after pressing the start/stop button with the ing cases: key in the stowage compartment page 180) The vehicle is unlocked again. after unlocking the vehicle using KEYLESS-GO A door is opened. when using HANDS-FREE ACCESS The vehicle is locked again.

  • Page 108: Seats And Stowing 105

    Seats and stowing 105 Your legs are not fully extended and you can Notes on the correct driver's seat position depress the pedals properly & WARNING Risk of accident due to adjust- The back of your head is supported at eye ing the vehicle settings while the vehicle is level by the centre of the head restraint in motion...

  • Page 109: Seats

    106 Seats and stowing Use the grab handles only to stabilise & WARNING Risk of becoming trapped dur- & WARNING Risk of accident due to adjust- the seating position or to assist in get- ing seat adjustment ing the vehicle settings while the vehicle is ting in and out of the seat.
  • Page 110 Seats and stowing 107 Adjust the head restraint fore-and-aft position so Children in particular could accidentally press & WARNING Risk of injury or death due to that it is as close as possible to the back of your the electrical seat adjustment buttons and objects under the co-driver seat head.
  • Page 111 108 Seats and stowing Make sure that the seat is engaged. * NOTE Damage to the seats when adjust- Adjusting the front seat electrically The seats may be damaged by objects when adjusting the seats. The switches for adjusting the seats do not move. You will therefore receive no direct feedback on When adjusting the seats, make sure the switch while pressing the switch.
  • Page 112 Seats and stowing 109 The head restraint height will be adjusted Lower automatically when you adjust the seat height Firmer or the seat fore-and-aft position. Use buttons to adjust the contour of the backrest. Adjusting the 4-way lumbar support Head restraints ▌Adjusting the head restraints on the front seats &...
  • Page 113 110 Seats and stowing Seats with manual and electric seat adjustment Seats with electric seat adjustment steering wheel and mirror, and fasten your seat belt. & WARNING Risk of injury due to incorrectly adjusted head restraints If head restraints have not been adjusted cor- rectly, there is an increased risk of injury in the head and neck area, e.g.
  • Page 114 Seats and stowing 111 ▌Adjusting the head restraints of the rear seats To raise: push release knob in the direc- ▌Fitting/removing the rear seat head restraints manually tion of the arrow and pull the head restraint up Removing until it engages. Move all head restraints up at least to the first To lower: press release knob in the direc-...
  • Page 115 112 Seats and stowing Push both release knobs at the Setting the seat heating balance If there is a risk of someone becoming trap- same time in the direction of the arrow and Select Heating settings. ped, stop the adjustment process immedi- pull out the head restraint.
  • Page 116 Seats and stowing 113 Select Start positioning. Classic Massage: Relaxing back massage Start the programme for the desired The driver's seat and steering wheel position seat ;. Mobilizing Massage Mobilising massage with is adjusted to the body size that has been set. To set the massage intensity: switch High upward-moving massage waves.
  • Page 117 114 Seats and stowing Requirements: The seat heating will automatically switch In particular, the health of persons with limited The power supply is switched on. down from the three heating levels after 8, 10 temperature sensitivity or a limited ability to and 20 minutes until the seat heating react to high temperatures may be affected or switches off.

  • Page 118: Steering Wheel

    Seats and stowing 115 ventilation setting for the driver's seat will & WARNING Risk of entrapment for children remain active. when adjusting the steering wheel Children could injure themselves if they adjust Steering wheel the steering wheel. Adjusting the steering wheel manually Never leave children unattended in the vehicle.
  • Page 119 116 Seats and stowing Unlocking Check and make sure that the steering col- & WARNING Risk of entrapment for children umn is locked by moving the steering wheel. when adjusting the steering wheel Children could injure themselves if they adjust Adjusting the steering wheel electrically the steering wheel.

  • Page 120: Easy Entry And Exit Feature

    Seats and stowing 117 Linking the steering wheel heater to the seat heat- Easy entry and exit feature Using the easy entry and exit feature Requirements: & WARNING Risk of accident when pulling The power supply or the vehicle has been away during the adjustment process of switched on.
  • Page 121 118 Seats and stowing The driver's seat will then move backwards Move the adjustment lever of the steer- Never leave children unattended in the only if it is not already at the rear of the seat ing wheel. vehicle. adjustment range. The adjustment process will be stopped.

  • Page 122: Memory Function

    Seats and stowing 119 Setting the easy entry and exit feature Memory function parts are in the area of movement of the seat or the steering wheel. Function of the memory function Requirements: If someone becomes trapped, press a The automatic seat adjustment has been acti- &...

  • Page 123: Stowage Areas

    120 Seats and stowing You can save the following settings for the front Operating the memory function Press one of the preset position buttons 4, seat: T or U within three seconds. Storing An acoustic signal sounds. The settings are Seat, backrest, head restraint position and stored.
  • Page 124 Seats and stowing 121 Always switch off the engine before & WARNING Risk of injury due to objects & WARNING Risk of accident from objects in opening the tailgate. being stowed incorrectly the driver's footwell and front-passenger footwell Never drive with the tailgate open. If objects in the vehicle interior are stowed incorrectly, they can slide or be thrown around Objects in the driver's footwell and front-...
  • Page 125 122 Seats and stowing the function of the automatic front passenger air- Always be particularly careful around the * NOTE Damage to the cup holder bag shut-off ( page 53). tailpipe and the tailpipe trims and super- When the rear armrest is folded back the cup vise children especially closely in this &...
  • Page 126 Seats and stowing 123 secure the load using the tie-down eyes and Stowage spaces in the vehicle interior distribute the load evenly. ▌Overview of the front stowage compartments Notes on driving with a roof load Distribute the roof load and the load inside the vehicle evenly, placing heavy objects at the bottom.
  • Page 127 124 Seats and stowing When adjusting a seat, make sure that After the load compartment enlargement no one has any body parts in the sweep has been folded forwards of the seat. Make sure that the red marking of the lock verifi- &...
  • Page 128 Seats and stowing 125 Ensure that the centre seat backrest is in an Folding the rear outer seat backrests forward upright position and engaged with the left seat electrically backrest ( page 128). Depending on the vehicle equipment, you can fold the outer seat backrests forward electri- cally.
  • Page 129 126 Seats and stowing In the rear: pull release lever 1. Press the seat belt tongue of seat belt into To fold the left seat backrest forward: briefly pull on left button 1. marked position 2. The left seat backrest can be folded forwards electrically only together with the centre seat backrest.
  • Page 130 Seats and stowing 127 To fold the right seat backrest forward: briefly Press release catch 3. pull on right button 1. Fold seat backrest forwards. The right seat backrest will fold forwards. ▌Folding back the rear seat backrest Folding the centre rear seat backrest forwards separately * NOTE Damage caused by trapping the If you no longer require the folded-down seat...
  • Page 131 128 Seats and stowing ▌Locking the release catch of the centre rear Observe the changes in the requirements for adjusting the head restraints when using the seat backrest cargo position ( page 111). Requirements: The left and centre seat backrests are engaged and joined together.
  • Page 132 Seats and stowing 129 Load compartment cover Do not place any objects above the lower edge of the side windows or on the ▌Extending/retracting the load compartment load compartment cover. cover The load compartment cover is attached behind & WARNING Risk of injury or death due to the seat backrest of the rear bench seat.
  • Page 133 130 Seats and stowing ▌Installing and removing the load compartment Installing the load compartment cover To remove: press the end cap of the load com- partment cover inward and remove it from cover Press in the end cap of load compartment mounting 2.
  • Page 134 Seats and stowing 131 Damaged partitioning nets can no longer fulfil Pull on the loose ends of the lashing straps their functions and must be replaced. Visit a quali- until the partitioning net is tight. fied specialist workshop. After driving a short distance, check the ten- sion of the partitioning net and re-tension it if necessary.
  • Page 135 132 Seats and stowing Objects or items of luggage may be flung around and hit vehicle occupants. Only hang light objects on the bag hooks. Never hang hard, sharp-edged or fragile objects on the bag hooks. Observe the notes on loading the vehicle page 120).
  • Page 136 You will find information on the maximum roof open it when using a roof luggage rack not load in the "Technical data" section. tested and approved for Mercedes-Benz. * NOTE Damage to the covers * NOTE Damage to the vehicle due to not...

  • Page 137: Cup Holders

    134 Seats and stowing Secure the roof luggage rack to the fastening Only use the cup holder when the vehicle Always make sure that objects do not points beneath covers 1. is stationary. protrude from stowage spaces, luggage nets or stowage nets. Comply with the installation instructions of the Only use the cup holder for containers of roof luggage rack manufacturer.
  • Page 138 Seats and stowing 135 To fit Push the side wall of rear beverage compart- Insert mats in the cup holder beverage com- ment to the left until the cup holder relea- partments can be removed for cleaning. Insert two lugs into the recesses in the ses and swing the cup holder out upwards.
  • Page 139 136 Seats and stowing Using the cup holder Gently push a beverage container into the bot- of the beverage compartment. Check whether the beverage container is held The side panel will automatically extend to the firmly by the cup holder. Some beverage con- left to secure the beverage container.

  • Page 140: Sockets

    Seats and stowing 137 USB ports Sockets Depending on its equipment, the vehicle has the Using the 12 V socket following USB ports: Requirements: In the stowage compartment in the front Only connect devices up to a maximum of centre console 180 W (15 A).

  • Page 141: Wireless Charging Of The Mobile Phone And Connection With The Exterior Aerial

    138 Seats and stowing Wireless charging of the mobile phone and con- Always stow and secure heavy, hard, Do not place credit cards, storage nection with the exterior aerial pointed, sharp-edged, fragile or bulky media, ski passes or other objects sensi- objects in the boot/load compartment.
  • Page 142 Small mobile phones may not be able to be A list of compatible mobile phones can be Radio equipment approval numbers for Brazil charged in every position of the mobile phone found at: https://www.mercedes-benz- This device operates on a secondary basis, that is stowage compartment. mobile.com/...

  • Page 143: 140 Light And Sight

    140 Light and sight Information about lighting systems and your Light switch Exterior lighting responsibility ▌Operating the light switch Notes on adjusting the lights when driving abroad The various lighting systems of the vehicle are If the automatic setting is selected in the only aids.
  • Page 144 Light and sight 141 If the battery is insufficiently charged, the stand- ▌Automatic driving lights function L Low beam/high beam ing lights or parking lights will be switched off When the vehicle is switched on, the standing R Switches the rear fog light on/off automatically to facilitate the next engine start.
  • Page 145 142 Light and sight Please observe the country-specific laws on the Use the combination switch to select the Turn signal light use of rear fog lamps. desired function. To indicate briefly: push the combination switch briefly to the point of resistance in the Switching on high beam direction of arrow or 4.
  • Page 146 Light and sight 143 Activating/deactivating the hazard warning lights When you pull away again, the hazard warning The system is active only when it is dark. light system will switch off automatically at ▌Active headlamps function approximately 10 km/h. You can also switch off the hazard warning light system using the warning lamp button.
  • Page 147 144 Light and sight ▌Cornering light function Roundabout and junction function: the cornering The function is not active in the following cases: light will be activated on both sides based on an at speeds below 80 km/h evaluation of the vehicle's current navigation posi- ▌Enhanced fog light function tion.
  • Page 148 Light and sight 145 The function is automatically deactivated under at an early stage. The active headlamps will be The assistance functions of the DIGITAL the following conditions: deactivated during this time so that steering LIGHT are available on-demand ( page 22).
  • Page 149 146 Light and sight The spotlight function runs in the background and If Traffic Sign Assist detects a corresponding sit- Notes flashes the headlamps at detected persons within uation, a triangle will be projected onto the road the lane markings in four short bursts. The driver in the following situations at speeds of at least is also made aware of the position of the person 30 km/h:...
  • Page 150 Light and sight 147 If you fall below the safe distance at speeds of at Lane keeping and blind spot warning least 30 km/h, a collision warning symbol will be projected onto the road. Observe the system limitations of Active Brake Assist ( page 265).
  • Page 151 148 Light and sight ▌Switching the Intelligent Light System on/off opened or switched off. You can choose In these, or in similar situations, the automatic between the Digital Rain Star Wave high beam will not be deactivated or will be Requirements: sequences.
  • Page 152 Light and sight 149 The high beam will switch off automatically in the Adaptive Highbeam Assist Plus following cases: ▌Adaptive Highbeam Assist Plus function At speeds below 25 km/h & WARNING Risk of accident despite Adap- If other road users are detected tive Highbeam Assist Plus If street lighting is sufficient Adaptive Highbeam Assist Plus does not react...
  • Page 153 150 Light and sight Adaptive Highbeam Assist Plus cannot take into ULTRA RANGE Highbeam increases the bright- account road, weather or traffic conditions. ness of the cone of light to the legally permitted maximum. Detection may be restricted in the following cases: Partial high beam does not include other road users in the high beam area.
  • Page 154 Light and sight 151 At speeds above 50 km/h: driver's display. When partial high beam or Setting the exterior lighting switch-off delay time high beam is active, the corresponding blue If no other road users are detected, the road is Multimedia system: indicator lamp will also light up.

  • Page 155: Interior Lighting

    152 Light and sight Operating unit inside the grab handle (rear) Adjusting the brightness Interior lighting Select Brightness. Adjusting the interior lighting Adjust the brightness. Depending on the ambient light conditions, the ambient lighting will automatically switch between day and night modes. Activating the brightness for zones Select Brightness.

  • Page 156: Windscreen Wipers And Windscreen Washer System

    Light and sight 153 Observe the notes on driving systems and Switching the interior lighting switch-off delay Windscreen wipers and windscreen washer sys- your responsibility; you may otherwise fail to time on/off recognise dangers ( page 237). Multimedia system: Switching the windscreen wipers on/off Select Effects.
  • Page 157 154 Light and sight Switching the rear window wiper on/off Switching intermittent wiping on/off: press ° Continuous wiping, slow button 2. ¯ Continuous wiping, fast The è symbol will appear on the driver's Turn the combination switch to the corre- display when the rear window wiper is sponding position 1 - 5.
  • Page 158 Light and sight 155 Within around 15 seconds, press and hold the Hold the wiper arm with one hand. With the Push the new wiper blade into the wiper arm î button on the combination switch for other hand, turn the wiper blade away from in the direction of arrow until release knob approximately three seconds (...
  • Page 159 156 Light and sight Replacing the rear window wiper blade & WARNING Risk of becoming trapped if the windscreen wipers are switched on while wiper blades are being replaced If the windscreen wipers begin to move while you are changing the wiper blades, you can be trapped by the wiper arm.

  • Page 160: Mirrors

    Light and sight 157 Fitting the wiper blade Fold the wiper arm from the replacement posi- & WARNING Risk of accident due to mis- tion back onto the rear window. judgement of distance when using the outside mirror Mirrors The outside mirrors reflect objects on a smaller scale.
  • Page 161 158 Light and sight Adjusting the outside mirrors If the battery has been disconnected or has Automatic anti-dazzle mirrors function discharged, the outside mirrors must be moved briefly using button 3. Only then will & WARNING Risk of acid burns and poison- the automatic mirror folding function work ing due to the anti-dazzle mirror electro- properly.
  • Page 162 Light and sight 159 the front-passenger mirror is selected. Storing the parking position of the front- Immediately change out of clothing passenger outside mirror using reverse gear which has been contaminated with reverse gear is engaged. electrolyte. Storing The front-passenger outside mirror will move back If an allergic reaction occurs, seek to its original position when: medical attention immediately.
  • Page 163 160 Light and sight Calling up Select the front-passenger outside mirror using button 2. Engage reverse gear. The front-passenger outside mirror will move into the stored parking position. Activating/deactivating the automatic mirror fold- ing function Multimedia system: © Settings Vehicle Opening/closing Activate or deactivate Automatic mirror fold-...

  • Page 164: Climate Control 161

    Depending on vehicle equipment and set- Use filters recommended and approved by tings: temperature display, demist function Mercedes-Benz. Always have maintenance work display, display for pre-entry climate control carried out at a qualified specialist workshop. or auxiliary heating ¿...
  • Page 165 162 Climate control Overview of the THERMOTRONIC climate bar Upper display area of the climate bar with the à Sets climate control to automatic mode, examples of j switching off climate con- right ( page 165) The indicator lamps indicate that the correspond- trol ( page 163), ¿...

