[VCO UNIT]

REF PARTS
DESCRIPTION
NO. NO.
Q1 1530003560 S.TRA 2SC5195-T1
Q2 1590003281 S.TRA UNR9211G0L
Q51 1530003560 S.TRA 2SC5195-T1
Q52 1590003281 S.TRA UNR9211G0L
Q101 1530003260 S.TRA 2SC5006-T1
Q102 1590003281 S.TRA UNR9211G0L
Q200 1530003260 S.TRA 2SC5006-T1
Q201 1530003260 S.TRA 2SC5006-T1
Q202 1530003260 S.TRA 2SC5006-T1
D1 1750001270 S.VAR 1SV325(TPH3,F)
D2 1790001621 S.DIO 1SV308(TPL3,F)
D3 1750001270 S.VAR 1SV325(TPH3,F)
D4 1790001251 S.DIO MA2S1110GL
D5 1750001270 S.VAR 1SV325(TPH3,F)
D6 1750001270 S.VAR 1SV325(TPH3,F)
D51 1750000771 S.VAR HVC376BTRF-E
D52 1790001261 S.DIO MA2S077G0L
D53 1790001251 S.DIO MA2S1110GL
D54 1750001270 S.VAR 1SV325(TPH3,F)
D55 1720000651 S.VAR 1SV286(TPH3,F)
D100 1720000651 S.VAR 1SV286(TPH3,F)
D101 1750000721 S.VAR HVC375BTRF-E
D102 1790001261 S.DIO MA2S077G0L
D103 1790001251 S.DIO MA2S1110GL
D104 1750000721 S.VAR HVC375BTRF-E
L2 6200011650 S.COI LQW18AN68NG00D
L3 6200011660 S.COI LQW18ANR15G00D
L52 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00)
L53 6200012050 S.COI LQW18AN24NG00D
L101 6200011031 S.COI ELJRF R10JFB
L102 6200010120 S.COI LQW18AN5N6C00D
L103 6200012060 S.COI LQW18AN9N1D00D
L104 6200013430 S.COI MLG1005S R15J-T
L200 6200010991 S.COI ELJRF 47NJFB
L202 6200007951 S.COI ELJRF 8N2JFB (8.2)
L203 6200007931 S.COI ELJRF 12NJFB
L204 6200007961 S.COI ELJRF 6N8JFB (6.8)
R1 7030005240 S.RES ERJ2GEJ 473 X (47K)
R2 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R3 7030004970 S.RES ERJ2GEJ 470 X (47)
R4 7030005050 S.RES ERJ2GEJ 103 X (10K)
R5 7030005050 S.RES ERJ2GEJ 103 X (10K)
R6 7030005710 S.RES ERJ2GEJ 121 X (120)
R7 7030005090 S.RES ERJ2GEJ 104 X (100K)
R8 7030005120 S.RES ERJ2GEJ 102 X (1K)
R9 7030010040 S.RES ERJ2GEJ-JPW
R10 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R50 7030005120 S.RES ERJ2GEJ 102 X (1K)
R51 7030005240 S.RES ERJ2GEJ 473 X (47K)
R52 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R53 7030004970 S.RES ERJ2GEJ 470 X (47)
R54 7030005210 S.RES ERJ2GEJ 822 X (8.2K)
R55 7030005050 S.RES ERJ2GEJ 103 X (10K)
R56 7030007270 S.RES ERJ2GEJ 151 X (150)
R58 7030005600 S.RES ERJ2GEJ 273 X (27K)
R59 7030005600 S.RES ERJ2GEJ 273 X (27K)
R60 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R61 7030007320 S.RES ERJ2GEJ 225 X (2.2M)
R62 7030005090 S.RES ERJ2GEJ 104 X (100K)
R101 7030005240 S.RES ERJ2GEJ 473 X (47K)
R102 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R104 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R105 7030005050 S.RES ERJ2GEJ 103 X (10K)
R106 7030004990 S.RES ERJ2GEJ 221 X (220)
R107 7030005090 S.RES ERJ2GEJ 104 X (100K)
R108 7030007320 S.RES ERJ2GEJ 225 X (2.2M)
R109 7030008410 S.RES ERJ2GEJ 392 X (3.9K)
R110 7030007340 S.RES ERJ2GEJ 153 X (15K)
R111 7030005120 S.RES ERJ2GEJ 102 X (1K)
R112 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R113 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R114 7030010040 S.RES ERJ2GEJ-JPW
R115 7030010040 S.RES ERJ2GEJ-JPW
R116 7030004980 S.RES ERJ2GEJ 101 X (100)
R200 7030009160 S.RES ERJ2GEJ 181 X (180)
R201 7030005070 S.RES ERJ2GEJ 683 X (68K)
R202 7030005300 S.RES ERJ2GEJ 150 X (15)
R203 7030004970 S.RES ERJ2GEJ 470 X (47)
R204 7030005570 S.RES ERJ2GEJ 820 X (82)
R205 7030004970 S.RES ERJ2GEJ 470 X (47)
R206 7030005060 S.RES ERJ2GEJ 333 X (33K)
R207 7030004970 S.RES ERJ2GEJ 470 X (47)
R208 7030005070 S.RES ERJ2GEJ 683 X (68K)
R209 7030004990 S.RES ERJ2GEJ 221 X (220)
C1 4030017460 S.CER ECJ0EB1E102K
C3 4030017690 S.CER ECJ0EC1H121J
C4 4030016790 S.CER ECJ0EB1C103K
C5 4030016790 S.CER ECJ0EB1C103K
C6 4030017460 S.CER ECJ0EB1E102K
C7 4030017460 S.CER ECJ0EB1E102K
C8 4030016790 S.CER ECJ0EB1C103K
C9 4030017680 S.CER ECJ0EC1H820J
C10 4030017460 S.CER ECJ0EB1E102K
C11 4030017530 S.CER ECJ0EC1H0R5B
C51 4030017460 S.CER ECJ0EB1E102K
All manuals and user guides at all-guides.com
[VCO UNIT]
H/V REF
M.
