Page 1 ML 350 ML 500...
Page 2 Your Mercedes-Benz represents the ef- forts of many skilled engineers and crafts- men. To help assure your driving pleasure, and also the safety of you and your passen-...
Page 3: Table Of Contents
Operator’s Manual ... 10 Service and warranty information .. 10 Important notice for California retail buyers and lessees of Mercedes-Benz automobiles ... 11 Maintenance ... 12 Roadside Assistance ... 12 Change of address or ownership... 13 Operating your vehicle outside the USA or Canada...
Page 4 Contents Safety and Security ... 57 Occupant safety... 58 Airbags ... 59 Seat belts ... 64 Children in the vehicle... 67 Blocking of rear door window operation... 73 Panic alarm ... 75 Activating ... 75 Deactivating ... 75 Driving and safety systems ... 76 ABS ...
Page 5 Transmission control – LOW RANGE mode... 125 Switching on LOW RANGE mode.. 125 Switching off LOW RANGE mode . 125 Good visibility ... 126 Rear view mirror... 126 Electrically folding exterior rear view mirrors... 128 Windshield wipers ... 129 Headlamp cleaning system* ... 131 Rear window wiper...
Page 6 Contents Operation ... 191 The first 1000 miles (1500 km) ... 192 Driving instructions... 193 Drive sensibly – save fuel ... 193 Drinking and driving ... 193 Pedals ... 193 Power assistance ... 193 Brakes ... 194 Driving off... 195 Parking ...
Page 7 Opening/closing in an emergency ... 265 Sliding/pop-up roof*... 265 Replacing bulbs ... 266 Bulbs ... 266 Replacing bulbs for front lamps ... 268 Replacing bulbs for rear lamps... 270 Adjusting headlamp aim... 272 Replacing wiper blades... 273 Removing ... 273 Installing ...
Page 9: Introduction
Product information Please observe the following in your own best interest: We recommend using genuine Mercedes-Benz parts as well as conversion parts and accessories explicitly approved by us for your vehicle model. We have tested these parts to determine their reliability, safety and special suitability for Mercedes-Benz vehicles.
Page 10: Operator's Manual
If you have any questions about the operation of any equipment, your au- thorized Mercedes-Benz Light Truck Cen- ter will be glad to demonstrate the proper procedures. We continuously strive to improve our...
Page 11: Of Mercedes-Benz Automobiles
Under California law you may be entitled to a replacement of your vehicle or a refund of the purchase price or lease price, if Mercedes-Benz USA, LLC and/or its au- thorized repair or service facilities fail to fix one or more substantial defects or mal-...
Page 12: Maintenance
Calls to the toll-free Roadside Assistance number 1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada) will be answered by Mercedes-Benz Cus- tomer Assistance Representatives 24 hours a day, 365 days a year. Roadside Assistance will be provided in ac-...
Page 13: Change Of Address Or Ownership
If you bought this vehicle used, be sure to send in the “Notice of Purchase of Used Truck” found in the Service and Warranty Information Booklet, or call the Mercedes-Benz Customer Assistance Cen- ter (in the USA) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.
Page 14 Introduction Operator’s Manual Warning! This Sport Utility Vehicle is designed for both on-road and off-road use. It can go places and perform tasks for which conventional 2-wheel drive passenger cars are not intended. This vehicle will handle and maneuver differently from conventional passenger cars in driving conditions which may occur on streets, highways and off-road use.
Page 15: Where To Find It
Here you will find all the information you need for your first drive. You should read this section first if this is your first Mercedes-Benz vehicle or if you are rent- ing or borrowing this vehicle. Safety and Security Here you will find descriptions of the safety features of your vehicle.
Page 16: Symbols
Introduction Symbols Symbols The following symbols are found in this Operator’s Manual: Optional equipment is identified with an asterisk. Since standard equipment varies between models, the descriptions and illustrations in this manual may differ slightly from the actual equipment of your vehi- cle.
Page 17: Operating Safety
Electronic malfunctions could seriously impair the operating safety of your vehicle. See your authorized Mercedes-Benz Light Truck Center for repairs or modifications to electronic components. Other improper work or modifications on the vehicle could also have a negative impact on the operating safety of the vehicle.
Page 18: Problems With Your Vehicle
Mercedes-Benz Light Truck Center to have the problem diagnosed and corrected if required. If the matter is not handled to your satisfaction, please discuss the problem with the Mercedes-Benz Light Truck Center management, or if necessary contact us at one of the following addresses:...
Page 19: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 21: At A Glance
At a glance Cockpit Instrument cluster Center console Overhead control panel...
Page 22: Cockpit
At a glance Cockpit Cockpit...
Page 23 Item Page 1 Hood lock release 2 Parking brake pedal 3 Parking brake release 4 Left cup holder 5 Combination switch Exterior lights High beam Turn signals 6 Cruise control lever 7 Instrument cluster 8 Hazard warning flasher switch 9 Lever for voice control system*, see separate operating instructions Item...
Page 24: Instrument Cluster
At a glance Instrument cluster Instrument cluster...
Page 25 Item Page 1 Gauge for Coolant tempera- ture Outside tempera- ture Fuel reserve warning lamp 2 Knob for Activating instru- ment cluster Adjusting intensity of instrument lamps Main odometer Trip odometer readout/reset Activating Flexible Service System (FSS) indicator Item Page 3 Left indicator lamps with: ¿...
Page 26 At a glance Instrument cluster Item Page 5 Photo sensor (adjusts the brightness of the digital displays located in 1, 4 and 8) 6 Right indicator lamps with: W Low wind- shield/headlamp washer system fluid level warning lamp 7 Front passenger air- bag switched off ‡...
Page 27: Center Console
Center console Upper part Item Page 1 Air vents, automatic climate control 2 MCS, see separate operating instructions 3 Automatic climate control Rear window defroster switch 4 Seat heater switch*, passenger side 5 Rear quarter window switch*, right 6 ESP control switch At a glance Center console Item...
Page 28: Lower Part
At a glance Center console Lower part Item Page 1 Ashtray with cigarette lighter 2 Gear selector lever for automatic transmission 3 Power window switch, right front door 4 Power window switch, right rear door 5 Parktronic system* deactivation switch 6 Storage compartment with cup holder Item...
Page 29: Overhead Control Panel
Overhead control panel 1 Front left interior lighting 2 Signal transmitter buttons 3 Front right interior lighting 4 Roadside Assistance 5 Interior lighting control 6 Trip computer* display 7 Rear view mirror Item Page 8 Right reading lamp on/off 9 Automatic antiglare func- for garage door opener a Left reading lamp on/off b Glass breakage sensor...
Page 31: Getting Started
Getting started Unlocking Adjusting Driving Parking and locking...
Page 32: Operating Your Vehicle Outside Unlocking
Getting started Unlocking The “Getting started” section provides an overview of the vehicle’s most basic func- tions. First-time Mercedes-Benz owners should pay special attention to the infor- mation given here. If you are already familiar with the basic functions described here, the “Controls in detail”...
Page 33 Steering lock positions 0 For removing key The steering is locked when the key is removed from the steering lock. If necessary, move steering wheel slightly to allow the locking mechanism to engage. 1 Unlocking steering Power supply to some electrical con- sumers, such as seat adjustment.
Page 34: Adjusting
Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air- bag when it is properly installed.
Page 35 A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Manual seat adjustment 1 Seat fore and aft adjustment 2 Backrest tilt 3 Seat height Getting started...
Page 36 Getting started Adjusting Seat backrest tilt Turn handwheel 2 forward or back- ward until your hands are slightly ang- led when holding the steering wheel. Seat height Lift handle 3. Use your body weight to push the seat downwards. Lift your weight off the seat to obtain a higher seat position.
Page 37 Head restraint tilt Manually adjust the angle of the head restraint. Push or pull on the upper edge of the head restraint cushion. More information on seats can be found in the “Controls in detail” section ( page 95). Power seat* adjustment The seat adjustment switch is located on the entry side of each front seat base.
Page 38 Getting started Adjusting Seat cushion tilt Press the switch up or down in the di- rection of arrow 3 until your upper legs are lightly supported. Seat backrest tilt Press the switch forward or backward in the direction of arrow 1 until your arms are slightly angled when holding the steering wheel.
Page 39: Steering Wheel
Head restraint tilt Manually adjust the angle of the head restraint. Push or pull on the upper edge of the head restraint cushion. More informations on seats can be found in the “Controls in detail” section ( page 95). Steering wheel Warning! Do not adjust the steering wheel while driv- ing.
Page 40: Mirrors
Getting started Adjusting Do not drive the vehicle until you have properly locked the steering column. If the indicator lamp _ ( page 26) comes on while the engine is running, the steering column is not locked prop- erly. Mirrors Adjust the interior and exterior rear view mirrors before driving so that you have a good view of the road and traffic condi-...
Page 41 The buttons are on the lower part of the center console. 1 Driver’s side exterior rear view mirror 2 Passenger-side exterior rear view mirror 3 Adjustment button Switch on the ignition by turning the key in the steering lock to position 2 ( page 33).
Page 42: Driving
( page 58). Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air- bag when it is properly installed.
Page 43 A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Warning! Never ride in a moving vehicle with the back- rest reclined.
Page 44 Damaged seat belts or belts that were highly ensure that it is properly positioned. stressed in an accident must be replaced. Contact an authorized Mercedes-Benz Light Ensure that the seat belt is always fit- Truck Center. ted snugly. You should avoid wearing bulky clothing, such as winter coats, when traveling in the vehicle.
Page 45 Seat belt height adjustment Seat belt height can be adjusted for the fol- lowing seats: Driver’s seat Passenger seat Outer rear seats Adjust seat belt so that the shoulder por- tion is located as close as possible to the middle of the shoulder (it should not touch the neck or pass under the arm).
Page 46: Starting The Engine
Getting started Driving Starting the engine Warning! Inhalation of exhaust gas is hazardous to your health. All exhaust gas contains carbon monoxide, and inhaling it can cause uncon- sciousness and lead to death. Do not run the engine in confined areas (such as a garage) which are not properly ventilated.
Page 47 If the engine does not start after several starting attempts, there could be a mal- function in the engine electronics or in the fuel supply system. Notify an authorized Mercedes-Benz Light Truck Center. Parking brake Warning! When leaving the vehicle, always remove the key from the steering lock and lock the vehi- cle.
Page 48: Switching On Headlamps
Getting started Driving If you hear a warning signal when driv- ing off, you have forgotten to release the parking brake. Release the parking brake. After a cold start, the automatic transmis- sion shifts at a higher engine revolution. This allows the catalytic converter to reach its operating temperature earlier.
Page 49: Turn Signals
High beam Push the combination switch forward. The high beam indicator A in the instrument cluster comes on. More information can be found in the “Controls in detail” section ( page 110). Turn signals The combination switch is on the left of the steering column.
Page 50 Turn the windshield wipers on again. If windshield wipers fail to function at all in switch position 1, set the combination switch to the next highest wiper speed have the windshield wipers checked at the nearest authorized Mercedes-Benz Light Truck Center...
Page 51: Rear Window Wiper
An ignition cable may be damaged. The engine electronics may not be operating properly. Unburned gasoline may have entered the catalytic converter and damaged it. Give very little gas. Have the problem repaired by an au- thorized Mercedes-Benz Light Truck Center as soon as possible.