  • Page 166: Operating The Climate Control System

    Climate control 163 Overview of the rear operating unit Switches climate control on/off Operating the climate control system page 164) Switching climate control on/off Sets the airflow in the rear passenger com- Switching on climate control partment, right, or switches climate control Set the airflow to level 1 or higher via J on on/off ( page 164)
  • Page 167 164 Climate control Switching climate control on/off via the rear oper- Press the ¿ button. right and it informs you of the current particu- ating unit late levels inside and outside of the vehicle. Switch off the A/C function only briefly; other- The measurement values are shown with the wise, the windows may mist up more quickly.
  • Page 168 Climate control 165 When the defrost function is activated, some Press AUTO on the climate bar on the central the climate control for the interior and the functions (e.g. the temperature setting) will footwells simultaneously. In doing so, the display. automatically be deactivated.
  • Page 169 166 Climate control Controlling the rear climate control automatically Demisting the windows Switching air-recirculation mode on/off Select AUTO. Press g on the climate bar on the central Windows misted up on the inside display. When the defrost function is activated, some Press Ã...
  • Page 170 Climate control 167 To switch on or off: select Residual heat Fragrance system A flacon is inserted. the climate bar of the central display. ▌Activating/deactivating the fragrance system Multimedia system: The residual heat function will automatically using the multimedia system Climate menu Air quality switch off after some time.
  • Page 171 168 Climate control If you do not use genuine Mercedes-Benz interior If symptoms continue, consult a doctor. perfumes, observe the manufacturers' safety noti- ces on the perfume packaging. ENVIRONMENTAL NOTE Environmental Dispose of the genuine Mercedes-Benz interior damage due to improper disposal of full...
  • Page 172 Climate control 169 Depending on the vehicle's equipment, the follow- ▌Setting pre-entry climate control when the vehi- To switch on: unlock the vehicle. ing functions will be activated as needed during The climate control functions are activated for cle is unlocked in the multimedia system pre-cooling: up to five minutes for pre-heating and pre- Multimedia system:...
  • Page 173 170 Climate control Pre-entry climate control for departure time (plug- The running time of pre-entry climate control may Do not repeatedly switch on the seat in hybrid) be reduced in the following circumstances: heating. The vehicle is not connected to power supply ▌Pre-entry climate control for departure time To protect against overheating, the seat heating equipment.
  • Page 174 Climate control 171 When the set temperature changes, climate con- Setting the repeat days before the selected departure time. It will trol mode will switch automatically as follows: remain active for another five minutes if depar- Select Edit departure time ´...
  • Page 175 172 Climate control Activating/deactivating immediate pre-entry cli- To protect against overheating, the seat heating Stationary heater/ventilation mate control may be temporarily deactivated after it has been ▌Stationary heater/ventilation function switched on repeatedly. The following function is equipment-depend- & WARNING Risk of fatal injury due to expo- Requirements: ent.
  • Page 176 Climate control 173 ▌Switching the stationary heater/ventilation Requirements: & WARNING Risk of fire due to hot station- The vehicle has a stationary heater. on/off via the operating unit ary heater components and exhaust gases The outside temperature is below 15°C. Flammable materials such as leaves, grass or &...
  • Page 177 174 Climate control in the separate Owner's Manual at https:// Air vents moba.i.daimler.com/markets/ece-row/baix/ ▌Adjusting the front air vents cars/connectmeen_GB/#emotions/ Startseite.html. & WARNING Risk of burns or frostbite due to ▌Setting the stationary heater/ventilation via the being too close to the air vents multimedia system Very hot or very cold air can flow from the air vents.
  • Page 178 Climate control 175 ▌Adjusting the rear air vents To open or close: turn controller to the left or right as far as it will go. To set the airflow direction: hold the centre of controller and move it up or down or to the left or right.

  • Page 179: 176 Driving And Parking

    176 Driving and parking the vehicle will start with the combustion Driving Stop the charging process immediately engine. in case of unusual odours, smoke or Notes on plug-in hybrids burn marks. Depending on the system, it may be that even ▌Notes on plug-in hybrid operation Leave the danger zone immediately.
  • Page 180 Driving and parking 177 Characteristics when the accelerator pedal is ter, the drive programmes are not available or ▌Manual disconnection of the high-voltage on- released during the journey: are restricted and the charge level of the high- board electrical system voltage battery may change.
  • Page 181 178 Driving and parking The vehicle is badly damaged, e.g. after an Secure the vehicle against rolling away. components have been modified or dam- accident, and the restraint system compo- aged. Open the bonnet. nents have not been triggered. Never touch damaged components of Press release tab in the direction of the the high-voltage on-board electrical sys-...
  • Page 182 Driving and parking 179 Switching on the power supply or the vehicle To switch on the power supply: press button Keep the vehicle key out of the reach of once. children. & WARNING Risk of accident and injury due You can, for example, switch on the wind- screen wiper.
  • Page 183 180 Driving and parking Starting the vehicle Requirements: ▌Starting the vehicle with the key in the marked The key is in the vehicle and is recognised. space (emergency operation mode) ▌Starting the vehicle with the start/stop button If the vehicle does not start and the Place the Shift the transmission to position j or i.
  • Page 184 Driving and parking 181 When you remove key from marked space Starting the vehicle via Remote Online Services It is safe to start and run the engine where 2, the vehicle can be driven. For further your vehicle is parked. ▌Cooling or heating the vehicle interior before engine starts, however, key must be loca-...
  • Page 185 182 Driving and parking Start the vehicle using the smartphone. Running-in notes Please also observe the following running-in After every engine start, the engine runs for notes: To preserve the engine during the first 1,500 km: ten minutes. In certain driving and driving safety systems, Drive at varying road speeds and engine the sensors adjust automatically while a cer- You can carry out a maximum of two consecutive...
  • Page 186 Driving and parking 183 Be sure to observe the safety notes and informa- After no more than five seconds, take your left * NOTE Increased wear due to optimised ® foot quickly off the brake, but keep the accel- tion on ESP page 240).
  • Page 187 184 Driving and parking This jeopardises the operating and road safety & WARNING Risk of accident if the vehicle is & WARNING Risk of skidding and of an acci- of the vehicle. switched off while driving dent due to shifting down on slippery road surfaces Stow all objects in the vehicle securely If you switch off the vehicle while driving,...
  • Page 188 Driving and parking 185 Open a window on the side of the vehicle Only depress the accelerator pedal * NOTE Causing wear to the brake linings by facing away from the wind to ensure an slightly. permanently depressing the brake pedal adequate supply of fresh air.
  • Page 189 186 Driving and parking bottom. Also comply with the notes on loading Observe the following notes during heavy precipi- Observe the signposted headroom clear- the vehicle ( page 120). tation or in conditions in which aquaplaning may ance. occur: Drive attentively, and avoid abrupt starts, brak- If the vehicle height is greater than the Reduce speed ing and steering as well as rapid cornering.
  • Page 190 Driving and parking 187 Vehicles travelling in front, or oncoming vehi- more direct steering resulting in improved When driving off-road or on unpaved sur- cles, can create waves which may exceed the handling of the vehicle faces, check the underside of the vehicle maximum permissible depth of the water.
  • Page 191 188 Driving and parking Off-road driving * NOTE Damage caused by driving over ENVIRONMENTAL NOTE Environmental Read this section before driving your vehicle off- obstacles damage due to non-observance of prohibi- road. Practise by driving over gentler off-road ter- tion signs The vehicle can be damaged by: rain first.
  • Page 192 Driving and parking 189 Do not use the HOLD function on steep down- Drive no faster than 10 km/h. Shift to a lower gear on uphill gradients and on hill or uphill gradients with slippery or loose long, steep downhill gradients. Observe the maximum permissible depth for surfaces.
  • Page 193 190 Driving and parking headlamps and tail lamps You depress the brake pedal when travelling at You release the brake pedal. a low speed. tyres, wheels and wheel arches You release the brake pedal on a downhill gra- dient and the vehicle does not roll. underbody If the system has detected one of the following situations, the engine will not stop:...
  • Page 194 Driving and parking 191 If the engine was switched off by the ECO start/ ▌Switching the ECO start/stop function on/off ECO display function stop function and you leave the vehicle, a warning tone will sound and the engine will not be restar- ted.
  • Page 195 192 Driving and parking The ECO display assesses the following criteria for fuel and recuperate. If the system detects an If a route event that can be dealt with more effi- an economical driving style: event ahead and the vehicle nears the event, ECO ciently by adjusting your driving style is detected Assist will calculate the optimum speed for maxi- ahead, corresponding symbol...
  • Page 196 Driving and parking 193 The following route events can be detected by The system may be impaired or may not function charge the high-voltage battery while driving. As ECO Assist: in the following situations: soon as you take your foot off the accelerator pedal when the vehicle is in motion and in trans- Roundabout If there is poor visibility, e.g.
  • Page 197 194 Driving and parking If you brake hard, the mechanical brake is hà is only available if the ECO Assist also used. This means that the maximum function is activated in the multimedia system recuperative energy cannot be recovered. The and if the function of the radar sensors is not more you drive and brake in an anticipatory impaired.
  • Page 198 Driving and parking 195 ECO Assist analyses data for the vehicle's expec- ted route. This allows the system to optimally adjust the driving style for the route ahead, save fuel and recuperate. If the system detects an event ahead and the vehicle nears the event, ECO Assist will calculate the optimum speed for maxi- mum fuel economy and recuperative energy based on the distance, speed and downhill gradi-...
  • Page 199 196 Driving and parking System limits If the traffic signs are hard to detect, e.g. due The "route based" option ( page 200) is If the calculated route is adhered to when route to dirt, snow or insufficient lighting, or selected for drive program n in the guidance is active, ECO Assist will operate with because they are obscured.

  • Page 200: Dynamic Select Button

    Driving and parking 197 Function of the haptic accelerator pedal (plug-in The drive program selected appears on the driv- The selection of the appropriate drive type by hybrid) er's display. the hybrid system depends on the driving con- ditions and the distance Individual The haptic accelerator pedal has an additional Vehicles with AIRMATIC:...
  • Page 201 198 Driving and parking Î Electric (plug-in hybrid) Hold battery (plug-in hybrid) from 120 km/h: lowers the vehicle to low level -2 Electric mode – driving without the combus- Prioritises maintaining the state of charge of below 80 km/h: raises the vehicle to low tion engine is possible up to approximately the high-voltage battery, e.g.
  • Page 202 Driving and parking 199 Plug-in hybrid: Steering Selecting the drive program Driving in hybrid or electric mode, depend- ing on a sufficient charge status of the Notes on the roof load display high-voltage battery and the setting in the ® Certain drive programs and ESP settings are multimedia system (...
  • Page 203 200 Driving and parking In the F drive program, some driving sys- Select Route-based or Standard. Function on: the next time the vehicle is started a If route guidance is active and the Route- prompt appears asking whether the last active tems are restricted in their function or not drive program should be restored.
  • Page 204 Driving and parking 201 Displaying vehicle data Outside temperature the country-specific guidelines for permissible tolerances (basis: UN-ECE No. 85 or country- Operating temperature of the engine Multimedia system: specific guidelines). © Info Adjust your driving style accordingly. Influencing variables that can influence this The p warning lamp in the instrument Select Vehicle.

  • Page 205: Automatic Transmission

    202 Driving and parking Calling up the fuel consumption indicator Use the DIRECT SELECT lever to switch the trans- & WARNING Risk of accident and injury due mission position. The current transmission posi- to leaving children unattended in the vehi- Multimedia system: tion will be shown on the driver's display.
  • Page 206 Driving and parking 203 ▌Engaging reverse gear R Risk of vehicle rolling away N activated man- Observe the notes on parking the vehicle ually No automatic switch to P message appears page 231). Depress the brake pedal and push the DIRECT SELECT lever upwards past the first point of in the driver's display.
  • Page 207 204 Driving and parking When the vehicle is rolling, you switch if off in The position of the accelerator pedal You have two options for manually shifting the transmission position h or k and bring it to automatic transmission: The driving speed a standstill.
  • Page 208 Driving and parking 205 To shift up: pull steering wheel gearshift pad- With an anticipatory driving style, Glide mode dle 2. helps you to reduce fuel consumption. Glide mode is characterised by the following: To shift down: pull steering wheel gearshift paddle 1.

  • Page 209: Function Of 4Matic

    206 Driving and parking Glide mode will be deactivated again if one of the maintaining a safe distance from the vehicle in & WARNING Risk of injury from fuels conditions is no longer met. front, for vehicle speed, for braking in good time Fuels are poisonous and hazardous to your and for staying in lane.
  • Page 210 Driving and parking 207 Change immediately out of clothing that Never refuel using petrol. Petrol with more than 10% ethanol by vol- has come into contact with fuel. ume, e.g. E15, E20, E85, E100 Never mix petrol with diesel fuel. Petrol with more than 3% methanol by vol- &...
  • Page 211 208 Driving and parking fuel with a sulphur content less than Even small amounts of the wrong fuel * NOTE Damage to the fuel system due to 50 ppm. could result in damage to the fuel system overfilling the fuel tank and the engine.
  • Page 212 Only fill the fuel tank until the pump nozzle cumstances. For more information, consult a switches off. Mercedes-Benz service centre. Vehicles with diesel engine: The tank filler Replace the cap on the filler neck and turn neck is designed for refuelling at diesel filling clockwise until it engages audibly.
  • Page 213 210 Driving and parking Depressurising the fuel tank (plug-in hybrid with Fuel tank is depressurised Ready for Only refuel when the fuel filler flap has petrol engine) refuelling message will appear on the driver's opened automatically. display and the fuel filler flap will open auto- matically.
  • Page 214 ® AdBlue level will lead to limited performance After topping up, carefully close the specialist workshops, e.g. Mercedes-Benz from the speed displayed. After the remaining ® AdBlue refill container. Service Centres, and at many filling stations in distance displayed has been covered, it will no ®...
  • Page 215 ® Opening the AdBlue filler cap ® Refilling AdBlue Top up AdBlue In XXX km Electric only. See ® Mercedes-Benz recommends refilling AdBlue ® Owner's ManualThe low AdBlue level will ® a filling pump. If no AdBlue filling pump is availa- result in the combustion engine being ®...

  • Page 216: Charging The High-Voltage Battery (Plug-In Hybrid)

    Driving and parking 213 ® Lift up and tip AdBlue refill canister 4. Charging the high-voltage battery (plug-in ® The filling process stops when the AdBlue hybrid) tank is completely full. Notes on charging the high-voltage battery ® AdBlue refill canister can be removed when it has been only partially emptied.
  • Page 217 214 Driving and parking keep the high-voltage battery continuously Type Combo 2 for charging with alternating ses over the course of its life. Due to this, both connected to power supply equipment. current (mode 2/3) and charging with direct the maximum electrical range that can be ach- current (mode 4) ieved by the vehicle and its maximum electri- If leaving the vehicle idle for lengthy periods of...
  • Page 218 Driving and parking 215 socket connections are used for It is recommended that you charge the high-volt- age battery at a wallbox or charging station due to charging. the improved charging performance and better Charging options for the high-voltage battery charging efficiency offered.
  • Page 219 216 Driving and parking Stowing the charging cable As delivered, charging cable bag with retaining strap is located in the boot or load compart- Always stow the vehicle's charging cable in the ment. To secure the charging cable bag, the charging cable bag provided, and secure the retaining strap must be attached to tie-down eye charging cable bag in the boot or load compart-...
  • Page 220 Driving and parking 217 Notes on charging the high-voltage battery at the The charging process can vary depending on the Mercedes-Benz thoroughly tests these original mains socket (mode 2) power supply equipment. The charging times charging cables for their suitability for high- when charging the high-voltage battery at the voltage charging of your vehicle.
  • Page 221 218 Driving and parking Notes on charging the high-voltage battery at a Observe the safety notes in the operat- For charging stations without a preinstal- wallbox or charging station (mode 3) ing instructions for the wallbox. led charging cable: For safety reasons, only use charging &...
  • Page 222 Driving and parking 219 vehicle is charging or from auxiliary consumers The charging cable for the vehicle must not be approved by the manufacturer for that are switched on. Further information on longer than 30 m due to the legal requirements in charging the high-voltage battery in recharge efficiency can be obtained at a qualified some countries.
  • Page 223 Temperature monitor indicator cable supplied with the vehicle or an laws when charging. Safety system indicator original Mercedes-Benz charging cable. Mercedes-Benz thoroughly tests these If you have questions concerning the charging Supply voltage indicator original charging cables for their suitabil-...
  • Page 224 Driving and parking 221 Charging process indicator Safety system indicator If temperature monitor indicates a malfunc- tion, it may help to protect the charging cable Display Meaning Display Meaning from direct sunlight. Flashes green The high-voltage bat- Flashes red Charging cable mal- To reset the charging cable operating unit: if tery is charging.
  • Page 225 222 Driving and parking display and flashes or lights up as with indicator lamp 2. Overview of the locking status Locking sta- Display Meaning %   Lights up Vehicle white socket unlocked, insert or remove charg- ing cable %   Flashes white Malfunction during locking...
  • Page 226 Driving and parking 223 Overview of the charging process status Starting the alternating current charging process * NOTE Damage due to overheating of (mode 2/3) charging cable and charge port Status of the Display Meaning charging During the charging process, the charging &...
  • Page 227 224 Driving and parking The vehicle is switched off. The õ display Make sure that the socket cover is in the driver's display is off. closed properly before closing the socket flap. This can otherwise result in damage The charging cable is not taut. which may prevent the socket flap from Depending on the vehicle's equipment and on the being opened again.
  • Page 228 Driving and parking 225 When the vehicle is switched on (the õ When the charging sequence for the ambient lighting is activated, the ambient lighting lights display is lit in the driver's display), socket flap up for approximately 30 seconds as with the cannot be opened.
  • Page 229 226 Driving and parking The vehicle is equipped with an electrical fuse Combo 1 vehicle socket Combo 1 vehicle socket: press charging inter- which protects it against overvoltage in the ruption button 3. mains supply. This electrical fuse may trip dur- The charging process is ended.
  • Page 230 Driving and parking 227 Combo 2 vehicle socket Combo 2 vehicle socket: press charging inter- After the charging cable connector has been ruption button 2. disconnected, the % indicator lamp The charging process is ended. The % indi- the vehicle socket remains lit for some time before switching off.
  • Page 231 228 Driving and parking The vehicle is not switched on. The õ dis- Make sure that the socket cover is * NOTE Damage due to overheating of play in the driver's display is off. closed properly before closing the socket charging cable and charge port flap.
  • Page 232 Driving and parking 229 When the vehicle is switched on (the õ charging prediction. The charging prediction refers to the time at which the high-voltage bat- display is lit in the driver's display), socket flap tery will be fully charged. cannot be opened.
  • Page 233 230 Driving and parking Combo 1 vehicle socket If you cannot remove the charging cable con- Press charging interruption button 2. nector, unlock the vehicle and repeat the pro- The charging process is ended. The % indi- cedure. If the charging cable connector is still cator lamp lights up white.

