Page 1 C 240 C 240 4MATIC C 320 C 320 4MATIC...
Page 2 Your Mercedes-Benz represents the ef- forts of many skilled engineers and crafts- men. To help assure your driving pleasure, and also the safety of you and your passen-...
Page 3: Table Of Contents
Operator’s Manual ... 10 Service and warranty information .. 10 Important notice for California retail buyers and lessees of Mercedes-Benz automobiles ... 11 Maintenance ... 12 Roadside Assistance ... 12 Change of address or ownership... 12 Operating your vehicle outside the USA or Canada...
Page 4 Contents Safety and Security ... 55 Occupant safety... 56 Airbags ... 57 Seat belts ... 62 Children in the vehicle... 65 Blocking of rear door window operation... 72 Panic alarm* ... 73 Activating ... 73 Deactivating ... 73 Driving safety systems... 74 ABS ...
Page 5 Automatic transmission... 139 One-touch gearshifting... 140 Gear ranges ... 141 Gear selector lever position ... 142 Program mode selector switch... 143 Accelerator position... 144 Emergency operation (Limp Home Mode) ... 144 Good visibility ... 145 Windshield wipers ... 145 Headlamp cleaning system* ... 145 Rear view mirrors...
Page 6 Contents Operation ... 237 The first 1000 miles (1500 km)... 238 Driving instructions... 239 Drive sensibly – save fuel ... 239 Drinking and driving ... 239 Pedals ... 239 Power assistance ... 239 Brakes ... 240 Driving off... 241 Parking ... 241 Tires ...
Page 7 Practical hints ... 273 What to do if … ... 274 Lamps in instrument cluster ... 274 Lamp in center console... 279 Messages in the display ... 280 Where will I find ...? ... 300 First aid kit... 300 Vehicle tool kit ... 300 Minispare wheel...
Page 8 Contents Technical data... 335 Spare parts service ... 336 Warranty coverage... 337 Loss of Service and Warranty Information Booklet... 337 Identification labels... 338 Layout of poly-V-belt drive ... 339 C 240/C 320 (all models) ... 339 Engine... 340 Rims and Tires ... 341 Same size tires ...
Page 9: Introduction
Product information Please observe the following in your own best interest: We recommend using genuine Mercedes-Benz parts as well as conversion parts and accessories explicitly approved by us for your vehicle model. We have tested these parts to determine their reliability, safety and special suitability for Mercedes-Benz vehicles.
Page 10: Operator's Manual
Therefore, you may find explanations for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment, your au- thorized Mercedes-Benz Center will be glad to demonstrate the proper proce- dures. We continuously strive to improve our...
Page 11: Mercedes-Benz Automobiles
Under California law you may be entitled to a replacement of your vehicle or a refund of the purchase price or lease price, if Mercedes-Benz USA, LLC and/or its au- thorized repair or service facilities fail to fix one or more substantial defects or mal-...
Page 12: Maintenance
Always have the Service Booklet with you when you take the vehicle to your autho- rized Mercedes-Benz Center for service. The service advisor will record each service in the booklet for you. Roadside Assistance...
Page 13: Operating Your Vehicle Outside The Usa Or Canada
Certain Mercedes-Benz models are avail- able for delivery in Europe under our Euro- pean Delivery Program. For details, consult your authorized Mercedes-Benz Center or...
Page 14: Where To Find It
Here you will find all the information you need for your first drive. You should read this section first if this is your first Mercedes-Benz vehicle or if you are rent- ing or borrowing this vehicle. Safety and Security Here you will find descriptions of the safety features of your vehicle.
Page 15: Symbols
Symbols The following symbols are found in this Operator’s Manual: Optional equipment is identified with an asterisk. Since standard equipment varies between models, the descriptions and illustrations in this manual may differ slightly from the actual equipment of your vehi- cle.
Page 16: Operating Safety
Electronic malfunctions could seriously impair the operating safety of your vehicle. See your authorized Mercedes-Benz Center for repairs or modifications to electronic components. Other improper work or modifications on the vehicle could also have a negative impact on the operating safety of the vehicle.
Page 17: Problems With Your Vehicle
If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact your authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is...
Page 18: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 19: At A Glance
At a glance Cockpit Instrument cluster Multifunction steering wheel Center console Overhead control panel Door control panel...
Page 20: Cockpit
At a glance Cockpit Cockpit...
Page 21 Item Page 1 Combination switch Turn signals Windshield wipers High beam 2 Cruise control lever 3 Instrument cluster 4 Multifunction steering wheel 5 Lever for voice control system*, see separate operating instructions Item Page 6 Overhead control panel 7 Glove box lid release, glove box lock 8 Glove box 9 Center console...
Page 22: Instrument Cluster
At a glance Instrument cluster Instrument cluster...
Page 23: Antilock Brake
Item Page 1 Left turn signal indicator lamp 2 Speedometer 3 Right turn signal indicator lamp 4 Fuel gauge with: Fuel reserve warning lamp 5 < Seat belt non-usage warning lamp 1 Supplemental restraint system indicator lamp 6 Multifunction display with: Trip odometer Main odometer...
Page 24: Multifunction Steering Wheel
At a glance Multifunction steering wheel Multifunction steering wheel Item Page 1 Multifunction display in speedometer Operating control system 2 Selecting the submenu or setting the volume ç down/to decrease æ up/to increase 3 Telephone*: Press button í to take a call ì...
Page 25: Important Notice For California Center Console
Center console Upper part Item Page 1 Seat heater*, driver’s side 2 Rear window wiper/washer 3 ESP control switch 4 Hazard warning flasher switch – switching on/off 5 Central locking switch 6 Anti-theft alarm system indicator lamp Tow-away alarm switch At a glance Center console Item...
Page 26: Lower Part
At a glance Center console Lower Part Item Page 1 Ashtray 2 Gear selector lever for automatic transmission 3 Storage compartment Cup holder Cigarette lighter 4 Armrest 5 Program mode selector for automatic transmission...
Page 27: Overhead Control Panel
Overhead control panel 1 Rear interior lighting 2 Sliding/pop-up roof* 3 Right reading lamp on/off 4 Interior lighting control 5 Hands-free microphone for 6 Interior rear view mirror 7 Garage door opener 8 Left reading lamp on/off 9 Tele Aid* (emergency call Item Page on/off...
Page 28: Door Control Panel
At a glance Door control panel Door control panel Item Page 1 Door handle 2 Memory function* (for storing seat, exterior mirror and steering wheel settings) 3 Seat adjustment 32, 90 4 Switches for opening/closing front door windows 5 Switch for rear door window override 6 Switches for opening/closing rear door...
Page 29: Getting Started
Getting started Unlocking Adjusting Driving Parking and locking...
Page 30: Unlocking
Getting started Unlocking The “Getting started” section provides an overview of the vehicle’s most basic func- tions. First-time Mercedes-Benz owners should pay special attention to the infor- mation given here. If you are already familiar with the basic functions described here, the “Controls in detail”...
Page 31: Starter Switch
Starter switch positions Starter switch 0 For removing SmartKey The steering is locked when the SmartKey is removed from the starter switch. If necessary, move steering wheel slightly to allow the locking mechanism to engage. 1 Power supply to some electrical con- sumers, such as seat adjustment 2 Ignition (power supply for all electrical consumers) and driving position...
Page 32: Adjusting
Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air- bag when it is properly installed.
Page 33 A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Manual seat adjustment 1 Seat fore and aft adjustment 2 Seat cushion tilt 3 Seat backrest tilt 4 Seat height...
Page 34 Getting started Adjusting Head restraint height 1 Release button Raising: Manually adjust the height of the head restraint by pulling it upward. Lowering: To lower head the restraint, push release button 1 and push down on the head restraint. Warning! For your protection, drive only with properly positioned head restraints.
Page 35 Power seat* adjustment The seat adjustment switches are located in each front door. 1 Head restraint height 2 Seat height 3 Seat cushion tilt 4 Seat fore and aft adjustment 5 Seat backrest tilt Turn the SmartKey in the starter switch to position 1 or 2 ( page 31).
Page 36: Steering Wheel
Getting started Adjusting Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the head restraint supports the back of the head at eye level. This will reduce the potential for injury to the head and neck in the event of an accident or similar situation.
Page 37: Handle (Manual)
Steering wheel adjustment, manual 1 Handle To unlock the steering column, pull handle 1 out to its stop limit. Move steering wheel to the desired position. To lock the steering column, push handle 1 all the way in until it engages.
Page 38: Mirrors
Getting started Adjusting Adjusting steering column in or out Move stalk forward or back in the direction of arrow 1 until a comfort- able steering wheel position is reached with your arms slightly bent at the elbow. Adjusting steering column up or down Move stalk up or down in the direction of arrow 2.
Page 39 The buttons are located above the exterior lamp switch. 1 Driver’s side exterior rear view mirror button 2 Adjustment button 3 Passenger-side exterior rear view mirror button Make sure the ignition is switched on. All lamps in the instrument cluster come on.
Page 40: Driving
( page 62). Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart system installed in the ve- hicle to deactivate the passenger front air- bag when it is properly installed.
Page 41 A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Warning! Never ride in a moving vehicle with the seat backrest reclined.
Page 42 Getting started Driving If necessary, tighten the lap portion to a snug fit by pulling shoulder portion Seat belt height adjustment Adjust seat belt so that shoulder portion is located as close as possible to the middle of your shoulder (it should not touch the neck).
Page 43: Starting The Engine
This could impair the effective- ness of the belts. Damaged seat belts or belts that were highly stressed in an accident must be replaced. Contact an authorized Mercedes-Benz Center. Starting the engine Warning! Inhalation of exhaust gas is hazardous to your health.
Page 44: 215 F Parking Brake Pedal
Get a jump start ( page 327). If the engine does not start after several starting attempts, there could be a mal- function in the engine electronics or in the fuel supply system. Notify an authorized Mercedes-Benz Center. Parking brake 1 Release handle 2 Parking brake...
Page 45 Release parking brake by pulling on handle 1. The warning lamp ; (USA only) or 3 (Canada only) in the instrument cluster goes out. Driving Depress the brake pedal. Move gear selector lever to position D or R. Wait for the gear selection process to complete before setting the vehicle in motion.
Page 46: Switching On Headlamps
Getting started Driving Warning! It is dangerous to shift the gear selector lever out of P or N if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse.
Page 47: Windshield Wipers
To signal minor directional changes, move combination switch to point of resistance only and release. The turn signal flashes three times. High beam Push combination switch forward. The high beam symbol A in the instrument cluster comes on. For more information on high beam, see “Combination switch”...
Page 48 Remove blockage. Turn the windshield wipers on again. If windshield wipers fail to function at all in switch position I, set the combination switch to the next highest wiper speed have the windshield wipers checked at the nearest authorized Mercedes-Benz Center...
Page 49: Rear Window Wiper/Washer
Rear window wiper/washer The switch is located on the center console. 1 Intermittent wipe 2 Indicator lamp 3 Rear window washer system Make sure the ignition is switched on. Activating intermittent wipe The rear window wiper will also auto- matically engage if Deactivating intermittent wipe the windshield wiper is engaged the gear selector lever is placed...
Page 50: Problems While Driving
Unburned gasoline may have entered the catalytic converter and damaged it. Give very little gas. Have the problem repaired by an au- thorized Mercedes-Benz Center as soon as possible. The coolant temperature is over 248°F (120°C) The coolant is too hot and is no longer cooling the engine.
Page 51: Parking And Locking
Parking and locking You have now completed your first drive. You have properly stopped and parked your vehicle. End your drive as follows. Warning! Wait until the vehicle is stationary before removing the SmartKey from the starter switch. The vehicle cannot be steered when the SmartKey is removed.
Page 52: Switching Off Headlamps
Getting started Parking and locking Warning! When leaving the vehicle, always remove the SmartKey from the starter switch, and lock the vehicle. Do not leave children unattend- ed in the vehicle, or with access to an un- locked vehicle. Children could release the parking brake and/or move the gear selec- tor lever from position P, either of which could result in an accident and/or serious...
Page 53: Turning Off Engine
Turning off engine Place the gear selector lever in position P. Always set the parking brake in addition to shifting to position P. On steep slopes, turn the front wheels towards the road curb. Turn the SmartKey in the starter switch to position 0 and remove it.
Page 55: Safety And Security
Safety and Security Occupant safety Panic alarm* Driving safety systems Anti-theft systems...
Page 56: Occupant Safety
For safety reasons, we strongly recom- mend that you visit an authorized Mercedes-Benz Center immediately to have the system checked. For more information, see “Practical hints”( page 278).
Page 57: Airbags
SRS may not be op- erational. For your safety, we strongly rec- ommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in an acci-...
Page 58 If you have any prob- lems, please see your authorized Mercedes-Benz Center. Do not lean with your head or chest close to the steering wheel or dash- board.
