SI Nano Box Installation Instructions Manual
Hide thumbs
Also See for Nano Box:
- Installation instructions manual (12 pages) ,
- Installation instructions (4 pages) ,
- Installation instructions manual (12 pages)
Subscribe to Our Youtube Channel
Related Manuals for SI Nano Box
Summary of Contents for SI Nano Box
- Page 1 Nano Box Installation Instructions 24v DC - Zigbee / RTS INSTALLERS: Please leave this manual with the owner. Doc. # 400024...
- Page 3 PARTS LIST - NANO BOX - 24v DC - ZIGBEE - RTS Shades Wall Brackets 275 Box 375 Box 475 Box Screws Included Please note all the Serial No.s on your Shade motors. (3 per Bracket) See the last page on these instructions.
- Page 4 SPACER BLOCKS AND LEVELING SHIMS (OPTIONAL) Spacer Blocks - used to clear an obstruction in the fabric path. Connect spacer blocks to shade brackets before installation. Note: Do not use more than 4 spacer blocks per bracket. Leveling Shims - used if the window frame is out of level. Connect to shade brackets before installation Note: do not use more than 2 leveling shims per bracket.
- Page 5 INSTALLATION - NANO BOX - 24v DC - ZIGBEE - RTS 1. Terminate pre-wire with the supplied terminal block. Header + 24 VDC - 24 VDC Data For 24vDC Only Used 2. Box bracket position is recommended 2”-4” from end caps.
- Page 6 INSTALLATION - NANO BOX - 24v DC - ZIGBEE - RTS 4. Install terminal block bracket between jamb and wall bracket on the motor side using the supplied screws Header 4” - 6” 4” - 6” Terminal block bracket must be on motor side.
- Page 7 INSTALLATION - NANO BOX - 24v DC - ZIGBEE - RTS 6. Hang shade onto wall brackets and center in opening 7. Use thumb to lock shade in place Installation - Nano Box - 24v DC - RTS...
- Page 8 WIRING - NANO BOX - 24v DC - ZIGBEE - RTS 24v DC V+ Positive 24vDC V- Negative 24vDC Not used For guaranteed motor performance the supplied voltage for 24v motors must be 24v DC. See the table below for maximum wire lengths.
- Page 9 PROGRAMMING - 24V DC - ZIGBEE PROGRAMMING STEPS (TaHoma/LinkPro Z must be plugged in and on the network) Step 1: Fine tune lower limit. Step 2: Assign shades to groups and remotes. Step 3: Pair devices and groups with remotes. The lower limit of every shade is preprogrammed to 1/2”...
- Page 10 TROUBLESHOOTING - 24V DC - ZIGBEE Tech Support: 512.832.6939 Problem Possible Cause Action to Take For Zigbee Check network connection to the internet, and ensure TaHoma LED is Red. No internet the TaHoma is properly connected via ethernet or connectivity. Wifi.
- Page 11 PROGRAMMING - 24v DC - RTS PROGRAMMING STEPS (must follow in order) Warning: Do not Step 1: Fine tune lower limit attempt to use any Step 2: Assign shades to groups installation remote until all the shades are installed. Step 3: Pair groups to control system (Mylink, LinkPro) Each RTS Nano shade includes an installation remote that is used to adjust limits and program group controls.
- Page 12 TROUBLESHOOTING - RTS Tech Support: 512.832.6939 Problem Possible Cause Action to Take For RTS Ensure that 24Volt motors have 24v DC supply and Shade won’t operate. Motor is not powered. that the polarity is correct. When operating an RTS remote hold the buttons Remote button presses down for at least 2 seconds.
- Page 13 MOTOR SERIAL NO.S Please keep a note of all the Serial No.s on your shade motors. OR for larger shade orders, refer to your Sales Order document for the list. Room Shade 1 Shade 2 Shade 3 Shade 4 Shade 5 Shade 6 Room Shade 1...
- Page 15 NOTES Notes...
- Page 16 Screen Innovations 9715-B Burnet Rd, Suite 400 Austin, TX 78758 512.832.6939 www.screeninnovations.com 400024 Ι v. 1.7 Ι 17 December 2021...