LOCATION
T 10.4/16.5 C53
T 4.6/15.1 C54
T 14/9.6 C55
T 18.1/17.4 C56
T 9/2.5 C57
T 19/1.8 C58
T 8.8/10.9 C59
T 3.8/3.5 C60
T 5.6/11.4 C61
C62
C63
T 3.2/18 C101
T 7.1/16.3 C102
T 12.2/15.5 C103
T 12.8/18.9 C104
T 4.4/17.3 C105
T 12.2/14.3 C106
T 16.5/14.2 C107
T 14.6/17.7 C108
T 12.4/7.4 C109
T 15.6/12.4 C110
T 17.4/10.6 C111
T 17.4/1.6 C112
T 12.2/2.2 C114
T 16.8/5.4 C115
T 7.4/1.6 C116
T 13.9/3.1 C117
C118
C200
T 6.8/18.3 C201
T 5/19.1 C202
C203
T 14.7/13.9 C204
T 14.7/15.1 C205
T 7.6/3.5 C206
T 12.3/4.7 C207
T 14.1/5.4 C208
C209
T 2.3/1.5 C210
T 3.6/10.1 C211
T 4.1/1.5 C213
T 6.3/5
J1
T 6.2/15
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
T 8/15
T 10.7/18.8
T 10.7/17.9
T 9.1/18.8
T 10/13.8
T 11.6/12.4
T 2.8/16.4
T 11.6/13.3
T 7.1/15
T 17.5/13.9
T 16.5/17.2
T 15.6/16.4
T 12.8/8.4
T 15.5/9.5
T 16.4/9.5
T 12.3/10.2
T 18.9/11.8
T 19.8/10.2
T 13.8/16.4
T 19.8/13.4
T 17.7/12.7
T 17.9/6.5
T 15.6/6.5
T 9.2/1
T 9/4.7
T 10.2/5.6
T 18.2/7.4
T 16.6/7.4
T 16.6/8.3
T 18.9/10.2
T 15.2/3.3
T 16.6/4.1
T 20.2/16.2
T 19.4/3.4
T 17.8/3.4
T 10/8.2
T 7.5/13.2
T 9.5/9.4
T 8.9/7
T 7.7/8.2
T 7.3/7
T 2.1/2.7
T 5.3/3.9
T 5.9/8.1
T 5.9/9
T 3.1/13.6
T 9.1/17.9
T 7.9/17.6
T 5.5/17
T 3.1/15.2
T 12.8/17.5
T 11.9/17.5
T 8.8/16.6
T 10/14.7
T 10.3/11.9
T 18.9/13.8
6 - 10
PARTS
DESCRIPTION
NO. NO.
4030018070 S.CER ECJ0EC1H300J
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017650 S.CER ECJ0EC1H270J
4030017420 S.CER ECJ0EC1H470J
4030017540 S.CER ECJ0EC1HR75B
4030016930 S.CER ECJ0EB1A104K
4030017530 S.CER ECJ0EC1H0R5B
4030017460 S.CER ECJ0EB1E102K
4030017500 S.CER ECJ0EC1H560J
4030017620 S.CER ECJ0EC1H100C
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017390 S.CER ECJ0EC1H180J
4030017380 S.CER ECJ0EC1H050B
4030017350 S.CER ECJ0EC1H020B
4030017530 S.CER ECJ0EC1H0R5B
4030017460 S.CER ECJ0EB1E102K
4030016930 S.CER ECJ0EB1A104K
4030017460 S.CER ECJ0EB1E102K
4030018860 S.CER ECJ0EB0J105K
4030017640 S.CER ECJ0EC1H150J
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017460 S.CER ECJ0EB1E102K
4030017380 S.CER ECJ0EC1H050B
4030017380 S.CER ECJ0EC1H050B
4030017360 S.CER ECJ0EC1H030B
4030017590 S.CER ECJ0EC1H070C
6510025380 S.CON AXK716147G
H/V
M.
LOCATION
T 15.5/11.1
T 14.7/16.4
T 17.5/15.7
T 19.6/17.7
T 12.3/9.3
T 14.9/8
T 13.9/11.1
T 13.4/12.3
T 12.3/11.1
T 19.8/11.8
T 16.4/11.1
T 15.9/1.5
T 15.9/2.4
T 10.8/1.1
T 14/6.5
T 17.8/4.4
T 19.8/4.5
T 7.2/4.7
T 8.1/4.7
T 10.5/2.5
T 10.2/4.7
T 10.7/6.8
T 12.5/1.1
T 18/8.6
T 18.9/8.6
T 19.8/7.7
T 19.8/15
T 10.2/3.8
T 8.4/12.9
T 9.1/8.2
T 2.4/5.6
T 2.3/4.4
T 5.3/5.5
T 3.2/1.5
T 5.6/12.9
T 7.2/10.5
T 3.1/11.9
T 3.3/8.3
T 2.4/8.3
T 2.7/10.1
T 5.5/2.7
B 4.8/10
S.=Surface mount