Page 59 Mercedes-Benz Center at an additional cost. Safety and Security Occupant safety Please contact your local authorized...
Page 60 Only use belts in- stalled or supplied by an authorized Mercedes-Benz Center. Airbags and emergency tensioning devices (ETDs) are designed to function on a one-time only basis. An airbag or ETD that was activated must be replaced.
Page 61 These instructions are available from your authorized Mercedes-Benz Center. Given the considerable deployment 1 Driver’s airbag speed and the textile structure of the...
Page 62: Seat Belts
Safety and Security Occupant safety Do not place objects heavier than 20 lbs (9 kg) on the front passenger seat. This could cause the front or side impact airbag on the front passenger side to deploy in a crash which exceeds the system's deployment threshold.
Page 63 Only use seat belts which have been ap- proved by Mercedes-Benz. Do not make any modifications to the seat belts. This can lead to unintended activation or to failure.
Page 64 Safety and Security Occupant safety Warning! USE SEAT BELTS PROPERLY Seat belts can only work when used properly. Never wear seat belts in any other way than as described in this sec- tion, as that could result in serious inju- ries in case of an accident.
Page 65: Children In The Vehicle
When scrapping the emergency tensioning device, our safety instructions must be followed. These are available at your authorized Mercedes-Benz Center. Do not place objects heavier than 20 lbs (9 kg) on the front passenger seat. This could cause the front or side...
Page 66 Safety and Security Occupant safety We recommend all infants and children be properly restrained at all times while the vehicle is in motion. All lap-shoulder belts except the driver’s seat belt have special seat belt retractors for secure fastening of child restraints. To fasten a child restraint, follow child re- straint instructions for mounting.
Page 67 Children 12 years old and under must never label on the restraint and in the ride in the front seat, except in a instruction manual provided with the Mercedes-Benz authorized BabySmart restraint. compatible child seat, which operates with When using any infant or child restraint...
Page 68 Special BabySmart compatible child seats, designed for use with the Mercedes-Benz system and available at any authorized Mercedes-Benz Center are required for use with the BabySmart air- bag deactivation system. With the special child seat properly installed, the passenger front airbag will not deploy.
Page 69 Warning! The BabySmart airbag deactivation sys- tem will ONLY work with a special child seat designed to operate with it. It will not work with child seats which are not BabySmart compatible. Never place anything between seat cushion and child seat (e.g. pillow), since it reduces the effectiveness of the deactivation sys- tem.
Page 70 Safety and Security Occupant safety Installation of infant and child restraint systems Anchorage rings 1 are located on the back side of the outer rear backrests and on the floor behind the rear center seat. 1 Anchorage ring 2 Hook Prior to installing a tether strap, note the following steps: Roll up retractable luggage cover and...
Page 71 For safety, make sure the hook has at- tached to the ring beyond the safety catch, as illustrated. Child seat anchors – LATCH-type This vehicle is equipped with two LATCH- (Lower Anchors and Tethers for CHildren) type anchors (at each of the outer rear seats) for the installation of a LATCH-type child seat with the matching mounting fittings.
Page 72: Blocking Of Rear Door Window Operation
Safety and Security Occupant safety Warning! Children too big for child restraint systems must ride in back seats using regular seat belts. Position shoulder belt across chest and shoulder, not face or neck. A booster seat may be necessary to achieve proper belt positioning for children from 41 lbs until they reach a height where a lap/shoulder belt fits properly without a booster.
Page 73: Panic Alarm
Panic alarm* An audible alarm and flashing exterior lamps will operate for approximately minutes. 1 Â button Canada only: Only vehicles equipped with an anti-theft alarm system* have SmartKeys with integrated panic button 1. Activating Press and hold button 1 for at least one second.
Page 74: Driving Safety Systems
Safety and Security Driving safety systems Driving safety systems In this section you will find information on the following driving safety systems: ABS (Antilock Brake System) BAS (Brake Assist System) ESP (Electronic Stability Program) 4MATIC (Four Wheel Electronic Traction System) In winter operation, the maximum effectiveness of the ABS, ESP and 4MATIC (if so equipped) is only...
Page 75: Bas
Braking At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode. Keep firm and steady pressure on the brake pedal while experiencing the pulsation.
Page 76: Esp
Safety and Security Driving safety systems Warning! The BAS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction. The BAS cannot prevent accidents, including those resulting from excessive speed in turns, following another vehicle too closely, or...
Page 77 Warning! The ESP cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded. The ESP cannot prevent accidents, including those resulting from excessive speed in turns or hydroplaning. Only a safe, attentive, and skillful driver can prevent accidents.
Page 78 Avoid spinning of a drive wheel for an extended period with the ESP switched off. This may cause serious damage to the drive train which is not covered by the Mercedes-Benz Limited Warranty. Warning! When the ESP warning lamp v is illuminated continuously, the ESP is switched off.
Page 79: Four Wheel Electronic Traction System (4Matic) With The Esp
Do not tow with one axle raised. Otherwise the transfer case can be damaged, which is not covered by the Mercedes-Benz Limited Warranty. Safety and Security Driving safety systems Performance testing must only be con- ducted on a two-axle dynamometer.
Page 80: Anti-Theft Systems
In case the engine cannot be started (yet the vehicle’s battery is charged), the system is not operational. Contact an authorized Mercedes-Benz Center or call 1-800-FOR-MERCedes (in the USA), or 1-800-387-0100 (in Canada). Anti-theft alarm system*...
Page 81: Tow-Away Alarm
Disarming the alarm system If the turn signal lamps do not flash The alarm system is disarmed when you three times, one of the following unlock your vehicle with the SmartKey. The elements may not be properly closed: turn signal lamps flash once to indicate that the alarm system is deactivated.
Page 82 Safety and Security Anti-theft systems Arming tow-away alarm When you lock your vehicle, the tow-away alarm is automatically armed after about 30 seconds. When you unlock your vehicle, the tow-away protection disarms automatically. Disarming tow-away alarm To prevent triggering the tow-away alarm, switch off the tow-away alarm feature before towing the vehicle, or when parking on a surface subject to movement, such as...
Page 83: Controls In Detail
Controls in detail Locking and unlocking Seats Memory function* Lighting Instrument cluster Control system Automatic transmission Good visibility Climate control Automatic climate control* Audio system Power windows Sliding/pop-up roof* Driving systems Loading Useful features...
Page 84: Locking And Unlocking
Controls in detail Locking and unlocking In the “Controls in detail” section you will find detailed information on how to oper- ate the equipment installed on your vehi- cle. If you are already familiar with the basic functions of your vehicle, this section will be of particular interest to you.
Page 85 To prevent possible malfunction, avoid exposing the SmartKey to high levels of electromagnetic radiation. Factory setting Global unlocking Press button Œ. All turn signal lamps flash once. The locking knobs in the doors move up. The vehicle will lock again automatically within approximately 40 seconds of unlocking if: neither door nor tailgate is opened...
Page 86 Use the mechanical key to lock the doors ( page 306) as required. Have the vehicle battery and the battery connections checked. If the SmartKey is malfunctioning, contact an authorized Mercedes-Benz Center. Checking the batteries Press button ‹ or Œ. Battery check lamp 4 comes on briefly to indicate that the SmartKey batteries are in order.
Page 87: Opening The Doors From The Inside
Opening the doors from the inside You can open a locked door from the inside. Open door only when conditions are safe to do so. 1 Locking knob 2 Inside door handle Pull on door handle 2. If door was locked, locking knob 1 will move up.
Page 88: Closing The Tailgate
Controls in detail Locking and unlocking The vehicle must be unlocked. Closing the tailgate 1 Handle Lower tailgate by pulling firmly on handle 1. Close tailgate with hands placed flat on Warning! To prevent possible personal injury, always keep hands and fingers away from the tail- gate opening when closing the tailgate.
Page 89: Locking And Unlocking From The Inside
For more information on towing the vehi- cle, see “Towing the vehicle” ( page 329). You can deactivate the automatic locking using the control system, see “Setting au- tomatic locking” ( page 131). Locking and unlocking from the inside You can lock or unlock the doors and the tailgate from inside using the central lock- ing switch.
Page 90: Seats
Controls in detail Seats Seats For information on seat adjustment, see “Seats” ( page 32). Easy-entry/exit feature* With the easy-entry/exit feature activated, the steering wheel tilts upwards and the driver’s seat moves to the rear. This allows easier entry into and exit from the vehicle when the driver’s door is opened.
Page 91: Removing And Installing Front Seat Head Restraints
Removing and installing front seat head restraints For information on head restraint adjustment, see “Seats” ( page 32). Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the head restraint supports the back of the head at eye level.
Page 92: Rear Seat Head Restraints
Controls in detail Seats Front seat head restraints, power seat* Removing front seat head restraints Press switch 1 upwards and hold until head restraint is fully extended. Pull out head restraint. Installing front seat head restraints Press switch 1 upwards and hold for about five seconds.
Page 93 Folding head restraints back The rear seat head restraints can be folded backward for increased visibility. 1 Release button Push release button 1. The head restraints will fold backward. Warning! For safety reasons, always drive with the rear head restraints in the upright position when the rear seats are occupied.
Page 94 Controls in detail Seats Removing and installing rear seat head restraints (outer seats) Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the head re- straint supports the back of the head at eye level.
Page 95: Multicontour Seat
Multicontour seat* This multicontour seat has a movable seat cushion and inflatable air cushions built into the backrest to provide additional lumbar and side support. The seat cushion movement, backrest cushion height and curvature can be con- tinuously varied with switches on the right side of the seat after starting the engine.
Page 96 Controls in detail Seats Switching on seat heating Press upper switch position 1. A red indicator lamp on the switch comes on. Switching off seat heating Press upper switch position 1 again. The seat heater will be automatically switched off after approximately 30 minutes.
Page 97: Memory Function
Memory function* The memory button and stored position switch are located on the door. Prior to operating the vehicle, the driv- er should check and adjust the seat You can store up to three different settings height, seat position fore and aft, and per SmartKey.
Page 98: Storing Positions Into Memory
Controls in detail Memory function* Storing positions into memory Adjust the seats, steering wheel and rear view mirrors to the desired posi- tion ( page 32). Turn button 2 to selected memory position. Press memory button 1. Release memory button and push button 2 within three seconds.
Page 99: Storing Exterior Rear View Mirror Parking Position
Storing exterior rear view mirror parking position For easier parking, you can adjust the passenger-side exterior rear view mirror so that you can see the right rear wheel as soon as you engage reverse gear R. For information on activating the parking position, see “Setting parking position for exterior rear view mirror”...
Page 100: Lighting
Relevant information can be obtained at your authorized Mercedes-Benz Center. Exterior lamp switch The exterior lamp switch is located on the dashboard to the left of the steering wheel.
Page 101 Manual headlamp mode If you remove the SmartKey and open The low beam headlamps and parking the driver’s door while the parking lamps can be switched on and off with the lamps or low beam headlamps are exterior lamp switch. For exterior lamp switched on, then switch, see ( page 100).
Page 102 Controls in detail Lighting With the daytime running lamp mode activated, the low beam headlamps will not be switched off automatically. The front fog lamps and rear fog lamp cannot be switched on manually with exterior lamp switch in position U. To activate the fog lamps, turn exterior lamp switch to position B and pull the exterior lamp switch to first or...
Page 103: Combination Switch
Switching on front fog lamps Fog lamps will operate with the parking lamps and/or the low beam headlamps on. Fog lamps should only be used in conjunction with low beam headlamps. Consult your State or Province Motor Vehicle Regulations regarding allow- able lamp operation.
Page 104: Hazard Warning Flasher
Controls in detail Lighting Switching on high beams Turn exterior lamp switch to position B or to U ( page 100). Push combination switch in direction of arrow 1. The high beam indicator A on the instrument cluster comes on. High beam flasher Pull combination switch briefly in direction of arrow 2.
Page 105: Interior Lighting
Interior lighting The controls are located in the overhead control panel. 1 Rear interior lights 2 Right front reading lamp 3 Rocker switch for automatic control system 4 Left front reading lamp Activating automatic control Press rocker switch 3 to center position.
Page 106: Door Entry Lamps
Controls in detail Lighting The setting selected for the interior lighting is used for the cargo compart- ment lighting as well. If you leave the tailgate open for an extended period of time, the cargo compartment lighting will switch off automatically after approximately ten minutes Switching rear interior lights on and off...
Page 107: Instrument Cluster
Instrument cluster For a full view illustration of the instrument cluster, see “At a glance” ( page 22). The instrument cluster is activated when open a door turn on the ignition press the reset button ( page 22) switch on the exterior lamps You can change the instrument cluster settings in the Instrument cluster submenu of the control system ( page 124).
Page 108: Coolant Temperature Display
248°F (120°C). The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious en- gine damage which is not covered by the Mercedes-Benz Limited Warranty.
Page 109: Trip Odometer
Avoid driving at excessive engine speeds, as it may result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. To help protect the engine, the fuel supply is interrupted if the engine is operated within the red marking.