Page 52 Do not start the engine under any cir- cumstances. Notify local fire and/or police authori- ties. If the extent of the damage cannot be de- termined: Notify an authorized Mercedes-Benz Light Truck Center. If no damage can be determined on the major assemblies fuel system engine mount:...
Page 53: Parking And Locking
Parking and locking You have now completed your first drive. You have properly stopped and parked your vehicle. End your drive as follows. Warning! Wait until the vehicle is stationary before re- moving the key from the steering lock. The vehicle cannot be steered when the key is removed.
Page 54: Switching Off Headlamps
Getting started Parking and locking Warning! When leaving the vehicle, always remove the key from the steering lock and lock the vehi- cle. Do not leave children unattended in the vehicle, or with access to an unlocked vehi- cle. Children could release the parking brake and/or move the gear selector lever from position P, either of which could result in an accident and/or serious personal...
Page 55 Press the seat belt release button ( page 42). Allow the retractor to completely re- wind the seat belt by guiding the latch plate. With the key removed and the driver’s door open, a warning sounds if the ve- hicles exterior lamps are not switched off.
Page 57: Safety And Security
Safety and Security Occupant safety Panic alarm Driving and safety systems Anti-theft systems...
Page 58: Occupant Safety
SRS may not be opera- tional. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Light Truck Center immediately to have the system checked; otherwise the SRS may not be activated when needed in an accident,...
Page 59: Airbags
If you have any prob- lems, please see your authorized Mercedes-Benz Light Truck Center. Airbags and emergency tensioning de- vices (ETDs) are designed to function on a one-time only basis. An airbag or ETD that was activated must be replaced.
Page 60 Manual. Warning Accident research shows that the safest place for children in an automobile is in the rear seat. Should you choose to place a child 12 years old or under in the front passenger seat of your vehicle, you must properly use...
Page 61 Mercedes-Benz Light Truck Center at an ad- ditional cost. Please contact your local au- thorized Mercedes-Benz Light Truck Center or call our Customer Assistance Center at 1-800-FOR-MERCedes (1-800-367-6372) for details.
Page 62 Use only belts in- stalled or supplied by an authorized Mercedes-Benz Light Truck Center. No modifications of any kind may be made to any components or wiring of the SRS. This includes changing or re-...
Page 63 SRS may not be operational. For your safety, we strongly recommend that you visit an autho- rized Mercedes-Benz Light Truck Center im- mediately to have the system checked; otherwise the SRS may not be activated...
Page 64: Seat Belts
Safety and Security Occupant safety Side impact airbags, window curtain airbags 1 Window curtain airbags 2 Side impact airbag, rear 3 Side impact airbag, front The side impact airbags and window curtain airbags are deployed: on the impacted side of the vehicle in impacts exceeding a preset deploy- ment threshold independently of the front airbags...
Page 65 Only use seat belts which have been ap- proved by Mercedes-Benz. Do not make any modifications to the seat belts. This can lead to unintended activation or to failure. Have all work carried out only by qualified technicians. Contact an authorized Mercedes-Benz Light Truck Center.
Page 66 Safety and Security Occupant safety Warning! USE SEAT BELTS PROPERLY Seat belts can only work when used properly. Never wear seat belts in any other way than as described in this sec- tion, as that could result in serious inju- ries in case of an accident.
Page 67: Children In The Vehicle
When disposing of the emergency tension- ing device, our safety instructions must be followed. These are available at your autho- rized Mercedes-Benz Light Truck Center. Do not place objects heavier than 20 lbs (9 kg) on the front passenger seat. This could cause the front or side...
Page 68 Safety and Security Occupant safety Infant and child restraint systems Use only a BabySmart compatible child restraint for the front passenger seat in this vehicle. We recommend that all infants and children be properly restrained at all times while the vehicle is in motion. All lap-shoul- der belts except the driver’s seat belt have special seat belt retractors for secure fas- tening of child restraints.
Page 69 Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart System installed in the ve- hicle to deactivate the passenger front air- bag when it is properly installed.
Page 70 Special BabySmart compatible child seats, designed for use with the Mercedes-Benz system and available at any authorized Mercedes-Benz Light Truck Center, are required for use with the BabySmart airbag deactivation system. With the special seat properly installed, the passenger front airbag will not deploy.
Page 71 Please be sure to check the indicator every time you use the special system child seat. Should the light go out while the restraint is installed, please check installation. If the light remains out, do not use the BabySmart restraint to transport children on the passenger seat until the system has been repaired.
Page 72 Safety and Security Occupant safety Vehicle with third row seats* 3 Anchorage rings for second row seats 4 Anchorage rings for third row seats* This vehicle is provided with tether anchor- ages for a top tether strap behind the second row seats 3 and the third row seats 4.
Page 73: Blocking Of Rear Door Window Operation
Warning! With a child seat installed in the left rear seat, the seat belt for the center Install child seat according to manufactu- seat occupied by a passenger must op- rer’s instructions. erate freely. Guide seat belt between The child seat must be firmly attached in the its seat cushion mount and backrest right and left side anchors 1 ( page 72).
Page 74 Safety and Security Occupant safety Warning! Activate the override switch when children are riding in the back seats of the vehicle. The children may otherwise injure them- selves, e.g. by becoming trapped in the win- dow opening. When leaving the vehicle, always remove the key from the steering lock, and lock the ve- hicle.
Page 75: Panic Alarm
Panic alarm An audible alarm and flashing turn signal lamps will operate for approximately 2½ minutes. 1 Â button Activating Press and hold button 1 for at least one second. Deactivating Press button 1 again. Insert key in steering lock. Safety and Security Panic alarm For operation in the USA only: This de-...
Page 76: Driving And Safety Systems
Safety and Security Driving and safety systems Driving and safety systems In this section you will find information on the following driving safety systems: ABS (Antilock Brake System) BAS (Brake Assist System) 4-ETS (Electronic Traction System) EBP (Electronic Brake Proportioning) ESP (Electronic Stability Program) In winter operation, the maximum ef- fectiveness of the ABS, the BAS, the...
Page 77 Braking At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode. Keep firm and steady pressure on the brake pedal while experiencing the pul- sation.
Page 78: Bas
Safety and Security Driving and safety systems Warning! The ABS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency be- yond that afforded by the condition of the vehicle brakes and tires or the traction af- forded.
Page 79: 4-Ets
4-ETS The 4-Electronic Traction System (4-ETS) improves vehicle’s ability to utilize avail- able traction, especially under slippery road conditions. The brakes are applied to the spinning wheel and power is trans- ferred to the wheel(s) with traction. The traction control engages at vehicle speeds up to approximately 24 mph (40 km/h), and switches off at approxi- mately 50 mph (80 km/h).
Page 80: Ebp
Safety and Security Driving and safety systems LOW RANGE 4-ETS During off-road driving, a special low range system for the 4-ETS is operational with transmission in LOW RANGE mode. More information can be found in the “Practical hints” section ( page 242) and ( page 252).
Page 81 Warning! The ESP cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded. The ESP cannot prevent accidents, including those resulting from excessive speed in turns, fol- lowing another vehicle too closely, or hydro- planing.
Page 82 Avoid spinning of a drive wheel for an extended period with the ESP switched off. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Turn ESP on immediately if the afore- mentioned circumstances do not apply anymore.
Page 83: Anti-Theft Systems
2 ( page 33) deactivates the im- mobilizer. In case the engine cannot be started (vehicle’s battery is in order), the sys- tem is not operational. Contact an au- thorized Mercedes-Benz Light Truck Center or call 1-800-FOR-MERCedes (in the USA), or 1-800-387-0100 (in Canada). Anti-theft alarm...
Page 84: Tow-Away Alarm, Glass Breakage Sensor
Safety and Security Anti-theft systems If the turn signal lamps do not flash three times, the tow-away - glass breakage sensor is malfunctioning or one of the following elements may not be properly closed: a door the liftgate the hood Close the respective element and lock the vehicle again.
Page 85 Arming tow-away alarm and glass breakage sensor When you lock your vehicle, the tow-away and glass breakage sensor alarm is auto- matically armed. Disarming tow-away alarm and glass breakage sensor To prevent triggering the tow-away alarm feature, switch off the tow-away alarm and glass breakage sensor before towing the vehicle, or when parking on a surface sub- ject to movement, such as a ferry or auto...
Page 86 Safety and Security Anti-theft systems Vehicles without trip computer The buttons are located in the overhead control panel. 1 Switching off tow-away alarm and glass breakage sensor Turn key in steering lock to position 2 ( page 33). Return key to position 0 and remove it from the steering lock.
Page 87: Controls In Detail
Controls in detail Locking and unlocking Seats Memory function* Lighting Instrument cluster Automatic transmission Transmission control – LOW RANGE mode Good visibility Automatic climate control Power windows Sliding/pop-up roof* Driving systems Loading Useful features...
Page 88: Locking And Unlocking
Controls in detail Locking and unlocking In the “Controls in detail” section you will find detailed information on how to ope- rate the equipment installed in your vehi- cle. If you are already familiar with the ba- sic functions of your vehicle, this section will be of particular interest to you.
Page 89 Unlocking Unlocking the vehicle with the remote control deactivates the anti-theft alarm. The vehicle will lock again automatical- ly and reactivate the anti-theft system within approximately 40 seconds of un- locking if neither door nor liftgate is opened. Unlocking the driver’s door and fuel filler flap Press button Œ...
Page 90: Opening The Doors From The Inside
If you lose a remote control or the folding key, you should do the following: Have the remote control deactivated by an authorized Mercedes-Benz Light Truck Center. Report the loss of the remote control or the folding key immediately to your car insurance company.
Page 91: Opening The Liftgate
Opening the liftgate If the vehicle has previously been locked from the outside with the re- Opening the liftgate from outside mote control, opening a door from the A minimum height clearance of 7 ft inside will trigger the alarm. (2.15 m) is required to open the liftgate.
Page 92: Closing The Liftgate
Controls in detail Locking and unlocking To unlock the liftgate, move the catch 2 to the right. Pull handle 1 down and swing liftgate upward. Always make sure that there is suffi- cient overhead clearance. To lock the liftgate, move the catch 2 to the left.
Page 93: Automatic Central Locking
Automatic central locking The doors and the liftgate automatically lock when the ignition is switched on and the left front wheel turns at vehicle speeds of approximately 9 mph (15 km/h) or more. If one of the front doors is then opened from the inside, the vehicle is unlocked centrally unless only the driver's door was previously unlocked.
Page 94: Locking And Unlocking From The Inside
Controls in detail Locking and unlocking Locking and unlocking from the inside You can lock or unlock the doors and the tailgate from inside using the central lock- ing switch. This can be useful, for example, if you want to lock the vehicle before start- ing to drive.
Page 95: Seats
Seats Information on seat adjustment can be found in the “Getting started” section ( page 34). Removing and installing front seat head restraints Information on head restraint adjustment can be found in the “Getting started” sec- tion ( page 34). Warning! For your protection, drive only with properly positioned head restraints.
