Quick Start Guide
SSR1200
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 5
Step 3: Keep Going | 15
Step 1: Begin
SUMMARY
In this guide, we provide a simple, three-step path, to quickly
get the Juniper Networks® SSR1200 appliance up and
running on Juniper Mist™ cloud. You'll learn how to install,
power on, and configure basic settings for an AC-powered
SSR1200 appliance.
Meet the SSR1200
The SSR1200 is a 1 U fixed configuration appliance that's ideal for large branch and small data center or campus
deployments. Powered by the Juniper® Session Smart Router (SSR) software, the SSR1200 provides secure and resilient
WAN connectivity.
The SSR1200 has seven 1 GbE ports, four 1/10 GbE SFP+ ports, a management port (for Mist operations), 64 GB of
memory, and a 256 GB enterprise-grade solid-state drive (SSD) for storage.
IN THIS SECTION
Meet the SSR1200 | 1
Install the SSR1200 | 2
Power On | 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Juniper SSR1200
Summary of Contents for Juniper SSR1200
- Page 1 Powered by the Juniper® Session Smart Router (SSR) software, the SSR1200 provides secure and resilient WAN connectivity. The SSR1200 has seven 1 GbE ports, four 1/10 GbE SFP+ ports, a management port (for Mist operations), 64 GB of memory, and a 256 GB enterprise-grade solid-state drive (SSD) for storage.
-
Page 2: What's In The Box
• A management host such as a laptop or desktop PC • A grounding cable CAUTION: Ensure that a licensed electrician has attached the appropriate grounding lug to your grounding cable. Using a grounding cable with an incorrectly attached lug can damage the SSR1200. - Page 3 M4 flat-head screws. Grasp both sides of the SSR1200 chassis, lift it, and position it in the rack so that the front mounting bracket holes align with the threaded holes in the rack rail.
- Page 4 Power On Now that you’ve installed your SSR1200 in the rack and grounded the chassis, you’re ready to connect it to power. The SSR1200 supports redundant AC power supplies that are pre-installed at the factory. It comes with two AC power supplies preinstalled on the rear of the device.
-
Page 5: Step 2: Up And Running
WARNING: Ensure that the power cord does not block access to the appliance components or drape where people can trip on it. 11. If the AC power source outlet has a power switch, turn it on. 12. Turn on the power switch on the SSR1200. Step 2: Up and Running IN THIS SECTION... - Page 6 Assign the SSR1200 to a Site | 14 Now that the SSR1200 is powered on, let's get it up and running on Juniper Mist™ cloud. Ensure that you have a Juniper Mist WAN Assurance subscription, and log in credentials for the Juniper Mist portal.
- Page 7 3. Click Claim WAN Edges in the upper right portion of the inventory screen. 4. Enter the SSR1200 claim code and click Add. 5. Uncheck the Assign claimed WAN Edges to site check box to place the SSR1200 in the inventory. The SSR1200 is assigned to a site later.
- Page 8 Mist AI App QR Scan You can download the Mist AI App from the Mac App Store or from Google Play Store. 1. Open the Mist AI app. 2. Click Claim Devices to Org. 3. Scan the QR code. Add the Network Add the network to be used for accessing applications over a LAN network segment.
- Page 9 5. Click Add. This network is now defined for use across the entire organization, including the template that you will apply to your SSR1200. Add Applications 1. Select Organization > Applications from the menu on the left. 2. Click Add Applications in the upper-right corner of the Applications page.
-
Page 10: Create A Template
Create a Template Excellent! Now you have the SSR1200 waiting to be claimed, a network for your LAN, and an Internet application for your WAN. Next, you need to create a WAN Edge template that ties them all together! Templates are reusable and keep the configuration consistent for every SSR1200 you deploy. - Page 11 4. Make sure that IP Configuration is set to be learned from DHCP, and that Source NAT is enabled. 5. Click Add. Configure the LAN Port Next, associate your LAN network segment with the appropriate port on the SSR1200. Scroll to the LAN section of the template, and click Add LAN. Video: Add LAN Configuration From the Network dropdown menu, select your network segment to associate it with the LAN port.
- Page 12 Select Server under DHCP to provide DHCP services to endpoints on this network. Give your DHCP server an address pool starting with 192.168.1.100 and ending with 192.168.1.200. Enter 192.168.1.1 as the gateway to be assigned to DHCP clients. Finally, enter the IP addresses for the DNS Servers to be assigned to clients on the network. For example, 8.8.8.8, 8.8.4.4.
- Page 13 Configure Traffic Steering and Application Policies Your template has the WAN and LAN information. Now, you need to tell the SSR1200 how to use the information to connect users to applications. This is done using traffic steering and application policies.
- Page 14 2. Click the Assign to Site button, and select the site where you want the template configuration applied. Assign the SSR1200 to a Site After the SSR1200 is onboarded to the Mist cloud, you'll need to assign it to a site so you can begin to manage the configuration and gather data in Mist cloud.
-
Page 15: What's Next
NOTE: Under Manage Configuration, do not check the Manage Configuration with Mist checkbox for the SSR1200 if it is using Session Smart Router software version 5.4.4. This allows the SSR1200 to reach out to the conductor IP address specified when the site was created to receive configuration information. -
Page 16: General Information
Juniper Learning Portal Juniper Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners.