Page 110 Controls in detail Instrument cluster The temperature sensor is located in the front bumper area. Due to its location, the sensor can be affected by road or engine heat during idling or slow driving. This means that the accuracy of the displayed temperature can only be verified by com- parison to a thermometer placed next to the sensor, not by comparison to external...
Page 111: Control System
Control system The control system is activated as soon as the SmartKey in the starter switch is turned to position 1. The control system enables you to call up information about your vehicle change vehicle settings For example, you can use the control system to find out when your vehicle is next due for service, to set the language for messages in the instrument cluster...
Page 112: Multifunction Steering Wheel
Controls in detail Control system Multifunction steering wheel The displays in the multifunction display and the settings in the control system are controlled by the buttons on the multifunc- tion steering wheel. 1 Multifunction display in the speedometer Operating the control system 2 Selecting the submenu or setting the volume ç...
Page 113 It is helpful to think of the menus, and the functions within each menu, as being ar- ranged in a circular pattern. If you press button è or ÿ repeatedly, you will pass through each menu one after the other. If you press button k or j repeatedly, you will pass through each function display, one after the other, in...
Page 114: Menus
Controls in detail Control system Menus This is what you will see when you scroll through the menus. The table on the next page provides an overview of the individual menus.
Page 115 Menus, submenus and functions Menu 1 Menu 2 Standard display AUDIO Coolant Select radio station Activate route temperature display Digital speedometer Operate CD player* Call up FSS Operate cassette player Check engine oil level Menu 3 Menu 4 Menu 5 NAVI* Malfunction Settings...
Page 116: Standard Display Menu
Controls in detail Control system The headings used in the menus table are designed to facilitate navigation within the system and are not neces- sarily identical to those shown in the control system displays. The first function displayed in each menu will automatically show you which part of the system you are in.
Page 117 Select radio station Turn on the radio ( page 172). Vehicles with COMAND*: Refer to separate operating instructions. Press button è or ÿ repeatedly until you see the currently tuned station in the display. 1 Station frequency 2 Waveband setting 3 Setting for station selection using memory Press button k or j repeatedly...
Page 118 Controls in detail Control system Press button k or j repeatedly until the desired channel is found. Feature description is based on preliminary information available at time of printing. For more information on satellite radio operation, see “Satellite radio (SAT)* (USA only)”...
Page 119: Navi* Menu
Operate the cassette player Turn on the radio and select the cassette player ( page 182). Vehicles with COMAND*: Refer to separate operating instructions. Press button è or ÿ repeatedly until the settings for the cassette currently being played are shown in the display.
Page 120: Malfunction Memory Menu
Mercedes-Benz Center to address the malfunction and warning messages ( page 280). Press button è or ÿ repeatedly until you see the malfunction message memory in the display.
Page 121: Settings Menu
Settings menu In the SETTINGS menu there are two functions: The function RESET TO FACTORY , with which you can reset all SETTINGS the settings to the original factory settings. A collection of submenus with which you can make individual settings for your vehicle.
Page 122 Controls in detail Control system Submenus in the Settings menu Press button k or j. In the display you see the collection of the submenus. Press button ç. The selection marker moves to the next submenu. The submenus are arranged by hierarchy. Scroll down with the ç...
Page 123 The table below shows what settings can be changed within the various menus. Detailed instructions on making individual settings can be found on the following pages. INSTRUMENT CLUSTER LIGHTING Set time (hours) Set daytime running lamp mode (USA only) Set time (minutes) Set locator lighting Select time display mode Exterior lamps delayed shut-off...
Page 124 Controls in detail Control system Instrument cluster submenu Access the INSTRUMENT CLUSTER submenu via the SETTINGS menu. Use the INSTRUMENT CLUSTER submenu to change the instrument cluster display settings. The following functions are available: Function Page Set time (hours) Set time (minutes) Select time display mode Select temperature display mode...
Page 125 Press button j or k repeatedly Selecting time display mode until you see this message in the display: TIME SETTINGS – MINUTES The selection marker is on the minute setting. Press æ or ç to set the minutes. Selecting temperature display mode Move the selection marker with the æ...
Page 126 Controls in detail Control system Selecting speedometer display mode Move the selection marker with the æ or ç button to the INSTRUMENT CLUSTER submenu. Press button j or k repeatedly until you see this message in the display: DISPLAY VALUES IN The selection marker is on the current setting.
Page 127 Selecting display (speed display or outside temperature) Move the selection marker with the æ or ç button to the INSTRUMENT CLUSTER submenu. Press button j or k repeatedly until you see this message in the display: SELECT DISPLAY The selection marker is on the current setting.
Page 128 Controls in detail Control system With daytime running lamp mode selected and the exterior lamp switch at position 0, the following lamps will come on automatically when the engine is turned on: Parking lamps and low beam headlamps License plate lamps (in low ambient light conditions) If you turn the exterior lamp switch to another position, the corresponding...
Page 129 Setting night security illumination (Exterior lamps delayed shut-off) Use the HEADLIGHTS DELAYED SHUT-OFF function to set whether and for how long you would like the exterior lamps to illumi- nate during darkness after all doors are closed. When the delayed shut-off feature is acti- vated and the exterior lamp switch is in position U, the following lamps will re- main lit after you remove the SmartKey...
Page 130 Controls in detail Control system You can temporarily deactivate the delayed shut-off feature: Before leaving the vehicle turn the SmartKey in the starter switch to position 0. Then turn it to position 2 and back to 0. The delayed shut-off feature is deactivated.
Page 131 Vehicle submenu Access the VEHICLE submenu via the SETTINGS menu. Use the VEHICLE submenu to make general vehicle settings. The following functions are available: Function Page Set station selection mode (radio) Set automatic locking Setting station selection mode Use the PRESS BUTTON IN AUDIO MODE function to select the manual or memory station selection mode for the radio...
Page 132 Controls in detail Control system Convenience submenu Access the CONVENIENCE submenu via the SETTINGS menu. Use the CONVENIENCE submenu to change the settings for a number of convenience features. The following functions are available: Function Page Activate easy-entry/exit feature* Set key-dependency Set parking position for exterior rear view mirror Activating easy-entry/exit feature*...
Page 133 Move the selection marker with the æ or ç button to the submenu. CONVENIENCE Press button j or k repeatedly until you see this message in the display: EASY-ENTRY FEATURE ACTIVATE The selection marker is on the current setting. Press æ or ç to change the easy-entry/exit setting.
Page 134: Trip Computer Menu
Controls in detail Control system Setting parking position for exterior rear view mirror Use the MIRROR SETTING WHEN PARKING function to select whether the passen- ger-side exterior rear view mirror should be turned downward during parking maneu- vers when reverse gear R is engaged. For additional information, see “Activating exterior rear view mirror parking position”...
Page 135 Fuel consumption statistics after start Press button ÿ or è repeatedly until you see the first function of the Trip computer menu. Press button j or k repeatedly until you see this message in the display: AFTER START 1 Distance driven since start 2 Time elapsed since start 3 Average fuel consumption since start 4 Average speed since start...
Page 136: Tel Menu
Controls in detail Control system Call up range (distance to empty) Press button ÿ or è repeatedly until you see the first function of the Trip computer menu. Press button j or k repeatedly until you see this message in the display: RANGE In the display you will see the...
Page 137 Which messages will appear in the display field depends on whether your telephone is switched on or off: If the telephone is off, the message in the multifunction display is: TEL OFF If the telephone is on: The telephone will then search for a network.
Page 138 Controls in detail Control system Dialing a number from the phone book If your telephone is ready to receive calls, you may select and dial a number from the phone book at any time. Press button ÿ or è repeatedly until you see the menu in the display.
Page 139: Automatic Transmission
Automatic transmission Information on driving with an automatic transmission is found in the “Getting started” section ( page 43). Your vehicle’s transmission adapts its gear shifting process to your individual driving style by continually adjusting the shift points up or down. These shift point adjust- ments are performed based on current operating and driving conditions.
Page 140: One-Touch Gearshifting
Controls in detail Automatic transmission One-touch gearshifting Even with an automatic transmission you can change the gears manually when the gear selector lever is in position D. Downshifting Briefly press the gear selector lever to the left in the D- direction. The transmission will shift from the current gear to the next lower gear.
Page 141: Gear Ranges
Gear ranges With the gear selector lever in position D, you can limit the transmission’s gear range by pressing the gear selector lever to the left (D-), and reverse the gear range limit by pressing the gear selector lever to the right (D+).
Page 142: Gear Selector Lever Position
Controls in detail Automatic transmission Gear selector lever position Effect ì Park position Gear selector lever position when the vehicle is parked. Place gear selector lever in position P only when vehicle is stopped. The park position is not intended to serve as a brake when the vehicle is parked.
Page 143: Program Mode Selector Switch
Coasting the vehicle, or driving for any other reason with gear selector lever in N can result in transmission damage that is not covered by the Mercedes-Benz Limited Warranty. Warning! Getting out of your vehicle with the gear selector lever not fully engaged in position P is dangerous.
Page 144: Accelerator Position
Move gear selector lever to P. Turn off the engine. Wait at least ten seconds before restarting. Restart the engine. Move gear selector lever to position D (for second gear) or R. Have the transmission checked at an authorized Mercedes-Benz Center as soon as possible.
Page 145: Good Visibility
Good visibility Windshield wipers More information on the windshield wipers can be found in the “Getting started” section ( page 47). Intermittent wiping Intermittent wiping is interrupted when the vehicle is at a standstill and a front door is opened. Windshield wipers with rain sensor* A rain sensor automatically controls the windshield wipers depending on how wet...
Page 146: Rear View Mirrors
Controls in detail Good visibility Rear view mirrors More information for setting the rear view mirrors can be found in the “Getting started” section ( page 38). Interior rear view mirror, antiglare position 1 Lever Tilt the mirror to the antiglare night position by moving lever 1 towards the windshield.
Page 147 Warning! In the case of an accident liquid electrolyte may escape from the mirror housing if the mirror glass breaks. Electrolyte has an irritating effect. Do not allow the liquid to come into contact with eyes, skin, clothing, or respiratory system. In case it does, immediately flush affected area with water, and seek medical help if necessary.
Page 148: Sun Visors
Controls in detail Good visibility The exterior rear view mirror returns to its previously stored driving position: ten seconds after you put the gear selector lever out of position R immediately once your vehicle exceeds a speed of approximately 6 mph (10 km/h) immediately when you press button 1 for driver’s side mirror...
Page 149: Rear Window Defroster
Rear window defroster The rear window defroster uses a large amount of power. To keep the battery drain to a minimum, switch off the defroster as soon as the rear window is clear. The defroster is automatically deactivated after approximately 6 to 17 minutes of operation depending on the outside temperature.
Page 150: Climate Control
Controls in detail Climate control Climate control...
Page 151 Item 1 Thumbwheel for air volume control for left center air vent 2 Left center air vent, adjustable 3 Right center air vent, adjustable 4 Thumbwheel for air volume control for right center air vent 5 Air volume control for side air vent 6 Side air vent, adjustable 7 Side defroster vent, fixed 8 Climate control panel...
Page 152: Setting The Temperature
Controls in detail Climate control The climate control is operational whenev- er the engine is running. You can operate the climate control system in either the au- tomatic or manual mode. The system cools or heats the interior depending on the se- lected interior temperature and the cur- rent outside temperature.
Page 153: Adjusting Air Distribution And Volume
When operating the climate control system in automatic mode, you will only rarely need to adjust the tempera- ture, air volume and air distribution. Increasing Turn the temperature control 2 or 3 slightly to the right. The climate control system will corre- spondingly adjust the interior air tem- perature.
Page 154: Defrosting
Controls in detail Climate control Defrosting These settings should only be selected for a short time. Activating Press button P ( page 151). The indicator lamp on the button comes on. Switch off air recirculation, if selected. Press button O ( page 151). The indicator lamp on the button goes out.
Page 155: Deactivating The Climate Control System
The closing of the side windows and sliding/pop-up roof* can be reversed by again pressing and holding the O button. The air recirculation mode is activated automatically at high outside tempera- tures. If you have turned off the air condi- tioning ( page 156) or the outside temperature is below 41°F (5°C), the air recirculation mode will not switch...
Page 156: Air Conditioning
The compressor has turned itself off. Have the air conditioning checked at the nearest authorized Mercedes-Benz Center. Ventilated storage compartment The front center console storage compart- ment has its own air vent that allows for cooling ventilation when the automatic climate control system is activated.
Page 157: Rear Passenger Compartment Adjustable Air Vents
Opening the air vent Raise lever 1. Closing the air vent Lower lever 1. The compartment can get very warm due to its confined space. When storing heat sensitive objects in the compart- ment, close the air vent while heating the passenger compartment.
Page 158: Automatic Climate Control
Controls in detail Automatic climate control* Automatic climate control*...