  • Page 234: Parking

    Driving and parking 231 Function of the charge level display in the driver's Specified remaining range may vary due to apply the parking brake. display different factors, e.g. driving style or topogra- Switch the transmission to position j. phy. When the vehicle is connected to the mains sup- &...
  • Page 235 232 Driving and parking operate vehicle equipment and become * NOTE Damage caused by vehicle being trapped, for example. lowered In addition, the children could also set the Vehicles AIRMATIC: The vehicle can be low- vehicle in motion by, for example: ered due to differences in temperature or extended non-operational times.
  • Page 236 Driving and parking 233 Engage transmission position j in a station- The vehicle will be switched off automatically after In addition, the children could also set the ary vehicle with the brake pedal depressed a further ten minutes. vehicle in motion by, for example: page 203).
  • Page 237 234 Driving and parking In the following situations, the electric parking The electric parking brake is not automatically You have previously driven at speeds brake is also applied: applied if the vehicle is switched off by the greater than 3 km/h. The HOLD function is keeping the vehicle sta- ECO start/stop function.
  • Page 238 Driving and parking 235 Push handle 1. Information on collision detection on a parked System limits vehicle The red ! indicator lamp lights up in the Detection may be restricted in the following situa- driver's display. tions: If a collision is detected when the tow-away pro- The electric parking brake is only securely tection is primed on a locked vehicle, you will the vehicle is damaged without impact,...
  • Page 239 236 Driving and parking A maximum of three incidents can be regis- Copying the collision photos to a USB flash drive Standby mode (extension of the starter battery's tered. Up to 15 photos are taken for every period out of use) Connect a USB flash drive .

  • Page 240: Driving And Driving Safety Systems

    Driving and parking 237 guaranteed that the starter battery will reliably Information on vehicle sensors and cameras Driving and driving safety systems start the vehicle. Some driving and driving safety systems use cam- Driving systems and your responsibility Charge the starter battery in the following situa- eras as well as radar or ultrasonic sensors to Your vehicle is equipped with driving systems tions:...
  • Page 241 238 Driving and parking Make sure that there are no overhanging loads & WARNING Risk of accident due to restric- protruding into the detection range. ted detection performance of vehicle sen- If there is damage to a bumper or the radiator sors and cameras grille, or after an impact, have the function of the If the area around vehicle sensors or cameras...
  • Page 242 Driving and parking 239 HOLD function ( page 243) Lane Keeping Assist and Active Emergency 360° Camera ( page 289) Stop Assist are also available without the Driv- Hill Start Assist ( page 244) Parking Assist PARKTRONIC ( page 296) ing Assistance Package, albeit with restricted Adaptive Brake Lights ( page 244)
  • Page 243 240 Driving and parking Functions of Off-road ABS Depress the brake pedal with full force in ® should only be deactivated in the emergency braking situations. ABS pre- following situations. Off-road ABS is activated automatically when vents the wheels from locking. you select the F drive program.
  • Page 244 Driving and parking 241 ® ® ® ® is deactivated if the å ESP OFF warn- Deactivate ESP in the following situations to Influence of drive programs on ESP improve traction: ing lamp lights up continuously in the driver's dis- The drive programs enable ESP ®...
  • Page 245 242 Driving and parking Function of EBD ® ® Function of ESP trailer stabilisation trailer stabilisation may be impaired or may not function if: Electronic Brakeforce Distribution (EBD) is charac- & WARNING Risk of accident in poor road The trailer is not connected correctly or is not terised by the following: and weather conditions detected properly by the vehicle.
  • Page 246 Driving and parking 243 ▌Activating/deactivating the HOLD function The electric parking brake is released. ® is malfunctioning. Active Distance Assist DISTRONIC is deactiva- The steering is malfunctioning. & WARNING Risk of an accident due to the ted. ® HOLD function being active when you If ESP is malfunctioning, you will be assisted fur- The transmission is in position h, k or i.
  • Page 247 244 Driving and parking In the following situations, the vehicle is held by The electric parking brake is released. If the vehicle is braked sharply from speeds above transmission position j and/or by the electric 50 km/h, the brake lamps flash rapidly. This pro- This gives you enough time to move your foot vides traffic travelling behind you with an even parking brake:...
  • Page 248 Driving and parking 245 ted by ATTENTION ASSIST is adapted accord- The attention level determined by ATTENTION Particularly in the following situations, ATTENTION ingly. ASSIST. ASSIST only functions in a restricted manner and warnings may be delayed or not occur: If drowsiness or increasing lapses in concentra- The more segments of the circle displayed,...
  • Page 249 246 Driving and parking If you unfasten your seat belt and open the You can store any speed above 20 km/h up to the Do not use cruise control in the following situa- driver's door (e.g. to change drivers or take a maximum design speed or up to the set winter tions: break).
  • Page 250 Driving and parking 247 Observe the notes on driving systems and your ▌Operating cruise control or the variable limiter responsibility; you may otherwise fail to recognise & WARNING Risk of accident due to stored dangers ( page 237). speed Displays in the driver's display If you call up the stored speed and this is È...
  • Page 251 248 Driving and parking Operating cruise control and the variable limiter When you switch off the vehicle, the last Press and hold M or N on control panel speed stored is deleted. Press the corresponding button with only one When you activate cruise control or Active The stored speed is increased or decreased to finger or swipe on the control panel.
  • Page 252 Driving and parking 249 ▌Setting the speed limit for winter tyres speed. The speed and distance to the vehicle in ® ® If you brake, deactivate ESP or if ESP inter- front are set and saved using the steering wheel. venes, cruise control is deactivated.
  • Page 253 250 Driving and parking Takes one-sided overtaking restrictions Observe the notes on driving systems and your Permanent status display into account on motorways or on multi- responsibility; you may otherwise fail to recognise ç (grey): Active Distance Assist lane roads with separate carriageways dangers ( page 237).
  • Page 254 Driving and parking 251 If you depress the accelerator pedal beyond Do not use Active Distance Assist DISTRONIC in & WARNING Risk of accident due to insuffi- the setting of the Active Distance Assist these situations. cient deceleration by Active Distance DISTRONIC, the system is switched to passive Assist DISTRONIC &...
  • Page 255 252 Driving and parking DSR is deactivated. Increases/decreases the speed to pedestrians, animals, bicycles or sta- tionary vehicles, or unexpected obstacles Drive program G is deactivated. Increases/decreases the specified distance Switches between the variable limiter and to complex traffic conditions Variable limiter: Active Distance Assist DISTRONIC to oncoming vehicles and crossing traffic...
  • Page 256 Driving and parking 253 To activate with a stored speed: pressJ. Briefly press M on the upper section or Accept the displayed speed limit: press J. N on the lower section of control panel Active Distance Assist DISTRONIC: remove The limit speed displayed in the driver's dis- your foot from the accelerator pedal.
  • Page 257 254 Driving and parking Reducing or increasing the specified distance If Active Distance Assist DISTRONIC has been put ® ® If you brake, deactivate ESP or if ESP inter- from the vehicle in front into passive mode by pressing the accelerator venes, Active Distance Assist DISTRONIC is pedal, only speed limits which are higher than the deactivated.
  • Page 258 Driving and parking 255 front, vehicles detected ahead and speed restric- traffic lights, as route-based speed adaptation & WARNING Risk of accident due to Active tions ahead are taken into account. does not brake the vehicle to a standstill. Speed Limit Assist adapting the vehicle's Route-based speed adaptation can be activated in If a corresponding route event is detected while speed...
  • Page 259 256 Driving and parking In difficult conditions, the speed selection made Further information about Active Distance If the driver does not follow the calculated by the system may not always be suitable. This Assist DISTRONIC ( page 252). route applies to the following situations, forexample: If map data is not up-to-date or available Setting speed adaptation the road's course not clearly visible...
  • Page 260 Driving and parking 257 Active Stop-and-Go Assist requires you, as the System limits tor in the driver's display goes out. You also hear driver, to keep your hands on the steering wheel The system limitations of Active Distance Assist a warning tone. at all times so that you are able to intervene at DISTRONIC and Active Steering Assist apply to ▌Information on DSR...
  • Page 261 258 Driving and parking ▌Activating or deactivating DSR (Downhill Speed ▌Changing the target speed Press and hold at M the top of the con- Regulation) trol panel. The target speed is increased in 1-km/hincre- Requirements: ments. You are driving at 40 km/h or slower. To decrease the target speed: swipe down- If the vehicle speed is too high, the Max.
  • Page 262 Driving and parking 259 Depending on the country, in the lower speed Contact detection If the driver does not react to this warning for a range Active Steering Assist can use the sur- The driver is required to keep their hands on the considerable period, an emergency stop is initi- rounding traffic as a reference.
  • Page 263 260 Driving and parking The system may be impaired or may not function If transport equipment, forexample a trailer or Always steer the vehicle paying attention in the following instances: bicycle rack, is attached to the trailer hitch to traffic conditions. and the electrical connection has been cor- There is poor visibility, e.g.
  • Page 264 Driving and parking 261 Function of Active Emergency Stop Assist Vehicles with Driving Assistance package: if In addition to display a warning tone Active Steering Assist is switched on and sounds. Active Emergency Stop Assist monitors the steer- active, only the steering wheel is monitored by The message Beginning emergency stop will...
  • Page 265 You are on a motorway or high-speed major tions: If possible, an emergency call is placed to the road. Mercedes-Benz emergency call centre. Active Distance Assist DISTRONIC The vehicle speed is between approximately page 249) 80 km/h and 180 km/h.
  • Page 266 Driving and parking 263 The system is not available and must be reactiva- Display in the driver's display in the Assistance appears along with grey arrows in the driver's dis- ted in the following situations: play. menu Active Distance Assist DISTRONIC and Active If no vehicle or obstacle is detected in the adja- Steering Assist were already activated before cent lane and a lane change is permitted, the lane...
  • Page 267 264 Driving and parking The vehicle cannot make the lane change as The system does not detect a suitable road, & WARNING Risk of accident if Lane Change planned. forexample, in tight bends or shortly after a Assist unexpectedly stops functioning slip road.
  • Page 268 Driving and parking 265 Active Brake Assist directly. In this case, the warning lamp and warn- ing tone occur simultaneously with the braking ▌Function of Active Brake Assist application. Active Brake Assist consists of the following func- If you apply the brake yourself in a critical situa- tions: tion or apply the brake during autonomous brak- Distance warning function...
  • Page 269 266 Driving and parking additional preventive measures for occupant pro- another driving system, the ê display message intermittent warning tone and the L warning ® tection (PRE-SAFE ) may also be initiated. appears in the driver's display. lamp. If the system is unavailable due to dirty or dam- Vehicles without Driving Assistance Package: &...
  • Page 270 Driving and parking 267 at speeds up to approximately 80 km/h when at speeds up to approximately 120 km/h at speeds up to approximately 60 km/h when approaching cyclists ahead when approaching crossing vehicles, pedes- approaching stationary pedestrians and trians and cyclists cyclists at speeds up to approximately 70 km/h when approaching stationary pedestrians and...
  • Page 271 268 Driving and parking Releasing the brake pedal. Evasive Steering Assist Evasive Steering Assist has the following charac- teristics: Active Brake Assist may cancel the brake applica- & WARNING Risk of accident despite Eva- Detection of pedestrians, cyclists and vehi- tion when one of the following conditions is fulfil- sive Steering Assist cles.
  • Page 272 Driving and parking 269 The system may be impaired or may not function, If the driver's seat belt is not fastened. Select Early, Medium or Late. particularly in the following situations: On bends with a tight radius. If ATTENTION ASSIST has detected indica- In snow, rain, fog, heavy spray, if there is glare, tions of fatigue or a microsleep, the system ▌Setting Active Brake Assist...
  • Page 273 270 Driving and parking Warning when the maximum permissible speed is The type, duration and activation threshold of cating the beginning or end of dual carriage- exceeded the speed warning, as well as the possibility of ways, can also be detected. The system can warn you if you unintentionally setting the activation threshold above which The system can show up to two traffic signs in the...
  • Page 274 Driving and parking 271 If the system is temporarily or permanently Digital LED traffic signs may not be detected ▌Setting Speed Limit Assist unavailable due to a technical fault or soiling of correctly or at all due to technical factors, Multimedia system: the windscreen, the warning light ê...
  • Page 275 272 Driving and parking Switching the advisory tone for a new speed limit Variable limiter The camera also detects and analyses traffic on or off signs with a restriction indicated by an additional Further information about Active Distance sign (e.g. when wet). The advisory tone for a new speed limit is Assist DISTRONIC ( page 252).
  • Page 276 Driving and parking 273 Displays in the driver's display Traffic Sign Assist can detect following additional signs and, if necessary, analyse the relevance of the restrictions using other vehicle sensors: when wet slippery road surfaces in fog temporary restrictions exits restrictions for car/trailer combinations Examples of traffic signs which can be displayed Traffic Sign Assist also uses data from the digital...
  • Page 277 274 Driving and parking sign in the driver display) or visual and audible. Additional functions of Traffic Sign Assist (coun- The selected setting is confirmed by an indication try-specific) in the driver's display. Warning for no-entry signs: Traffic Sign Assist can warn you if you drive the wrong way down a sec- tion of road, forexample on motorway slip roads Traffic Sign Assist is not available in all countries.
  • Page 278 Driving and parking 275 The following conditions must be fulfilled: If there is dirt on the windscreen in the vicinity guidance of the navigation system, e.g. in or of the multifunction camera or if the camera is after road works Several traffic lights have been detected.
  • Page 279 276 Driving and parking Setting the warning threshold Multimedia system: Blind Spot Assist and Active Blind Spot Assist This value determines the speed at which a warn- © Settings Assistance ▌Function of Blind Spot Assist and Active Blind ing is issued when exceeded. Assistance Traffic light view Spot Assist with exit warning...
  • Page 280 Driving and parking 277 waves are displayed next to your vehicle in the Exit warning The exit warning is an additional function of Blind assistance graphic. Spot Assist and Active Blind Spot Assist and can If the turn signal indicator remains on, the display warn vehicle occupants attempting to leave a sta- in the outside mirror flashes for all other detected tionary vehicle about approaching vehicles.
  • Page 281 278 Driving and parking and the warning lamps in the corresponding out- System limits Blind Spot Assist and Active Blind Spot Assist are side mirror flash red. not operational if transport equipment, for exam- Blind Spot Assist and Active Blind Spot Assist may ple a trailer or bicycle rack, is attached to the Vehicles with ambient lighting: the Warning...
  • Page 282 Driving and parking 279 The course-correcting brake application is availa- If a course-correcting brake application occurs, A loss of tyre pressure or a defective tyre is ble in the speed range between approximately the red warning lamp flashes in the outside mirror detected.
  • Page 283 280 Driving and parking steering wheel. Active Lane Keeping Assist is In the following situations (country-dependent), Display will appear in the driver's display and a available in the speed range between 60 km/h Active Lane Keeping Assist may already react warning tone will sound in the following situations: and 200 km/h.
  • Page 284 Driving and parking 281 Keeping Assist is automatically deactiva- Active Lane Change Assist display in the "Assis- If a driving safety system intervenes, such as ted. tance" menu ® , Active Brake Assist or Active Blind Spot Assist. ï Yellow: there is a malfunction. Please also observe the display messages.
  • Page 285 282 Driving and parking If there are no lane markings, or several Alternatively, Active Lane Keeping Assist can be The last selected setting will be adopted the next unclear lane markings are present for one activated and deactivated via quick-access. time the vehicle is started.
  • Page 286 Driving and parking 283 AIRMATIC Suspension setting and vehicle level per drive pro- Drive program F: gram suspension setting for off-road ▌Function of AIRMATIC Drive program A: AIRMATIC is an air suspension system with varia- raising the vehicle at speeds below approx. ble damping for improved driving comfort.
  • Page 287 284 Driving and parking Low level -1 Choose a vehicle level which is suited to You or anyone else in the vicinity of the wheel in drive program ;: approx. -10 mm the driving style and the road surface arches or the underbody could thus become conditions.
  • Page 288 Driving and parking 285 Off-road level +1: the vehicle is not moving When the trailer socket is contacted (trailer/ Lowering the vehicle faster than 80 km/h. bicycle rack): the vehicle is moving faster than Select t. 30 km/h. Off-road level +2: the vehicle is not moving The indicator lamp goes out.
  • Page 289 286 Driving and parking Lowering the rear of the vehicle The vehicle is lowered at the rear axle by Make sure no one is underneath the approx. 40 mm. When the vehicle has been vehicle or in the immediate vicinity of the lowered, indicator lamp remains lit.
  • Page 290 Driving and parking 287 Pull switch briefly. The area behind the vehicle is displayed as a Activates/deactivates Parking Assist mirror image, as in the inside rear view mirror. Indicator lamp goes out. PARKTRONIC ( page 299) Warning display of Parking Assist The vehicle will be raised to the currently PARKTRONIC ( page 308, 296)
  • Page 291 288 Driving and parking System limits If the system is not ready for operation, the Sys- tem inoperative message appears in the central display. The reversing camera will not function or will only partially function in the following situations: You are driving forwards at a speed greater than approximately 16 km/h.
  • Page 292 Driving and parking 289 Also observe the information on vehicle sensors the central display when reverse gear is selected Menu overview Camera views and cameras ( page 237). page 295). Do not use the reversing camera in these The 360° Camera includes the following cameras types of situations.
  • Page 293 290 Driving and parking Function of the guide lines When Active Parking Assist is active, lanes To activate/deactivate Parking Assist and guide lines are displayed in green instead PARKTRONIC ( page 299) of yellow ( page 299). To set the GPS activation point ( page 295) To switch between standard and wide-angle Top view with image from the front or reversing...
  • Page 294 Driving and parking 291 3D view, left/right-hand side of the vehicle * NOTE Risk of accident due to objects being severely distorted in the display or not displayed at all Due to the projection of the cameras, objects in the 3D views may be severely distorted when displayed or not displayed at all.
  • Page 295 292 Driving and parking Wide-angle view Trailer view: locating aid Trailer view: side view of the mirror cameras To switch between standard and trailer view To switch between standard and trailer view Display of Parking Assist PARKTRONIC Yellow locating aid page 296) System limits Ball head of the trailer hitch...
  • Page 296 Driving and parking 293 The weather conditions are poor, e.g. heavy The contrast of the display may be impaired when it is switched on. Please also note the rain, snow, fog, storm or spray. by abrupt, direct sunlight or by other light system limits of the respective functions.
  • Page 297 294 Driving and parking Front and rear view Position of the wheels Lane indicating the route the vehicle will take at the current steering angle Area under the bonnet Pitch display Lane indicating the route the vehicle will take at the current steering angle Note that the area between the vehicle and up to approx.
  • Page 298 Driving and parking 295 Observe the instructions on the function of the In the multimedia system, select the desired The settings for deactivating the reversing 360° camera as well as its system limits, other- view ( page 289). camera are not available in every country. wise you will not be able to recognise dangers ▌360°...
  • Page 299 296 Driving and parking Confirm the prompt. of a lateral collision, a warning is issued. The pas- Displays in the central display The activation position is deleted. sive side impact protection can be activated and deactivated via the multimedia system. ▌Opening the camera cover In order for front or rear obstacles to the side to Multimedia system:...
  • Page 300 Driving and parking 297 As soon as Parking Assist PARKTRONIC is opera- tional, the respective areas of the display are shown in blue. Operational, front and rear Operational, all around Operational, all around and obstacle detected The colour of the display changes depending on the distance to the detected obstacle: Blue: >...
  • Page 301 298 Driving and parking Vehicles with Active Parking Assist: when driv- Obstacles above the detection range, e.g. Vehicles with towbar: If a transport device, e.g. ing no faster than 18 km/h. overhanging loads, overhangs or loading trailer or bicycle carrier, is attached to the towbar ramps of lorries.
  • Page 302 Driving and parking 299 ▌Activating/deactivating Parking Assist Parking Assist PARKTRONIC is automatically Audio fadeout select and Audio fadeout in activated when the vehicle is started. trans. position R switch on or off. PARKTRONIC The volume of the currently playing media Alternatively, Parking Assist PARKTRONIC can be * NOTE Risk of an accident from objects at source is reduced when reverse gear is...
  • Page 303 300 Driving and parking Vehicles with reversing camera system detects parking spaces, È appears. System limits In drive mode F or when the exterior lighting The arrows show on which side of the road free Parking in parking spaces parallel to the road parking spaces are located.
  • Page 304 Driving and parking 301 If the parking space is on a steep downhill or ▌Parking with Active Parking Assist & WARNING Risk of accident due to objects uphill gradient. located above or below the detection When snow chains are fitted. range of Active Parking Assist When a trailer or bicycle rack is attached.
  • Page 305 302 Driving and parking Vehicles with 360° Camera: to change the parking direction, tap the selected parking space again. To start the parking procedure: press button again. The vehicle drives into the selected parking space. The turn signal indicator is switched on automati- cally when the parking procedure begins.
  • Page 306 Driving and parking 303 Immediate parking via the Camera views menu The vehicle has been parked with Active Park- Where necessary, stop the vehicle or ing Assist. cancel the parking procedure with Active Parking Assist. Start the vehicle. Press button 1. On completion of the parking procedure, the Active Parking Assist finished display message...
  • Page 307 304 Driving and parking To start exiting the parking space: press but- ▌Pausing Active Parking Assist ▌Automatic braking function of Active Parking again. You can interrupt the parking or exiting procedure Assist of Active Parking Assist by performing one of the Persons or objects detected in the manoeuvring If necessary, change the gearbox setting.
  • Page 308 Driving and parking 305 If the driver engages an incorrect gear. If Drive Away Assist is not available, the same System limits symbol appears in grey. If the Camera & park- The drive-away assistance F is not available in If the driver depresses the accelerator pedal menu is not opened in the central display, the driving programme.
  • Page 309 306 Driving and parking approx. 10 km/h and the camera image is Warning for crossing traffic ahead Always pay careful attention to the traffic shown in the central display ( page 295). If Active Parking Assist is active, the vehicle situation;...
  • Page 310 Driving and parking 307 attached to the towbar and the electrical con- Always pay careful attention to the traffic nection is correctly established. situation; do not rely on the manoeuvring brake function alone. ▌Manoeuvring brake function Be ready to brake. The manoeuvring brake function can prevent colli- If the manoeuvring brake function is not avail- sions with pedestrians when the vehicle is revers-...
  • Page 311 308 Driving and parking ▌Activating/deactivating manoeuvring assis- parking remains with you. Make sure that there Due to this, the trailer cannot be manoeuvred are no persons, animals or objects in the manoeu- tance in the desired direction and you can cause a vring area while manoeuvring and parking in/exit- Multimedia system: collision or the trailer can overturn.
  • Page 312 Driving and parking 309 The system may be impaired or may not function Using Trailer Manoeuvring Assist in the following situations: The gradient is greater than approximately 15 %. ▌Using Trailer Manoeuvring Assist Requirements: The vehicle has been started and is stationary. A trailer is selected in the Vehicle menu...