Page 96: Rear Seat Head Restraints
Controls in detail Seats Installing head restraint Insert head restraint and push it down to the stop. Push button 1 and adjust head restraint to the desired position ( page 36). Rear seat head restraints Head restraint height Raising: Manually adjust the height of the head restraint by pulling it upward.
Page 97 Removing and installing rear seat head restraints Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the head re- straint supports the back of the head at eye level. This will reduce the potential for injury to the head and neck in the event of an ac- cident or similar situation.
Page 98: Heated Seats
Controls in detail Seats Remove rear center head restraint ( page 96). If necessary, remove cargo floor plates, see “Removing cargo floor plates” ( page 162). Slide rear seats forward, see “Adjusting rear seat fore and aft” ( page 99). Fold rear seat backrests down, see “Folding down the backrest”...
Page 99: Rear Seats
Switching off rapid seat heating Press lower switch position 2 again. Both red indicator lamps on the switch turn off. If one or both of the lamps on the seat heater switch are flashing, there is in- sufficient voltage available since too many electrical consumers are turned on.
Page 100 Controls in detail Seats Folding down the backrest 1 Lock button Close cup holder ( page 167) and ashtray ( page 169) in rear center console ( page 167). Move front seats forward. Manual seat ( page 35) or power seat ( page 37). Slide seat forward.
Page 101 Close cup holder in rear center console Folding up the rear seat ( page 167). Move front seats forward. Manual seat ( page 35) or power seat ( page 37). Press and hold release button 1 to un- lock lever 2. Pull lever 2 in direction of arrow.
Page 102: Third Row Seats
Controls in detail Seats Resetting rear seat Pull down on seat bench until it locks into place. Pull lock button 1 ( page 100) up and unfold backrest until it locks into place. Check for secure locking by pulling and pushing on the backrest.
Page 103 Attach belt at hook and loop velcro strip 4 ( page 102) on underside of seat. 5 Backrest release 6 Seat release Fold seat down until it locks securely in place. The red marking on the seat release 6 should not be visible. Store cargo floor plates inside the backrest ( page 162).
Page 104 Controls in detail Seats Removing single seat 1 Hook 2 Tensioner 3 Hook and loop velcro strip 4 Release lever Lift tensioner 2 upward to a horizon- tal position to release tension of the belt. Disengage hook 1 while holding onto the seat firmly with one hand.
Page 105: Memory Function
Memory function* With the memory button you can store up to three different settings for the driver- Prior to operating the vehicle the driver and passenger seat. should check and adjust the seat height, seat position fore and aft, and Together with the driver’s seat you can seat backrest angle if necessary, to en- store the exterior rear view mirrors.
Page 106: Storing Positions In Memory
Controls in detail Memory function* Storing parking position Stop the vehicle. Switch on ignition (if not already on). Press button 2. The passenger-side exterior rear view mirror is selected. Adjust the exterior rear view mirror with button 3 so that you see the rear wheel and the road curb.
Page 107: Lighting
Relevant information can be obtained at your authorized Mercedes-Benz Light Truck Center. Combination switch The combination switch is on the left of the steering column.
Page 108 Controls in detail Lighting If you remove the key and open the driver’s door while the parking lamps or low beam headlamps are switched on, then a warning sounds. Manual headlamp mode The low beam headlamps and parking lamps can be switched on and off with the combination switch.
Page 109 Daytime running lamp mode Canada only: Turn combination switch to position M or U. When the engine is running, the low beam headlamps are automatically switched on. In low ambient light conditions, the parking lamps will also switch on. When you shift from a driving position to position N or P, the low beam switches off (three minutes delay).
Page 110 Controls in detail Lighting Stop the vehicle. Make sure the ignition is switched on. All the lamps in the instrument cluster light up. Turn combination switch to position M. Press upper part 1 of switch until the clock, located in the instrument clus- ter, displays the actual illumination time.
Page 111: Fog Lamps
Fog lamps Warning! In low ambient lighting or foggy conditions, only switch from position U to B with the vehicle at a standstill. Switching from U to B will briefly switch off the headlamps. Doing so while driving in low ambient lighting conditions may result in an accident.
Page 112: Hazard Warning Flasher
Controls in detail Lighting Hazard warning flasher The hazard warning flasher can be activa- ted with the ignition switched on or off. It is activated automatically when an airbag is deployed. The switch is located on top of the steering column.
Page 113 Automatic control Activating automatic control Bring the rocker switch to center position 4. Interior lamps (except cargo compart- ment lamp) are switched on in dark- ness, when you unlock the vehicle open a door remove the key from the steering lock In addition, the entry/exit lamps in the door trays will come on when you open...
Page 114 Controls in detail Lighting Press on upper part 5 of rocker switch again. The rear interior lighting goes off. If the switch is pressed while the rear interior lighting is on, the function is re- versed. Operating rear interior lighting with lamp lens Rear interior lighting Push on lamp lens (arrow) to switch...
Page 115 Switching on continuous cargo compartment lamp Slide the switch to position 2. The cargo compartment lamp is switched on continuously. To prevent the vehicle battery from be- ing discharged, make sure the switch is not in position 2 when leaving the ve- hicle.
Page 116: Instrument Cluster
Controls in detail Instrument cluster Instrument cluster A full view illustration of the instrument cluster can be found in the “At a glance” section of this manual ( page 24). 1 Left knob 2 Right knob The instrument cluster is activated when you: open the driver’s door turn the key in steering lock to...
Page 117: Coolant Temperature Gauge
Doing so may cause serious engine dam- age which is not covered by the Mercedes-Benz Limited Warranty. Warning! Driving when your engine is badly overheat- ed can cause some fluids which may have leaked into the engine compartment to catch fire.
Page 118: Resetting Trip Odometer
Controls in detail Instrument cluster Resetting trip odometer Press the left knob 1 ( page 116) re- peatedly until you see the trip odome- ter display. Press and hold the left knob 1 until the trip odometer is reset. Tachometer To help protect the engine, the fuel supply is interrupted if the engine is operated above its specified limit.
Page 119: Automatic Transmission
Automatic transmission Information on driving with an automatic transmission is found in the “Getting started” section ( page 46). Your vehicle’s transmission adapts its gear shifting process to your individual driving style by continually adjusting the shift points up or down. These shift point adjust- ments are performed based on current operating and driving conditions.
Page 120: One-Touch Gearshifting
Controls in detail Automatic transmission One-touch gearshifting Even with an automatic transmission you can change the gears manually when the gear selector lever is in position D. Downshifting Briefly press the gear selector lever to the left in the D– direction. The transmission will shift from the current gear to the next lower gear.
Page 121: Gear Ranges
Gear ranges With the gear selector lever in position D, you can limit the transmission’s gear range by pressing the gear selector lever to the left (D-), and reverse the gear range limit by pressing the gear selector lever to the right (D+).
Page 122: Gear Selector Lever Position
Controls in detail Automatic transmission Gear selector lever position Effect ì Park position Gear selector lever position when the vehicle is parked. Place gear selector lever in position P only when vehicle is stopped. The park position is not intended to serve as a brake when the vehicle is parked.
Page 123: Accelerator Position
Coasting the vehicle, or driving for any other reason with gear selector lever in N can result in transmission damage that is not covered by the Mercedes-Benz Limited Warranty. Warning! Getting out of your vehicle with the gear selector lever not fully engaged in position P is dangerous.
Page 124: Towing A Trailer
Turn off the engine. Wait at least ten seconds before restarting. Restart the engine. Move selector lever to position D (for second gear) or R. Have the transmission checked at an authorized Mercedes-Benz Light Truck Center as soon as possible.
Page 125: Transmission Control - Low Range Mode
1500 rpm Failure to do so may result in transmis- sion or engine damage which is not covered by the Mercedes-Benz Limited Warranty. Transmission control – LOW RANGE mode You should only operate the vehicle on a single axle dynamometer for briefly testing the brakes.
Page 126: Good Visibility
Controls in detail Good visibility Good visibility Information on the windshield wipers ( page 49) and for setting the rear view mirrors ( page 40) is found in the “Getting started” section. Rear view mirror Interior rear view mirror, antiglare position 1 Lever Tilt the mirror to the antiglare night po-...
Page 127 Warning! Exercise care when using the passen- ger-side exterior rear view mirror. The mirror surface is convex (outwardly curved surface for a wider field of view). Objects in mirror are closer than they appear. Check your in- terior rear view mirror or glance over your shoulder before changing lanes.
Page 128: Electrically Folding Exterior Rear View Mirrors
Controls in detail Good visibility Engage reverse gear R. The passenger-side exterior rear view mirror moves automatically to the stored parking position. The exterior rear view mirror returns to its stored driving position: ten seconds after you put the gear selector lever in position D immediately once your vehicle exceeds a speed of approx.
Page 129: Windshield Wipers
Turn the windshield wipers on again. If windshield wipers fail to function at all in switch position 1, set the wiper switch to the next highest wiper speed. have the windshield wipers checked at the nearest authorized Mercedes-Benz Light Truck Center.
Page 130 Controls in detail Good visibility Intermittent wiping Intermittent wiping is interrupted when the vehicle is at a standstill and a front door is opened. Windshield wipers without rain sensor* At speeds of approximately 105 mph (170 km/h) the wiper switches automati- cally to continuous wiping.
Page 131: Headlamp Cleaning System
Headlamp cleaning system* The button is located on the right side of the dashboard. Headlamp washer button Switch on ignition. Briefly press the upper part of button. The headlamps will be cleaned with a high-pressure water jet. Information on filling up the washer reser- voir can be found in the “Operation”...
Page 132: Sun Visor
Controls in detail Good visibility Sun visor The sun visors protect you from sun glare while driving. Warning! Do not use the vanity mirror while driving. Keep the mirrors in the sun visors closed while vehicle is in motion. Reflected glare can endanger you and others.
Page 133: Rear Window Defroster
Rear window defroster The rear window defroster uses a large amount of power. To keep the battery drain to a minimum, switch off the defrost- er as soon as the rear window is clear. The defroster is automatically deactivated after approximately 6 to 17 minutes of operation depending on the outside tem- perature.
Page 134: Automatic Climate Control
Controls in detail Automatic climate control Automatic climate control...
Page 135 Item 1 Thumbwheel for center air vent 2 Center air vent, adjustable 3 Defroster air vent windshield 4 Thumbwheels for side air vent 5 Side air vent, adjustable 6 Footwell air vent 7 Automatic climate control Automatic climate control panel in the front Controls in detail Automatic climate control Item...
Page 136 Controls in detail Automatic climate control The automatic climate control is operatio- nal whenever the engine is running. You can operate the climate control system in either the automatic or manual mode. The system cools or heats the interior depend- ing on the selected interior temperature and the current outside temperature.
Page 137: Automatic Mode
Automatic mode Switching on Briefly press button U ( page 135). The indicator lamp comes on. The tem- perature, air volume and distribution are controlled automatically. Adjust the temperature with the tem- perature control 4 ( page 135). Temperature control is switched off in the extreme position (blue or red dot).
Page 138: Defrosting
Controls in detail Automatic climate control Adjusting air distribution Turn air distribution control 8 ( page 135) to one the following symbols: Symbol Function Directs air to the center and side air vents Directs air to the wind- shield and side air vents Directs air into the en- tire vehicle interior Directs air to the foot-...