Page 159 Item 1 Thumbwheel for air volume control for left center air vent 2 Left center air vent, adjustable 3 Thumbwheel for adding outside air 4 Right center air vent, adjustable 5 Thumbwheel for air volume control for right center air vent 6 Thumbwheel for air volume control for side air vent 7 Side air vent, adjustable...
Page 160 Controls in detail Automatic climate control* The automatic climate control is operation- al whenever the engine is running. You can operate the climate control system in ei- ther the automatic or manual mode. The system cools or heats the interior depend- ing on the selected interior temperature and the current outside temperature.
Page 161: Setting The Temperature
Setting the temperature Severe conditions (e.g. strong air Use temperature controls 1 and e for pollution) may require replacement of the left side or 6 and 7 for the right side the filter before its scheduled interval. ( page 159) to separately adjust the air A clogged filter will reduce the air temperature on each side of the passenger volume to the interior.
Page 162: Adjusting Air Distribution
Controls in detail Automatic climate control* Adjusting air distribution Use air distribution controls 2 and 5 ( page 159) to separately adjust the air distribution on each side of the passenger compartment. The following symbols are found on the controls: Symbol Function Directs air through the center, side and rear passenger...
Page 163: Maximum Cooling Maxcool
Maximum cooling MAXCOOL If the left and right air distribution controls as well as the airflow volume control are set to U and there is a high need for cooling, the display “MAXCOOL” appears. This provides the fastest possible cooling of the vehicle interior (when windows and sliding/pop-up roof* are closed).
Page 164 Controls in detail Automatic climate control* If you keep button O pressed, the side windows and the sliding/pop-up roof* will close. Warning! Never operate the side windows and the sliding/pop-up roof* if there is the possibility of anyone being harmed by the closing procedure.
Page 165: Charcoal Filter
Charcoal filter An activated charcoal filter markedly reduces bad odors and removes pollutants from air entering the passenger compart- ment. Activating Press button e ( page 159). The indicator lamp on the button comes on. The system switches automatically to the air recirculation mode if the carbon monoxide (CO) or nitrogen oxide (NO concentration of the outside air increases...
Page 166: Air Conditioning
CFCs which are harmful to the ozone layer. If the air conditioning cannot be turned on again, this indicates that the air conditioning is losing refrigerant. The compressor has turned itself off. Have the air conditioning checked at the nearest authorized Mercedes-Benz Center.
Page 167: Residual Heat And Ventilation
Residual heat and ventilation* With the engine switched off, it is possible to continue to heat or ventilate the interior for up to 30 minutes. This feature makes use of the residual heat produced by the engine. Activating Turn the SmartKey in the starter switch to position 1 or 0, or remove it from the starter switch.
Page 168: Rear Passenger Compartment Adjustable Air Vents
Controls in detail Automatic climate control* Rear passenger compartment adjustable air vents 1 Left center air vent 2 Thumbwheel for air volume control for center air vents 3 Right center air vent 4 Closing center air vents 5 Opening center air vents 6 Switching on blower Adjusting the air volume Turn thumbwheel 2.
Page 169: Audio System
Audio system Audio and telephone, operation These instructions are intended to help you become familiar with your Mercedes-Benz audio system. They con- tain useful tips and a detailed description of the user functions. Warning! In order to avoid distraction which could...
Page 170: Operating And Display Elements
Controls in detail Audio system Operating and display elements...
Page 171 Item Page 1 CD mode selector 2 Manual tuning (radio) Fast forward/reverse 184, (cassette, CD) Speed dialing memory (telephone*) 3 Radio mode selector 4 Display panel Cassette compartment behind display panel Item Page 5 Alpha-numeric keypad Band selection, station buttons (radio) CD selection (CD) Telephone number entry, retrieving speed dialing...
Page 172: Button And Soft Key Operation
Controls in detail Audio system Button and soft key operation In these instructions, the alpha-numeric keypad (right side of radio panel) and the function buttons (left side of radio panel) are referred to as “buttons”. The four keys below the display panel are referred to as “soft keys”.
Page 173 Bass Regardless of operating mode, press key repeatedly until BASS appears on the display. Press key to increase or de- crease level. Press both keys simultaneously to reset the Bass to its center (flat) lev- Treble Regardless of operating mode, press key repeatedly until TREBLE appears on the display.
Page 174 Controls in detail Audio system Balance Regardless of operating mode, press key repeatedly until BALANCE appears on the display. Press key to shift sound accord- ingly to the left or right speakers. Press both keys simultaneously to reset the Balance to its center level. Returning audio functions to factory settings Regardless of operating mode, press...
Page 175: Radio Operation
You can select from among the following settings: : The tone level is set to the Driver position; sound is directed toward the passengers. : The tone level is set for Speech, optimizing the sound for the spoken word. : The tone level is set for Ambience, producing a three-dimensional sound.
Page 176: 190 D Seek Tuning (Radio)
Controls in detail Audio system Direct frequency input Select the desired frequency band. Press “ button. Enter desired frequency using buttons 4 to M. You can only enter frequencies within the respective waveband. If a button is not pressed within four seconds, the radio will return to the station last tuned to.
Page 177 Scan tuning Starting scan tuning Select desired frequency band. Press 2 button. will appear on the display. The radio briefly tunes in all receivable stations on the band selected. The first scan cycle will tune in only the stations with a strong signal. The second scan cycle will tune in every receivable station.
Page 178: Satellite Radio (Sat)* (Usa Only)
At time of printing, no date for the availability of optional equipment re- quired for satellite radio operation had been set. Contact your authorized Mercedes-Benz Center for details and availability for your vehicle. Satellite radio service may be unavail- able or interrupted from time to time...
Page 179 Starting satellite radio (SAT) Start radio mode. If the radio was in SAT radio mode be- fore being turned off or changed to an- other operating mode, the last SAT channel selected is called up. Press the key. When you call up the SAT radio mode for the first time, will appear ACQUIRING...
Page 180 Controls in detail Audio system Channel selection The following options are available for se- lecting a channel: Direct channel input ( page 180) Manual tuning ( page 180) Preset channels ( page 180) Direct channel input Press “ key. Enter desired channel number using buttons 4 to M.
Page 181 Program type (PTY) mode In PTY mode, you can tune in and select channels of a specific program type. Calling up PTY mode Start SAT radio mode. Press the key. The name of the channel currently being received is shown. Leaving PTY mode Press the key.
Page 182: Cassette Operation
Controls in detail Audio system Cassette operation Playing cassettes Press 3 button. The display panel folds down and the cassette compartment becomes ac- cessible. Insert cassette into the cassette com- partment until it engages and tap it gently. The cassette will be pulled in automati- cally.
Page 183 Cassette eject Press eject button 3. The display folds down and the cas- sette is ejected. The system will switch back to radio mode automatically. Fold display panel back up and press gently on the display panel frame to lock it. Do not press directly on the display face.
Page 184 Controls in detail Audio system Scanning Starting scan Press 2 button. will appear on the display. Each track on the cassette will be played briefly in ascending order. Stopping scan Press 2 , d, c, f or e button. The system will switch to Play. Fast forward/reverse Starting cassette fast forward mode Press d button.
Page 185: Cd Changer* Operation
Dolby NR (noise reduction system) To enable optimum sound reproduction of cassettes recorded using Dolby B NR, the Dolby NR system should be switched on. The Dolby NR function should be switched off when playing cassettes not recorded with Dolby B NR. DOLBY and the double-D symbol Ù...
Page 186 Controls in detail Audio system Only use original CDs. Using copied CDs may create problems during playback. Clean CDs from time to time with a com- mercially available cleaning cloth. Do not use solvents, anti-static sprays, etc. for cleaning. Replace the CD in its case after use.
Page 187 1 CD 2 CD changer 3 CD tray 4 CD magazine Remove magazine and pull CD tray fully out. Place CD in recess of tray, label side Push tray into magazine in direction of arrow. CDs which have been inserted improp- erly or are unreadable will not be played.
Page 188: Fast Forward/Reverse 184, (Cassette, Cd)
Controls in detail Audio system Skipping tracks forward/backward Skipping tracks forward Press f button. The next track will be played. Skipping tracks backward Press e button. If the track has been playing for more than ten seconds, it will revert to the start of that track.
Page 189: Telephone* Operation
Repeat The repeat function (RPT) repeats the cur- rent track. Switching on repeat: Press the key. is highlighted in the display. Switching off repeat: Press the key. The highlighted in the display dis- appears. The Random play and Repeat function cannot be used simultaneously.
Page 190 Controls in detail Audio system Switching on the telephone Press h button. If you have programmed an unlock code for the telephone, you must enter the code now. Enter the desired telephone number using buttons 4 to M. If necessary, correct number entered with the key.
Page 191 Phone book The numbers stored in the phone book can be called up either by name or number. Calling up the phone book Press d, c, f or e button. Switching between name search and number search Press the key. The name search is called up.
Page 192 Controls in detail Audio system Searching and selecting phone book en- tries by number Press the key. The current number is marked in the display. Press either the d or c button. The stored entries are selected according to numerical order. Press either the f or e button.
Page 193: Speed Dialing Memory
Automatic repeat dialing (redial) If a call cannot be connected, press key. REDIAL will appear on the display and re- peated attempts to place the call will be made for the next four minutes. Selecting numbers directly from the directory Enter previously selected 3-digit (1-999) number of the entry using number keys 4 to M.
Page 194 Controls in detail Audio system Emergency call Press button 4 longer than one second. A call will be placed to the saved num- ber (e.g. 911). Please be aware that the 911 emergen- cy call system is a public service. Using it without due cause is a criminal of- fense.
Page 195 Accepting an incoming call in cassette, CD or radio mode If the telephone is activated in the back- ground (receiving symbol visible on dis- play), the audio source is muted when a call is received. The ringing tone is heard and the caller’s telephone number or the name under which this telephone number has been saved in the telephone book ap-...
Page 196: Opening And Closing The Windows
Controls in detail Power windows Power windows Opening and closing the windows The side windows can be opened and closed electrically. The switches for all the side windows are on the driver’s door. The switches for the respective windows are on the front passenger door and the rear doors.
Page 197 Turn SmartKey in the starter switch to position 1 or 2. Opening the windows Press switch 1 to 4 to the resistance point. The corresponding window will move downwards until you release the switch. Closing the windows Pull switch 1 to 4 to the resistance point.
Page 198: Synchronizing Power Windows
Controls in detail Power windows Opening and closing the windows with the SmartKey The sliding/pop-up roof* ( page 200) will also be opened or closed when the power windows are operated with the SmartKey . Warning! Never operate the windows or sliding/pop-up roof* if there is the possibility of anyone being harmed by the opening or closing procedure.
Page 199: Sliding/Pop-Up Roof
Sliding/pop-up roof* Opening and closing the sliding/pop-up roof The sliding/pop-up roof can be opened and closed electrically. The switch for the sliding/pop-up roof is on the overhead control panel. 1 Push up to raise roof at rear 2 Pull down to lower roof at rear 3 Push forward to slide roof closed 4 Push back to slide roof open With the roof closed or tilted open, a...
Page 200 Controls in detail Sliding/pop-up roof* You can also open or close the sliding/pop-up roof using the: SmartKey (summer opening/con- venience feature) ( page 200) button O in the control panel of the climate control ( page 151) or the automatic climate control* ( page 159) button e in the control panel of the automatic climate control*...
Page 201: The Sliding/Pop-Up Roof
Opening (Summer opening feature) Press and hold button Œ after unlocking the vehicle. The windows and the sliding/pop-up roof begin to open after approximately one second. Release the Œ button to stop procedure. Closing (Convenience feature) Press and hold button ‹ after locking the vehicle.
Page 202: Driving Systems
Controls in detail Driving systems Driving systems The driving system of your vehicle is described on the following pages: Cruise control, with which the vehicle can maintain a preset speed For information on the BAS, ABS and ESP driving systems, see “Driving safety sys- tems”...
Page 203 1 Set current or higher speed 2 Set current or lower speed 3 Cancel cruise control 4 Resume at last set speed Setting current speed Accelerate or decelerate to the desired speed. Briefly lift 1 or depress 2 cruise control lever. The current speed is set.
Page 204 Controls in detail Driving systems Setting a higher speed Lift cruise control lever to position 1 and hold it up until the desired speed is reached. Release cruise control lever. The new speed is set. Depressing the accelerator pedal does not deactivate cruise control.
Page 205: Loading
Loading Roof rack* Warning! Only use roof racks approved by Mercedes-Benz for your vehicle model to avoid damage to the vehicle. Follow manu- facturer’s installation instructions. Attach the roof rack only to the roof rails. Secure the roof rack according to manufacturer’s instructions for...
Page 206 Controls in detail Loading 5 Button Open tailgate. Press button 5. The flap opens downward. From cargo compartment, slide skis into ski sack. Warning! The ski sack is designed for up to four pairs of skis. Do not load the ski sack with other objects.