  • Page 313: Trailer Hitch

    310 Driving and parking short countersteering movement of the trailer longer the trailer is, the higher the maximum Use a tongue weight as close as possible to while the vehicle is reversed, which then articulation angle (max. approximately 60°). the maximum tongue weight guides it back to the desired line.
  • Page 314 Driving and parking 311 When you are reversing with a trailer, remem- Extending the ball neck fully electrically * NOTE Increased risk of damage to prop- ber to use the Trailer Manoeuvering Assist erty due to folded-out ball neck function ( page 308).
  • Page 315 312 Driving and parking Wait until the ball neck has reached the Retracting the ball neck fully electrically Coupling up/uncoupling a trailer swung-out position with a clear locking noise. Pull button 2. When indicator lamp is continuously lit, the & WARNING Risk of injury due to a change Indicator lamp will flash and the message ball neck is securely locked in place.
  • Page 316 Driving and parking 313 Vehicles with level control system: ensure the Active Parking Assist vehicle is at the normal level ( page 284). Blind Spot Assist or Active Blind Spot Assist Use the normal level in trailer operation. High- Drive Away Assist level driving is not permitted in trailer opera- Cross traffic warning tion on public roads.
  • Page 317 314 Driving and parking In the following circumstances, a message may * NOTE Damage during uncoupling with an * NOTE Damage to the rear bumper from appear on the driver's display even if the trailer engaged overrun brake installing adapter cables or adapter plugs has been connected correctly: The vehicle may be damaged if you uncouple The following parts could be damaged when...

  • Page 318: Bicycle Rack Function

    Only use bicycle racks approved by capacity of the trailer hitch. the country. Mercedes-Benz properly as described always observe the permissible rear axle To save changes: select Confirm. below. load of the towing vehicle.
  • Page 319 316 Driving and parking When mounted on ball head and guide pin neck or, in the case of a fully electric 2, the maximum load capacity is 100 kg. You trailer hitch, retract the ball neck. can transport up to four bicycles. * NOTE The operating permit may be invali- The maximum load capacity is calculated from the dated due to the illegal installation of...

  • Page 320: Vehicle Towing Instructions

    Driving and parking 317 Mercedes-Benz recommends removing all detach- Loading the bicycle rack able parts from bicycles (e.g. baskets, child seats, 3 bicycles 4 bicycles rechargeable batteries) before loading them onto the bicycle rack. This will improve the aerody- Total weight...
  • Page 321 318 Driving and parking anteed for the towing vehicle or the towed vehicle. The vehicle-trailer combination may swerve from side to side. Observe the following information: Permitted towing methods ( page 413) Plug-in hybrid: permitted towing methods page 413) The notes on towing the vehicle with both axles on the ground ( page 414)

  • Page 322: Driver Display 319

    Driver display 319 Status displays for the driving systems Notes on the driver's display and traffic conditions and operate the Display messages equipment with the vehicle stationary. & WARNING Risk of accident if the driver Information on speed, Consumption display fails Observe the legal requirements for the country in range which you are currently driving when operating...

  • Page 323: Driver Display Menus

    320 Driver display Scrolling on the menu bar one finger. Confirm your selection by pressing the Only operate this equipment when the Touch Control. traffic situation permits. To operate Touch Control in the most If you cannot be sure of this, stop the effective way, use the tip of your thumb if pos- vehicle whilst paying attention to road sible.

  • Page 324: Head-Up Display

    Driver display 321 On most of the menus, you can use Options You can use the head-up display menu bar to configure further settings for the menu-specific select various contexts, e.g.: display content. Minimal You can find further information about the possi- Sport ble settings and selections on the menus in the Standard...
  • Page 325 322 Driver display Head-up display content with navigation (9x3°) System limits Visibility is particularly influenced by the following conditions: Seat position Image position setting Light conditions Wet road surfaces Objects on the display cover Polarisation in sunglasses Switching between display content on the head- up display Navigation instructions Operating the head-up display...

  • Page 326: Overview Of Status Displays On The Driver's Display

    Driver display 323 Setting the position and brightness Switching the head-up display on/off Swipe to the left or right on the left-hand Driver's display: Touch Control and select Settings on the © menu bar of the head-up display. To switch on Press the left-hand Touch Control.
  • Page 327 324 Driver display h Cruise control ( page 246) _ Adaptive Highbeam Assist ( page 148) È Limiter ( page 246) Adaptive Highbeam Assist Plus page 149) ç Active Distance Assist DISTRONIC ð Maximum permissible speed exceeded (for page 249) certain countries only) Ò...

  • Page 328: Mbux Multimedia System 325

    Touch Control and control panel for the MBUX Only operate this equipment when the multimedia system traffic situation permits. MBUX stands for Mercedes-Benz User Experi- If you cannot be sure of this, stop the ence. vehicle whilst paying attention to road •...
  • Page 329 326 MBUX multimedia system use. When you select © on the central display, The lower display area shows an active mas- a Switches sound on or off sage programme, for example. the digital map with the applications appears in ø Adjusts the volume the lower display area.
  • Page 330 MBUX multimedia system 327 ▌Overview zero layer e.g. a massage programme Calls up user profile settings Content sharing menu (if available) Telephone Digital map and user-specific applications (exam- Telephone Entertainment sources ple) Requirement for phone: the mobile phone is Online voice applications connected to the MBUX multimedia system.
  • Page 331 328 MBUX multimedia system Requirement for suggestions: the Calls & mes- Raising or lowering the vehicle level The suggested voice applications are made availa- sages option is activated in the suggestions. ble online and are based on your previous voice Suggestions for comfort and vehicle functions as inputs.
  • Page 332 MBUX multimedia system 329 To answer a call or call a missed call: tap on Destination the contact. Press the © button on the steering wheel Searches for a filling station After the connection has been established, on the right. Switches traffic information display on or off the call functions are available.
  • Page 333 330 MBUX multimedia system Showing all applications Switching between zero layer and home screen Starts/stops a massage programme for the with classic menu front passenger Sets the massage programme intensity for the Long press on ©. driver's or front passenger seat The home screen with classic menu is shown.
  • Page 334 MBUX multimedia system 331 Home screen overview Operating the MBUX multimedia system Calls up an application Quick-access to application Using Touch Control Global menu G Calls up previous menu © Press and hold: switches between home screen and zero layer û...
  • Page 335 332 MBUX multimedia system Using the touchscreen 8 Switches off the sound: press Adjusts the volume ß Calls up favourites (press briefly) or Press ± or q or swipe over the button adds favourites (press and hold) To select a menu item or entry: tap on a sym- £...
  • Page 336 MBUX multimedia system 333 To move the digital map: touch the operated from all seats. Further information and Only operate this equipment when the touchscreen and move your finger in any examples of voice commands can be found in the traffic situation permits.
  • Page 337 334 MBUX multimedia system To change the system language to English Make sure that when the position of the (short command): "Change language to Eng- Press the £ button on the multifunction driver's seat is being adjusted via the lish". multimedia system, no people or body steering wheel.
  • Page 338 MBUX multimedia system 335 User profiles and user-specific content User-specific content and applications with per- Depending on the vehicle equipment you can, as sonal data are protected by different levels of a user, save the following settings, for example: Prerequisites for the vehicle owner: security.
  • Page 339 336 MBUX multimedia system Configuring users, suggestions and favourites If more than one user profile is available, you radio stations, contacts and messages are will be directed to the user selection. protected. Requirements: When the vehicle is stationary, the set-up ENERGIZING COACH To use the set-up assistant: the vehicle is sta- assistant starts automatically after user selec-...
  • Page 340 MBUX multimedia system 337 If necessary, authenticate yourself on the mul- Select Yes. Select Change user. timedia system. Select a user. Teaching in the vehicle key for profile selection Authenticating using fingerprints When requested to do so, authenticate with Protect content.

  • Page 341: System Settings

    338 MBUX multimedia system numbers dialled as well as suggestions based Control elements System reset on your music preferences. Keyboard language and handwriting recog- To delete collected suggestions: select Î. nition Overview of software updates Select Yes. Sensitivity of the Touch Control Important software updates may be necessary for The suggestions are reset.
  • Page 342 MBUX multimedia system 339 Online software updates cannot be performed Some software updates require a safe vehicle via external Wi-Fi hotspots that are encrypted status for the installation to be completed. using TKIP. They can only be carried out in a safely parked vehicle with the vehicle switched off.
  • Page 343 340 MBUX multimedia system and have the vehicle checked at a qualified spe- supported by the multimedia system and by When the Wi-Fi function is switched off, it is not cialist workshop immediately ( page 480). the device to be connected. The type of con- possible to establish a hotspot connection.
  • Page 344 MBUX multimedia system 341 Connecting using a QR code When a new security key is generated, all cannot be carried out via the external Wi-Fi Requirement: an app for scanning the QR code is existing Wi-Fi connections are then discon- hotspot.

  • Page 345: Amg Track Pace

    342 MBUX multimedia system Resetting the multimedia system (reset function) Vehicles with rear telephony: handset connec- AMG TRACK PACE tion Function of AMG TRACK PACE & WARNING Risk of accidents due to failure The data used and saved in the multimedia of the central display functions This function is an on-demand feature and system by the driver assistance systems is...
  • Page 346 MBUX multimedia system 343 Setting Track Race Searching by track name Confirm the prompt with OK. Select ª Search. Select the weather. Multimedia system: Enter the track name. Select to save the times driven for this TRACK PACE Track Race Tracks with the searched name are displayed.
  • Page 347 344 MBUX multimedia system By selecting ¨ on the active display, you can Set the desired parameters. The following values can be set for the param- deactivate this. The analysis is displayed. eters, for example: speed Displaying the analysis Longitudinal/lateral acceleration Steering angle Select tracks.
  • Page 348 MBUX multimedia system 345 Select options u for the desired track. Start off and begin the measurement. Start off and begin the measurement. Measurement begins when the vehicle accel- Brake to a stop. Select Rename or Delete. erates. Measurement is incremental, in steps of 10 km/h to a stop.
  • Page 349 346 MBUX multimedia system Calling up the telemetry display The TRACK PACE app is installed on the De-authorising the mobile device mobile end device. Select TRACK PACE App. Multimedia system: The mobile end device is connected to the Select a device. TRACK PACE Telemetry multimedia system via Wi-Fi.

  • Page 350: Off-Road Menu

    MBUX multimedia system 347 Displaying statistics Select Dashcam. Setting the off-road menu in the multimedia sys- Select TRACK PACE statistics. Select Track Race Drag Race and activate Statistics on the current user profile are dis- Activate recording. Multimedia system: played. You can set which overlay is to be used in the ©...

  • Page 351: Navigation And Traffic

    348 MBUX multimedia system Activating or deactivating DSR (Downhill Speed Switching navigation on Always keep an eye on the actual traffic Regulation) situation. Multimedia system: Press î to switch the function on or off. Avoid extended observation of the cam- ©...
  • Page 352 MBUX multimedia system 349 Navigation overview 3D and direction of travel Tapping opens the navigation module in the expanded view with the Route Map with complete route Digital map Destination entry If the map is moved, the map switches Searches for a parking space between 3D direction of travel and 2D north Map orientation Ä...
  • Page 353 350 MBUX multimedia system Navigation module (expanded view) Entering a destination Multimedia system: © ª Requirements: For the online search: There is an Internet connection. Mercedes me connect is available. You have set up a user account in the Mercedes me Portal. The vehicle is connected with the user account and you have accepted the terms of use.
  • Page 354 MBUX multimedia system 351 Select the destination in the list. Calculating a route and using settings for route Adopts the search result in the input line and The route is calculated. guidance continues the search Deletes the last character entered Observe the notes on the MBUX multimedia system ( page 325).
  • Page 355 352 MBUX multimedia system To share a destination: select Ç Share. announcements for the route are taken into Selects a point of interest in the vicinity of the account via Dynamic route guidance This option allows you to scan the displayed destination QR code.
  • Page 356 MBUX multimedia system 353 Activating a commuter route Activate or deactivate the avoid option. Activate Street names House numbers. During route guidance, the activated options A user profile has been created and Allow Activating route guidance with augmented reality are shown as additional information in the destination suggestions has been activated in In the navigation module (expanded view),...
  • Page 357 354 MBUX multimedia system To reset the map to the current vehicle posi- The vehicle is connected to a user account Displaying hazard warnings tion: select \ Centre and you have accepted the conditions of use If hazard warnings are available these can be for the service.
  • Page 358 Parking service parking time, maximum access height. Mercedes-Benz does not guarantee the accu- The maximum access height shown by the racy of the information provided in relation to * NOTE Damage to the vehicle due to not parking service does not replace the need the car park or parking area.
  • Page 359 Notes on the dashcam the USB flash drive format. So FAT32 format- Mercedes-Benz recommends that you use ted USB flash drives do not allow files larger USB devices with one partition. * NOTE Risk of legal consequences follow- than 4 GB, for example.