Page 139: Air Conditioning
Activating Press button Ä ( page 135). The indicator lamp on the button comes on. To achieve the fastest possible cooling of the interior, the automatic climate control automatically switches to air recirculation. The indicator lamp in the button Ä is not illuminated when the system automatically switches to air recirculation.
Page 140: Residual Heat And Ventilation
Have the air conditioning system checked at the nearest authorized Mercedes-Benz Light Truck Center. Residual heat and ventilation With the engine switched off, it is possible to continue to heat or ventilate the interior for up to 30 minutes.
Page 141: Rear Passenger Compartment Ventilation And Rear Automatic Climate Control
Rear passenger compartment ventila- tion and rear automatic climate control Deactivating For an improved cooling or heating output in the front passenger compartment, you can switch off the rear passenger compart- ment ventilation. Press button § ( page 135). The indicator lamp on the button comes on.
Page 142: Front And Rear Air Vents
Controls in detail Automatic climate control When in manual mode, the rear blower setting cannot be increased beyond the setting for the front blower setting. For example, if the driver or front pas- senger changes the blower setting to level 3, the rear blower will not go high- er than level 3 as well.
Page 143 Center air vents Opening Turn thumbwheel for center air vent 1 ( page 135) upward to position h. Closing Turn thumbwheel for center air vent 1 downward to position M. Use the left thumbwheel to adjust the cen- ter air vents on the left and in the center. Use the right thumbwheel to adjust the right center air vent.
Page 144: Power Windows
Controls in detail Power windows Power windows Opening and closing the side windows The side windows can be opened and closed electrically. The switches for all the side windows are on the driver’s door. The switches for the respective windows are on the passenger door and on the rear cen- ter console.
Page 145 Opening the windows Press switch 1 to 4 at the symbol k to the resistance point. The corresponding window will move downwards until you release the switch. Closing the windows Press switch 1 to 4 at the symbol j to the resistance point. The corresponding window will move upwards until you release the switch.
Page 146: Synchronizing Power Windows
Controls in detail Power windows Synchronizing power windows The power window must be resynchroni- zed each time after the battery has been discon- nected. if the power windows cannot be fully opened (Express-open) or closed (Ex- press-close). Synchronizing the power windows Switch on ignition.
Page 147 Controls in detail Power windows Closing the windows Press and hold the lower part of switches 1 or 2. The corresponding window will move upwards until you release the switch.
Page 148: Sliding/Pop-Up Roof
Controls in detail Sliding/pop-up roof* Sliding/pop-up roof* Opening and closing the sliding/pop-up roof The sliding/pop-up roof can be opened and closed electrically. The switch for the sliding/pop-roof is on the overhead control panel. 1 Push up to raise roof at rear 2 Push back to slide roof open 3 Push down to lower roof at rear 4 Push forward to slide roof closed...
Page 149: Synchronizing The Sliding/Pop-Up Roof
Turn the key in the steering lock to position 1 or 2 ( page 33). Opening and closing the sliding/pop-up roof To open, close, raise or lower the sliding/pop-up roof, move the switch in the required direction 1 to 4. Release the switch when the roof has reached the desired position.
Page 150: Driving Systems
Controls in detail Driving systems Driving systems The driving systems of your vehicle are de- scribed on the following pages: Cruise control, with which the vehicle can maintain a preset speed. Parktronic*, with which you can assist your parking maneuvers. The driving systems BAS, ABS, ESP, EBB and 4-ETS, are described in the “Safety and Security”...
Page 151 1 Set current or higher speed 2 Set current or lower speed 3 Cancel cruise control 4 Resume at last set speed Setting current speed Accelerate or decelerate to the desired speed. Briefly lift 1 or depress 2 the cruise control lever.
Page 152 Controls in detail Driving systems Setting a higher speed Lift the cruise control lever to position 1 and hold it up until the de- sired speed is reached. Release the cruise control lever. The new speed is set. Depressing the accelerator pedal does not deactivate the cruise control.
Page 153: Parktronic System* (Parking Assist)
Parktronic system* (Parking assist) Warning! Parktronic is a supplemental system. It is not intended to nor does it replace the need for extreme care. The responsibility during parking and other critical maneuvers rests always with the driver. Make sure that no persons or animals are lo- cated in the area in which your are maneu- vering.
Page 154 Controls in detail Driving systems Monitoring reach of sensors The sensors must be free of dirt, ice and snow or they will be unable to function properly. Clean the sensors regularly with- out scratching or damaging them. Front sensors Center approx.
Page 155 Warning indicators The warning indicators show the distance between the sensor and the obstacle. The warning indicators for the front area are lo- cated above the center air vents in the dashboard. The warning indicator for the rear area is located in the rear passenger compartment lamp.
Page 156 If the Parktronic system is malfunction- ing, all red segments of the warning in- dicators light up and an additional warning sounds. Contact your Mercedes-Benz Light Truck Center as soon as possible. Switching Parktronic off Press switch on the upper part 1.
Page 157: Loading
Loading Loading instructions Warning! Always fasten items being carried as secure- ly as possible using cargo tie-down rings and fastening materials appropriate for the weight and size of the load. In an accident, during hard braking or sud- den maneuvers, loose items will be thrown around inside the vehicle, and can cause in- jury to vehicle occupants unless the items are securely fastened in the vehicle.
Page 158 Controls in detail Loading For additional safety when transporting cargo while the rear seats are unoccupied, fasten the outer seat belts crosswise into the opposite side buckles. The cargo area is the preferred place to carry objects. The enlarged cargo area should only be used for items which do not fit in the cargo area alone.
Page 159: Partition Net
Hooks Four hooks located on the rear compart- ment trim panels, two on each side. Hooks Use the hooks to secure light weight items. The maximum permissible weight per hook is 9 lbs (4 kg). Partition net* Warning! Always lock backrest in its upright position when rear seat bench is occupied by pas- sengers, or cargo is being carried behind the seat bench.
Page 160 Controls in detail Loading One after the other, press the two mounting hooks 2 inward against the spring pressure and turn them. The mounting hooks are locked in this position and you can move the net into position more easily. Turn one of the mounting hooks 2 in the opposite direction.
Page 161: Cargo Area Cover Blind
Removing partition net Lift tensioner 3 upward to a horizon- tal position to release tensioning of the strap. Disengage tie-down hooks 1 from rings 2. Remove mounting hooks 2 ( page 159) from holder 1 ( page 159). Roll up and close the partition net. Store partition net behind rear seat bench.
Page 162: Cargo Floor Plates
Controls in detail Loading Installing blind Place left side of blind in left mount. Position right side of blind over right mount. Push button 3, releasing mounting sleeve to slide into mount. Cargo floor plates Removing cargo floor plates Before you can remove the cargo floor plates, it is possible that the third row seats* ( page 102) must be removed.
Page 163: Roof Rack
Roof rails Controls in detail Loading Attach roof racks to the roof rails only. Use only those roof racks approved by Mercedes-Benz for your vehicle model. Follow manufacturer’s installation in- structions. The vehicle could otherwise be dam- aged. For further information, inquire at your...
Page 164: Useful Features
Controls in detail Useful features Useful features Interior storage spaces Warning! To help avoid personal injury during a colli- sion or sudden maneuver, exercise care when stowing objects in the vehicle. Put lug- gage or cargo in the cargo compartment if possible.
Page 165 Opening the storage compartment Press the lock cylinder in and pull stor- age compartment out using handle 2. Closing the storage compartment Push the storage compartment in until the lock engages. Armrest storage spaces A flat storage tray with a deeper storage compartment underneath is located below the armrest.
Page 166: Cup Holders
Controls in detail Useful features Opening the storage compartment in front of armrest Slide the cover 3 rearward. The storage compartment below con- tains a cup holder ( page 167). Cup holders Warning! When not in use, keep the cup holder closed.
Page 167: Armrest In Rear Seat Bench
Cup holder in front of armrest Opening the cup holder Slide cover rearward ( page 166). Fold the cup holder forward. Closing the cup holder Fold the cup holder backward. Slide cover forward. Cup holder in rear center console Opening the cup holder Briefly touch the cover.
Page 168: Ashtrays And Cigarette Lighter
Controls in detail Useful features Ashtrays and cigarette lighter Warning! Never touch the heating element or sides of the cigarette lighter; they are extremely hot. Hold the knob only. When leaving the vehicle always remove the key from the steering lock. Do not leave chil- dren unattended in the vehicle, or with ac- cess to an unlocked vehicle.
Page 169 Cigarette lighter Switch on the ignition. Push in cigarette lighter 2 ( page 168). The cigarette lighter will pop out auto- matically when hot. Ashtray and cigarette lighter in the rear center console Close the ashtray in the rear center console before folding the rear seat bench.
Page 170: Electrical Outlet
The external antenna must be approved by Mercedes-Benz. Please contact an autho- rized Mercedes-Benz Light Truck Center for information on the installation of an ap- proved external antenna. Refer to the radio transmitter operation instructions regard- ing use of an external antenna.
Page 171: Tele Aid
Warning! Please do not forget that your primary re- sponsibility is to drive the vehicle. A driver’s attention to the road must always be his /her primary focus when driving. For your safety and the safety of others, we rec- ommend that you pull over to a safe location and stop before placing or taking a tele- phone call.
Page 172 Controls in detail Useful features The Tele Aid system (Telematic Alarm Identification on Demand) The Tele Aid system consists of three types of response: automatic and manual emergency roadside assistance and information. The Tele Aid system is operational provid- ing that the vehicle’s battery is charged, properly connected, not damaged and cel- lular and GPS coverage is available.
Page 173 SOS button will not illuminate during or will remain illuminated after the system self-check. Have the system checked at the nearest Mercedes-Benz Light Truck Center as soon as possible. If the indicator lamps in the SOS button, in the Roadside Assistance button and/or in...
Page 174 Controls in detail Useful features Once the emergency call is in progress, the indicator lamp in the SOS button will begin to flash. The message EMERGENCY CALL – CONNECTING CALL appears in the MCS dis- play. When the connection is established, the message EMERGENCY CALL –...
Page 175 The cover will open. Press and hold the button 2 (for long- er than two seconds). A call to a Mercedes-Benz Roadside As- sistance dispatcher will be initiated. The button will flash while the call is in progress. The message ROADSIDE ASSISTANCE –...
Page 176 Describe the nature of the need for as- sistance. The Mercedes-Benz Roadside assistance dispatcher will either dispatch a qualified Mercedes-Benz technician or arrange to tow your vehicle to the nearest Mercedes-Benz Light Truck Center. For services such as labor and/or towing, charges may apply.
Page 177: Information Button
The nearest Mercedes-Benz Light Truck Center message INFO – CONNECTING CALL will or Mercedes-Benz USA products and ser- appear in the MCS display. vices is available to you. Controls in detail Useful features appears INFO –...
Page 178 Visit propriate indicator lamp will flash. If your Mercedes-Benz Light Truck Cen- certain information such as vehicle identi- ter and have the system checked or...
Page 179 Controls in detail Useful features Contact the Mercedes-Benz Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada). You will be asked to provide your pass- word which you provided when you completed the subscriber agreement.