Page 207 7 Hook 8 Eye Connect hook 7 to eye 8. Tighten strap by pulling at the loose end (arrow). Unloading and folding Loosen the straps. Disconnect hook 7 from eye 8. Unload skis. Close flap in cargo compartment. Fold and flatten ski sack lengthwise. Place folded ski sack inside recess of backrest.
Page 208: Parcel Net In Cargo Compartment
Controls in detail Loading Warning! Never drive vehicle with tailgate open while the ski sack is removed. Deadly carbon monoxide (CO) gases may enter vehicle in- terior, resulting in unconsciousness and death. Installing the ski sack Install the ski sack in the reverse order. Push ski sack frame 2 with ski sack inward until the ski sack frame snaps into place.
Page 209: Storage Compartment Under Cargo Compartment Floor
Storage compartment under cargo compartment floor To open cargo compartment floor Press handle 1 on the recess. Lift compartment cover. The compartment can be used to store small, light or flat objects. To close cargo compartment floor Lower the cover and lock by applying light pressure to handle 1.
Page 210 Controls in detail Loading Partition net with rear seats folded down 1 Tab 2 Eyelets on roof Pull out upper blind (safety net) by tabs 1 until it engages. Fold seat forward ( page 211). Pull out upper blind fully. Engage it into eyelets on the roof 2.
Page 211: Split Rear Bench Seat
Installing Fold split rear bench seat forward. Place twin-reel roller blind 1 into right and left guide rails 2. Slide towards right to the end stop. Split rear bench seat To expand the cargo compartment, you can fold down the left and right rear seat backrests.
Page 212 Controls in detail Loading Right hand side of rear seat Slip seat belt webbing behind retainer 3. Fully retract and fold rearward head restraints ( page 93). Setting up rear seat bench Pull release lever 4. Fold backrest 5 forward. With the twin-reel roller blind installed: When folding the backrest forward, fold the right section first and then...
Page 213: Loading Instructions
If the backrest is not locked into position, a red indicator 6 will be visible. Check for secure locking by pushing and pulling on the backrest. Warning! If a red indicator is visible with the backrest up, then the backrest is not properly locked into position.
Page 214: Cargo Tie-Down Rings
Controls in detail Loading The handling characteristics of a fully load- ed vehicle depend greatly on the load dis- tribution. It is therefore recommended to load the vehicle according to the illustra- tions shown, with the heaviest items being placed towards the front of the vehicle. Always place items being carried against front or rear seat backrests, and fasten them as securely as possible.
Page 215: Useful Features
Useful features Interior storage spaces Warning! To help avoid personal injury during a colli- sion or sudden maneuver, exercise care when stowing objects in the vehicle. Put lug- gage or cargo in the cargo compartment if possible. Do not pile luggage or cargo higher than the seat backs.
Page 216 Controls in detail Useful features Cup holder in front of seat armrest Warning! When not in use, keep the cup holder closed. Place only containers that fit into the cup holder to prevent spills. Use lids on open containers and do not fill containers to a height where the contents, especially hot liquids, could spill during vehicle maneu- vers.
Page 217 Cup holder in rear seat armrest Warning! When not in use, keep the cup holder closed. Place only containers that fit into the cup holder to prevent spills. Use lids on open containers and do not fill containers to a height where the contents, especially hot liquids, could spill during vehicle maneu- vers.
Page 218 Controls in detail Useful features Armrest storage spaces 1 Handle 2 Armrest 3 Button Opening storage compartment Pull handle 1 and lift armrest. Closing storage compartment Press armrest down until it engages into place. Opening telephone compartment Press button 3 on driver’s or passenger side and lift armrest.
Page 219: Ashtrays
Parcel net in front passenger footwell A small convenience parcel net is located in the front passenger footwell. It is for small and light items, such as road maps, mail, etc. Warning! Do not place heavy or fragile objects, or ob- jects having sharp edges, in the parcel net.
Page 220: Cigarette Lighter
Controls in detail Useful features Rear seat ashtray Opening ashtray Pull at top of cover 1 to open ashtray. Removing ashtray insert Press latch 2 to disengage ashtray insert and remove it. Reinstalling the ashtray insert Install ashtray insert. Close the ashtray. Cigarette lighter The cigarette lighter is located in the center console compartment in front of the...
Page 221: Electrical Outlet
The external antenna must be approved by Mercedes-Benz. Please contact an autho- rized Mercedes-Benz Center for informa- tion on the installation of an approved external antenna. Refer to the radio trans- mitter operation instructions regarding use of an external antenna.
Page 222: Tele Aid
Controls in detail Useful features You can take and place telephone calls using the í and ì buttons on the steering wheel. To carry out other tele- phone functions, use the control system ( page 136). See separate operating manual for instruc- tions on how to use the telephone.
Page 223 If a malfunction is indicated as outlined above, the system may not operate as expected. Have the system checked at the nearest Mercedes-Benz Center as soon as possible.
Page 224 Controls in detail Useful features Emergency calls An emergency call is initiated automatically: following an accident in which the emergency tensioning devices (ETDs) or airbags deploy. if the anti-theft alarm or the tow-away alarm stays on for more than 20 seconds. See anti-theft alarm system ( page 80) and tow-away alarm ( page 81).
Page 225 Warning! If the indicator lamp in the SOS button is illuminated continuously and there was no voice connection to the Response Center established, then the Tele Aid system could not initiate an emergency call (e.g. the rele- vant cellular phone network is not available). The message EMERGENCY CALL –...
Page 226 Located below the center armrest cover is the Roadside Assistance button •. Press and hold button (for longer than two seconds). A call to a Mercedes-Benz Roadside Assistance dispatcher will be initiated. The button will flash while the call is in progress. The message TELE DIAGNOSIS –...
Page 227 TELE AID – INFO CALL ACTIVE appears in the multifunction display. Information regarding the operation of your vehicle, the nearest Mercedes-Benz Center or Mercedes-Benz USA products and services is available to you. For more details concerning the Tele Aid system, please visit www.mbusa.com and...
Page 228 Tele Aid system has detected a fault or the service is not currently active, and may not initiate a call. Visit your Mercedes-Benz Center and have the system checked or contact the Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada) as soon as possible.
Page 229 The Response Center will then unlock your vehicle with the remote door unlocking feature. Contact the Mercedes-Benz Response Center at 1-800-756-9018 (in the USA) or 1-888-923-8367 (in Canada). You will be asked to provide your pass- word which you provided when you completed the subscriber agreement.
Page 230: Garage Door Opener
Report the incident to the police. The police will issue a numbered incident report. Pass this number on to the Mercedes-Benz Response Center along with your password issued to you when you subscribed to the service. The Response Center will then attempt to covertly contact the vehicle’s...
Page 231 Certain types of garage door openers are incompatible with the integrated opener. If you should experience difficulties with programming the transmitter, contact your authorized Mercedes-Benz Center, or call Mercedes-Benz Customer Assistance Center (in the USA only) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.
Page 232 Controls in detail Useful features Programming or reprogramming the integrated remote control Step 1: Switch on ignition. Step 2: If you have previously programmed an integrated signal transmitter button and wish to retain its programming, proceed to step 3. Otherwise, press and hold the two outer signal transmit- ter buttons 2 and 4 and release them only when the indicator light...
Page 233 If the indicator lamp 1 flashes rapidly for about two seconds and then turns to a constant light, continue with programming steps 8 through 12 as your garage door opener may be equipped with the “rolling code” feature. Step 7: To program the remaining two buttons, repeat the steps above starting with step 3.
Page 234 Controls in detail Useful features Step 12: Confirm the garage door operation by pressing the programmed integrated signal transmitter button (2, 3 or 4). Step 13: To program the remaining two buttons, repeat the steps above starting with step 3. Gate operator/Canadian programming Canadian radio-frequency laws require transmitter signals to “time-out”...
Page 235 Operation of integrated remote control Switch on ignition. Select and press the appropriate integrated signal transmitter button (2, 3 or 4) to activate the remote controlled device. The integrated remote control trans- mitter continues to send the signal as long as the button is pressed – up to 20 seconds.
Page 237: Operation
Operation The first 1000 miles (1500 km) Driving instructions At the gas station Engine compartment Tires and wheels Winter driving Maintenance Vehicle care...
Page 238: The First 1000 Miles (1500 Km)
Operation The first 1000 miles (1500 km) In the “Operation” section you will find detailed information on operating, main- taining and caring for your vehicle. The first 1000 miles (1500 km) The more cautiously you treat your vehicle during the break-in period, the more satis- fied you will be with its performance later Drive your vehicle during the first 1000 miles (1500 km) at varying but...
Page 239: Driving Instructions
Have all maintenance work performed at the intervals specified in the Service Booklet and as required by the FSS. Contact your authorized Mercedes-Benz Center. Fuel consumption is also increased by driving in cold weather, in stop-and-go traffic, on short trips and in hilly country.
Page 240: Brakes
Contact your authorized Mercedes-Benz Center. Only install brake pads and brake fluid rec- ommended by Mercedes-Benz. Warning! If other than recommended brake pads are installed, or other than recommended brake fluid is used, the braking properties of the vehicle can be degraded to an extent that safe braking is substantially impaired.
Page 241: Driving Off
ESP switched off. Doing so may cause serious damage to the drivetrain which is not covered by the Mercedes-Benz Limited Warranty. Simultaneously depressing the accelerator pedal and applying the brake reduces engine performance and causes premature brake and drivetrain wear.
Page 242: Tires
Inspect the tires and the vehicle underbody for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for repairs. Tread wear indicators (TWI) are required by law. These indicators are located in six...
Page 243: Tire Traction
If ice has formed on the road, tire traction will be substantially reduced. Under such weather conditions, drive, steer and brake with extreme caution. Mercedes-Benz recommends M+S rated radial-ply tires with a minimum tread depth of approximately in (4 mm) on all four wheels for the winter season to ensure normal balanced handling characteristics.
Page 244: Winter Driving Instructions
Operation Driving instructions Winter driving instructions The most important rule for slippery or icy roads is to drive sensibly and to avoid abrupt acceleration, braking and steering maneuvers. Do not use the cruise control system under such conditions. When the vehicle is in danger of skidding, move gear selector lever to position N.
Page 245: Standing Water
Operation Driving instructions Driving abroad Abroad, there is an extensive Mercedes-Benz service network at your disposal. If you plan to drive into areas which are not listed in the index of your Mercedes-Benz Center directory, you should request pertinent information from...
Page 246: Control And Operation Of Radio Transmitter
Refer to the radio transmitter operation instructions regarding use of an external antenna. Catalytic converter Your Mercedes-Benz is equipped with monolithic-type catalytic converters, an important element in conjunction with the oxygen sensors to achieve substantial control of the pollutants in the exhaust emissions.
Page 247: Emission Control
Any adjustments on the engine should, therefore, be carried out only by qualified Mercedes-Benz Center authorized techni- cians. Engine adjustments should not be altered in any way. Moreover, the specified service jobs must be carried out regularly according to Mercedes-Benz servicing requirements.
Page 248: Coolant Temperature
The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty. Warning! Driving when your engine is badly overheated can cause some fluids, which may have leaked into the engine compartment, to catch fire.
Page 249: At The Gas Station
At the gas station Refueling Warning! Gasoline is highly flammable and poisonous. It burns violently and can cause serious injury. Whenever you are around gasoline, avoid inhaling fumes and skin contact, extinguish all smoking materials. Never allow sparks, flame or smoking materials near gasoline! Warning! Flexible Fuel Vehicles only (identified by a...
Page 250 Operation At the gas station Open fuel filler flap by pushing at the point indicated by the arrow. The fuel filler flap springs open. Turn fuel cap to the left and hold on to it until possible pressure is released. Take off cap and set it in the recess on fuel filler flap.
Page 251: Check Regularly And Before A Long Trip
Opening hood ( page 252). brake system checked for brake pad thickness and leaks immediately. Vehicle lighting Notify an authorized Mercedes-Benz Check function and cleanliness. For more Center immediately. Do not add brake fluid as this will not solve the problem.
Page 252: Engine Compartment
Operation Engine compartment Engine compartment Hood Warning! Do not pull the release lever while the vehicle is in motion. Otherwise the hood could be forced open by passing air flow. Opening 1 Hood release Pull lever 1 downwards. The hood is unlocked and handle 2 will extend out of the radiator grille.
Page 253 Warning! If you see flames or smoke coming from the engine compartment, or if the coolant tem- perature display indicates that the engine is overheated, do not open the hood. Move away from vehicle and do not open the hood until the engine has cooled.
Page 254: Engine Oil
Do not use any special lubricant addi- tives, as these may damage the drive assemblies. Using special additives not approved by Mercedes-Benz will restrict your warranty entitlement. More information on this subject is available at any Mercedes-Benz Center.