  • Page 360: Telephone

    An individual record- If you operate communication equipment inte- Have the camera checked in a Mercedes-Benz ing is automatically protected against being grated in the vehicle when driving, you could service centre. overwritten.
  • Page 361 358 MBUX multimedia system The menu view and the available functions in the & WARNING Risk of accident from operating and hit vehicle occupants. In addition, cup telephone menu are in part dependent on the holders, open stowage spaces and mobile mobile communication equipment while ®...
  • Page 362 For information on the range of functions of the Further information can be obtained from a ▌Telephone menu overview mobile radio unit to be connected, see the manu- Mercedes-Benz service centre or at: https:// facturer's operating instructions. www.mercedes-benz.com/connect Network connection:...

  • Page 363: Mercedes Me App

    Mercedes me calls are not possible in every In the telephony menu you have the following ▌Connecting a mobile phone country. Find out at a Mercedes-Benz service functions, for example: centre if these functions are available in your Requirements: country.
  • Page 364 Access to a GSM network is available. the me button The contract partner's GSM network coverage A call to the Mercedes-Benz Customer Centre has is available in the respective region. been initiated via the me button in the overhead The vehicle must be switched on so that vehi- control panel or the multimedia system cle data can be transferred automatically.
  • Page 365 Depending on the severity of the accident, an The vehicle has detected an accident or break- Find out at a Mercedes-Benz service centre if this automatic emergency call can be initiated. down situation. functions is available in your country.
  • Page 366 After your agreement, the vehicle data is vehicle's position to the Mercedes-Benz Cus- transferred and the Mercedes-Benz customer tomer Centre to improve the processing of your The quality of the mobile connection is suffi- centre takes your preferred appointment date.
  • Page 367 Country indicator of the vehicle been confirmed, the following data can also be The available mobile phone transmission tech- Set language for the multimedia system called up from the vehicle by the Mercedes-Benz nology. Customer Centre: Telephone number of the communication plat- The activated Mercedes me connect services.
  • Page 368 Mercedes me connect services. You can find page 360). Mercedes me connect or individual Mercedes these in your Mercedes me user account. You can also call the Mercedes-Benz Customer me connect services are not available in every Centre using the multimedia system Data processing country.
  • Page 369 366 MBUX multimedia system The Accident and Breakdown Management can Addition to the Mercedes me connect service number first or use the Mercedes-Benz emer- include the following functions: Telediagnostics gency call system ( page 370). Supplement to the Mercedes-Benz emergency...
  • Page 370 Mercedes me Portal, then services and offers services with the multimedia system. ber is saved) from Mercedes-Benz will be available to you. Requirements for In-Car Office: Navigating to appointments (requirement For more information consult a Mercedes-Benz...
  • Page 371 368 MBUX multimedia system Alternatively, you can record text contents for Web browser overview Under Ä you have the following options: your e-mail via the MBUX voice assistant or Tabs via the dictation function. Bookmarks & Browsing History. Further information on the MBUX voice assis- Reading mode tant ( page 333).
  • Page 372 (VIN) and is deleted when the multi- tem. media system is reset ( page 342). Mercedes-Benz recommends disconnecting The following driving status data is transmitted: the connection via the device manager or the Transmission position engaged...

  • Page 373: Mercedes-Benz Emergency Call System

    Differences between the Mercedes-Benz emergency call system and the 112 emergency call system (EU eCall) Mercedes-Benz emergency call system 112 emergency call system (EU eCall)
  • Page 374 MBUX multimedia system 371 The 112 emergency call system (EU eCall) in Mercedes-Benz recommends the activation of the If the Mercedes-Benz emergency call centre is your vehicle meets the delegated regulation Mercedes-Benz emergency call system for the fol- not available, the 112 emergency call is car- EU 2017/79.
  • Page 375 Dial the emergency number 112 or the appro- The starter battery is sufficiently charged. phone networks and the Mercedes-Benz emer- priate local emergency call number on your gency call centre. mobile phone.
  • Page 376 Emergency call system data transfer of the MBUX voice assistant. site. For both the Mercedes-Benz emergency call sys- The emergency call has been made: A message with accident data is transmitted tem as well as the 112 emergency call system (EU to the emergency call centre.
  • Page 377 Whether Mercedes me connect is available or not This is a requirement for the option of forwarding the call to the Mercedes-Benz Customer Centre if necessary. If only the 112 emergency call system (EU eCall) is activated in the vehicle, the accident data is transmitted directly to the public emergency call centre.
  • Page 378 (GDPR)". Kyrgyzstan system failure, you will be informed with text mes- The data is solely used by the Mercedes-Benz sage on the instrument cluster and with red indi- emergency call system for rescue and recovery in cator SOS NOT READY on the display.
  • Page 379 112 emergency call system evant emergency call inquiry terminals that are is required to fulfil the purpose of handling the instead of the Mercedes-Benz emergency call sys- specified to first receive and handle emergency emergency call, and under no circumstances tem.

  • Page 380: Radio & Media

    MBUX multimedia system 377 schutz, Daimler AG, HPC G353, D-70546 Stutt- gart, Germany Radio & media Overview of the symbols and functions in the media menu Symbol Designation Function Play Select to start or continue playback. Rest Select to pause the playback. Repeat a track Select to repeat the current track or the active playlist.
  • Page 381 378 MBUX multimedia system Symbol Designation Function Categories Select to show or search through available categories (e.g. playback lists, albums, artists, etc.). ª Search Select to search in the active menu. You can search for artists, genres or moods, for example.
  • Page 382 MBUX multimedia system 379 Overview of the symbols and functions in the radio menu Symbol Designation Function © Home Select to return to the home screen. Messaging Select to call up messaging. Skip forwards/back Select to skip to the next or to the previous station. û/ü...
  • Page 383 380 MBUX multimedia system Additional functions of TuneIn Radio A relatively large volume of data can be trans- mitted when using TuneIn Radio. Symbol Designation Function Settings The following additional settings are available in the TuneIn Radio menu: Selecting stream Logging on to or out of the TuneIn account ß...

  • Page 384: Sound Settings

    Treble, mid-range and bass Mercedes me Portal. Balance and fader The functions and services are country- Volume dependent. For more information, consult a Mercedes-Benz service centre. Automatic adjustment Multimedia system: © Radio Select TuneIn Radio.

  • Page 385: 382 Maintenance And Care

    Adhere to the prescribed service inter- ing of your vehicle from a qualified specialist vals. Function of the ASSYST PLUS service interval dis- workshop, e.g. a Mercedes-Benz Service Centre. play Always have the prescribed maintenance work carried out at a qualified specialist...

  • Page 386: Maintenance Management

    Maintenance and care 383 Frequent operation in mountainous terrain or Mercedes-Benz service centre to find out Maintenance Management on poor road surfaces whether this function is available in your coun- Notes about Maintenance Management try. When the engine is often left idling for long...

  • Page 387: Engine Compartment

    Details on data transfer can be found in the data with the bonnet unlocked Mercedes-Benz Customer Centre. From this mes- protection information for the Mercedes me con- The bonnet may open and block your view.
  • Page 388 Maintenance and care 385 & WARNING Risk of accident and injury In the event of a fire in the engine com- & WARNING Risk of injury from touching partment, keep the bonnet closed and when opening and closing the bonnet components under voltage call the fire service.
  • Page 389 386 Maintenance and care Opening the bonnet Allow the engine to cool down and only touch component parts described in the following. & WARNING Risk of injury from using the windscreen wipers when the bonnet is open If the windscreen wipers start moving when the bonnet is open, you could be trapped by the wiper linkage.
  • Page 390 Maintenance and care 387 Lower the bonnet to a height of around 30 cm One of the following messages will appear on the Switch on the vehicle to check the engine oil and then allow it to fall, applying a little force driver's display: level.
  • Page 391 388 Maintenance and care & WARNING Risk of fire and injury from * NOTE Damage caused by topping up too engine oil much engine oil If engine oil comes into contact with hot com- Too much engine oil can damage the engine or ponent parts in the engine compartment, it the catalytic converter.
  • Page 392 Maintenance and care 389 Checking the coolant level Topping up the windscreen washer system Allow the engine to cool down and only touch component parts described in the & WARNING Risk of burns from hot compo- & WARNING Risk of injury due to moving following.

  • Page 393: Cleaning And Care

    390 Maintenance and care Keeping the air/water duct free * NOTE Damage from automatic braking Keep the area between the bonnet and the If one of the following functions is activated, windscreen free of deposits, e.g. ice, snow or the vehicle brakes automatically in certain sit- leaves.
  • Page 394 Maintenance and care 391 For car washes with a conveyor system: Parking Assist PARKTRONIC will be deactiva- Ensure there is sufficient ground clear- ted. ance between the underbody and the Neutral i is engaged. guide rails of the car wash. Vehicles with 360°...
  • Page 395 392 Maintenance and care Vehicles with 360° camera: the front image Deactivating automatic car wash mode To avoid damage to your vehicle, observe the fol- will be deactivated at speeds above 18 km/h. lowing when using a high-pressure cleaner: Select Deactivate. Vehicles with HANDS-FREE ACCESS: kick rec- The automatic car wash settings are reset.
  • Page 396 ( page 393). They also apply to Only use care products approved for matt decorative films. Mercedes-Benz. Notes on paintwork/matt finish paintwork care Observe the notes on cleaning decorative films to Do not attach stickers, films or similar materi- avoid damage.
  • Page 397 Sunlight (e.g. at a Mercedes-Benz Service Centre). after cleaning before parking it. The brake Temperature (e.g. hot air blower) disks and brakepads will warm up and dry out.
  • Page 398 Use clean water and a soft cloth to clean the Vehicle socket (high-voltage battery) ded for Mercedes-Benz. Failure to observe the camera lens. Use clean water and a soft cloth to clean the application instructions may result in damage, Do not use a high-pressure cleaner.
  • Page 399 For heavy soiling: use a cleaning agent recom- vents can cause surfaces in the cockpit to Clean the surface carefully with a microfibre mended for Mercedes-Benz. become porous. When the airbags are cloth and a suitable display care product (TFT- Do not use solvent-based cleaning agents, pol- deployed, plastic parts may break away.
  • Page 400 Leather care: use a leather care agent that solution and then wipe with a dry cloth. Imitation leather seat covers has been recommended for Mercedes-Benz. Vacuum up dirt such as crumbs or dust and For heavy soiling: use a cleaning agent recom- Do not use a microfibre cloth.
  • Page 401 398 Maintenance and care soap solution to clean the entire seat cover. Do not spot clean. Use cleaning and care products recommen- ded for Mercedes-Benz. Do not use oil-based cleaning and care prod- ucts.

  • Page 402: Breakdown Assistance 399

    Breakdown assistance 399 The maximum permissible number of washes Emergency is exceeded Removing the safety vest The fluorescence has faded Warning triangle ▌Removing the warning triangle Maximum number of washes Maximum wash temperature Do not bleach The safety vests are located in the stowage com- Do not iron partments in the driver's and front passenger Do not tumble dry...
  • Page 403 400 Breakdown assistance ▌Setting up the warning triangle First-aid kit (soft sided) overview This jeopardises the operating and road safety of the vehicle. The fire extinguisher can be flung around and injure the driver or other vehicle occupants. Always store and secure the fire extin- guisher in the bracket.

  • Page 404: Flat Tyre

    Breakdown assistance 401 In the event of a flat tyre, the following options are TIREFIT kit storage location Flat tyre available depending on your vehicle's equipment: Notes on flat tyres Plug-in hybrid Vehicles with a TIREFIT kit: you can repair the tyre so that it is possible to continue the jour- &...
  • Page 405 402 Breakdown assistance Not plug-in hybrid You can find information on the power cate- & WARNING Risk of accident when using gory (LK) and/or electrical data on the back tyre sealant of the tyre inflation compressor. The tyre sealant may be unable to seal the The tyre inflation compressor is maintenance- tyre properly, especially in the following cases: free.
  • Page 406 Breakdown assistance 403 Comply with the manufacturer's safety notes on Observe the following if you come into contact the sticker on the tyre inflation compressor. with the tyre sealant: Have the tyre sealant bottle replaced in a qualified Rinse off the tyre sealant from your skin specialist workshop every five years.
  • Page 407 404 Breakdown assistance Do not switch off the tyre inflation compressor Pump up the tyre again. during this phase! After a maximum of ten minutes the tyre pres- sure must be at least 200 kPa (2.0 bar/ Let the tyre inflation compressor run for a 29 psi).
  • Page 408 Adapt your driving style accordingly and Have the tyre sealant bottle disposed of Do not continue driving. drive carefully. professionally, e.g. at a Mercedes-Benz Consult a qualified specialist workshop. Service Centre. Do not exceed the maximum speed limit with a tyre that has been repaired using Countries that have Mercedes-Benz Service24h: Switch off the tyre inflation compressor.

  • Page 409: Battery (Vehicle)

    Mercedes-Benz. Work carried out incorrectly on the battery All vehicles except vehicles with a lithium-ion bat- can, for example, lead to a short circuit. This...
  • Page 410 Alternatively: connect the battery to a battery rubbish. Avoid contact with the skin, eyes or cloth- charger approved by Mercedes-Benz or con- ing. Wear suitable protective clothing, in sult a qualified specialist workshop to discon- particular gloves, an apron and a face nect the battery.
  • Page 411 Mercedes-Benz. Work carried out incorrectly on the battery Fire, naked flames and smoking are pro- can, for example, lead to a short circuit. This ENVIRONMENTAL NOTE Environmental hibited when handling the battery.
  • Page 412 Breakdown assistance 409 Keep children away. During starting assistance, always take * NOTE Damage to the battery due to over- care to connect only battery terminals of voltage identical polarity. Wear safety glasses. When charging using a battery charger without During starting assistance, observe the a maximum charging voltage, the battery or sequence described for connecting and...
  • Page 413 Only use battery chargers tested and In this case you may neither jump-start the vehi- Avoid numerous and extended attempts approved for Mercedes-Benz. cle nor charge the battery. to start the engine. Read the battery charger's operating instruc- The service life of a battery that has been thawed tions before charging the battery.
  • Page 414 Breakdown assistance 411 Vehicles with a petrol engine: jump-start the Open cover of the jump-starting connec- using the jump lead. Always begin with posi- vehicle only when the engine and exhaust sys- tive contact on your own vehicle first. tion points. tem are cold.
  • Page 415 406). Fit any existing or supplied cell caps. charging cable. Always begin with positive Mercedes-Benz recommends that you have the Otherwise, gases or battery acid could contact of the vehicle. 12 V battery replaced at a qualified specialist escape.

  • Page 416: Tow-Starting Or Towing Away

    HOLD function Front axle Permitted towing methods (plug-in hybrid) Active Parking Assist raised Mercedes-Benz recommends transporting your To avoid damage to the vehicle, deactivate Rear axle Yes, if the steering wheel is vehicle in the case of a breakdown, rather than...
  • Page 417 414 Breakdown assistance Observe the information on towing and transport- Vehicles with rear wheel drive Towing the vehicle with both axles on the ground ing the vehicle in the vehicle Owner's Manual. Permitted towing methods Observe the notes on the permitted towing In the following situations, only transporting the methods.
  • Page 418 Breakdown assistance 415 Deactivate tow-away protection towed away exceeds the permissible * NOTE Damage due to towing away at page 103). gross mass. excessively high speeds or over long dis- Deactivate Active Brake Assist ( page 269). tances If a vehicle has to be tow-started or towed away, Vehicles with automatic transmission: shift to The drivetrain could be damaged when towing its permissible gross mass must not exceed the...
  • Page 419 416 Breakdown assistance Shift the automatic transmission to position Make sure that the front and rear axles come Make sure that the steering wheel can to rest on the same transportation vehicle. move freely before towing the vehicle away. The automatic transmission may be locked in * NOTE Damage to the drive train due to position j in the event of damage to the incorrect positioning of the vehicle...

  • Page 420: Electrical Fuses

    Breakdown assistance 417 Fitting and removing the towing eye Make sure that cover engages in the Vehicles with automatic transmission bumper when you remove the towing eye. must not be tow-started. * NOTE Damage to the vehicle due to incor- Vehicles with an automatic transmission must rect use of the towing eye or trailer hitch not be tow-started.
  • Page 421 418 Breakdown assistance Opening and closing the fuse box in the engine When closing the fuse box, make sure * NOTE Damage due to incorrect fuses compartment that the seal of the lid is positioned cor- Using incorrect fuses can result in damage to rectly on the fuse box.
  • Page 422 Mercedes-Benz recommends you have the Loosen screws and remove fuse box lid fuse box opened at a Mercedes-Benz Service from the top. Centre. Closing Check whether the seal is positioned correctly...
  • Page 423 420 Breakdown assistance Opening and closing the fuse box in the front Opening and closing the fuse box in the load com- passenger footwell partment Observe the notes on electrical fuses Observe the notes on electrical fuses page 417). page 417). Remove cover 1.

  • Page 424: Wheels And Tyres 421

    Wheels and tyres 421 Visually inspect wheels and tyres for damage. Notes on noise or unusual handling characteris- & WARNING Risk of aquaplaning due to tics Check the valve caps. insufficient tyre tread Make sure there are no vibrations, noises or Visual check of the tyre tread depth and the Insufficient tyre tread will result in reduced unusual handling characteristics when the vehicle...