Page 180: Garage Door Opener
Report the incident to the police The police will issue a numbered inci- dent report. Pass this number on to the Mercedes-Benz Response Center along with your password issued to you when you subscribed to the service. The Response Center will then attempt to covertly contact the vehicle’s Tele...
Page 181 If you should experience diffi- culties with programming the transmit- ter, contact your authorized Mercedes-Benz Light Truck Center, or call Mercedes-Benz Customer Assis- tance Center (in the USA only) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at...
Page 182 Controls in detail Useful features For operation in the USA only: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any inter- ference received, including interfer- ence that may cause undesired operation.
Page 183 The indicator lamp 6 flashes the first time the signal transmitter button is programmed. If this button has already been programmed, the indicator lamp will only start flashing after 20 sec- onds. Step 5: When the indicator lamp 6 flashes rapidly, release both buttons.
Page 184 Controls in detail Useful features Step 9: Press “training” button on the garage door opener motor head unit. The “training light” is activated. You have 30 seconds to initiate the follow- ing step. Step 10: Firmly press, hold for two seconds and release the programmed integrated signal transmitter button (3, 4 or 5).
Page 185 Step 4: Continue to press and hold the inte- grated signal transmitter button (3, 4 or 5) while you press and re-press (“cycle”) your hand-held remote con- trol transmitter 1 every two seconds until the frequency signal has been learned. Upon successful training, the indicator lamp 6 will flash slowly and then rapidly after several seconds.
Page 186: Trip Computer
Controls in detail Useful features Trip computer* The trip computer is located in the overhead console. 1 RESET 2 MODE 3 Display Switching on the trip computer Switch on ignition. Display 3 shows one of the available functions. If a function display does not appear, press MODE 2.
Page 187 Compass The compass displays the direction the ve- hicle is traveling. The display 3 will show you N, NE, E, SE, S, SW, W or NW. The presence of buildings, bridges, power lines and large antenna masts can influence the displayed values. Me- tallic or magnetic objects in or on the vehicle can influence the accuracy of the compass.
Page 188 Controls in detail Useful features Setting the compass zone Determine the geographical point of the vehicle with the aid of the zone maps. Switch on the ignition. Press MODE 2 ( page 186) repeat- edly until the compass display appears in the trip computer display 3.
Page 189 Start the vehicle and start the cali- bration procedure described previ- ously. We recommend that you have the com- pass calibrated at a Mercedes-Benz Light Truck Center. Stop watch Press MODE 2 ( page 186) repeat- edly until the stop watch display ap- pears in the trip computer display 3.
Page 190 Controls in detail Useful features Country Press MODE 2 ( page 186) repeat- edly until the country display appears in the trip computer display 3. Press and hold RESET 1 a minimum of five seconds to change the country unit system.
Page 191: Operation
Operation The first 1000 miles (1500 km) Driving instructions At the gas station Engine compartment Tires and wheels Winter driving Maintenance Vehicle care...
Page 192: The First 1000 Miles (1500 Km)
Operation The first 1000 miles (1500 km) In the “Operation” section you will find de- tailed information on operating, maintain- ing and caring for your vehicle. The first 1000 miles (1500 km) The more cautiously you treat your vehicle during the break-in period, the more satis- fied you will be with its performance later Drive your vehicle during the first 1000 miles (1500 km) at varying but...
Page 193: Driving Instructions
Service Booklet and as required by the FSS. Contact your authorized Mercedes-Benz Light Truck Center Fuel consumption is also increased by driv- ing in cold weather, in stop-and-go traffic, on short trips and in hilly country.
Page 194: Brakes
Have the brake system inspected immedi- ately. Contact your authorized Mercedes-Benz Light Truck Center. All checks and service work on the brake system should be carried out by qualified technicians only. Contact your authorized...
Page 195: Driving Off
Install only brake pads and brake fluid recommended by Mercedes-Benz. Warning! If other than recommended brake pads are installed, or other than recommended brake fluid is used, the braking properties of the vehicle can be degraded to an extent that safe braking is substantially impaired.
Page 196: Parking
Inspect the tires and the vehicle underbody for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Light Truck Center or tire dealer for repairs. Tread wear indicators (TWI) are required by law. These indicators are located in six...
Page 197: Hydroplaning
If ice has formed on the road, tire traction will be substantially reduced. Under such weather conditions, drive, steer and brake with extreme caution. Mercedes-Benz recommends M+S rated radial-ply tires with a minimum tread depth of approximately in (4 mm) on all four wheels for the winter season to ensure normal balanced handling characteristics.
Page 198: Tire Speed Rating
Avoid spinning of one drive wheel. This may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Tire speed rating Regardless of the tire speed rating, local speed limits should be obeyed. Use pru- dent driving speeds appropriate to prevail- ing conditions.
Page 199 Warning! On slippery road surfaces, never downshift in order to obtain braking action. This could result in drive wheel slip and reduced vehi- cle control. Your vehicle’s ABS will not pre- vent this type of control loss. Do not engage the transfer case in position LOW when driving on ice or packed snow.
Page 200: Standing Water
Any such dam- age is not covered by the Mercedes-Benz Limited Warranty. Off-road driving Warning! Drive slowly in unknown terrain. This will make it easier to recognize unexpected ob- stacles and avoid damage to the vehicle.
Page 201 Special driving features for off-road driving The following driving features are available for specific kind of operation: LOW RANGE mode ( page 125) LOW RANGE – ABS ( page 77) LOW RANGE – 4-ETS ( page 80) LOW RANGE – ESP ( page 81) Off-road driving rules Engage the LOW RANGE mode before driv- ing under off-road conditions...
Page 202 Operation Driving instructions Rims Dented or bent rims can cause tire pressure loss and damage the tire beads. For this reason, check and, if necessary, change rims before driving off-road. Vehicle tool kit Check if the vehicle jack is functional. In all cases take the vehicle tool kit, a strong tow rope, a shovel and a small plank (to put under the vehicle jack on...
Page 203 The 4-ETS recognizes the situation and limits the torque for the front wheels by braking them. Simultaneously the torque for the rear wheels is increased. Driving across a hilltop Decelerate just ahead of a hilltop (do not select gear range N), to prevent the vehicle from speeding up too much af- ter climbing a hill.
Page 204 Operation Driving instructions Switch off the exterior lamps as well as the climate control. Select gear range 1 on the automatic transmission ( page 121). Enter the water only at a shallow spot, driving at walking speed. Never accelerate before driving into the water.
Page 205 Inspect the tires and under the vehicle for possible damage. If the vehicle or tires ap- pear unsafe, have it towed to the nearest Mercedes-Benz Light Truck Center or tire dealer for repairs. Operation Driving instructions...
Page 206: Trailer Towing
Ask your authorized Mercedes-Benz Light Truck Center should you require an explana- After continued operation in mud, tion of information contained in this guide.
Page 207 Gross Trailer Weight (GTW) is the maxi- mum permissible trailer weight to be towed: 5000 lbs (2260 kg). Trailer Tongue Weight Rating (TWR) is the maximum permissible weight on the trailer tongue: 500 lbs (225 kg) limit for Mercedes-Benz approved hitch receiver.
Page 208 The tongue weight at the hitch ball must be added to the GVW to prevent exceeding your Mercedes-Benz tow vehicle’s rear GAWR. We recommend loading the trailer in such a manner that it has a tongue weight (TW) between 10% and 15% of the GTW.
Page 209 You should consider using a trailer sway control system. For further infor- mation see your authorized Mercedes-Benz Light Truck Center. Adjust the mirrors to permit unobstructed view beyond rear of trailer. In order to gain skill and an under- standing of the vehicle’s behavior, you...
Page 210 Operation Driving instructions The vehicle and trailer combination is heavier, and therefore is limited in ac- celeration and climbing ability, and re- quires longer stopping distances. It is more prone to reacting to side wind gusts, and requires more sensitive steering input.
Page 211: Passenger Compartment
Driving abroad Abroad, there is an extensive Mercedes-Benz service network at your disposal. If you plan to drive into areas which are not listed in the index of your Mercedes-Benz Light Truck Center directo-...
Page 212: Catalytic Converter
Refer to the radio transmitter operation in- structions regarding use of an external an- tenna. Catalytic converter Your Mercedes-Benz is equipped with monolithic-type catalytic converters, an important element in conjunction with the oxygen sensors to achieve substantial con- trol of the pollutants in the exhaust emis- sions.
Page 213: Coolant Temperature
Mercedes-Benz servicing requirements. For details refer to the Service Booklet. Warning! Inhalation of exhaust gas is hazardous to your health. All exhaust gas contains carbon monoxide, and inhaling it can cause uncon- sciousness and lead to death.
Page 214: At The Gas Station
Operation At the gas station At the gas station Refueling Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious inju- ry. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extinguish all smoking materials. Never allow sparks, flame or smoking materials near gasoline! The fuel filler flap is located on the left-hand side of the vehicle towards the...
Page 215: Check Regularly And Before A Long Trip
Replace the fuel cap by turning it to the right. You will hear when the fuel cap is tight- ened. Close the fuel filler flap. Use only premium unleaded gasoline with a minimum Posted Octane Rating of 91 (average of 96 RON/86 MON). Information on gasoline quality can normally be found on the fuel pump.
Page 216 Noti- fy an authorized Mercedes-Benz Light Truck Center immediately. Do not add brake fluid as this will not solve the problem. For more information, see “Practical Hints”...
Page 217: Engine Compartment
Engine compartment Hood Warning! Do not pull the release lever while the vehi- cle is in motion. Otherwise the hood could be forced open by passing air flow. Opening 1 Release lever Pull release lever 1 downwards. The hood is unlocked. Handle 2 pro- trudes slightly from the radiator-grille.
Page 218: Engine Oil
Do not use any special lubricant addi- tives, as these may damage the drive assemblies. Using special additives not approved by Mercedes-Benz will restrict your warranty entitlement. More information on this subject is available at any Mercedes-Benz Light Truck Center.
Page 219 OIL HI The oil level is too high. Have excess oil siphoned. Excess oil must be siphoned or drained off. It could cause damage to the engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty.
Page 220 ( page 220). In this case we recommend that you have the system checked at a Mercedes-Benz Light Truck Center. See the “Practical hints” section ( page 253) if the low engine oil level warning lamp in the instrument cluster flashes.
Page 221 Using engine oils of other specifi- cation may cause the FSS to incorrect- ly determine the next service interval and will result in engine damage not covered by the Mercedes-Benz Limited Warranty. Operation Engine compartment 1 Oil dipstick 2 Filler cap Unscrew filler cap 2 from filler neck.
Page 222: Transmission Fluid Level
Excess oil must be siphoned or drained off. It could cause damage to the engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. Screw filler cap 2 back on filler neck. More information on engine oil can be found in the “Technical data”...
Page 223: Battery
Operation Engine compartment When replacing batteries, always use bat- teries approved by Mercedes-Benz. If you do not intend to operate your vehicle for an extended period of time, consult an authorized Mercedes-Benz Light Truck Center about steps you need to observe.
Page 224: Windshield Washer System And Headlamp Cleaning System
Operation Engine compartment Wear eye protection. Keep children away. Follow the instructions in this Operator's Manual. Batteries contain materials that can harm the environment if disposed of improperly. Recycling of batteries is the preferred method of disposal. Many states require sellers of batteries to accept old batteries for recycling.