Page 255 Mercedes-Benz Center. Excess oil must be siphoned or drained off. It could cause damage to the engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. More information on messages in the display concerning engine oil can be found in the “Practical hints”...
Page 256: Transmission Fluid Level
Using engine oils of other specification may cause the FSS to incorrectly determine the next service interval and will result in engine dam- age not covered by the Mercedes-Benz Limited Warranty. 1 Filler cap Unscrew filler cap 1 from filler neck.
Page 257: Coolant Level
Coolant level The engine coolant is a mixture of water and anticorrosion/antifreeze. To check the coolant level, the vehicle must be parked on level ground and the engine must be cool. The coolant expansion tank is located on the passenger side of the engine compart- ment.
Page 258: Battery
When replacing the battery, always use batteries approved by Mercedes-Benz. If you do not intend to operate your vehicle for an extended period of time, consult an authorized Mercedes-Benz Center about steps you need to observe.
Page 259: Windshield Washer System And Headlamp Cleaning System
Windshield washer system and headlamp cleaning system* The windshield washer reservoir is located in the engine compartment. 1 Washer fluid reservoir Fluid for the windshield washer system and the headlamp cleaning system* is supplied from the windshield washer reservoir. It has a capacity of: 3.2 US qt (3.0 l) in vehicles without headlamp cleaning system*...
Page 260: Tires And Wheels
When replacing rims, only use genuine Mercedes-Benz wheel bolts specified for the particular rim type. Failure to do so can result in the bolts loosening and possibly an accident.
Page 261: Life Of Tire
Life of tire The service life of a tire is dependent upon varying factors including but not limited to: Driving style Tire pressure Distance driven Warning! Tires and spare tire should be replaced after six years, regardless of the remaining tread. Keep unmounted tires in a cool, dry place with as little exposure to light as possible.
Page 262: Rotating Wheels
Warning! Have the tightening torque checked after changing a wheel. Wheels could become loose if not tightened with a torque of 80 lb-ft (110 Nm). Only use genuine Mercedes-Benz wheel bolts specified for your vehicle's rims.
Page 263: Winter Driving
Winter driving Before the onset of winter, have your vehicle winterized at an authorized Mercedes-Benz Center. This service includes: Check of anticorrosion and antifreeze concentration. Addition of cleaning concentrate to the water of the windshield and headlamp cleaning system. Add MB Concentrate “S”...
Page 264: Block Heater (Canada Only)
Block heater (Canada only) The engine is equipped with a block heater. The electrical cable may be installed at your authorized Mercedes-Benz Center. Snow chains Snow chains should only be driven on snow-covered roads at speeds not to exceed 30 mph (50 km/h). Remove chains as soon as possible when driving on roads without snow.
Page 265: Maintenance
Maintenance We strongly recommend that you have your vehicle serviced by your authorized Mercedes-Benz Center, in accordance with the Service Booklet at the times called for by the FSS (Flexible Service System). Failure to have the vehicle maintained in accordance with the Service Booklet at the...
Page 266: Calling Up The Service Indicator
Operation Maintenance The Mercedes-Benz Center will reset the service indicator following a completed service. Calling up the service indicator Switch on ignition. The standard display of the control system appears ( page 111). Press button k or j on the mul-...
Page 267: Vehicle Care
Post-production treatment is neither necessary nor recommended by Mercedes-Benz because of the possibility of incompatibility between materials used in the production process and others applied later.
Page 268 We have selected car-care products and compiled recommendations which are specially matched to our vehicles and which always reflect the latest technology. You can obtain Mercedes-Benz approved car-care products at your authorized Mercedes-Benz Center. Scratches, corrosive deposits, corrosion or damage due to negligent or incorrect care cannot always be removed or repaired with the car-care products recommended here.
Page 269 Vehicle washing Do not use hot water or wash your vehicle in direct sunlight. Only use a mild car wash detergent, such as Mercedes-Benz approved Car Shampoo. Thoroughly spray the vehicle with a dif- fused jet of water. Direct only a very weak spray towards the ventilation intake.
Page 270 If released, the force of the impact from the tensioning spring could crack the windshield. Light alloy wheels Mercedes-Benz approved Wheel Care should be used for regular cleaning of the light alloy wheels. If possible, clean wheels once a week with...
Page 271 Steering wheel and gear selector lever Wipe with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care. Cup holder Use a gentle dishwashing detergent or mild detergent for delicate fabrics as a washing solution. Wipe with a cloth moist- ened in lukewarm solution.
Page 272 Clean with soft bristle brush, or use a dry-shampoo cleaner in case of excessive dirt. MB Tex upholstery Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure. Plastic and rubber parts Do not use oil or wax on these parts.
Page 273: Practical Hints
Practical hints What to do if … Where will I find ...? Unlocking/locking in an emergency Opening/closing in an emergency Replacing bulbs Replacing wiper blades Flat tire Battery Jump starting Towing the vehicle Fuses...
Page 274: What To Do If
Continue driving with added caution. Wheels may lock during hard braking, reducing steering capability. Have the system checked at an autho- rized Mercedes-Benz Center as soon as possible. Failure to follow these instructions increases the risk of an accident. Read and observe messages in the display ( page 280).
Page 275 Practical hints What to do if … Release the parking brake ( page 44). Risk of accident! Carefully stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem.
Page 276 Your gas tank is empty. Suggested solution Have the vehicle checked as soon as possible by an authorized Mercedes-Benz Center. An on-board diagnostic connector is used by the service station to link the vehicle to the shop diagnostics system. It allows the accurate identifi-...
Page 277 Suggested solution Switch the ESP back on ( page 76). If the ESP cannot be switched back on, have the system checked at an autho- rized Mercedes-Benz Center as soon as possible. When driving off, apply as little throttle as possible.
Page 278 SRS may not be operational. For your safety, we strongly recommend that you visit an autho- rized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may not be activated when needed in...
Page 279: Lamp In Center Console
The system is malfunctioning. Practical hints What to do if … Have the system checked as soon as possible by an authorized Mercedes-Benz Center. Make sure there is nothing between seat cushion and child seat and check installation of the child seat.
Page 280: Messages In The Display
Mercedes-Benz Center. Failure to repair condition noted may cause damage not covered by the Mercedes-Benz Limited Warranty, or result in property damage or personal injury. Warning!
Page 281 If necessary, have the generator and battery checked. Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. Have the system checked at an authorized Mercedes-Benz Center as...
Page 282 Synchronize the ESP. With vehicle stationary and the engine running, turn the steering wheel completely to the left and then to the right to synchro- nize the ESP. Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 283 ESP is operational again. If necessary, have the generator and battery checked. Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 284 Continue driving with added caution. Wheels may lock during hard braking, reducing steering capability. Have the system checked at an authorized Mercedes-Benz Center as soon as possible. Continue driving with added caution. Wheels may lock during hard braking, reducing steering capability.
Page 285 Do not continue to drive. Otherwise the engine will overheat due to an inoperative water pump which may result in damage to the engine. Notify an authorized Mercedes-Benz Center. Drive immediately to the nearest authorized Mercedes-Benz Center. Start the engine ( page 43).
Page 286 ( page 44). Have the brake pads replaced as soon as possible. Risk of accident! Stop the vehicle and notify an authorized Mercedes-Benz Center. Do not add brake fluid! This will not solve the problem. Brake pad thickness must be visually...
Page 287 Do not ignore the low engine coolant level warning. Extended driving with the message and symbol displayed may cause serious engine damage not covered by the Mercedes-Benz Limited Warranty. Do not drive without sufficient amount of coolant in the cooling system. The engine will overheat causing major engine damage.
Page 288 Only start the engine again after the message disappears. You could otherwise damage the engine. The engine should not be operated with the coolant temperature above 248°F (120°C). Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty.
Page 289 Notify an authorized Mercedes-Benz Center. Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty.
Page 290 Coolant temperature display Tachometer Cruise control display You are attempting to drive with one or more doors open. Visit an authorized Mercedes-Benz Center. Continue driving with added caution. Visit an authorized Mercedes-Benz Center as soon as possible. Have the electronic systems checked by an authorized Mercedes-Benz Center.
Page 291 Display symbol Display messages USA only: ADD 1.0 Qt. ENGINE OIL WHEN NEXT REFUELING! Canada only: ADD 1.0 LITER ENG. OIL WHEN NEXT REFUELING! ENGINE OIL LEVEL STOP, ENGINE OFF! ENGINE OIL LEVEL REDUCE OIL LEVEL ENGINE OIL VISIT WORKSHOP! Possible cause Suggested solution The engine oil level is too low.
Page 292 Have the measuring system checked by an authorized Mercedes-Benz Center. The engine oil level warnings should not be ignored. Extended driving with the symbol displayed could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty.
Page 293 Check the fuel cap ( page 249). Close the hood ( page 252). Remove the SmartKey from the starter switch. Change the SmartKey. Visit an authorized Mercedes-Benz Center as soon as possible. Remove SmartKey from the starter switch. Visit an authorized Mercedes-Benz Center as soon as possible.
Page 294 In the control system, set lamp operation to manual ( page 121). Switch on headlamps using the exterior lamp switch. Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible. Replace the bulb as soon as possible.
Page 295 Practical hints What to do if … Insert SmartKey in the starter switch. Switch off the headlights. Visit an authorized Mercedes-Benz Center as soon as possible. Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible.
Page 296 The right turn signal in the side mirror is malfunctioning. This message will only appear if all light emitting diodes have stopped working. Visit an authorized Mercedes-Benz Center as soon as possible. Replace the bulb as soon as possible. Replace the bulb as soon as possible.
Page 297 In the event a malfunction of the SRS is indi- cated as outlined above, the SRS may not be operational. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz Center immediately to have the system checked; otherwise the SRS may Possible cause Possible solution The display reminds you and your passengers to fasten seat belts.
Page 298 Do not add steering oil without checking the steering system. Do not drive the vehicle. Have the system checked at your authorized Mercedes-Benz Center as soon as possible. Possible cause Possible solution The steering column is not properly locked.
Page 299 Practical hints What to do if … Close the sliding/pop-up roof ( page 199). Close the sliding/pop-up roof ( page 199). Have the Tele Aid system* checked by an authorized Mercedes-Benz Center. Close the tailgate. Add washer fluid ( page 259).
Page 300: Where Will I Find
Practical hints Where will I find ...? Where will I find ...? First aid kit The first aid kit is located in the storage compartment behind the left trim panel. Press button 1. Fold down panel 2. Vehicle tool kit The vehicle tool kit is located in the storage compartment behind the left trim panel.
Page 301 3 Vehicle tool kit The following is included: Towing eye bolt Wheel wrench Alignment bolt Vehicle jack Wheel bolts Special fuse puller Spare fuses Vehicle jack Warning! The jack is designed exclusively for jacking up the vehicle at the jack take-up brackets built into both sides of the vehicle.
Page 302: Minispare Wheel
Practical hints Where will I find ...? Operational position Turn crank handle clockwise until it engages (operational position). Before storing the vehicle jack in its compartment: It should be fully collapsed. The handle must be folded in (storage position). Minispare wheel The Minispare wheel is located in the storage compartment underneath the cargo compartment floor.
Page 303 Place storage well casing 2 over the Warning! luggage bowl 5 and turn retaining screw 1 clockwise as far as it will go The dimensions of the Minispare wheel are to secure the Minispare wheel. different from those of the road wheels. As a result, the vehicle handling characteristics change when driving with a Minispare wheel Arrow 3 on luggage bowl 5 must...
Page 304 Practical hints Where will I find ...? Minispare wheel bolts 1 Wheel bolt for light alloy rims 2 Wheel bolt for Minispare wheel or other steel rims (located in vehicle tool kit) Warning! Wheel bolts 2 must be used when mounting the Minispare wheel or other Make sure to use the original length wheel steel rims.
Page 305: Unlocking/Locking In An Emergency
Unlocking/locking in an emergency Unlocking the vehicle If you are unable to unlock the vehicle with the SmartKey, open the driver’s door using the mechanical key and the tailgate using the emergency release. The passenger door cannot be unlocked manually. Unlocking your vehicle with the mechanical key will trigger the anti-theft alarm system.
Page 306: Locking The Vehicle
It is recommended to have the batteries replaced at an authorized Mercedes-Benz Center. Warning! Keep the batteries out of reach of children. If a battery is swallowed, seek medical help immediately.
Page 307 Replacement batteries: Lithium, type CR 2025 or equivalent. When changing batteries, always replace both batteries. The required replacement batteries are available at any Mercedes-Benz Center. Unlocking/locking in an emergency Remove mechanical key 1 ( page 305). Insert mechanical key 1 in side opening and push grey slide.
Page 308: Fuel Filler Flap
Practical hints Unlocking/locking in an emergency Fuel filler flap In case the central locking system does not release the fuel filler flap, you can open it manually. Open the tailgate. Press button 1. Fold down trim panel 2. Reach inside through opening 3 in direction of arrow.