  • Page 425: Activating Or Deactivating Snow Chain Mode

    For safety reasons, only use snow chains that steering and braking characteristics may © ß have been specifically approved for your vehi- be greatly impaired. cle by Mercedes-Benz, or snow chains with Activate or deactivate Snow chain mode. the same quality standard. Comply with the recommended tyre...
  • Page 426 Wheels and tyres 423 Notes on trailer operation monthly If you are unable to rectify the damage, Always inflate the rear axle tyres to the recom- contact a qualified specialist workshop. when the load changes mended tyre pressures on the tyre pressure table before embarking on a longer journey for increased load.
  • Page 427 424 Wheels and tyres The tyre pressure table shows the recommended Tyre pressure monitoring system System limits tyre pressure for all tyres approved for this vehi- The system may be impaired or may not function ▌Function of the tyre pressure monitoring sys- cle.
  • Page 428 Wheels and tyres 425 The values displayed in the driver's display Swipe downwards on Touch Control on the may deviate from those of the tyre pressure steering wheel. gauge as they refer to sea level. At high eleva- Use current tyre pressures as new refer- tions, the tyre pressure values indicated by a ence values? message is shown in the driver's...

  • Page 429: Wheel Change

    Notes on selecting, fitting and replacing tyres city or the permissible speed rating MO1 = Mercedes-Benz Original (only cer- & WARNING Risk of accident due to incor- tain AMG tyres) Exceeding the load-bearing capacity of the...
  • Page 430 Accessory parts which are not approved for your Do not use used tyres if you have no * NOTE Damage to electronic component vehicle by Mercedes-Benz, or which are not used information about their previous usage. parts due to the use of tyre-fitting tools correctly, can impair the operating safety.
  • Page 431 428 Wheels and tyres The use of shims or brake dust shields is not When replacing with tyres that do not feature Use i M+S tyres at outside tempera- permitted and may invalidate the vehicle's run-flat characteristics: vehicles with tures of less than 10 °C. general operating permit.
  • Page 432 Wheels and tyres 429 Notes on interchanging wheels Do not drive with tyres that have too little tread Required tyre-changing tools may include, depth. This significantly reduces traction on wet forexample: & WARNING Risk of injury through different roads (aquaplaning). Jack wheel sizes On vehicles with the same front and rear wheel...
  • Page 433 430 Wheels and tyres The tyre-change tool kit includes the following: Shift the transmission to position j. Aluminium hub cap Jack Vehicles with AIRMATIC: set the normal vehi- cle level ( page 284). Wheel wrench Switch off the vehicle. Wheel studs Make sure that the vehicle cannot be started.
  • Page 434 430). Important notes on using the jack: Use only a vehicle-specific jack that has been approved by Mercedes-Benz to raise the vehi- cle. The jack is only designed for raising and hold- ing the vehicle for a short time while a wheel...
  • Page 435 432 Wheels and tyres * NOTE Damage to the vehicle due to the jack If you do not position the jack at the jack sup- port points provided for this purpose, you could damage your vehicle. Only position the jack at the jack sup- port points provided for this purpose.
  • Page 436 Wheels and tyres 433 Removing a wheel & WARNING Risk of accident from losing a wheel Requirements: The vehicle is raised ( page 431). Oiled or greased wheel bolts can cause the wheel bolts to come loose, as too can dam- When changing a wheel, avoid applying any force aged wheel bolts or wheel hub threads.
  • Page 437 Be sure to observe the instructions and safety level. notes on "Changing a wheel" ( page 426). Remove the jack from under the vehicle. For safety reasons, only use wheel bolts which have been approved by Mercedes-Benz and for the wheel in question.

  • Page 438: Emergency Spare Wheel

    Wheels and tyres 435 & WARNING Risk of accident due to incor- Emergency spare wheel shop. The new wheel must have the cor- rect dimensions. rect tightening torque Notes on the emergency spare wheel The wheels could come loose if the wheel The emergency spare wheel is fastened in the &...
  • Page 439 436 Wheels and tyres Vehicles with a tyre pressure monitoring sys- tem: if an emergency spare wheel is fitted, the tyre pressure monitoring system cannot func- tion reliably. For a few minutes after an emer- gency spare wheel is fitted, the system may still display the tyre pressure of the removed wheel.

  • Page 440: Technical Data 437

    The exterior aerial is fitted incorrectly or is & WARNING Risk of accident due to vehicles with standard equipment. You can obtain not a low-reflection aerial. further information from a Mercedes-Benz Service improper work on two-way radios This could jeopardise the operating safety of Centre.
  • Page 441 438 Technical data retrofitting two-way radios. Comply with the legal Frequency band Maximum transmis- requirements for detachable parts. sion output If your vehicle has fittings for two-way radio equip- Two-way radio ment, use the power supply and aerial connectors provided in the pre-installation. Observe the man- ufacturer's supplements when fitting.

  • Page 442: Regulatory Radio Identification And Notes

    Technical data 439 Further component-specific information Regulatory radio identification and notes Vehicle identification plate, VIN and engine num- ber overview Further component-specific information can be Regulatory radio identification of small compo- found using the key phrase "further component- nents Vehicle identification plate specific information"...
  • Page 443 440 Technical data Maximum permissible gross weight of vehicle combination (kg) (only for specific countries) Maximum permissible front axle load (kg) Maximum permissible rear axle load (kg) Paint code The data shown in the illustration is example data. Vehicle identification plate (example: Kuwait) Vehicle identification plate (example: all other countries) Vehicle manufacturer...

  • Page 444: Operating Fluids

    Technical data 441 VIN below the front right-hand seat VIN at the lower edge of the windscreen Operating fluids Notes on operating fluids & WARNING Risk of injury from operating fluids harmful to your health Operating fluids may be poisonous and harm- ful to your health.
  • Page 445 Further information on approved operating fluids: Dispose of operating fluids in an environ- Keep children away from fuel. mentally responsible manner. in the Mercedes-Benz Specifications for Oper- Keep doors and windows closed during ating Fluids by entering the designation the refuelling process.
  • Page 446 Technical data 443 Flexible-fuel vehicles can be identified by the Fuel of this specification may contain up to Ethanol up to E85 sticker on the inside of the fuel 10% ethanol by volume. Your vehicle is suita- filler flap. ble for use with E10 fuel. Depending on the country, the fuels you can use See the information label in fuel filler flap in your vehicle may differ from the information in...
  • Page 447 Only refuel using sulphur-free diesel fuel fuel filler flap ( page 206). ommended by Mercedes-Benz. Observe the notes that conforms to European standard and mixing ratios indicated on the tank. Never refuel using petrol with a lower RON.
  • Page 448 Technical data 445 According to European standard EN 16942 you Total fuel tank capacity Do not switch on the vehicle. can find the compatibility indications at the fol- Model Consult a qualified specialist workshop. lowing locations: All models 62.0 litres On the vehicle on the information label on the The following compatibility indications for fuel fuel filler flap (...
  • Page 449 446 Technical data ® ▌AdBlue ® AdBlue (vehicles with a diesel engine only) filling capacity and consumption * NOTE Damage and malfunctions due to ® impurities in AdBlue ▌Notes on AdBlue ® ® Total capacity of AdBlue tank Observe the notes on operating fluids ®...
  • Page 450 Technical data 447 Mercedes-Benz recommends having the oil ® The AdBlue range shown depends strongly changed at a qualified specialist workshop. on the driving style and operating conditions. The actual range may therefore differ from the Only use engine oils approved for your vehicle by range currently displayed on the driver's dis- Mercedes-Benz.
  • Page 451 448 Technical data Engine oil specification (diesel engines) Engine oil filling capacity If the engine oils listed in the table are not available, you may add a maximum of 1.0 litre Model MB-Freigabe or MB- Model Capacity of the following engine oils once only. Approval Petrol: MB-Freigabe or MB-Approval 229.31 All models...
  • Page 452 Information on coolant is available at the fol- Proportion of antifreeze concentrate in the cool- lowing locations: ▌Notes on coolant ing system: In the Mercedes-Benz Specification for Observe the notes on operating fluids A minimum of 50% (antifreeze protection down Operating Fluids 320.1 page 441).

  • Page 453: Vehicle Data

    450 Technical data A maximum of 55% (antifreeze protection Only use windscreen washer fluids which Vehicle data down to -45°C) are also suitable for use on plastic surfa- Vehicle dimensions ces, e.g. MB SummerFit or MB WinterFit. The heights specified may vary as a result of the Notes on windscreen washer fluid following factors: * NOTE Blocked spray nozzles caused by...
  • Page 454 Technical data 451 Height when open and headroom Plug-in hybrid Weights and loads Model Height Headroom Please observe the following notes for the speci- Height when open and headroom (plug-in hybrid) when open fied vehicle data: Model Height Headroom Items of optional equipment increase the unla- when open All models 2149 mm...
  • Page 455 452 Technical data Off-road driving All fluids are topped up With driver in vehicle Also observe the notes on driving off-road, driving in mountainous terrain and fording ( page 187). On vehicles with AIRMATIC, loads up to the maxi- mum payload have no influence on the approach/ Fording departure angles.
  • Page 456 Technical data 453 Plug-in hybrid Standard: EN 62196-3 Design: FF Angle of approach/departure (plug-in hybrid) Plug type: charging cable socket and vehicle Model front rear plug Voltage range: 200 V to 920 V All models 23.2° 22.4° Missing values were not available at the time of going to press.

  • Page 457: Trailer Hitch

    454 Technical data content. Charging time –mode 4 applies to DC GLC 350 e 4MATIC All other models charging from 10 % to 80 % of the usable energy content. Charging time – mode approx. 2 h 15 min Charging time – mode approx.
  • Page 458 The overhang dimension and fastening points are Not for plug-in hybrid: valid for a trailer hitch installed at the factory. Towing capacity, braked Not for plug-in hybrid: Model Overhang dimension length GLC 200 4MATIC 2000 kg Model Overhang dimen- sion GLC 220 d 4MATIC 2500 kg...
  • Page 459 The tongue weight must not be below weight head 50 kg. GLC 200 4MATIC 80 kg Use a tongue weight that is as close as When attaching the 100 kg possible to the maximum permissible...
  • Page 460 Not for plug-in hybrid: GLC 350 e 4MATIC Axle load in when towing trailer GLC 400 e 4MATIC 1778 kg Model Axle load GLC 200 4MATIC 1411 kg GLC 220 d 4MATIC 1449 kg GLC 300 4MATIC 1410 kg GLC 300 d 4MATIC...