Page 225 Warning! Washer solvent/antifreeze is highly flam- mable. Do not spill washer solvent/antifreeze on hot engine parts, be- cause it may ignite and burn. You could be seriously burned. More information can be found in the “Technical data” section ( page 307). Operation Engine compartment...
Page 226: Tires And Wheels
Replace rims or tires with the same designa- tion, manufacturer and type as shown on the original part. See your authorized Mercedes-Benz Light Truck Center for fur- ther information. If incorrectly sized rims and tires are mounted: The wheel brakes or suspension compo- nents can be damaged.
Page 227: Life Of Tire
When the wheels are heavily soiled, e.g. after driving through mud, clean the inside of the wheels with a jet of water. Life of tire The service life of a tire is dependent upon varying factors including but not limited to: Driving style Tire pressure Distance driven...
Page 228: Rotating Wheels
Operation Tires and wheels The pressures listed for light loads are minimum values offering high driving comfort. Increased inflation pressures listed for heavier loads may also be used for light loads. These higher pressures produce favorable handling characteristics. The ride of the vehicle, however, will be somewhat harder.
Page 229 Operation Tires and wheels Warning! Have the tightening torque checked after changing a wheel. Wheels could become loose if not tightened with a torque of 110 lb-ft (150 Nm). Use only genuine Mercedes-Benz wheel bolts specified for your vehicle's rims.
Page 230: Winter Driving
Operation Winter driving Winter driving Before the onset of winter, have your vehi- cle winterized at an authorized Mercedes-Benz Light Truck Center. This service includes: Check of anticorrosion and antifreeze concentration. Addition of cleaning concentrate to the water of the windshield and headlamp cleaning system.
Page 231: Block Heater (Canada Only)
Follow the manufacturer’s mounting instructions. Only use snow chains that are ap- proved by Mercedes-Benz. Your autho- rized Mercedes-Benz Light Truck Center will be glad to advise you on this subject.
Page 232: Maintenance
Maintenance Maintenance We strongly recommend that you have your vehicle serviced by your authorized Mercedes-Benz Light Truck Center, in accordance with the Service Booklet at the times called for by the FSS (Flexible Ser- vice System). Failure to have the vehicle maintained in...
Page 233: Service Term Exceeded
2 for 30 seconds and a signal sounds after switching on the ignition. it is preceded by a “–” (minus symbol). The Mercedes-Benz Light Truck Center will reset the service indicator following a com- pleted service. Calling up the service indicator Within one second press knob 1 twice.
Page 234: Vehicle Care
Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others ap- plied later.
Page 235 We have selected car-care products and compiled recommendations which are specially matched to our vehicles and which always reflect the latest technology. You can obtain Mercedes-Benz approved car-care products at your authorized Mercedes-Benz Light Truck Center. Scratches, corrosive deposits, corrosion or...
Page 236 Vehicle washing Do not use hot water or wash your vehicle in direct sunlight. Use only a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo. Thoroughly spray the vehicle with a dif- fused jet of water. Direct only a very weak spray towards the ventilation intake.
Page 237 Cleaning the Parktronic* system sensors 1 Parktronic system sensors Use a mild car wash detergent, such as Mercedes-Benz approved Car Sham- poo, with plenty of water to clean the sensors 1. When using a steam cleaner or power washer, aim nozzle only briefly from a min- imum distance of 4 in (10 cm) at sensors 1.
Page 238 Mercedes-Benz approved Wheel Care should be used for regular cleaning of the light alloy wheels. If possible, clean wheels once a week with Mercedes-Benz approved Wheel Care, us- ing a soft bristle brush and a strong spray of water. Follow instructions on container.
Page 239 Leather upholstery* Wipe leather upholstery with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care. Exercise particular care when cleaning per- forated leather as its underside should not become wet. MB Tex upholstery...
Page 241: Practical Hints
Practical hints What to do if … Where will I find ...? Unlocking/locking in an emergency Opening/closing in an emergency Replacing bulbs Replacing wiper blades Flat tire Battery Jump starting Towing the vehicle Fuses...
Page 242: What To Do If
Continue driving with added caution. Wheels may lock during hard braking reducing steering capability. Have the system checked at an autho- rized Mercedes-Benz Light Truck Cen- ter as soon as possible. Failure to follow these instructions in- creases the risk of an accident.
Page 243 What to do if … Suggested solution Have the system checked as soon as possible by an authorized Mercedes-Benz Light Truck Center. Make sure there is nothing between seat cushion and child seat and check installation of the child seat ( page 67).
Page 244 Suggested solution Risk of accident! Carefully stop the vehicle and notify an authorized Mercedes-Benz Light Truck Center. Do not add brake fluid! This will not solve the problem. Release the parking brake ( page 47).
Page 245 Practical hints What to do if … Suggested solution Have the system checked immediate- ly at an authorized Mercedes-Benz Light Truck Center. Failure to follow these instructions in- creases the risk of accidents. will go out after driving a short distance at...
Page 246 If the BAS/ESP malfunction indicator lamp does not go out: Continue driving with added caution. Visit an authorized Mercedes-Benz Light Truck Center as soon as possi- ble. Failure to follow these instructions increases the risk of an accident.
Page 247 If necessary, have the generator and the battery checked. Continue driving with added caution. Have the BAS/ESP checked at an au- thorized Mercedes-Benz Light Truck Center as soon as possible. Failure to follow these instructions increases the risk of an accident.
Page 248 Your fuel tank is empty. Suggested solution Have the vehicle checked as soon as possible by an authorized Mercedes-Benz Light Truck Center. An on-board diagnostic connector is used by the service station to link the vehicle to the shop diagnostics sys- tem.
Page 249 Check the coolant level and add coolant if necessary ( page 222). Have the cooling system checked by an authorized Mercedes-Benz Light Truck Center. Stop as soon as possible and allow the engine and coolant to cool down.
Page 250 Do not ignore the coolant warning lamps. Extended driving with the sym- bol displayed may cause serious engine damage not covered by the Mercedes-Benz Limited Warranty. Do not drive without sufficient amount of coolant. The engine will overheat, causing major engine damage.
Page 251 Switch the ESP back on ( page 82). If the ESP cannot be switched back on, have the system checked at an autho- rized Mercedes-Benz Light Truck Center as soon as possible. During take-off, apply as little throttle as possible.
Page 252 As soon as the brakes have cooled off, 4-ETS switches on again. The indicator lamp goes out. Have the 4-ETS checked at an autho- rized Mercedes-Benz Light Truck Cen- ter as soon as possible. Repeat the gear selection process ( page 125).
Page 253 Add approved oil at the next gas station ( page 302). If oil loss is visible on the engine, have the malfunction corrected as soon as possible at a Mercedes-Benz Light Truck Center. Lock the adjustable steering column ( page 39).
Page 254 Suggested solution Stop immediately and check the poly-V-belt. If it is broken Do not continue to drive, before the poly-V-belt is replaced. Notify an authorized Mercedes-Benz Light Truck Center. Have the system checked at an autho- rized Mercedes-Benz Light Truck Center.
Page 255 SRS may not be operational. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Light Truck Center immedi- ately to have the system checked, otherwise the SRS may not be activated when needed...
Page 256: Additional Indicators In The Speedometer Display
Suggested solution Visit an authorized Mercedes-Benz Light Truck Center to perform service. Visit an authorized Mercedes-Benz Light Truck Center to perform service. Contact an authorized Mercedes-Benz Light Truck Center or call 1-800-FOR-MERCedes (in the USA), or 1-800-387-0100 (in Cana- da).
Page 257: Where Will I Find
Where will I find ...? First aid kit Check expiration dates and contents for completeness at least once a year and replace missing/expired items. The first aid kit is stored in the liftgate. Open and fold down panel 1. The first aid kit can be removed. Vehicle tool kit The vehicle tool kit is stored in the cargo area behind the right trim panel.
Page 258 Practical hints Where will I find ...? 1 Vehicle jack 2 Wheel bolt wrench 3 Screwdriver 4 Interchangeable slot Screwdriver 3 is placed inside the wheel- bolt wrench handle. Vehicle jack Please also observe the safety guidelines in the “Flat tire” section ( page 274) when using the jack.
Page 259: Spare Wheel (Space-Saver Tire)
Spare wheel (space-saver tire) Use the spare wheel only temporarily, while observing the following restrictions: Do not exceed vehicle speed of 50 mph (80 km/h). Drive to the nearest repair facility to have the flat tire repaired or replaced as appropriate. Do not operate vehicle with more than one spare wheel mounted.
Page 260 Practical hints Where will I find ...? 5 Bayonet lock Turn the bayonet lock 5 90° to the left. Pull off bayonet lock 5. Remove the spare wheel cover and the spare wheel. Store bayonet lock 5 and spare wheel cover in cargo area.
Page 261: Unlocking/Locking In An Emergency
Unlocking/locking in an emergency Unlocking the vehicle Unlocking the driver’s door If you are unable to unlock the driver’s door using the remote control, open the door using the key. 1 Release button Press release button 1 on the remote control.
Page 262: Locking The Vehicle
It is recommended to have the batteries replaced at an autho- rized Mercedes-Benz Light Truck Center. Warning! Keep the batteries out of reach of children. If a battery is swallowed, seek medical help immediately.
Page 263: Fuel Filler Flap
If it is not possible to resynchronize the remote control, have the system checked at your authorized Mercedes-Benz Light Truck Center. The fuel filler flap can now be opened. Practical hints Open the tailgate. Open cover 1 in cargo area behind the left trim panel.
Page 264: Manually Unlocking The Transmission Gear Selector Lever
Practical hints Unlocking/locking in an emergency Manually unlocking the transmission gear selector lever In the case of power failure the transmis- sion gear selector lever can be manually unlocked, e.g. to tow the vehicle. 1 Pin Insert a pin 1, e.g. ball point pen, into the covered opening below the position D of the shift pattern.
Page 265: Opening/Closing In An Emergency
Opening/closing in an emergency Sliding/pop-up roof* You can open or close the sliding/pop-up roof manually should an electrical malfunc- tion occur. The sliding/pop-up roof drive is located behind the cover between the front interior lamps. 1 Hexagon drive hole 2 Crank 3 Cover Pry off cover 3 using a flat blade srewdriver.
Page 266: Replacing Bulbs
Have headlamps checked and readjusted at regular intervals and when a bulb has been replaced. See your autho- rized Mercedes-Benz Light Truck Center for headlamp adjustment. If the headlamps are fogged up on the inside as a result of high humidity, driv- ing the vehicle a distance should clear out the fogging.
Page 267 Your hands should be dry and free of oil and grease. If the newly installed bulb does not light up, visit an authorized Mercedes-Benz Light Truck Center. Have the LEDs and bulbs for the follow- ing lamps replaced by an authorized...
Page 268: Replacing Bulbs For Front Lamps
Practical hints Replacing bulbs Replacing bulbs for front lamps Replacing low beam bulbs 1 Low beam halogen or Bi-Xenon* head- lamp cover with locking tab 2 Electrical connector Bi-Xenon* headlamp Warning! Do not remove the cover for the Bi-Xenon headlamp. Because of high voltage in xenon lamps, it is dangerous to replace the bulb or repair the lamp and its compo- nents.