Page 309: Opening/Closing In An Emergency
Opening/closing in an emergency Sliding/pop-up roof* You can open or close the sliding/pop-up roof manually should an electrical malfunction occur. The sliding/pop-up roof drive is located behind the lens 1 of the interior overhead light. Pry off lens 1 using a flat blade screwdriver.
Page 310: Replacing Bulbs
Correct headlamp adjustment is extremely important. Have headlamps checked and readjusted at regular intervals and when a bulb has been replaced. See your autho- rized Mercedes-Benz Center for headlamp adjustment. Backup bulbs will be brought into use when the following lamps malfunction:...
Page 311: Replacing Bulbs
If the newly installed bulb does not come on, visit an authorized Mercedes-Benz Center. Have the LEDs and bulbs for the following lamps replaced by an authorized Mercedes-Benz Center: Additional turn signals in the exterior rear view mirrors High mounted brake lamp Xenon lamps...
Page 312: Replacing Bulbs For Front Lamps
Practical hints Replacing bulbs Replacing bulbs for front lamps Halogen headlamps 1 Bulb socket for turn signal lamp 2 Headlamp cover for high beam head- lamp and for parking and standing lamp 3 Headlamp cover for low beam head- lamp 4 Low beam bulb 5 High beam bulb 6 Bulb socket for parking and standing...
Page 313 Parking and standing lamp bulb Switch off the lights. Open the hood ( page 252). Press the clamp and remove headlamp cover 2. Pull out bulb socket 6 with the bulb. Pull the bulb out of bulb socket. Insert a new bulb in the socket. Reinstall bulb socket.
Page 314 Practical hints Replacing bulbs Twist bayonet socket 5 counterclock- wise to the stop (do not remove). Pull the bulb out of the socket. Insert the new bulb so that the base locates in the recess in bayonet socket 5. Twist bayonet socket clockwise until you hear it snap into place.
Page 315: Side Marker Lamp Bulb
Side marker lamp bulb Switch off the lights. Carefully slide lamp towards rear. Remove front end first. Twist bulb socket counterclockwise and pull out. Pull bulb out of the bulb socket. Insert new bulb in socket. Reinstall bulb socket, push in and twist clockwise.
Page 316 Practical hints Replacing bulbs 4 Brake lamp 5 Turn signal lamp 6 Backup lamp 7 Rear fog lamp (driver’s side)/tail lamp, parking, standing and side marker lamp Gently push bulb into socket, turn License plate lamp counterclockwise and pull out. Insert new bulb and turn clockwise.
Page 317: Replacing Wiper Blades
Make certain that the wiper blades are properly installed. Improperly installed wiper blades may cause windshield damage. For your convenience, we recommend that you have this work carried out by an authorized Mercedes-Benz Center.
Page 318: Flat Tire
Practical hints Flat tire Flat tire Preparing the vehicle Park the vehicle as far as possible from moving traffic on a hard surface. Turn on the hazard warning flashers. Engage the steering wheel lock in the straight ahead position and set the parking brake.
Page 319 Warning! The jack is designed exclusively for jacking up the vehicle at the jack take-up brackets built into both sides of the vehicle. To help avoid personal injury, use the jack only to lift the vehicle during a wheel change. Never get beneath the vehicle while it is supported by the jack.
Page 320 Practical hints Flat tire The jack take-up brackets are located directly behind the front wheel housings and in front of the rear wheel housings. 1 Jack 2 Take-up bracket Place jack 1 on firm ground. Position jack 1 under take-up bracket 2 so that it is always vertical (plumb-line) as seen from the side, even if the vehicle is parked on an...
Page 321 Never apply oil or grease to wheel bolts. Damaged wheel hub threads should be repaired immediately. Do not continue to drive under these circumstances! Contact an authorized Mercedes-Benz Center or call Roadside Assistance. Incorrect wheel bolts or improperly tight- ened wheel bolts can cause the wheel to come off.
Page 322 Unscrew the alignment bolt, install last wheel bolt and tighten slightly. Warning! Only use genuine equipment Mercedes-Benz wheel bolts. Other wheel bolts may come loose. Do not tighten the wheel bolts when the vehicle is raised. Otherwise the vehicle could tip over.
Page 323 Mounting wheel cover (Canada only) The wheel cover does not fit the Minispare wheel. Wheel cover on vehicles with steel rims (Canada only) Practical hints Flat tire Position small wheel cover opening over tire valve and press wheel cover against wheel rim. Now press (do not hit) opposite side of wheel cover against wheel rim until seated.
Page 324: Battery
Have the battery checked regularly by an authorized Mercedes-Benz Center. Refer to Service Booklet for mainte- nance intervals or contact your autho- rized Mercedes-Benz Center for further information. Warning! Do not place metal objects on the battery as this could result in a short circuit.
Page 325: Disconnecting The Battery
Warning! With a disconnected battery you will no longer be able to turn the SmartKey in the starter switch the gear selector lever will remain locked in position P 1 Negative terminal 2 Positive terminal cover Disconnecting the battery Turn off all electrical consumers. Open the hood ( page 252).
Page 326: Reconnecting The Battery
Practical hints Battery Reconnecting the battery Turn off all electrical consumers. Connect the positive lead and fasten its cover 2. Connect negative lead 1. NEVER invert the terminal connections. Reinstall the filter box ( page 324). The battery, its filler caps and the vent tube must always be securely installed when the vehicle is in operation.
Page 327: Jump Starting
(12 V). Jump starting with a more powerful battery could damage the vehicle’s electrical system, which will not be covered by the Mercedes-Benz Limited Warranty. Only use jumper cables with sufficient cross-section and insulated terminal clamps. Always make sure the jumper cables...
Page 328 Remove the jumper cables first from negative terminals 3 and 4 and then from positive terminals 1 and 2. You can now turn on the lights. Have the battery checked at the near- est authorized Mercedes-Benz Center. Do not tow-start the vehicle.
Page 329: Towing The Vehicle
Towing the vehicle Mercedes-Benz recommends that the vehicle be transported with all wheels off the ground using flatbed or appropriate wheel lift/dolly equipment. This method is preferable to other types of towing. Use flatbed or wheel lift/dolly equip- ment with SmartKey in starter switch turned to position 0.
Page 330: Towing The Vehicle
Practical hints Towing the vehicle To be certain to avoid a possibility of damage to the drive train, however, we recommend the drive shaft be discon- nected at the rear axle drive flange (vehicles with 4MATIC: disconnected at the front and rear axle drive flanges) for any towing beyond a short tow to a nearby garage.
Page 331 Warning! With the engine not running, there is no power assistance for the brake and steering systems. In this case, it is important to keep in mind that a considerably higher degree of effort is necessary to brake and steer the ve- hicle.
Page 332: Installing Towing Eye Bolt
Practical hints Towing the vehicle Installing towing eye bolt 1 Cover on right side of front bumper. 2 Cover on right side of rear bumper. Removing cover Press mark on cover in direction of arrow. Lift cover off to reveal threaded hole for towing eye bolt.
Page 333: Fuses
Fuses Only install fuses that have been tested and approved by Mercedes-Benz and that have the specified amperage rating. Never attempt to repair or bridge a blown fuse. Have the cause determined and remedied by an authorized Mercedes-Benz Center. Fuse box in passenger compartment...
Page 334: Auxiliary Fuse Box In Cargo Compartment
Practical hints Fuses Install cover 2 in reverse order. Opening fuse box 4 Fuse box cover 5 Clamps Release clamps 5. Remove cover 4. Closing fuse box Ensure that the sealing rubber is properly positioned. Press cover 4 down and secure with clamps 5.
Page 335: Technical Data
Technical data Spare parts service Warranty coverage Identification labels Layout of poly-V-belt drive Engine Rims and Tires Electrical system Main Dimensions Weights Fuels, coolants, lubricants, etc. Consumer information...
Page 336: Spare Parts Service
More than 300000 different spare parts for Mercedes-Benz models are available. Genuine Mercedes-Benz parts are subjected to stringent quality inspections. Each part has been specifically developed, manufactured or selected for and adapted to Mercedes-Benz vehicles.
Page 337: Warranty Coverage
Emission System Warranty Emission Performance Warranty California, Maine, Massachusetts, and Vermont Emission Control Systems Warranty Replacement parts and accessories are covered by the Mercedes-Benz Spare Parts and Accessories warranties, copies of which are available at any Mercedes-Benz Center. Technical data Warranty coverage...
Page 338: Identification Labels
Technical data Identification labels Identification labels 1 Certification label 2 Vehicle Identification Number (VIN) 3 Information label, California version Vacuum line routing for emission control system 4 Engine number (engraved on engine) 5 VIN, visible (lower edge of windshield) 6 Emission control label When ordering spare parts, please specify vehicle identification and engine numbers.
Page 339: Layout Of Poly-V-Belt Drive
Technical data Layout of poly-V-belt drive Layout of poly-V-belt drive C 240/C 320 (all models) 1 Automatic belt tensioner 2 Power steering pump 3 Air conditioning compressor 4 Crankshaft 5 Coolant pump 6 Generator (alternator) 7 Idler pulley...
Page 340: Engine
Maximum engine speed Firing order Poly-V-belt The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. C 240 (203.261) C 240 4MATIC (203.281) 4-stroke engine, gasoline injection 3.54 in (89.90 mm)
Page 341: Rims And Tires
Rims and Tires Only use tires and rims which have been specifically developed for your vehicle and tested and approved by Mercedes-Benz. Other tires and rims can have detrimental effects, such as poor handling characteristics increased noise increased fuel consumption...
Page 342: Same Size Tires
Technical data Rims and Tires Same size tires Model C 240 C 240 4MATIC Rims (light alloy) 7 J x16 H2 Rims (steel – Canada only) 7 J x16 H2 Wheel offset 1.46 in (37 mm) Summer tires (radial-ply tires) 225/50 R16 91H All-season tires (radial-ply tires) 205/55 R16 91H...
Page 343: Electrical System
Electrical system Model C 240 C 240 4MATIC Generator (alternator) 14 V/120 A Starter motor 12 V/1.7 kW Battery 12 V/100 Ah Spark plugs Bosch F 8 DPP 332 NGK PFR 5 R-11 Electrode gap 0.039 in (1.0 mm) Tightening torque 15 –...
Page 344: Main Dimensions
Technical data Main Dimensions Main Dimensions Model C 240 C 320 Overall vehicle length 178.9 in (4543 mm) Overall vehicle width 68.0 in (1728 mm) Overall vehicle height 57.8 in (1468 mm) Wheelbase 106.9 in (2715 mm) Track, front 58.8 in (1493 mm) Track, rear 57.6 in (1464 mm) C 240 4MATIC...
Page 345: Weights
Technical data Weights Weights Roof load max. 220 lb (100 kg)
Page 346: Fuels, Coolants, Lubricants, Etc
2.1 oz (60 g) each High temperature roller bearing grease 0.5 US qt (0.5 l) MB Brake Fluid (DOT 4+) approx. 6.8 US qt (6.4 l) MB 325.0 Anticorrosion/Antifreeze Agent Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Center.
Page 347 Model Fuel tank including a reserve of Air conditioning system Windshield washer Windshield washer and headlamp cleaning system* Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing point or MB Windshield Washer Concentrate “S” and commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing point.
Page 348: Engine Oils
Always check the oil filler cap ( page 256) for important information pertaining to the engine oil needing to meet a specific Mercedes-Benz specifi- cation (e.g. MB 229.5). If such informa- tion is printed on the oil filler cap, only...
Page 349: Premium Unleaded Gasoline
Premium unleaded gasoline To maintain the engine’s durability and performance, premium unleaded gaso- line must be used. If premium unleaded is not available and low octane fuel is used, follow these precautions: Have the fuel tank only partially filled with unleaded regular and fill up with premium unleaded as soon as possible.
Page 350: Gasoline Additives
Fuels, coolants, lubricants, etc. Gasoline additives A major concern among engine manufacturers is carbon build-up caused by gasoline. Mercedes-Benz recommends only the use of quality gasoline containing additives that prevent the build up of carbon deposits. After an extended period of using fuels...
Page 351 E85 compared to gasoline operation. Use of E85 may reduce your driving range. Maintenance Please inform your Mercedes-Benz Center if you use or have used E85 fuel when your vehicle is delivered for maintenance or repairs.
Page 352: Coolants
Ser- vice Booklet is only applicable if MB 325.0 anticorrosion/antifreeze solution or other Mercedes-Benz approved products of equal specification (see Factory Approved Service Products pamphlet) are used to re- new the coolant concentration or bring it back up to the proper level.
Page 353 Before the start of the winter season (or once a year in hot southern regions), you should have the anticorrosion/antifreeze concentration checked. The coolant is also regularly checked each time you bring your vehicle to your authorized Mercedes-Benz Center for service.