  • Page 461: 458 Display Messages And Warning/Indicator Lamps

    458 Display messages and warning/indicator lamps Display messages to be acknowledged can be hid- Display messages den by pressing the back button G or with the Introduction left-hand Touch Control. The display messages will then be stored in the message memory. ▌Information about display messages Display messages appear on the driver display.
  • Page 462 Display messages and warning/indicator lamps 459 Occupant safety Display messages Possible causes/consequences and Solutions * The restraint system is malfunctioning ( page 44). & WARNING Risk of injury due to malfunctions in the restraint system Restraint system malfunc- Components in the restraint system may be activated unintentionally or not deploy as intended in an accident. tion Consult workshop Have the restraint system checked and repaired immediately at a qualified specialist workshop.
  • Page 463 460 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * The corresponding restraint system is malfunctioning ( page 44). & WARNING Risk of injury due to malfunctions in the restraint system Components in the restraint system may be activated unintentionally or not deploy as intended in an accident. Front left malfunction Con- sult workshop (example)
  • Page 464 Display messages and warning/indicator lamps 461 Display messages Possible causes/consequences and Solutions * The corresponding restraint system is malfunctioning ( page 44). & WARNING Risk of injury or fatal injury due to a malfunction in the windowbag The windowbag might be triggered unintentionally or might not be triggered at all in the event of an accident. Left window airbag mal- function Consult work- Have the windowbag checked and repaired immediately at a qualified specialist workshop.
  • Page 465 462 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Front passenger airbag ena- * The front passenger airbag will be enabled while the vehicle is in motion in the following situations: bled See Owner's Manual even when a child, a small adult or an object weighing less than the system weight threshold is located on the front passenger seat even when the front passenger seat is not occupied The system may detect objects or forces that are adding to the weight applied to the seat.
  • Page 466 Display messages and warning/indicator lamps 463 Display messages Possible causes/consequences and Solutions PRE-SAFE inoperative See * The PRE‑SAFE ® functions are malfunctioning. Owner's Manual Consult a qualified specialist workshop. PRE-SAFE impulse side * The PRE‑SAFE ® Impulse Side system is malfunctioning or inoperative after having already been triggered. inoperative See Owner's Consult a qualified specialist workshop.
  • Page 467 464 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions ® * The key is currently undetected. Change the location of the key in the vehicle. Try to start the vehicle. Key not detected (white dis- If the key is still not detected, place it in the slot for starting with the key ( page 180).
  • Page 468 Display messages and warning/indicator lamps 465 Display messages Possible causes/consequences and Solutions ® * The vehicle is processing in order to teach in the new key. Wait until processing is complete. Key being taught in Please wait Place the key in the * Key detection is malfunctioning.
  • Page 469 466 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * The exterior lighting is malfunctioning. Consult a qualified specialist workshop. * Vehicles with a trailer hitch: a fuse may have blown. Malfunction See Owner's Stop the vehicle in accordance with the traffic conditions. Manual Check the fuses and replace them if necessary ( page 417).
  • Page 470 Display messages and warning/indicator lamps 467 Display messages Possible causes/consequences and Solutions * You are driving without low-beam headlamps. Turn the light switch to the L or à position. Switch on headlamps * You are leaving the vehicle and the lights are still switched on. Turn the light switch to theÃ...
  • Page 471 468 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Adaptive Highbeam Assist * Adaptive Highbeam Assist is temporarily unavailable. currently unavailable See The system limits have been reached ( page 148). Owner's Manual Once the cause of the problem is no longer present, the system will be available again. The Adaptive Highbeam Assist available again display message will appear.
  • Page 472 Display messages and warning/indicator lamps 469 Display messages Possible causes/consequences and Solutions Adaptive Highbeam Assist * Adaptive Highbeam Assist Plus is malfunctioning. Plus inoperative Drive on Stop the vehicle in accordance with the traffic conditions and restart the vehicle. If the display message does not disappear: consult a qualified specialist workshop. Until then, operate the high beam manually.
  • Page 473 470 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * The on-board electrical system voltage is too low. & The stationary heater has switched itself off. Drive an extended distance until the battery has reached a sufficient charge level again. Currently unavailable Bat- tery low * There is too little fuel in the fuel tank.
  • Page 474 Display messages and warning/indicator lamps 471 Display messages Possible causes/consequences and Solutions * The charge of the high-voltage battery is too low. Pre-entry climate control cannot be switched on. & Charge the high-voltage battery ( page 213). Currently unavailable Charge high-voltage battery * You have attempted to switch on pre-entry climate control more than twice with the vehicle switched off.
  • Page 475 472 Display messages and warning/indicator lamps Hybrid system Display messages Possible causes/consequences and Solutions * The drive system is malfunctioning. Have the vehicle transported only using a transporter or trailer ( page 413). Towing not permitted See Owner's Manual ò * The sound generator (acoustic vehicle warning system) is malfunctioning.
  • Page 476 Display messages and warning/indicator lamps 473 Display messages Possible causes/consequences and Solutions Request service personnel from the operator of the charging station via the emergency call button or the emer- gency numbers attached to the charging station. Vehicle not currently being * A malfunction has occurred in the charging station or the RFID card is not recognised.
  • Page 477 474 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Only electric drive availa- * The fuel tank is empty and the combustion engine is switched off. The output of your vehicle is limited because you ble Power limited are driving in electric mode.
  • Page 478 Display messages and warning/indicator lamps 475 Display messages Possible causes/consequences and Solutions * The high-voltage battery has overheated. There is a risk of fire. Û Stop the vehicle immediately in accordance with the traffic conditions. If possible, stop the vehicle in the open air and ensure that all vehicle occupants get out. Battery overheated Stop, Supporting vehicle functions may activate automatically, e.g.
  • Page 479 476 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Consult a qualified specialist workshop and do not change the transmission position. * A function restriction has occurred in the drive system. Û Consult a qualified specialist workshop. Have high-voltage system checked See Owner's Man- Consult workshop without...
  • Page 480 Display messages and warning/indicator lamps 477 Display messages Possible causes/consequences and Solutions If the display message appears again: Drive on carefully. Fully charge the high-voltage battery ( page 213). If the output and range are still reduced, there is a malfunction in the drive system. Drive on carefully.
  • Page 481 478 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Drive malfunction Achieva- * The drive system is malfunctioning. ble speed severely limited The maximum vehicle speed is restricted. See Owner's Manual Consult a qualified specialist workshop. * The drive system is malfunctioning. The output of your vehicle is restricted. Consult a qualified specialist workshop.
  • Page 482 Display messages and warning/indicator lamps 479 Display messages Possible causes/consequences and Solutions Drive on carefully. Consult a qualified specialist workshop. * Vehicles with petrol engines: the pressure in the fuel tank is reduced before the fuel filler flap is opened. This pressure reduction can take up to 15 minutes.
  • Page 483 480 Display messages and warning/indicator lamps Vehicle Display messages Possible causes/consequences and Solutions * The driver's display is inoperative due to a failed software update. The display message will be shown every time the engine is started. & WARNING Risk of accident if the driver display fails If the driver display has failed or is malfunctioning, function restrictions in systems relevant to safety cannot be detected.
  • Page 484 Display messages and warning/indicator lamps 481 Display messages Possible causes/consequences and Solutions Have the vehicle checked by a qualified specialist workshop immediately. * You are leaving the vehicle in a ready-to-drive state. Get out of the vehicle, secure it against rolling away and take the key with you. If you do not leave the vehicle, switch off the electrical consumers, e.g.
  • Page 485 482 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions ï * The ball neck will not swivel because transmission position h, k or neutral i is selected. Depress the brake pedal. Engage park position j. Operation only possible in transmission position P ï...
  • Page 486 Display messages and warning/indicator lamps 483 Display messages Possible causes/consequences and Solutions If the display message does not disappear, the trailer hitch is malfunctioning and the ball neck is not locked. Do not couple up the trailer. Drive on without the trailer. Note the reduced ground clearance due to the unlocked ball neck.
  • Page 487 484 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Head-up display currently * The head-up display is temporarily unavailable. Possible causes: unavailable See Owner's malfunctions in the power supply Manual signal interference Stop in accordance with the traffic conditions and switch the vehicle off and on again. If the display message still appears, consult a qualified specialist workshop.
  • Page 488 Display messages and warning/indicator lamps 485 Display messages Possible causes/consequences and Solutions Ù * A power steering malfunction has occurred. Steering characteristics may be impaired as a result. Drive on carefully. Consult a qualified specialist workshop. Steering malfunction Drive carefully Visit workshop Ù...
  • Page 489 486 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Ù * The rear-axle steering is temporarily unavailable. The turning circle may become wider. Stop the vehicle in accordance with the traffic conditions and restart the vehicle. If the display message does not disappear: Rear axle steering cur- rently malfunctioning Drive on carefully.
  • Page 490 Display messages and warning/indicator lamps 487 Display messages Possible causes/consequences and Solutions Pull over and stop the vehicle safely as soon as possible, paying attention to road and traffic conditions. Do not continue driving under any circumstances. Consult a qualified specialist workshop. When stopping, bear the enlarged vehicle width in mind.
  • Page 491 488 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * The tailgate is open. & DANGER Risk of poisoning from exhaust gases Combustion engines emit poisonous exhaust gases, such as carbon monoxide. Exhaust gases can enter the vehi- cle interior if the tailgate is open when the engine is running, especially if the vehicle is in motion.
  • Page 492 Display messages and warning/indicator lamps 489 Display messages Possible causes/consequences and Solutions Restart the vehicle. If the display message still appears: Consult a qualified specialist workshop. Engine Display messages Possible causes/consequences and Solutions To switch off the vehicle, * You have pressed the start/stop button while the vehicle is in motion. press the Start/Stop but- Information about switching off the vehicle while driving ( page 180).
  • Page 493 490 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * The coolant level is too low. * NOTE Engine damage due to insufficient coolant Top up coolant See Own- Avoid long journeys with insufficient coolant. er’s Manual Add coolant ( page 389).
  • Page 494 Display messages and warning/indicator lamps 491 Display messages Possible causes/consequences and Solutions Make sure that the air supply to the radiator is not obstructed. Avoiding high loads on the engine, drive to the nearest qualified specialist workshop. In doing so, ensure that the coolant temperature display remains below 120°C.
  • Page 495 492 Display messages and warning/indicator lamps Transmission Display messages Possible causes/consequences and Solutions Only select P when vehicle * It is possible to select the park position j only if the vehicle is stationary. is stationary Depress the brake pedal to stop. Shift the transmission to park position j when the vehicle is stationary.
  • Page 496 Display messages and warning/indicator lamps 493 Display messages Possible causes/consequences and Solutions Select transmission position k. Apply parking brake to * A malfunction has occurred in the emergency power supply to park position j. park Visit workshop Consult a qualified specialist workshop. Until then, always select park position j manually before you switch off the vehicle.
  • Page 497 494 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions The vehicle may roll away. Be ready to brake. Do not leave the vehicle unattended. Depress the brake pedal until the vehicle comes to a standstill. Engage park position j when the vehicle is stationary with the brake pedal depressed. To continue driving with the brake pedal depressed, select transmission position h or k.
  • Page 498 Display messages and warning/indicator lamps 495 Display messages Possible causes/consequences and Solutions Depress the brake pedal. Engage park position j. Consult a qualified specialist workshop. Consult workshop without * The transmission is malfunctioning. It is no longer possible to change the transmission position. changing the transmission If transmission position h is selected, consult a qualified specialist workshop and do not change the transmission position...
  • Page 499 496 Display messages and warning/indicator lamps Brakes Display messages Possible causes/consequences and Solutions * The yellow ! indicator lamp is lit. The electric parking brake is malfunctioning. To apply: Switch the vehicle off and switch it back on Parking brake See Owner's Apply the electric parking brake manually ( page 234).
  • Page 500 Display messages and warning/indicator lamps 497 Display messages Possible causes/consequences and Solutions The electric parking brake could not be applied or released. Switch the vehicle off and switch it back on. To apply: Release and then apply the electric parking brake manually ( page 234).
  • Page 501 498 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions If it is not possible to apply the electric parking brake: Consult a qualified specialist workshop. Where necessary, also secure the parked vehicle against rolling away. To release: If the conditions for automatic release are fulfilled and the electric parking brake is not released automatically, release the electric parking brake manually ( page 234).
  • Page 502 Display messages and warning/indicator lamps 499 Display messages Possible causes/consequences and Solutions * The red ! indicator lamp is lit. You have attempted to release the electric parking brake with the vehicle switched off. Switch on the vehicle. Parking brake Switch on vehicle to release * A malfunction has occurred while the HOLD function was activated.
  • Page 503 500 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * The brake force boosting function is impaired and the braking characteristics may be affected. & WARNING Risk of accident and injury if brake force boosting is malfunctioning If brake force boosting is malfunctioning, increased brake pedal force may be necessary for braking.
  • Page 504 Display messages and warning/indicator lamps 501 Driving systems Display messages Possible causes/consequences and Solutions ë * The HOLD function is deactivated because the vehicle is slipping or a condition for activation is not fulfilled. Reactivate the HOLD function later or check the activation conditions for the HOLD function ( page 243).
  • Page 505 502 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Cruise control off * Cruise control has been deactivated. If there is an additional warning tone, cruise control has been deactivated automatically ( page 246). È * The limiter can temporarily not be engaged. Once the cause of the problem is no longer present, the system will be available again.
  • Page 506 Display messages and warning/indicator lamps 503 Display messages Possible causes/consequences and Solutions ç * If you depress the accelerator pedal beyond the setting of Active Distance Assist DISTRONIC, the system will switch to passive mode ( page 249). suspended ç * Active Distance Assist DISTRONIC was deactivated.
  • Page 507 504 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Stop the vehicle in accordance with the traffic conditions and restart the vehicle. If the display message does not disappear: consult a qualified specialist workshop. Active Distance Assist * Active Distance Assist DISTRONIC is operational again.
  • Page 508 Display messages and warning/indicator lamps 505 Display messages Possible causes/consequences and Solutions ð * You have exceeded the maximum permissible speed (for certain countries only). Drive more slowly. Maximum speed exceeded î * The Downhill Speed Regulation is malfunctioning. Consult a qualified specialist workshop. inoperative î...
  • Page 509 506 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Active Steering Assist cur- * Active Steering Assist is temporarily unavailable. rently unavailable See Own- The ambient conditions are outside the system limits ( page 258). er's Manual As soon as the ambient conditions are within the system limits, the system will become available again.
  • Page 510 Display messages and warning/indicator lamps 507 Display messages Possible causes/consequences and Solutions Ø * Your hands are not on the steering wheel. Active Steering Assist will initiate an emergency stop ( page 258). Put your hands on the steering wheel. Information on cancelling an emergency stop ( page 261).
  • Page 511 508 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Stop the vehicle in accordance with the traffic conditions and restart the vehicle. If the display message does not disappear: consult a qualified specialist workshop. Active Lane Change Assist * Active Lane Change Assist is temporarily unavailable.
  • Page 512 Display messages and warning/indicator lamps 509 Display messages Possible causes/consequences and Solutions Active Stop-and-Go Assist * Active Stop-and-Go Assist is malfunctioning. inoperative See Owner's Active Stop-and-Go Assist has been deactivated. Active Distance Assist DISTRONIC and Active Steering Assist are still Manual available.
  • Page 513 510 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Drive on If the display message does not disappear, stop the vehicle in accordance with the traffic conditions and restart the vehicle. Blind Spot Assist inopera- * Blind Spot Assist is malfunctioning. tive Drive on Stop the vehicle in accordance with the traffic conditions and restart the vehicle.
  • Page 514 Display messages and warning/indicator lamps 511 Display messages Possible causes/consequences and Solutions Active Blind Spot Assist * Active Blind Spot Assist is malfunctioning. inoperative Drive on Stop the vehicle in accordance with the traffic conditions and restart the vehicle. If the display message does not disappear: consult a qualified specialist workshop. Active Blind Spot Assist * When you establish the electrical connection to the trailer, Active Blind Spot Assist will be unavailable.
  • Page 515 512 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Ø * Your hands are not on the steering wheel. The Active Lane Keeping Assist will initiate an emergency stop page 279). Put your hands on the steering wheel. Beginning emergency stop Information on cancelling an emergency stop ( page 261).
  • Page 516 Display messages and warning/indicator lamps 513 Display messages Possible causes/consequences and Solutions ¸ * Front and corner radar sensors (hereafter "sensors") are malfunctioning. Possible causes: The sensors are dirty Heavy rain or snow ð Extended country driving without other traffic, e.g. in the desert Driving systems and driving safety systems may be malfunctioning or temporarily unavailable.
  • Page 517 514 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions á * The view of the multifunction camera is restricted. Possible causes: Dirt on the windscreen in the field of vision of the multifunction camera Heavy rain, snow or fog ð...
  • Page 518 Display messages and warning/indicator lamps 515 Display messages Possible causes/consequences and Solutions ð * When the trailer socket is occupied, some driving systems will be available only to a limited extent. Drive carefully if you are towing a trailer or have the bicycle rack mounted. ¸...
  • Page 519 516 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions  * The vehicle level will lower for the following reasons: You have selected a different drive program. You have exceeded the speed limit. Lowering You have changed the vehicle level by pressing the button. Operation with a trailer or bicycle rack: if an electrical connection has been correctly made, you have exceeded the speed limit.
  • Page 520 Display messages and warning/indicator lamps 517 Display messages Possible causes/consequences and Solutions If the display message does not disappear and a warning tone also sounds, AIRMATIC is malfunctioning: Do not drive at speeds greater than 80 km/h and consult a qualified specialist workshop immediately. * NOTE The tyres on the front axle or the fenders could be damaged by large steering movements Avoid large steering movements while driving and listen for scraping sounds.
  • Page 521 518 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions PARKTRONIC inoperative * Parking Assist PARKTRONIC is malfunctioning. See Owner's Manual Once the cause of the problem is no longer present, the system will be available again. Continue driving while paying attention to the vehicle's surroundings. Stop the vehicle in accordance with the traffic conditions and restart the vehicle.
  • Page 522 Display messages and warning/indicator lamps 519 Display messages Possible causes/consequences and Solutions Limited availability of * Active Parking Assist’s manoeuvring assistant is temporarily unavailable or only partially available. Active Parking Assist Clean all sensors of the parking and camera system ( page 394).
  • Page 523 520 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * ABS and ESP ® are malfunctioning. Other driving systems and driving safety systems (e.g. BAS) may also be malfunctioning. The brake system will continue to operate normally. Braking distance may increase in an emergency braking situation. ÷...
  • Page 524 Display messages and warning/indicator lamps 521 Display messages Possible causes/consequences and Solutions If the display message does not disappear, consult a qualified specialist workshop immediately. Drive care- fully. ÷ * ESP ® is malfunctioning. Other driving systems and driving safety systems (e.g. BAS) may also be malfunctioning. The brake system will continue to operate normally.
  • Page 525 522 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * EBD, ABS and ESP ® are malfunctioning. Other driving systems and driving safety systems (e.g. BAS) may also be malfunctioning. & WARNING Risk of skidding if EBD, ABS and ESP ®...
  • Page 526 Display messages and warning/indicator lamps 523 Display messages Possible causes/consequences and Solutions Drive on carefully. As soon as the ambient conditions are within the system limits, the system will become available again. If the display message does not disappear, stop the vehicle in accordance with the traffic conditions and restart the vehicle.
  • Page 527 524 Display messages and warning/indicator lamps Mercedes-Benz emergency call system Display messages Possible causes/consequences and Solutions * The Mercedes-Benz emergency call system is malfunctioning. The Mercedes me connect system is also malfunction- ing. Consult a qualified specialist workshop. Inoperative Battery...
  • Page 528 Display messages and warning/indicator lamps 525 Display messages Possible causes/consequences and Solutions Consult a qualified specialist workshop. Stop the vehicle immediately in accordance with the traffic conditions. Do not continue driving. Switch off the vehicle. Consult a qualified specialist workshop. * The vehicle is off and the state of charge of the 12 V battery is too low.
  • Page 529 526 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * The 48 V on-board electrical system is malfunctioning. Û Stop the vehicle immediately in accordance with the traffic conditions. Do not continue driving. Switch off the vehicle. Stop vehicle See Owner's Consult a qualified specialist workshop.
  • Page 530 * The state of charge of the 48 V battery is too low. You can no longer start the vehicle. Owner's Manual Switch off electrical consumers that are not required. Connect a suitable charger approved for Mercedes-Benz with sufficient charge output to the jump-start connection point of the 12 V battery ( page 411).
  • Page 531 528 Display messages and warning/indicator lamps Tyre pressure monitor Display messages Possible causes/consequences and Solutions Tyre press. monitor cur- * There is interference from a powerful radio signal source As a result, no signals from the tyre pressure sensors are rently unavailable being received.
  • Page 532 Display messages and warning/indicator lamps 529 Display messages Possible causes/consequences and Solutions é * The tyre pressure in one or more tyres has dropped significantly. The wheel position is displayed. A warning tone will also sound. & WARNING Risk of an accident due to insufficient tyre pressure Check tyre(s) The tyres can burst.
  • Page 533 530 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions é * The pressure in one or more tyres has dropped suddenly. The wheel position is displayed. & WARNING Risk of an accident from driving with a flat tyre The tyres can overheat and be damaged.
  • Page 534 Display messages and warning/indicator lamps 531 Display messages Possible causes/consequences and Solutions Reduce speed so that the tyres cool down. é * At least one tyre is overheating. The affected tyres are displayed in red. At temperatures close to the limit value, the tyres are displayed in yellow.
  • Page 535 532 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions Ø * The low AdBlue ® level will lead to limited performance after the remaining distance displayed has been covered. ® Top up AdBlue immediately ( page 211). Top up AdBlue Emergency op.
  • Page 536 Display messages and warning/indicator lamps 533 Display messages Possible causes/consequences and Solutions ¯ * The AdBlue ® system is malfunctioning. Consult a qualified specialist workshop immediately. AdBlue system fault See Owner's Manual ¯ * The AdBlue ® system is malfunctioning. Performance will be reduced once the remaining distance displayed has been covered.
  • Page 537 534 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions ¯ * The AdBlue ® system is malfunctioning. You can no longer start the vehicle. Consult a qualified specialist workshop immediately. AdBlue system fault Engine start not possible Ø...
  • Page 538 Display messages and warning/indicator lamps 535 Display messages Possible causes/consequences and Solutions ¯ * Plug-in hybrid: ® The AdBlue system is malfunctioning. The combustion engine will switch off after the remaining distance displayed. From this point on, the vehicle can be driven only in all-electric mode, depending on the state of charge of the high- AdBlue system malfunction voltage battery.
  • Page 539 536 Display messages and warning/indicator lamps Engine oil Display messages Possible causes/consequences and Solutions * The engine oil level has dropped to the minimum level. * NOTE Engine damage caused by driving with insufficient engine oil Add 1 litre engine oil when Avoid long journeys with insufficient engine oil.
  • Page 540 Display messages and warning/indicator lamps 537 Display messages Possible causes/consequences and Solutions Switch off the vehicle. Add 1 l of engine oil ( page 387). Check the engine oil level. Notes on engine oil ( page 447). * The oil pressure is too low. * NOTE Engine damage caused by driving with insufficient oil pressure Engine oil pressure Stop Avoid driving with insufficient oil pressure.