Page 269 High beam bulbs 1 High beam headlamp cover with lock- ing tab Switch off the lights. Open the hood ( page 217). Twist cover 1 counterclockwise and remove. 2 Electrical connector Pull electrical connector 2 off. Unclip the retainer springs and take out the bulb.
Page 270: Replacing Bulbs For Rear Lamps
Practical hints Replacing bulbs Align headlamp cover and click into place. Fog lamp bulbs 1 Fog lamp Switch off the lights. Use a suitable object (e.g. screwdriver) to press on the release lever behind the front panel. Front fog lamp 1 releases. Remove fog lamp out of bumper.
Page 271 7 Tabs Squeeze tabs 7 together and remove bulb holder. Gently push bulb into socket, turn counterclockwise and remove. Insert new bulb in socket, push in and turn clockwise. Reinstall bulb holder. You should hear it engage. Insert the tail lamp in the body, lower edge first.
Page 272: Adjusting Headlamp Aim
2: 0.50° pitch screw 3: 0.67° pitch The left and right headlamps must be ad- justed individually. If it is not possible to obtain a proper headlamp adjustment, have the system checked at your authorized Mercedes-Benz Light Truck Center.
Page 273: Replacing Wiper Blades
Make certain that the wiper blades are properly installed. Improperly installed wiper blades may cause windshield damage. For your convenience, we recommend that you have this work carried out by an authorized Mercedes-Benz Center.
Page 274: Flat Tire
When driving with spare wheel mounted, en- sure proper tire pressure and do not exceed vehicle speed of 50 mph (80 km/h). Drive to the nearest Mercedes-Benz Light Truck Center as soon as possible to have the spare wheel replaced with a regular road wheel.
Page 275 Warning! The jack is designed exclusively for jacking up the vehicle at the jack take-up brackets built into both sides of the vehicle. To help avoid personal injury, use the jack only to lift the vehicle during a wheel change. Never get beneath the vehicle while it is supported by the jack.
Page 276 Damaged wheel hub threads should be re- paired immediately. Do not continue to drive under these circumstances! Contact an au- thorized Mercedes-Benz Light Truck Center or call Roadside Assistance. Incorrect wheel bolts or improperly tight- ened wheel bolts can cause the wheel to come off.
Page 277 1-5 Wheel bolts Tighten the five wheel bolts evenly, fol- lowing the diagonal sequence illustrat- ed (1 to 5), until all bolts are tight. Observe a tightening torque of 110 lb-ft (150 Nm). Warning! Have the tightening torque checked after changing a wheel.
Page 278: Battery
Have the battery checked regularly by an authorized Mercedes-Benz Light Truck Center. Refer to Service Booklet for mainte- nance intervals or contact your autho- rized Mercedes-Benz Light Truck Center for further information.
Page 279: Disconnecting The Battery
Disconnecting the battery Warning! With a disconnected battery you will no longer be able to turn the key in the steering lock the gear selector lever will remain locked in position P Depress parking brake firmly or move gear selector lever to position P. Turn off all electrical consumers.
Page 280 Practical hints Battery The following procedures must be car- ried out following any interruption of battery power (e.g. due to reconnec- tion): Set the clock ( page 118). Set the date in trip computer ( page 186). Calibrate the compass ( page 188).
Page 281: Jump Starting
If engine does not run after several un- successful starting attempts, have it checked at the nearest authorized Mercedes-Benz Light Truck Center. Excessive unburned fuel generated by repeated failed starting attempts may damage the catalytic converter and may present a fire risk.
Page 282 Remove the jumper cables first from the negative terminals 2 and 3 and then from positive terminals 1 and 4. You can now turn on the lights. Have the battery checked at the nearest authorized Mercedes-Benz Light Truck Center. Do not tow-start the vehicle.
Page 283: Towing The Vehicle
Towing the vehicle Mercedes-Benz recommends that the vehi- cle be transported with all wheels off the ground using flatbed or appropriate wheel lift/dolly equipment. This method is pref- erable to other types of towing. Use flatbed or wheel lift/dolly equip- ment, with key in steering lock turned to position 0.
Page 284 Practical hints Towing the vehicle Warning! If circumstances require towing the vehicle with all wheels on the ground, always tow with a tow bar if: the engine will not run there is a malfunction in the power sup- ply or in the vehicle’s electrical system Prior to towing the vehicle with all wheels on the ground, make certain that the key is in steering lock position 2.
Page 285: Front Towing Eye
Front towing eye The gear selector lever will remain The front towing eye is located on the pas- locked in position P and the key will not senger side below the bumper. turn in the steering lock if the battery is disconnected or discharged.
Page 286: Stranded Vehicle
Practical hints Towing the vehicle Vehicles with sport package* 1 Cover 2 Towing eye To remove cover: Grip cover 1 at bottom and securely pull out. To reinstall cover: Engage cover and press in securely. Stranded vehicle Freeing a stranded vehicle, on which the wheels are dug into sand or mud, should be done with the greatest of care, especial- ly if the vehicle is heavily loaded.
Page 287: Fuses
Fuses Only install fuses that have been tested and approved by Mercedes-Benz and that have the specified amperage rat- ing. Never attempt to repair or bridge a blown fuse. Have the cause determined and remedied by an authorized Mercedes-Benz Light Truck Center.
Page 288: Auxiliary Fuse Box In Front Passenger Footwell
Practical hints Fuses Auxiliary fuse box in front passenger footwell The auxiliary fuse box is located in the front passenger compartment. 1 Lock 2 Cover Removing/installing cover Turn both locks 1 90 ° counterclock- wise. Remove cover 2 in direction of arrow. Install cover 2 in reverse order.
Page 289: Technical Data
Technical data Spare parts service Warranty coverage Identification labels Layout of poly-V-belt drive Engine Rims and tires Electrical system Main Dimensions Weights Fuels, coolants, lubricants etc. Consumer information...
Page 290: Spare Parts Service
Spare parts service All authorized Mercedes-Benz Centers maintain a stock of genuine Mercedes-Benz Parts parts required for maintenance and repair work. In addition, strategically located parts distribution cen- ters provide quick and reliable parts ser- vice.
Page 291: Warranty Coverage
Emission Performance Warranty California, Maine, Massachusetts, and Vermont Emission Control Systems Warranty Replacement parts and accessories are covered by the Mercedes-Benz Spare Parts and Accessories warranties, copies of which are available at any Mercedes-Benz Center. Loss of Service and Warranty...
Page 292: Identification Labels
Technical data Identification labels Identification labels 1 Certification label and Paintwork num- 2 Engine number (engraved on engine) 3 VIN, visible (lower edge of windshield) 4 Emission control label Vacuum line routing for emission con- trol system 5 Information label, California version When ordering spare parts, please specify vehicle identification and en- gine numbers.
Page 293: Layout Of Poly-V-Belt Drive
Technical data Layout of poly-V-belt drive Layout of poly-V-belt drive 1 Automatic belt tensioner 2 Power steering pump 3 Air conditioning compressor 4 Crankshaft 5 Coolant pump 6 Generator (alternator) 7 Idler pulley...
Page 294: Engine
Maximum torque acc. to SAE J 1349 Maximum engine speed Firing order Poly-V-belt The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Light Truck Center for the corresponding data of all special bodies and special equipment. ML 350 (163.157 ML 500 (163.175)
Page 295: Charging And Reinstalling Rims And Tires
Rims* (light alloy) Wheel offset* All-season tires (radial-ply tires)* Moreover, tires and rims not approved by Mercedes-Benz may, under load, ex- hibit dimensional variations and differ- ent tire deformation characteristics that could cause them to come into contact with the vehicle body or axle parts.
Page 296: Spare Wheel
Technical data Rims and tires Spare wheel Model ML 350, ML 500 4 Jx18 H2 ET0 Wheel offset 0 in (0 mm) Space-saver tire T155/90 D18 113M Must not be used with snow chains.
Page 297: Electrical System
Electrical system Model ML 350 Generator (alternator) 14 V/120 A Starter motor 12 V/1.7 kW Battery 12 V/100 Ah Spark plugs Bosch F 8 DPP332 Bosch F 8 DPER Electrode gap 0.039 in (1.0 mm) Tightening torque 15 – 22 lb-ft (20 – 30 Nm) Technical data Electrical system ML 500...
Page 298: Main Dimensions
Technical data Main Dimensions Main Dimensions Model ML 350, ML 500 Overall vehicle length 182.6 in (4638 mm) Overall vehicle width 83.7 in (2126 mm) Overall vehicle height 71.7 in (1820 mm) Wheelbase 111.0 in (2820 mm) Track, front 61.2 in (1555 mm) Track, rear 61.2 in (1555 mm) Ground clearance...
Page 299: Weights
Technical data Weights Weights Roof load max. 220 lbs (100 kg)
Page 300: Fuels, Coolants, Lubricants Etc
(Hypoid gear oil SAE 90) approx. 0.65 US qt (0.6 l) MB Power Steering Fluid approx. 1.5 oz (43 g) each High temperature roller bearing grease Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Light Truck Center.
Page 301 Model Cooling system Fuel tank ML 350, ML 500 including a reserve of Air conditioning system Windshield washer and headlamp cleaning system* Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing or MB Windshield Washer Concentrate “S” and commercially available pre- mixed windshield washer solvent/antifreeze for temperatures below freezing.
Page 302: Engine Oils
Always check the oil filler cap ( page 221) for important information pertaining to the engine oil needing to meet a specific Mercedes-Benz specifi- cation (e.g. MB 229.5). If such informa- tion is printed on the oil filler cap, only...
Page 303: Premium Unleaded Gasoline
Fuels, coolants, lubricants etc. Gasoline additives A major concern among engine manufac- turers is carbon build-up caused by gaso- line. Mercedes-Benz recommends only the use of quality gasoline containing additives that prevent the build-up of carbon depos- its. After an extended period of using fuels...
Page 304: Coolants
Please make sure the mixture is in accor- dance with label instructions. The water in the cooling system must meet minimum requirements, which are usually satisfied by normal drinking water. If you are not sure about the water quality, con- sult your authorized Mercedes-Benz Light Truck Center.
Page 305: Anticorrosion/Antifreeze
Before the start of the winter season (or once a year in hot southern regions), you should have the anticorrosion/antifreeze concentration checked. The coolant is also regularly checked each time you bring your vehicle to your authorized Mercedes-Benz Light Truck Center for service.
Page 306 Technical data Fuels, coolants, lubricants etc. Anticorrosion/antifreeze quantity Model Approx. freeze protection – 35°F (– 37°C) – 49°F (– 45°C) ML 350, ML 500, 6.4 US qt (6.0 l) 7.0 US qt (6.6 l)
Page 307: Windshield Washer System And Headlamp Cleaning System
Windshield washer system and headlamp cleaning system* Both the windshield washer and headlamp cleaning system* are supplied from the windshield washer fluid reservoir. The windshield and headlamp washer fluid reservoir has a capacity of approx. 8.0 US qt (7.6 l). Refill the reservoir with MB Windshield Washer Concentrate “S”...
