Quick Start Guide
SSR1500
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 6
Step 3: Keep Going | 15
Step 1: Begin
SUMMARY
In this guide, we provide a simple, three-step path, to quickly
get the Juniper Networks® SSR1500 appliance up and
running on Juniper Mist™ cloud. You'll learn how to install,
power on, and configure basic settings for an AC-powered
SSR1500 appliance.
Meet the SSR1500
The SSR1500 is a 1 U fixed configuration appliance that's ideal for large data center or campus deployments. Powered
by the Juniper® Session Smart Router (SSR) software, the SSR1500 provides secure and resilient WAN connectivity.
The SSR1500 has four 1 GbE ports, twelve 1/10/25 GbE SFP28 ports, a management port (for Mist operations), 512
GB of memory, and a 1 TB enterprise-grade solid-state drive (SSD) for storage.
IN THIS SECTION
Meet the SSR1500 | 1
Install the SSR1500 | 2
Power On | 5

Advertisement

Table of Contents
loading

Related Manuals for Juniper SSR1500

Summary of Contents for Juniper SSR1500

  • Page 1 SSR1500 appliance. Meet the SSR1500 The SSR1500 is a 1 U fixed configuration appliance that's ideal for large data center or campus deployments. Powered by the Juniper® Session Smart Router (SSR) software, the SSR1500 provides secure and resilient WAN connectivity.

  • Page 2: What's In The Box

    What's in the Box? | 2 What Else Do I Need? | 2 Rack It | 3 What's in the Box? Along with your SSR1500, you’ll find: • RJ-45 to USB A serial cable • AC power cord (country-specific) • Rack mount kit •...
  • Page 3 M4 flat-head screws to secure the rails. Grasp both sides of the SSR1500 chassis, lift it, and position it in the rack so that the front mounting bracket holes align with the threaded holes in the rack rail.
  • Page 4 Continue to support the SSR1500 in place and have the second person slide the rear mounting blades into the channels of the side mounting rails. Secure the rear mounting blades on each side of the chassis to the rack post using the rack mounting screws.
  • Page 5 Power On Now that you’ve installed your SSR1500 in the rack and grounded the chassis, you’re ready to connect it to power. The SSR1500 supports redundant AC power supplies that are pre-installed at the factory. It comes with two AC power supplies preinstalled on the rear of the device.

  • Page 6: Step 2: Up And Running

    Your SSR1500 uses port MGMT (mgmt-0/0/0) as the default port to contact Mist for zero-touch provisioning (ZTP). It uses port 2/1 (xe-0/2/1) to connect to the LAN. 1. Connect the MGMT port to an Ethernet link that can assign a DHCP address to the SSR1500 and provide connectivity to the Internet and Mist.
  • Page 7 Enter the Mist Claim Code | 8 To add the SSR1500 to your organization's WAN Edge inventory, you'll need to enter the SSR1500 claim information into Mist. The claim label (QR code sticker) on the front panel has the claim information.
  • Page 8 3. Click Claim WAN Edges in the upper right portion of the inventory screen. 4. Enter the SSR1500 claim code and click Add. 5. Uncheck the Assign claimed WAN Edges to site check box to place the SSR1500 in the inventory. The SSR1500 is assigned to a site later.
  • Page 9 4. Enter the network subnet as 192.168.1.0/24. 5. Click Add. This network is now defined for use across the entire organization, including the template that you'll apply to your SSR1500. Add Applications 1. Select Organization > Applications from the menu on the left.

  • Page 10: Create A Template

    Create a Template Excellent! Now you have the SSR1500 waiting to be claimed, a network for your LAN, and an Internet application. Next, you need to create a WAN Edge template that ties them all together. Templates are reusable and keep the configuration consistent for every SSR1500 you deploy.
  • Page 11 3. Enter the interface as ge-0/1/0 to designate it as a WAN port. 4. Click Add. Configure the LAN Port Next, associate your LAN network segment with the appropriate port on the SSR1500. Scroll to the LAN section of the template, and click Add LAN. Video: Add LAN Configuration From the Network drop-down menu, select your network segment to associate it with the LAN port.
  • Page 12 Select Server under DHCP to provide DHCP services to endpoints on this network. Give your DHCP server an address pool starting with 192.168.1.100 and ending with 192.168.1.200. Enter 192.168.1.1 as the gateway to be assigned to DHCP clients. Finally, enter the IP addresses for the DNS Servers to be assigned to clients on the network. For example, 8.8.8.8, 8.8.4.4.
  • Page 13 Configure Traffic Steering and Application Policies Your template has the WAN and LAN information. Now, you need to tell the SSR1500 how to use the information to connect users to applications. This is done using traffic steering and application policies.
  • Page 14 2. Click the Assign to Site button, and select the site where you want the template configuration applied. Assign the SSR1500 to a Site After the SSR1500 is onboarded to the Mist cloud, you'll need to assign it to a site so you can begin to manage the configuration and gather data in Mist cloud.

  • Page 15: What's Next

    NOTE: Under Manage Configuration, do not check the Manage Configuration with Mist checkbox for the SSR1500 if it is using Session Smart Router software version 5.4.4. This allows the SSR1500 to reach out to the conductor IP address specified when the site was created to receive configuration information.

  • Page 16: General Information

    Juniper Learning Portal Juniper Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners.