  • Page 541: Warning And Indicator Lamps

    538 Display messages and warning/indicator lamps Display messages Possible causes/consequences and Solutions * Vehicles with a diesel engine: the engine oil quality is no longer sufficient. Visit a qualified specialist workshop and have the oil changed. Engine oil Quality loss Oil change required Driver's display ü...
  • Page 542 ® OFF ( page 553) indicator ( page 545) Mercedes-Benz emergency call system Brakes H Mercedes-Benz emergency call system ! Electric parking brake (yellow) page 555) page 548) Tyre pressure monitoring system ! Electric parking brake (red) ( page 548)
  • Page 543 540 Display messages and warning/indicator lamps Occupant safety Warning/indicator lamp Possible causes/consequences and Solutions * The restraint system red warning lamp is lit while the vehicle is on. The restraint system is malfunctioning ( page 44). & WARNING Risk of injury due to malfunctions in the restraint system Restraint system warning Components in the restraint system may be activated unintentionally or not deploy as intended in an accident.
  • Page 544 Display messages and warning/indicator lamps 541 Warning/indicator lamp Possible causes/consequences and Solutions ü * The red seat belt warning lamp flashes and an intermittent warning tone sounds. The driver or front passenger has not fastened his/her seat belt while the vehicle is in motion. Fasten your seat belt ( page 47).
  • Page 545 542 Display messages and warning/indicator lamps Warning/indicator lamp Possible causes/consequences and Solutions *The red system error warning lamp is lit while the vehicle is in a state of operational readiness õ. Ú There is a malfunction in the drive system. Note the messages on the driver's display.
  • Page 546 Display messages and warning/indicator lamps 543 Warning/indicator lamp Possible causes/consequences and Solutions Initiate a new swivelling procedure and do not re-couple the trailer until the display message disappears. Note the messages on the driver's display. If the trailer hitch is swivelling: Wait until the ball neck has reached the operational position.
  • Page 547 544 Display messages and warning/indicator lamps Warning/indicator lamp Possible causes/consequences and Solutions Ù * The yellow rear axle steering warning lamp is lit while the vehicle is running. The rear axle steering is malfunctioning. Note the messages on the driver's display. Rear axle steering warning lamp (yellow) Ù...
  • Page 548 Display messages and warning/indicator lamps 545 Engine Warning/indicator lamp Possible causes/consequences and Solutions ÿ * The red coolant warning lamp is lit while the engine is running. Possible causes: The temperature sensor is malfunctioning Coolant warning lamp (red) The coolant level is too low The air supply to the radiator is obstructed The radiator fan is faulty The engine coolant pump is faulty...
  • Page 549 546 Display messages and warning/indicator lamps Warning/indicator lamp Possible causes/consequences and Solutions Note the messages on the driver's display. If the coolant temperature display is at the lower end of the temperature scale: Consult a qualified specialist workshop. If the coolant temperature display is at the upper end of the temperature scale: Exit the vehicle and keep a safe distance from it until the engine has cooled down.
  • Page 550 Display messages and warning/indicator lamps 547 Warning/indicator lamp Possible causes/consequences and Solutions * The yellow engine diagnostics warning lamp is lit while the engine is running. A malfunction has occurred in the engine, the exhaust system or the fuel system. The emissions limit value may have been exceeded and the engine may be running in emergency operation mode.
  • Page 551 548 Display messages and warning/indicator lamps Brakes Warning/indicator lamp Possible causes/consequences and Solutions * The red electric parking brake indicator lamp flashes or is lit. The yellow electric parking brake indicator lamp is also lit in the event of a malfunction. Note the messages on the driver's display.
  • Page 552 Display messages and warning/indicator lamps 549 Warning/indicator lamp Possible causes/consequences and Solutions If the driver's display shows a display message, observe it. Consult a qualified specialist workshop. * The red brake warning lamp is lit while the vehicle is running. Possible causes: The brake force boosting is malfunctioning and the braking characteristics may be affected.
  • Page 553 550 Display messages and warning/indicator lamps Warning/indicator lamp Possible causes/consequences and Solutions Do not top up the brake fluid. Driving systems Warning/indicator lamp Possible causes/consequences and Solutions Û * The ATTENTION ASSIST warning lamp is lit. ATTENTION ASSIST is malfunctioning. Consult a qualified specialist workshop.
  • Page 554 Display messages and warning/indicator lamps 551 Warning/indicator lamp Possible causes/consequences and Solutions * The red distance warning lamp lights up while the vehicle is in motion. The distance to the vehicle in front is too small for the speed selected. If there is an additional warning tone, you are approaching an obstacle at too high a speed.
  • Page 555 552 Display messages and warning/indicator lamps Warning/indicator lamp Possible causes/consequences and Solutions Æ * The Active Brake Assist warning lamp is on. After you drive off, the system's range of functions will be restricted due to the teach-in process. Depending on the ambient conditions, the teach-in process may take a few minutes. Active Brake Assist warning Observe the notes on Active Brake Assist ( page 265).
  • Page 556 Display messages and warning/indicator lamps 553 Driving safety systems Warning/indicator lamp Possible causes/consequences and Solutions * The yellow ABS warning lamp is lit while the vehicle is running. ABS is malfunctioning. If an additional warning tone sounds, EBD is malfunctioning. ABS warning lamp Other driving systems and driving safety systems may also be malfunctioning.
  • Page 557 554 Display messages and warning/indicator lamps Warning/indicator lamp Possible causes/consequences and Solutions ÷ * The yellow ESP ® warning lamp is lit while the vehicle is running. ® is malfunctioning. Other driving systems and driving safety systems (e.g. BAS) may also be malfunctioning. ®...
  • Page 558 Observe the notes on deactivating ESP page 240). Mercedes-Benz emergency call system Warning/indicator lamp Possible causes/consequences and Solutions *The Mercedes-Benz emergency call system is malfunctioning. The Mercedes me connect system is also malfunctioning. Consult a qualified specialist workshop. Mercedes-Benz emergency call system warning lamp...
  • Page 559 556 Display messages and warning/indicator lamps Tyre pressure monitor Warning/indicator lamp Possible causes/consequences and Solutions *The yellow tyre pressure monitor warning lamp (pressure loss/malfunction) flashes for approximately one minute and then remains lit. The tyre pressure monitoring system is malfunctioning. Tyre pressure monitoring &...
  • Page 560 Display messages and warning/indicator lamps 557 Warning/indicator lamp Possible causes/consequences and Solutions Stop the vehicle in accordance with the traffic conditions. Check the tyre pressure and the tyres.

  • Page 561: 558 Index

    558 Index Acoustic presence indicator, Sound gen- Active Lane Change Assist 1, 2, 3 ... erator............176 Activating/deactivating......264 48 V on-board electrical system Function..........262 Acoustic Vehicle Indication, Sound gener- Operating safety........22 ator.............. 176 Active Lane Keeping Assist Activating/deactivating......
  • Page 562 Index 559 Active Lane Change Assist..... 262 Fuel............444 Front airbag..........49 Function..........258 Overview..........49 After-sales service, ASSYST PLUS....382 PASSENGER AIR BAG indicator lamps..54 Active Stop-and-Go Assist Air conditioning menu Protection..........51 Function..........256 Air distribution........165 Reduced protection........
  • Page 563 560 Index Angle of approach/departure....... 452 Interior protection........104 Automatic mirror folding function....160 Tow-away protection......103 Animals, Pets in the vehicle......78 Automatic seat adjustment......112 ATTENTION ASSIST Anti-lock braking system, ABS...... 239 Automatic transmission Function..........244 Changing gear........202 Anti-theft alarm system, ATA......
  • Page 564 Adaptive brake lights......244 Battery operation, Plug-in hybrid operation... 176 Brakes ABS (Anti-lock Braking System)....239 Belt, Seat belt..........45 Calling the customer centre for Active Brake Assist......... 265 Bicycle rack Mercedes-Benz..........361 Adaptive brake lights......244 Load capacity........456...
  • Page 565 562 Index Calls Car parts..........394 Central locking system Mercedes me......... 360 Decorative foil........393 Button............. 85 Using overhead control panel....360 Display........... 396 Key............81 Exterior lighting........394 Camera Centre airbag (driver's backrest)....49 Head-up display........396 360° camera......... 289 Charge level display........
  • Page 566 Index 563 Starting the charging process (direct Seats suitable for i‑Size child restraint Paint............393 current, mode 4)........227 systems........... 67 Vehicle interior........396 Stowing the charging cable....216 Seats suitable for ISOFIX child Vehicle socket for the high-voltage USB port..........137 restraint systems........
  • Page 567 564 Index Fragrance system........167 Collision detection (parked vehicle) Cruise control Immediate pre-entry climate control..172 Information..........235 activating/deactivating......247 Inserting/removing the flacon (fra- Setting........... 235 Calling up a speed......... 247 grance system)........167 Function..........246 Combination switch Ionisation..........167 Requirements:........
  • Page 568 Index 565 Electronic control units......38 DIGITAL LIGHT Display (driver's display) Online services........41 Activating/deactivating......148 Overview of displays....... 323 Active light function....... 143 Deactivating the alarm......... 103 Display message Assistance functions......145 Calling up on driver display..... 458 Dealership............. 36 Bad weather light........
  • Page 569 566 Index AdBlue system fault See Own- Brake immediately......499 currently unavailable See Own- ¯ ÷ er's Manual..........533 á Camera view restricted See er's Manual..........520 AdBlue system malfunction Engine oil level cannot be meas- ¯ Owner's Manual........514 Emerg.
  • Page 570 Index 567 inoperative See Owner's Manual... 521 Û Malfunction........475 Please wait Depressurising fuel ÷ inoperative See Owner's Manual... 522 Max. speed 20km/h..... 516 tank............479 Á G Inoperative........524 î Max. speed 40 km/h....505 Pre-entry climate control via key &...
  • Page 571 568 Index ý Replace air filter......491 Stop vehicle See Owner's Man- Top up AdBlue XX,X l Switch Ø ual............524 vehicle on, wait 60 sec. or engine ® Replace key........463 Stop vehicle See Owner's Man- start not poss........532 Reserve fuel level......
  • Page 572 Index 569 "Electric" drive program currently Active Emergency Stop Assist inoper- Active Stop-and-Go Assist currently unavailable..........474 ative............507 unavailable see Owner's Manual..... 508 AC charging inoperative Consult work- Active Lane Change Assist currently Active Stop-and-Go Assist inoperative shop............473 unavailable See Owner's Manual....
  • Page 573 570 Index Auxiliary battery malfunction (white Consult workshop without starting the Head-up display currently unavailable display message)........495 vehicle again.......... 476 See Owner's Manual......484 Blind Spot Assist currently unavailable Cruise control and Limiter inoperative..501 Head-up display inoperative....484 See Owner's Manual......
  • Page 574 Index 571 PARKTRONIC and manoeuvring assis- Risk of vehicle rolling away Apply Tyre press. monitor currently unavaila- tant unavailable at rear when towing a parking brake to park......493 ble............528 trailer............. 518 Risk of vehicle rolling away Driver's Tyre press. monitor inoperative....
  • Page 575 572 Index Child safety lock (rear door)..... 77 Warning/indicator lamps....10, 538 Off-road ABS.......... 240 Emergency key......... 87 On radar and ultrasonic sensors..... 237 Driver's seat Opening (from the inside)......85 Overview..........238 Adjusting (Seat Comfort)......106 Unlocking (inside)........85 STEER CONTROL........
  • Page 576 Index 573 ECO display..........191 Warning triangle........400 ® Dynamic handling control system, ESP ..240 ECO start/stop button Emergency braking DYNAMIC SELECT Automatic engine start/stop....191 Active Brake Assist......... 265 Calling up the fuel consumption indi- Brake Assist System....... 240 cator............
  • Page 577 574 Index Engine number........439 ERA-GLONASS test mode......375 Favourites............ 336 Starting assistance........ 409 Error message Film covering Switching off, start/stop button..... 231 Driver's display........458 On cameras/sensors......237 Tow-starting........... 417 On radar and ultrasonic sensors..... 237 ESC, Electronic Stability Control....240 Engine data Fire extinguisher..........
  • Page 578 Index 575 Inserting/removing the flacon....167 Refilling..........206 General driving tips........183 Perfume vial........... 167 Reserve..........445 Genuine parts..........20 Setting........... 167 Sulphur content........443 Glide mode..........205 Tank content.......... 445 Free software, Open Source Software..... 42 Glove compartment........123 Fuel consumption indicator......
  • Page 579 4)........227 Immediate pre-entry climate control..... 172 Stowing the charging cable....216 Help call Immobiliser..........102 Type............453 Mercedes-Benz emergency call system.. 371 Implied warranty..........38 Voltage types......... 453 High beam Wallbox, mode 3........218 Importer addresses Activating/deactivating......142 Wireless components.......
  • Page 580 Index 577 Individual drive program Web browsers........368 Locking/unlocking the vehicle....85 Configuring..........200 Problem........... 86 Ionisation............. 167 Unlocking setting........81 Inside rearview mirror, Rear-view mirror..158 ISOFIX child seat anchor Kickdown Intelligent Light System Fitting............67 Using............. 205 Activating/deactivating......148 Suitable seats..........
  • Page 581 578 Index Level regulation Locator lighting........151 Storing a speed........247 Suspension..........282 Low beam..........140 LINGUATRONIC, MBUX voice assistant..333 Motorway mode........144 Licence plate, front assembly......25 Live Traffic Information, Traffic information... 354 Off-road light.......... 145 Light adjustment Load capacity Parking lights.........
  • Page 582 Index 579 KEYLESS-GO..........85 Maintenance, ASSYST PLUS......382 Massage programme........113 Mercedes me connect......84 Maintenance Management Massage programmes........113 Loud sound Notes............. 383 Maximum full-stop braking, Brake Transferred data........383 ® PRE-SAFE Sound........57 Assist System..........240 Malfunction Low beam Maximum permissible gross vehicle weight...
  • Page 583 580 Index Telephone..........357 Calling the Mercedes-Benz Customer Mirror heater..........168 Touchscreen.......... 331 Centre after automatic accident/ Mirrors Zero layer..........326 breakdown detection......362 Mirror folding function......160 Calls via the overhead control panel..360 MBUX voice assistant Outside mirrors........157 Consenting to the transfer of data..
  • Page 584 Index 581 Opening angle Parking position........159 Limiting (tailgate)........93 Setting........... 157 Occupant safety, Restraint system Warning lamp......... 276 Opening the tailgate using your foot Airbag............49 HANDS-FREE ACCESS......91 Overhead control panel........12 Automatic front passenger airbag shut Operating fluids Overview of airbags........
  • Page 585 582 Index Adjusting warning tones......299 Personalisation Notes on plug-in hybrid operation... 176 Function..........296 User profiles.......... 334 Operating safety........22 Route-based operating-mode strategy..196 Parking assistance systems Petrol............443 Sets recuperation........194 Active Parking Assist......299 Pets in the vehicle, Occupant safety....78 Starting the charging process (alter- Drive Away Assist........
  • Page 586 Index 583 Optimised acceleration......183 Rear axle steering........187 ® PRE-SAFE , Anticipatory occupant protection Function..........57 Rear compartment climate control....165 ® PRE-SAFE Sound........57 Rear door (child safety lock) Reversing measures......... 57 QR code rescue card........38 Securing..........77 ®...
  • Page 587 584 Index Reducing agent Responsibility Roller sunblind ® Driving safety systems......237 Side windows......... 102 AdBlue ..........211 Sliding sunroof......... 98 Restraint system Refuelling Basic instructions for children....59 Roof load............. 451 Depressurising the fuel tank (plug-in Function in the event of an accident..44 hybrid with petrol engine).......
  • Page 588 Index 585 Route-based speed adaptation, DISTRONIC Massage programme......113 Seat heating..........113 Function..........255 Memory function........120 Seat height..........108 Setting........... 256 Resetting the settings......113 Seat ventilation..........114 Settings........... 14 Running boards Selecting a gear........... 204 Side airbag..........49 Care............
  • Page 589 Opening with the key........ 96 Sound generator, Acoustic presence indi- Hill Start Assist........244 Opening/closing........98 cator............176 Optimised acceleration......182 Problem..........101 Spare parts, Mercedes-Benz GenuineParts..20 Start/stop button Rain closing function......100 Spare wheel Parking the vehicle......... 231 ® Smartphone Integration, iPhone Emergency spare wheel......
  • Page 590 Index 587 Starter battery Steering wheel Level regulation........282 Charging via Remote Online....181 Adjusting electrically......116 Setting the suspension level (AIR- Driver's airbag......... 49 MATIC)........... 284 Starting assistance........411 Manually adjusting......... 115 SVHC Starting the engine Memory function........120 Substances of very high concern....
  • Page 591 588 Index Tank content Telemetry display TIREFIT kit ® Calling up..........346 Declaration of conformity......34 AdBlue ..........446 Storage location........401 Fuel............445 Telephone Reserve..........445 Tongue weight..........456 ® Bluetooth ..........360 Technical data Connecting a mobile phone/Secure Top Tether............
  • Page 592 Index 589 Towing away Trailer hitch Making settings........315 Both axles on the ground....... 414 Axle load..........457 Notes............. 310 Bicycle rack........... 315 Socket........... 312 Towing eye........... 416, 417 Care............394 ® Trailer stabilisation, ESP ......242 Towing methods Coupling up/uncoupling a trailer.... 312 Overview..........
  • Page 593 590 Index Tyre pressure monitoring system Tyre pressure table......... 423 Collision detection......... 235 Function..........424 Unusual handling characteristics.... 421 Correct use..........37 Restarting..........425 Data storage..........38 Diagnostics connection......35 Tyre pressure table........423 Emergency key......... 87 Unfastening........... 48 Tyre sealant..........402 enabling, Remote Online......
  • Page 594 Index 591 Switching on, start/stop button..... 179 Model type..........439 Ventilating, Convenience opening....96 Towing........... 317 Paint code..........439 Ventilation........... 174 Transporting.......... 416 Permissible axle load......439 Vents............174 ventilate / comfort opening..... 96 VIN............439 VIN, Vehicle identification number Vehicle camera Vehicle interior Engine compartment......
  • Page 595 Fitting a new wheel........ 433 ï Trailer tow hitch warning lamp..542 up............547 Lowering the vehicle......434 h Tyre pressure monitoring sys- H Mercedes-Benz emergency call Preparation..........430 tem warning lamp flashes....... 556 system warning lamp......555 Raising the vehicle......... 431 Removing a wheel........
  • Page 596 Index 593 Removing/fitting wheel trim....430 Windows Wiper blades Care............394 Care............394 Wheel rotation..........429 De-icing..........164 Replacing (windscreen)......154 Wheels Opening/closing........94 Wipers Breakdown..........401 Removing mist........166 Windscreen wipers......... 153 Care............394 Windscreen Checking..........421 Wireless charging De-icing..........
  • Page 600 Germany Publication details Internet Further information about Mercedes-Benz vehi- cles and about Mercedes‑Benz AG can be found on the following websites: https://www.mercedes-benz.com https://www.daimler.com Documentation team You are welcome to forward any queries or sug- gestions you may have regarding this Owner's...
  • Page 601 Digital – as an App Familiarise yourself with the con- Here you can find comprehensive You can find the Owner's Manual The Mercedes-Benz Guides App is tents of the Owner's Manual information about operating your on the Mercedes-Benz homepage. available free-of-charge in familiar...

This manual is also suitable for:

Glc 220 d 4maticGlc 300 4maticGlc 300 d 4maticGlc 300 e 4maticGlc 300 de 4maticGlc 350 e 4matic ... Show all

Table of Contents

Save PDF