Page 354: Windshield Washer And Headlamp Cleaning* System
Technical data Fuels, coolants, lubricants, etc. Windshield washer and headlamp cleaning* system Both the windshield and headlamp washer systems are supplied from the windshield washer fluid reservoir. The washer fluid reservoir has a capacity of approx.: 3.2 US qt (3.0 l) in vehicles without headlamp cleaning system* 6.4 US qt (6.0 l) in vehicles with headlamp cleaning system*...
Page 355: Consumer Information
Consumer information The following text is published as required of all manufacturers of passenger cars under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”. Uniform tire quality grading Quality grades can be found, where applicable, on the tire sidewall between tread shoulder and maximum section...
Page 356 Technical data Consumer information Temperature The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden...
Page 357: Technical Terms
(PASS. AIRBAG OFF indicator lamp located in the center console comes on). See your authorized Mercedes-Benz Center for availability. BabySmart is a trademark of Siemens Automotive Corp. BabySmart compatible child seats Special restraint system for children.
Page 358 Technical terms COMAND* (Cockpit Management and Data System) Information and operating center for vehicle sound and communications systems, including the radio and the navigation system, as well as other optional equipment (CD changer*, telephone*, etc.). Control system The control system is used to call up vehicle information and to change component settings.
Page 359 Engine speeds within the red marking of the tachometer dial. Avoid this engine speed range, as it may result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. Poly-V-belt drive Drives engine-components (alternator, AC compressor, etc.) from the engine.
Page 360 Used to switch the automatic trans- mission between standard operation S and comfort operation C. Remote Vehicle Diagnostics Transmission of vehicle data and current location to the Mercedes-Benz Customer Assistance Center for subscribers to Tele Aid service. REST (Residual engine heat utilization)
Page 361 Tele Aid* System (Telematic Alarm Identification on Demand) The Tele Aid system consists of three types of response: automatic and manual emergency, roadside assis- tance and information. Tele Aid is initially activated by completing a subscriber agreement and placing an acquaintance call.
Page 363: Index
ABS 23, 74, 357 Indicator lamp 274 Malfunction indicator lamp 274 Messages in display 284 ABS control 74 Accelerator position, automatic transmission 144 Accident In case of 50 Activating Air conditioning (cooling) 156, 166 Air recirculation mode 154, 163 Anti-theft alarm system 80 Automatic climate control* 159 Central locking (control system) 131 Charcoal filter 165...
Page 364 Index Seats 32, 33 Steering column height 38 Steering column length 38 Steering wheel 36 Air conditioning (cooling) Turning off 156, 166 Turning on 156, 166 Air conditioning refrigerant 348 Air distribution Adjusting 153, 162 Air pressure see Tire inflation pressure Air recirculation mode 154, 163 Activating 154, 163 Deactivating 155, 164...
Page 365 Operating safety 169 Operation 172 Radio operation 175 Switching off 172 Switching on 172 Telephone operation 189 Automatic antiglare for rear view mirror 146 Automatic central locking Activating/deactivating (control system) 131 Automatic climate control* 158 Activating 159 Adjusting air distribution 162 Adjusting air volume 162 Air recirculation mode 163 Deactivating 159...
Page 366 Index Battery discharged Jump starting 327 Battery, vehicle 258, 324 Charging 325 Disconnecting 325 Messages in display 285 Reconnecting 326 Reinstalling 325 Removing 325 Bi-Xenon headlamps* 357 Bi-Xenon type Front lamp bulbs 313 Block heater 264 Blocking Rear door window operation 72 Bolts For Minispare wheel 304 Brake assist system (BAS) 357...
Page 367 Storage compartment inside 209 Tailgate 87 Tie-down rings 214 Cargo tie-down rings 214 Cassette operation Playing cassettes 182 Cassette player Operating 119 Catalytic converter 246 CD changer* 185 CD operation 185 CD player Operating 118 Center console 25 Lower part 26 PASS.
Page 368 Index Upholstery 271 Windows 270 Windshield 48 Wiper blades 270 Wood trims 272 Climate control 150 Adjusting 153 Defogging windshield 153 Defrosting 154 Setting the temperature 152 Clock 23, 124 Closing Glove box 215 Hood 253 Side windows 197 Sliding/pop-up roof 199, 309 Sliding/pop-up roof with SmartKey 200 Tailgate 88...
Page 369 Coolant 257, 352 Adding 257 Anticorrosion/antifreeze quantity 352 Capacities 346 Checking level 257 Messages in display 287, 288 Temperature 248 Temperature gauge 108 Warning lamp 288 Coolant level Checking 257 Cruise control 202, 358 Canceling 203 Driving downhill 203 Driving uphill 203 Fine adjustment 204 Saving current speed 203 Setting speeds 204...
Page 370 Index Difficulties While driving see Problems while driving With starting 44 Digital clock 23 Digital speedometer 116 Direction of rotation (tires) 261 Discharged battery Jump starting 327 Disconnecting Vehicle battery 325 Display Selecting 127 Display elements Audio system 170 Displays Digital speedometer 116 Messages 255, 280 Selecting 127...
Page 371 Electrical outlet 221 Electrical system Technical data 343 Electronic stability program (ESP) 358 Electronic Stability Program see ESP Emergency call system* 222 Emergency calls Initiating an emergency call 225 Telephone* 194 With Tele Aid* 224 Emergency operation (Limp Home Mode) 144 Emergency operations Closing sliding/pop-up roof 309 Locking the vehicle 306...
Page 372 Index Fahrenheit Setting temperature units 125 Fastening the seat belts 40 Fine adjustment Cruise control 204 First aid kit 300 Flat tire 318 Lowering the vehicle 322 Minispare wheel 302 Mounting the Minispare wheel 318 Preparing the vehicle 318 Flexible fuel vehicles 350 At the gas station 249 Switching fuels 350 Flexible Service System (FSS) 265...
Page 373 Fuel filler flap 249 Locking 249 Opening 308 Unlocking 249 Fuel requirements 349 Fuel reserve tank Message in display 293 Fuel tank Capacity 347 Filler flap 249 Fuels, coolants, lubricants etc. Capacities 346 Functions (control system) 112, 115 Resetting 122 Fuse box 333 Fuse chart 333 Fuse extractor 334...
Page 374 Index Head restraints 91 Manual seats 34 Power seats* 35 Rear seats 92 Headlamp cleaning system 259 Headlamp shut-off delay see Delayed shut-off, exterior lamps Headlamps Automatic control 101 Bi-Xenon type* Replacing bulbs 313 Cleaning 269 Cleaning system 145, 259 Halogen-type Replacing bulbs 312 Refilling washer fluid 259...
Page 375 Instrument cluster 22, 107, 359 Cleaning 270 Coolant temperature gauge 108 Illumination 107 Lamps in 274–278 Multifunction display 111 Outside temperature indicator 109 Selecting language 126 Instruments and controls see Cockpit Interior lighting 105 Activating automatic control 105 Deactivating automatic control 105 Delayed shut-off 130 Manual operation 105 Interior rear view mirror...
Page 376 Index Labels, identification 338 Lamp bulbs, exterior 310 Lamps, exterior Front 310 Light sensor 294 Messages in display 293–296 Rear 311 Lamps, indicator and warning ABS 274 Airbag Off 61 Battery (SmartKey) 85 Brakes 275 CHECK ENGINE 276 Coolant 287 Engine diagnostics 276, 278 ESP 277 Fuel reserve 278...
Page 377 Lock button Doors 359 Locking 51, 84 Automatic while driving 88 Centrally from inside 89 Fuel filler flap 249 Global, SmartKey 85 Vehicle in an emergency 306 Loss of keys 86 Loss of Service and Warranty Information Booklet 337 Low beam headlamps Messages in display 295 Replacing bulbs 310, 312 Lowering...
Page 378 Index Menus 112 AUDIO 116 In control system 114, 115 Malfunction memory 120 NAVI 119 Settings menu 121 Standard display 116 Submenus 113 TEL* 136 Trip computer 134 Microphone Hands-free microphone 27 Miles/kilometers in speedometer Setting 126 Minispare wheel 302, 342 Bolts 304 Mounting 318 Mirrors...
Page 379 Navigation system Operating 119 See separate COMAND* operating instructions Night security illumination 102 Setting 129 Occupant safety 56 Airbags 57 Children and airbags 58 Children in the vehicle 65 Fastening the seat belt 40 Infant and child restraint systems 65 LATCH-type child seat anchors 71 Seat belts 40, 60 Odometer, main 23...
Page 380 Index Paintwork 268 Panic alarm 73 Panic button on SmartKey 73 Parcel net In cargo compartment 208 In front passenger footwell 219 Parking 51, 241 Parking brake 44, 51 Engaging 51 Message in display 286 Releasing 44 Parking lamps Replacing bulbs 310, 311, 313, 314 Switching on 100 Parking position Exterior rear view...
Page 381 Practical hints First aid kit 300 Fuses 333 Lamp in center console 279 Lamps in instrument cluster 274 Messages in the display 280 Minispare wheel 302 Symbol messages 284 Text messages 281 Towing the vehicle 329 Vehicle jack 301 Vehicle tool kit 300 Premium unleaded gasoline 349 Problems While driving 50...
Page 382 Index Rear view mirror automatic antiglare 146 Rear view mirrors see Mirrors Rear window defroster 149 Rear window wiper/washer 49 Reconnecting Vehicle battery 326 Refrigerant Air conditioning 348 Refueling 249 Regular checks 251 Reinstalling vehicle battery 325 Remote control SmartKey 84 Remote door unlock With Tele Aid* 229 Remote Vehicle Diagnostics 360...
Page 383 Safety Occupant 56 Safety belts see Seat belts Safety defects Reporting 18 Safety systems Driving 74 Saving current speed 203 Searching Radio station 117 Seat belt force limiter 65 Seat belt height adjustment 42 Front seats 42 Rear outer seats 42 Seat belts 62 Cleaning 271 Fastening 40...
Page 384 Index Setting Convenience functions 123, 132 Cruise control 203 Daytime running lamp mode 127, 128 Exterior rear view mirror parking position 99 Higher speed in cruise control 204 Hours (clock) 124 Individual vehicle settings 121 Interior lighting delayed shut-off 130 Key dependent memory 133 Lamps and lighting (control system) 127...
Page 385 Closing with SmartKey 198 Opening 196, 197, 198 Opening fully 197 Opening with SmartKey 198 Stopping 197 Synchronizing power windows 198 Simultaneous wiping and washing Rear window wiper/washer 49 Windshield wipers 48 Single wipe 48 Ski sack* 205 Installing 208 Removing 207 Unfolding and loading 205 Unloading and folding 207...
Page 386 Index Station selection Setting 131 Steel rims Technical data 342 Steering column Height adjustment 37, 38 Length adjustment 37, 38 Messages in display 298 Steering gear oil Message in display 298 Steering wheel Adjusting 36 Buttons 24 Cleaning 271 Electrical adjustment 37 Height adjustment 38 Manual adjustment 37 Stolen vehicle...
Page 387 Hazard warning flasher 104 Headlamps 46 High beams 104 Rapid seat heating* 96 Rear fog lamp 103 Seat heating* 96 Windshield wipers 47 Synchronizing ESP 282 Power windows 198 Sliding/pop-up roof* 201 Tachometer 23, 109 Displaying gear range 141 Overspeed range 109 Tail lamps Cleaning 269 Replacing bulbs 311, 315...
Page 388 Index Messages in display 299 Operating 136 Operation 189 Redialing 138 Signal strength 137 Temperature Display mode 125 Grades of tires 356 Setting interior temperature 152 Setting units in display 125 Tires 262 Tie-down rings (Cargo compartment) 214 Tightening torque (Wheel bolts) 322 Tilt Head restraint 34 Time...
Page 389 Trip computer 134 Trip odometer Resetting 109 Trunk lid Message in display 299 Trunk see Cargo compartment Turn signal lamps Replacing bulbs 310, 311 Turn signals 46 Additional in mirrors 310 Cleaning lenses 269 Front bulbs 310, 312, 314 Indicator lamps 23 Rear bulbs 311, 316 Turning off Engine 53...
Page 390 Index Vehicle battery 324 Vehicle care 267 Cloth upholstery 272 Cup holder 271 Engine cleaning 269 Gear selector lever 271 Hard plastic trim items 271 Headlamps 269 Instrument cluster 270 Leather upholstery 271 Light alloy wheels 270 MB Tex upholstery 272 Ornamental moldings 269 Paintwork 268 Plastic and rubber parts 272...
Page 391 Wheel change Tightening torque 322 Wheels Rotating 262 Tires and wheels 260 Window curtain airbags 62 Windows see Side windows Windshield Defogging 153, 162 Refilling washer fluid 259 Replacing wiper blades 317 Washer fluid 259, 354 Washer system 354 Windshield washer fluid 354 Message in display 299 Mixing ratio 354 Refilling 259...
Page 399 If you have questions about carrying out any type of service, turn to the advice of an authorized Mercedes-Benz Center.