Page 308: Consumer Information
Technical data Consumer information Consumer information This has been prepared as required of all manufacturers of passenger cars under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”. Uniform tire quality grading Quality grades can be found, where appli- cable, on the tire sidewall between tread...
Page 309: Temperature
Temperature The temperature grades are A (the high- est), B, and C, representing the tire’s resis- tance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high tem- perature can cause the material of the tire to degenerate and reduce tire life, and ex- cessive temperature can lead to sudden...
Page 311: Technical Terms
(indicator lamp 7 in the instrument cluster lights up). See your authorized Mercedes-Benz Light Truck Center for availability. BabySmart compatible child seats Special restraint system for children.
Page 312 Technical terms Engine oil viscosity Measurement for the inner friction (vis- cosity) of the oil at different tempera- tures. The higher the temperature an oil can tolerate without becoming thin, or the lower the temperature it can tol- erate without becoming viscous, the better the viscosity.
Page 313 GVWR (Gross Vehicle Weight Rating) This is the maximum permissible vehi- cle weight. It is indicated on certifica- tion label located on the driver’s door pillar. Instrument cluster The displays and indicator/warning lamps in the driver’s field of vision, in- cluding the tachometer, speedometer, engine temperature and fuel gauge.
Page 314 Remote Vehicle Diagnostics Transmission of vehicle data and cur- rent location to the Mercedes-Benz Customer Assistance Center for sub- scribers to Tele Aid service. REST (Residual engine heat utilization) Feature that uses the engine heat...
Page 315 Tele Aid System* (Telematic Alarm Identification on Demand) The Tele Aid system consists of three types of response: automatic and man- ual emergency, roadside assistance and information. Tele Aid is initially ac- tivated by completing a subscriber agreement and placing an acquain- tance call.
Page 317: Index
ABS 25, 76, 311 ABS control 76 LOW RANGE mode 77 Malfunction indicator lamp 242 Warning lamp 242 Accelerator position, automatic transmission 123 Accident In case of 52 Activating Air circulation mode 139 Air recirculation mode 139 Anti-theft alarm system 83 Automatic climate control 135 ESP 82 Exterior headlamps 48...
Page 318 Index Air conditioning refrigerant 302 Air outlets Automatic climate control 142 Air pressure see Tire inflation pressure 227 Air recirculation mode 138 Activating 139 Deactivating 139 AIRBAG OFF Warning lamp 243 Airbags 59 BabySmart airbag deactivation system 311 BabySmart deactivation system 70 Children 60 Front 63...
Page 319 Rear passenger compartment 141 Rear window defroster 133 Residual heat utilization 140 Residual ventilation 140 Switching off 137 Switching on 137 Automatic headlamp mode 108 Automatic interior lighting control Activating 113 Deactivating 113 Automatic locking when driving 93 Automatic transmission 119 Accelerator position 123 Emergency operation (Limp Home Mode) 124...
Page 320 Index Bulbs, replacing 266 Additional turn signals 266 Backup lamps 267 Brake lamps 267 Fog lamps 266 Front fog lamp 270 Front lamps 266 High beam 266 High mounted brake lamp 267, 271 License plate lamps 267, 271 Low beam 266 Parking lamps 266, 267, 269 Rear fog lamp 267 Rear fog lamps 270...
Page 321 Chart Fuses 287 CHECK ENGINE malfunction indicator lamp 248 Checking Coolant level 215, 222 Oil level 218 Tire inflate pressure 216 Vehicle lighting 216 Checking weights Trailer and vehicle 208 Checklist Off-road driving 201 Returning from off-road driving 206 Child safety 67 Airbags 60 Infant and child restraint systems 64, LATCH child seat mounts 72...
Page 322 Index Coolant 222, 304 Adding 223 Anticorrosion/antifreeze quantity 304 Checking level 222 Indicator lamp 249 Temperature 213 Temperature gauge 117 Coolant level Checking 215, 222 Crossing obstacles 204 Cruise control 150, 311 Canceling 151 Driving downhill 151 Driving uphill 151 Fine adjustment 152 LOW RANGE mode 152 Saving current speed 151...
Page 323 Display messages Error 256 Service indicator (FSS) 256 StArt 256 Displays Messages 219 Service indicator 232 Distance remaining 189 Door entry lamps 113 Door unlock With Tele Aid* 179 Doors Opening from inside vehicle 90 Opening from outside 89 Downhill driving Cruise control 151 Downshifting 120 Drink holder see Cup holder 167...
Page 324 Index Emergency calls Initiating an emergency call 175 With Tele Aid* 173 Emergency operation (Limp Home Mode) 124 Emergency operations Closing sliding/pop-up roof* 265 Locking the vehicle 262 Opening sliding/pop-up roof* 265 Remote door unlock 179 Unlocking the vehicle 261 Emergency tensioning device see ETD 67, 312 Emission control 212...
Page 325 Fastening the seat belts 42 Fine adjustment Cruise control 152 First aid kit 257 Flat tire 274 Lowering the vehicle 276 Mounting the spare wheel 274 Preparing the vehicle 274 Spare wheel 259 Flexible Service System (FSS) 232, 312 Fluid level Automatic transmission 222 Fog lamp, rear 267 Fog lamps 111...
Page 326 Index Gear range 312 Automatic transmission 121 Limiting 121 Shifting into optimal 120 Gear range limit Canceling 120 Gear selector lever Cleaning 238 Position 122 Glass breakage sensor 84 Global Positioning System (GPS) 312 Glossary 311 Glove box 23, 164 Closing 164 Opening 164 Good visibility 126...
Page 327 Identification labels 292 Certification label 292 Vehicle identification number (VIN) 292 Ignition 33 Immobilizer 83 Activating 54, 83 Deactivating 83 Indicator lamp Adjustable steering column 253 Brake pad wear 254 Coolant 249 Front fog lamps 253 Low engine oil level 253 Indicators, additional Speedometer display 256 Infant and child restraint systems 68...
Page 328 Index Global locking 89 Global unlocking 89 Loss of 90 Positions in steering lock 33 Remote control with folding key 88 Unlocking liftgate 89 Unlocking the driver’s door, fuel filler flap 89 Key positions in steering lock 33 Key, Mechanical 261 Key, Remote control Unlocking with 32 Kickdown 123, 313...
Page 329 Lighting 107 Automatic headlamp mode 108 Cargo compartment 114 Combination switch 110 Daytime running lamp mode 109 Door entry lamps 113 Front fog lamps 111 High beam flasher 110 High beams 110 Instrument cluster illumination 116 Interior 112 Locator lighting 110 Night security illumination 109 Limiting the gear range 121 Limp Home Mode 124...
Page 330 Index Manual seat Adjusting 35 Adjusting backrest tilt 36 Adjusting head restraint height 36 Adjusting head restraint tilt 37, 39 Seat fore and aft adjustment 35 Seat height 36 MB Tex upholstery Cleaning 239 Modular Control System 313 Mechanical key 261 Memory function 105, 313 Memory function* 106 Recalling positions from...
Page 331 Adding 221 Consumption 218 Dipstick 218 Oil dipstick 221 Viscosity 312 One-touch gearshifting 120 Canceling gear range limit 120 Downshifting 120 Upshifting 120 Opening Doors from the inside 90 Fuel filler flap 214 Fuel filler flap manually 263 Glove box 164 Hood 217 Liftgate 89, 91 Liftgate from inside 91...
Page 332 Index Partition net* 159 Engaging 159 Removing 161 Tightening 160 Parts see Spare parts service Passenger compartment 211 Interior lighting 112 Passenger footwell Fuse box in 288 Passenger safety see Occupant safety 58 Pedals 193 Plastic and rubber parts Cleaning 239 Poly-V-belt drive 314 Layout 293 Positions (Memory function*)
Page 333 Reading lamps 114 Rear automatic climate control 141 Adjusting air volume and air distribu- tion manually 141 Automatic mode 141 Rear bench seat Foldable 99 Rear door window Blocking operation 73 Rear fog lamp 267 Bulb 267 Switching on 111 Rear lamp bulbs Replacing 270 Rear parking lamp...
Page 334 Index Remote door unlock With Tele Aid* 179 Remote Vehicle Diagnostics 314 Removing Vehicle battery 279 Wheel 276 Wiper blades 273 Removing spare wheel 259 Replacing Backup lamp bulbs 270 Brake lamp bulbs 270 Bulbs 266 Front lamp bulbs 268 Front turn signal bulbs 268 Fuses 287 High beam bulbs 269...
Page 335 Seat belts 64 Cleaning 238 Fastening 42 Height adjustment 45 Proper use of 44, 66 Safety guidelines 62 Warning lamp 253 Seat heater* Switching off 98 Switching on 98 Seats 95 Adjusting 34 Heater* 98 Manual 35 Power 37 Rapid seat heating* 98 Rear 99 Split rear bench seat 99 Securing cargo...
Page 336 Index Side windows 144 Automatic closing 145 Automatic opening 145 Cleaning 237 Closing 145 Closing fully (Express-close) 145 Opening 145 Opening and closing 144 Opening fully (Express-open) 145 Rear quarter window 146 Stopping 145 Synchronizing power windows 146 Simultaneous wiping and washing Rear window wiper/washer 51 Windshield wipers 50 Single wipe 50...
Page 337 Sun visor 132 Supplemental Restraint System (SRS) 314 Switching off Automatic climate control 137 ESP 81 Hazard warning flasher 112 Headlamps 54 Rapid seat heating 99 Transmission control – LOW RANGE mode 125 Switching on Automatic climate control 137 ESP 82 Front fog lamps 111 Front fog lamps, rear fog lamp 111 Hazard warning flasher 112...
Page 338 Index Tele Aid* 171 Emergency calls 173 Information 177 Initiating an emergency call manually 175 Remote door unlock 179 Roadside assistance 175 Stolen vehicle tracking services 180 System self-check 172 Upgrade signals 178 Telematics* 315 Telephone* 170 Temperature Grades of tires 309 Tires 228 Third row seats* 102 Folding down single seat 102...
Page 339 Traction 308, 315 Trailer Attaching 208 Loading 208 Towing 209 Trailer hitches 207 Trailer towing 206 Attaching a trailer 208 Checking weights 208 Electrical connections 207 Hitches 207 Loading 208 Weights and ratings 207 Trailer weights and ratings 207 Transfer case 315 Transmission control –...
Page 340 Index Useful features 164 Ashtrays and cigarette lighter 168 Cup holder 166 Electrical outlet 170 Garage door opener 180 Interior storage spaces 164 Programming or reprogramming the in- tegrated remote control 182 Tele Aid* 171 Telephone* 170 Trip computer* 186 Vehicle Locking 28 Locking in an emergency 262...
Page 341 Wear pattern (tires) 228 Weights 299 Wheel bolt wrench 258 Wheel change Tightening torque 277 Wheels Rotating 228 Window curtain airbags 64 Windows see Side windows Windshield Defogging 138 Refilling washer fluid 224 Replacing wiper blades 273 Washer fluid 224, 307 Washer system 307 Windshield washer fluid 307 Filler neck 224...
Page 343 If you have questions about carrying out any type of service, turn to the advice of an authorized Mercedes-Benz Light Truck Center.
